LOFTNESS 721D1HH User manual

Model Number:
Serial Number:
Date of Purchase:
Hydraulic Snow Blower
High Flow Series
721D1HH • 781D1HH • 721D2HH • 781D2HH • 841D2HH
781D3HH • 841D3HH • 721EMHH • 781EMHH • 721ESHH
Owner’s Manual and Parts Book
(Originating w/Serial Number 88-101)
N142336 Rev. A 08.17.18

LOFTNESS SPECIALIZED EQUIPMENT, INC.
LIMITED WARRANTY POLICY
The limited warranty policy begins upon delivery of the unit to the original customers.
All Loftness products have a one (1) year limited warranty. The XLB10 Grain Bag Loader has a two (2) year limited warranty.
If any Loftness product is used as rental equipment, or in a commercial application, the limited warranty period is for only 30 days
from the delivery date to the original customers.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since 1956, warrants
new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser, to be free from defects in material and
workmanship when properly set up and operated in accordance with the recommendations set forth in the LOFTNESS Operator’s
Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an authorized dealer or
other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above shall be in accordance with
LOFTNESS warranty adjustment policies.
WARRANTY REQUIREMENTS
.smialcytnarrawllaetadilavottnempiuqEdezilaicepSssentfoLotdenruterdnatuodellifebtsummrofnoitartsigerytnarraW
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be returned in an
.gnicivresrofyrenihcamgninruternehwderrucnisegrahcyreviledrothgierfedulcnitonseodytnarrawsihT.sutatsderepmatnu
Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
LIMITATIONS OF WARRANTY
LOFTNESS products are designed to provide years of dependable service when proper use and maintenance is adhered to. The
potential for misuse in many applications exists; therefore, a limited warranty is provided as follows.
This warranty shall not apply to any machine or attachment which shall have been repaired or altered outside the LOFTNESS factory
or authorized LOFTNESS dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has
been subject to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity. LOFTNESS may elect to have
an area representative evaluate the condition of the machine before warranty is considered.
In addition, this limited warranty provides no coverage for general wear or maintenance items, misuse, environmental conditions and/
or contamination for which they were not designed or not intended, including but not limited to the following items:
•Use of machine beyond its rated capacity;
•Improper knife replacement;
•Missing knives;
•Striking foreign objects
•Lack of lubrication
•Failures caused by running in an “out-of-balance” condition;
•Tires;
•Conveyors;
•Auger wear;
•Saw blades; and
•Brakes and brake pads.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed or implied. The
implied warranty of merchantability and fitness for a particular purpose are excluded from this limited warranty. The
remedies set forth in this warranty are the only remedies available to any person under this warranty. LOFTNESS shall have no
liability to any person for incidental, consequential or special damages of any description, whether arising out of express or implied
warranty or any other contract, negligence, or other tort or otherwise. This exclusion of consequential, incidental and special damages
is independent from and shall survive any finding that the exclusive remedy failed of its essential purpose. Upon purchase, the buyer
assumes all liability, all personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee or representative of LOFTNESS has any authority to bind LOFTNESS to any affirmation, representation or
warranty concerning its machinery and/or attachments except as specifically set forth herein.
April 2017

Hydraulic Snow Blower OM
Table of Contents
Warranty
Table of Contents
Ordering Code
Ordering Code ...............................................................1
Snow Blower (Example) .....................................................1
Introduction
Owner Information ............................................................3
Owner Responsibility .......................................................3
Warranty Policy ..............................................................3
Serial Number Location ........................................................3
Manual Storage ..............................................................3
Hydraulic Snow Blower Features ................................................4
Safety Instructions
Safety First..................................................................5
Owner’s Responsibility ........................................................5
Mandatory Shut-Down Procedure................................................6
Safety Rules.................................................................6
Operating Safety ..........................................................6
Maintenance Safety ........................................................8
Hydraulic Safety...........................................................8
California Proposition 65 Warning ................................................9
Safety Decal Locations .......................................................10
Hydraulic Snow Blower Identification ............................................12
Operating Instructions
Operation Safety ............................................................13
Initial Use Inspection and Adjustments ...........................................13
Chain Inspection .........................................................13
Skid Shoe Adjustment .....................................................13
Installing the Snow Blower to the Loader .........................................13
Blowing Snow ..............................................................14
Freeing Plugged Snow.....................................................15
Maintenance
General Maintenance.........................................................17
Maintenance Schedule .......................................................17
Break-In Schedule ...........................................................17
Lubrication.................................................................17
Grease Points Location ....................................................17
Auger Chain Lubrication ...................................................18
Removing Chain Cover .......................................................19
Adjusting Chain Tension ......................................................19
Aligning Chain ..............................................................20

Hydraulic Snow Blower OM
Table of Contents
Maintenance (Cont’d)
Adjusting Skid Shoes.........................................................20
Storage ...................................................................21
End of Season ...........................................................21
Beginning of the Season ...................................................21
Troubleshooting .............................................................22
Parts Identification
Snow Blower Frame and Fan Drive ..............................................24
Auger with Sprocket, 72" x 13" (201104), 78" x 13" (201127),
78" x 16" (201143), 84" x 16" (201150), 72" x 16" (201174) .........................26
Cutting Edge and Skid Shoes ..................................................28
Spout with Deflector, 9.5" (N10525) and 11" (N10599) ...............................29
Auger Drive ................................................................30
Hydraulics and Electrical ......................................................32
Blower Motor and Valve 6.2 (N52175), Valve 9.6 (N124723),
Valve 11.9 (N124725), Valve 4.9 (201191), Valve 8.0 (201193) .......................34
Actuator Valve (N52173) ......................................................35
Spout Hydraulic Deflector Kit (N67193)...........................................36
Hydraulic Spout Rotator Kit (N67175) ............................................37
Machine Decals and Signs ....................................................38
Appendix
Specifications ..............................................................41
Dimensions ................................................................42
Torque Specifications ........................................................43
Inches Hardware and Lock Nuts .............................................43
Metric Hardware and Lock Nuts .............................................44

1Hydraulic Snow Blower OM
Ordering Code
Ordering Code
Snow Blower (Example)
The ordering code will consist of two numbers (machine size), one letter (auger configuration), one letter (machine type),
one number or letter (motor system), one letter (rotator system), and one letter (deflector system). An example for a snow
blower of this type would be as shown below.
SIZE
72 = 72" Cut
78 = 78" Cut
84 = 84" Cut
AUGER
1 = SINGLE
TYPE
E = STANDARD FLOW
D = HIGH FLOW
MOTOR SYSTEM
S = 15-16 GPM
M = 17-20 GPM
1 = 21-25 GPM
2 = 26-32 GPM
3 = 33-40 GPM
ROTATOR
H = HYDRAULIC
DEFLECTOR
H = HYDRAULIC
781ESHH

2Hydraulic Snow Blower OM

3Hydraulic Snow Blower OM
Owner Information
Thank you for your decision to purchase a snow blower
from Loftness Specialized Equipment, Inc. It has been
designed to provide years of profitable and dependable
service. To ensure maximum performance of your snow
blower, it is mandatory that you thoroughly study the
owner’s manual and follow its recommendations. Proper
operation and maintenance are essential to maintain and
maximize the life of the machine and to prevent damage
or injury.
NOTE: This manual provides setup, operation, and
maintenance instructions for ten Loftness snow
blower models - the 721D1HH, 781D1HH,
721D2HH, 781D2HH, 841D2HH, 781D3HH,
841D3HH, 721EMHH, 781EMHH, and
721ESHH. The instructions provided apply to all
models unless specified by model number.
Owner Responsibility
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation, and maintenance procedures.
Provide impact-resistant shielding on the power unit to
protect the operator from the possible dangers of flying
debris.
Make sure the snow blower is set-up correctly before
being placed in service. It should be serviced at regular
intervals thereafter, in accordance with procedures
outlined in this manual.
Operate and maintain this snow blower in a safe manner
and in accordance with all applicable local, state, and
federal codes, regulations and/or laws, and in compliance
with on-product labeling and these instructions.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment
that may not be reflected in this publication. Loftness
reserves the right to make product improvements to the
machine at any time. Although great care has been taken
to ensure the accuracy of this publication, Loftness does
not assume any liability for errors or omissions.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely with
your dealer so as not to void the warranty.
Serial Number Location
The arrows above indicate the location of the serial
number tag (1) and the location of the serial number
stamped into the frame (2).
Always use your model and serial number when
requesting information or when ordering parts.
Manual Storage
Keep the owner’s manual and the entire machine
documentation in a clean, dry place free from potential
damage. The owner’s manual must be available for all
operators.
Introduction

4Hydraulic Snow Blower OM
Introduction
Hydraulic Snow Blower Features
• Hydraulic flow
• 15 to 20 GPM (E-Series)
• 21 to 40 GPM (D-Series)
• Hydraulic rotator
• Hydraulic deflector
• Interfaces with factory electrical connections to
enable using the joystick functions
• Shorter hitch for more maneuverability
• Optimized discharge fan
• Replaceable hardened steel bolt-on cutting edge
• Side mounted adjustable skid shoes for accurate
engaging
• 28 inch cutting height (E-Series)
• 32 inch cutting height (D-Series)
• 72, 78, and 84 inch widths
• 270 degrees of spout movement
• 9.5 inch diameter spout (E-Series)
• 11.5 inch diameter spout (D-Series)
• 20 inch diameter discharge fan with five-blades
(E-Series)
• 24 inch diameter discharge fan with five-blades
(D-Series)
• Open spoke auger design
• 13 inch diameter auger (E-Series)
• 16 inch diameter auger (D-Series)
• #50 roller chain (E-Series)
• #60 roller chain (D-Series)
• 1 inch bearings (E-Series)
• 1-3/8 inch bearing (D-Series)
• No shear bolts
• Laser cut components

5Hydraulic Snow Blower OM
Safety First
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be
heeded.
NOTE: A reminder of other related information that needs
to be considered.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Due to the potential danger of flying debris, it is the owner’s
responsibility and is “ABSOLUTELY MANDATORY that
IMPACT-RESISTANT SHIELDING” be installed on the
machine to protect the operator.
It is ABSOLUTELY MANDATORY that all personnel read
and follow all safety precautions before operating the
machine and attachment.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation, and maintenance procedures.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws; and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel know how to stop the
machine and attachment by disengaging all controls.
See “Mandatory Shut-Down Procedure” on page 6.
Make sure the attachment is installed on the machine
correctly before being placed in service. At regular
intervals thereafter, the attachment should be serviced
in accordance with procedures outlined in this owner’s
manual.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see this
symbol, be alert to the possibility of personal
injury and carefully read the message that
follows.
Safety Instructions

6Hydraulic Snow Blower OM
Mandatory Shut-Down Procedure
• Stop the machine and attachment on a level surface
and lower the attachment to the ground.
• Move throttle to idle position.
• Disengage all power to the snow blower (hydraulic
valve, or clutch, etc).
• Shut off engine and remove the key.
Wait until the auger has stopped completely before
inspecting the unit.
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
Operating Safety
• Do not start, operate, or work on this attachment
until you have carefully read and thoroughly
understand the contents of this manual and the
owner’s/operator’s manual for your loader.
• Read and observe all warnings decals on the machine
before attempting to operate the attachment. Do not
attempt to operate this attachment unless all factory
devices and decals are in place. Keep safety decals
clean of dirt and grime. Keep all guards, shields and
decals in place.
• Become familiar with and know how to operate all
safety devices and controls on the machine and
attachment before attempting to operate. Know how
to stop the machine and attachment before starting
it.
• Do not allow anyone to operate the attachment
until he or she has read the owner’s manual and is
completely familiar with all safety precautions and
controls. Keep the work area clear of all unauthorized
personnel.
• Because of the potential safety hazard to eyes from
hydraulic leaks and/or flying debris, use of protective
eyewear is absolutely mandatory for operator and
others in the work area.
• Before using a snow blower on a new job site, check
the rules and regulations at the location. The rules
may include an employer’s work safety requirements.
• Do not wear loose hanging clothes, neckties or
jewelry around rotating parts. Long hair is to be
placed under a cap or hat. These precautions will
help prevent you from becoming caught in any
moving parts on the machine and attachment.
• Do wear safety glasses, ear protection, respirators,
gloves, hard hats, safety shoes and other protective
clothing when required.
• Due to the possible danger of flying debris, impact-
resistant shielding must be provided for the operator.
The owner is responsible for providing the operator
protection devices on the power unit.
• Never operate the snow blower without guards,
shields, plates or other safety precaution devices in
place. Shields are for your protection, please keep
all shields in place.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Never allow children to operate the equipment.
• Keep children, bystanders and other workers off
and away from the machine and attachment during
operation. No riders allowed.
• Do not allow any people or animals within 1000 feet
of the work area while operating this machine.
• Use the handholds and step plates when getting on
and off the machine to prevent falls. Keep steps and
platform cleared of mud and debris.
• Always have an operator in the machine while the
attachment is in operation. Never leave the machine
and attachment running and unattended.
Safety Instructions

7Hydraulic Snow Blower OM
Safety Rules (Cont’d)
Operating Safety (Cont’d)
• Keep your feet on the pedals, (floor plates) seat belt
fastened snuggly and seat bar lowered, (if equipped),
when operating the attachment.
• Always use an approved roll bar and seat belt for
safe operation. Overturning a machine without a roll
bar and seat belt can result in injury or death.
• Operate the attachment only from the operator’s
seat.
• Before leaving the operator’s position for ANY reason
or allowing anyone to approach the machine and
attachment, always follow the mandatory shutdown
procedure.
• Keep hands and feet clear! Never step over or climb
over the attachment while the engine is running;
entanglement could occur.
• Disengage auxiliary hydraulics and place all machine
controls in neutral and engage the parking brake
before starting the engine.
• Remove from area of operation all foreign objects
such as bottles, rocks, wire, etc., that might become
tangled in the auger, causing damage to the machine
or be thrown, striking other objects.
• Stay alert for hidden hazards or traffic. Do not carry
passengers.
• Never operate the snow blower without good light
and visibility.
• Engage the hydraulic valve slowly at idle speed to
prevent unnecessary stress to driveline.
• Do not direct discharge spout towards people,
houses, vehicles, or other objects that could be
damaged.
• Never operate the snow blower in a lifted position.
Work only on the surface that the loader is standing
on.
• Do not operate the snow blower above the rated rpm.
• Always operate snow blower level with the ground
(front to rear).
Safety Instructions
• Always remove snow by traveling in an up and down
direction on slopes. To avoid loss of control and to
prevent overturn, never drive diagonally across the
slope.
• Reduce speed when turning.
• Never operate snow blower over 2 feet above the
ground.
• Do not operate on extremely steep slopes.
• After striking a foreign object, be sure to follow the
“Mandatory Shut-Down Procedure” on page 6.
Thoroughly inspect snow blower for any damage
before restarting and operating.
• Never attempt to make any adjustments while the
attachment is running or the key is in the “ON”
position in the machine. Before leaving the operator’s
position, disengage power to the attachment, shut
off engine and remove ignition key.
• Should excessive vibration occur, disengage
hydraulic valve immediately. Do not continue
operation of snow blower until the problem has
been detected and corrected. Be sure to follow the
“Mandatory Shut-Down Procedure” on page 6.
• Before servicing or adjusting the snow blower,
or removing material from it, be sure to follow the
“Mandatory Shut-Down Procedure” on page 6.
• Be sure the auger has stopped completely before
servicing.
• Disengage power to snow blower when transporting
or not in use.
• When transporting the snow blower on the road
at day or night, provide adequate warning to the
operators of other vehicles.
• Never park on a steep incline.
• Do not leave equipment in raised position.

8Hydraulic Snow Blower OM
Safety Rules (Cont’d)
Maintenance Safety
• Do not work on this attachment until you have
carefully read and thoroughly understand the
contents of this manual and the owner’s/operator’s
manual for your loader.
• Before inspecting, cleaning, lubricating, adjusting or
servicing any part of the attachment, always follow
the “Mandatory Shut-Down Procedure” on page
6. After service has been performed, be sure to
restore all guards, shields and covers to their original
position.
• Never attempt to lubricate, or make any adjustments
while the skid loader or attachment is running, or the
key is in the “ON” position in the machine. Before
leaving the operator’s position, disengage power to
the attachment, shut off engine and remove ignition
key.
• When performing any maintenance, make sure the
area is clear of any distracting objects. Keep work
areas clean and free of grease and oil to avoid
slipping or falling.
• Before working under the a hydraulically controlled
attachment, be certain it is securely blocked!
• Do not smoke while servicing the machine.
• Do not touch loader or any attachment parts which
might be hot from operation. Allow such parts to
cool before attempting to maintain, adjust or service.
• Make sure all controls, (levers, pedals and switches),
are in NEUTRAL position before starting the engine.
• Before leaving the operator’s position for ANY reason
or allowing anyone to approach the machine and
attachment, always follow the mandatory shutdown
procedure.
• Periodically check all guards, shields and structural
members. Replace or repair anything that could
cause a potential hazard.
• Do not replace components or parts with other than
factory-recommended service parts. To do so may
decrease the effectiveness of the machine and/or
void the warranty.
• It is the operator’s responsibility to be aware of
machine and attachment operation and work area
hazards at all times.
• Operators are responsible to know the location
and function of all guards and shields including but
not limited to the drive and auger. Operators are
responsible to make certain that all guards are in
place when operating the machine and attachment.
• Operators are responsible to be aware of safety
hazard areas and follow instructions on warning,
caution, or danger decals applied to the machine.
• Know the area before operating the machine. Be
aware of power lines or other equipment.
Hydraulic Safety
WARNING: Contact with high pressure
fluids may cause fluid penetration and burn
hazards. Fluid that is under pressure can
penetrate body tissue. Fluid penetration can
cause serious injury and possible death. If
fluid is injected into the skin, seek medical
attention immediately!
• Always wear safety goggles or glasses when working
on hydraulic system to avoid eye injury.
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.
• To prevent serious personal injury from escaping
high pressure fluid, never attempt to inspect, service
or disassemble any part of the hydraulic system until
all pressure has been relieved from the system.
Safety Instructions

9Hydraulic Snow Blower OM
California Proposition 65 Warning
WARNING: This product can expose you to
Mineral Oil, which is known to the State of
California to cause cancer. For more
information, go to www.p65warnings.ca.gov.
A decal with this warning statement is adhered to the
machine. If the decal should become worn or missing,
replace immediately.
Safety Instructions

10 Hydraulic Snow Blower OM
Safety Instructions
Safety Decal Locations
Check and replace any worn, torn, hard to read or missing safety decals on your machine.
NOTE: This section shows where safety-related decals are applied on the machine. For all machine decals see “Machine
Decals and Signs” on page 38.
See the following page for detailed images of the safety decals called out above.

11Hydraulic Snow Blower OM
Safety Instructions
4
Safety Decal Locations (Cont’d)
1
3
2
Part No. 4256
Part No. 4190
Part No. 4191
Part No. N68716
6
Part No. 203264
5
Part No. 4257

12 Hydraulic Snow Blower OM
Safety Instructions
Hydraulic Snow Blower Identification

13Hydraulic Snow Blower OM
Operating Instructions
Operation Safety
Before operating this machine become familiar with and
study all the hazard warning and safety precautions
listed in the Safety Instructions section of this manual
beginning on page 5.
CAUTION: Become familiar and know how
to use all safety devices and controls on the
snow blower before attempting to operate
the unit. Know how to stop the unit before
starting it.
WARNING: Read and observe all warnings
on the machine before attempting to
operate the snow blower. Do not attempt to
operate this machine unless all factory
installed safety devices are in place.
CAUTION: Before proceeding to perform
any adjustments on the snow blower, follow
the “Mandatory Shut-Down Procedure” on
page 6.
Initial Use Inspection and
Adjustments
Chain Inspection
The chain and sprockets should be inspected for
alignment and tension before the initial use. Check
periodically thereafter and ensure they stay in alignment.
See “Adjusting Chain Tension” on page 19 and
“Aligning Chain” on page 20 for information and
instructions on auger chain maintenance.
Skid Shoe Adjustment
Check the position of the skid shoes. Adjust the blower
skid shoes if necessary so the cutting blade is about
1/2 in. (1.27 cm) above the ground for best results. See
“Adjusting Skid Shoes” on page 21 for adjustment
instructions.
Installing the Snow Blower to the
Loader
Your skid steer may be equipped with a manual coupler or
optional powered quick-coupler.
IMPORTANT: For manual coupling, fully raise the
attachment-locking levers on the loader
mounting plate before attempting to
connect the blower to the skid steer.
Tilt the loader mounting plate ahead. Drive forward with
the loader and hook the top edge of the loader mounting
plate under the top flange (1) on the snow blower
mounting plate. Be careful not to damage the locking
levers on the loader mounting plate.
Tilt the loader mounting plate back until the snow blower
mounting plate is firmly against the loader mounting
plate, but DO NOT lift the attachment off the ground.
For manual coupling, the operator will need to exit the
skid steer and fully lower the attachment-locking levers
on the loader mounting plate.
WARNING: Before you leave the operator’s
seat, stop engine and remove ignition key.
Engage the parking brake.
For powered quick-coupling, Use the skid steer
controls to engage the locking pins. Refer to the skid
steer manufacturer’s owner’s/operator’s manual for
instructions on using the quick-coupling controls .
WARNING: Locking-wedge pins must
extend through the holes in attachment-
mounting plate. Levers must be fully down
in the locked over-center position. Failure to
secure wedge pins can allow attachment to
come off, causing serious injury or death.
(Procedure continued on following page.)

14 Hydraulic Snow Blower OM
Operating Instructions
Installing the Snow Blower to the
Loader (Cont’d)
Hydraulic Connection
NOTE: The hydraulic hose quick couplers shown above
are not supplied with the snow blower.
Before hooking up the hydraulic lines, clean the
connectors.
Install the snow blower quick couplers to the loader.
Electrical Connection
Connect the wiring harness to the loader's connector.
NOTE: Depending on your model of skid loader, a pigtail
adapter (not included with the snow blower) may
be required to couple the snow blower's harness
to the skid loader's connector.
Blowing Snow
A definite pattern of operation is required to thoroughly
clean the snow area. The patterns shown in this section
should be used to avoid throwing snow in unwanted
places, as well as eliminating a second removal of snow.
The drawing above illustrates the removal of snow when
it is possible to throw the snow to the left and right, as
on a long driveway.
Start in the middle and work towards the opposite ends,
throwing the snow to both sides without changing the
direction of the discharge chute.
(Procedure continued on following page.)
