Zoom™ AM1808 eXperimenter Kit User Guide
Logic PD // Products
Published: March 2011
This document contains valuable proprietary and confidential information and the attached file contains source code, ideas, and
techniques that are owned by Logic PD, Inc. (collectively “Logic PD’s Proprietary Information”). Logic PD’s Proprietary Information
may not be used by or disclosed to any third party except under written license from Logic PD, Inc.
Logic PD, Inc. makes no representation or warranties of any nature or kind regarding Logic PD’s Proprietary Information or any
products offered by Logic PD, Inc. Logic PD’s Proprietary Information is disclosed herein pursuant and subject to the terms and
conditions of a duly executed license or agreement to purchase or lease equipment. The only warranties made by Logic PD, Inc., if
any, with respect to any products described in this document are set forth in such license or agreement. Logic PD, Inc. shall have no
liability of any kind, express or implied, arising out of the use of the Information in this document, including direct, indirect, special or
consequential damages.
Logic PD, Inc. may have patents, patent applications, trademarks, copyrights, trade secrets, or other intellectual property rights
pertaining to Logic PD’s Proprietary Information and products described in this document (collectively “Logic PD’s Intellectual
Property”). Except as expressly provided in any written license or agreement from Logic PD, Inc., this document and the information
contained therein does not create any license to Logic PD’s Intellectual Property.
The Information contained herein is subject to change without notice. Revisions may be issued regarding changes and/or additions.
© Copyright 2011, Logic PD, Inc. All Rights Reserved.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. ii
Revision History
REV
EDITOR
DESCRIPTION
APPROVAL
DATE
A SMC Initial release JCA 03/28/11

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. iii
Table of Contents
1Introduction...........................................................................................................................................1
1.1 Scope of Document.......................................................................................................................... 1
1.2 Requirements...................................................................................................................................1
2Application Baseboard ........................................................................................................................2
2.1 Application Baseboard Features Diagram.......................................................................................2
2.2 DIP Switches....................................................................................................................................2
3Removing the AM1808 SOM-M1..........................................................................................................4
4Connect Blackhawk Emulator............................................................................................................. 5
5Installing Code Composer Studio....................................................................................................... 6
6Running Board Support Library (BSL) Sample Programs............................................................... 7
6.1 Connect eXperimenter Kit to Host PC .............................................................................................7
6.2 Copy BSL Files to PC ...................................................................................................................... 7
6.3 Launch Code Composer Studio....................................................................................................... 7
6.4 Run Sample Test ...........................................................................................................................10
Appendix A: Additional Documentation.................................................................................................16

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 1
1 Introduction
This User Guide continues where the QuickStart Guide ended by providing additional hardware
details about the Zoom AM1808 eXperimenter Kit, as well as introductory instructions for using
Code Composer Studio and the included Board Support Library (BSL) files.
1.1 Scope of Document
■This User Guide references specific connectors on the application baseboard. However, the
discussion is limited to special use instructions; detailed information about the connectors
should be referenced on the respective schematic and Bill of Material (BOM) documents. See
Appendix A for links to these documents.
■This User Guide does not provide detailed instructions for the software included with the kits.
Please refer to the specific User Guides for each respective software product for additional
information. A list of additional documentation is available in Appendix A.
1.2 Requirements
■It is assumed that the QuickStart Guide has been read in its entirety. See Appendix A for link
to the QuickStart Guide.
■A development PC with CD/DVD drive, USB port, and at least 2 GB of hard drive space.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 2
2 Application Baseboard
2.1 Application Baseboard Features Diagram
2.2 DIP Switches
There are two 8-position DIP switches located on the application baseboard at reference
designators S2 and S7. By default, all of the switches are set to the “OFF” position.
The S2 DIP switch is reserved for user application general purpose. The S7 DIP switch controls
the processor’s boot mode and several FET muxes on the baseboard. Table 2.1 describes the
function of each switch.
RS232 serial debug
port
60-pin LCD header
USB OTG port
USB host port
Ethernet jack
(for use with
MII PHY only)
Power-in jack
Power switch
Expansion board
connector
Expansion
board
connector
Expansion
board connector
General
purpose user
DIP switches
(S2)
Boot mode /
FET mux DIP
switches (S7)
SATA
connector
Emulation USB
port
JTAG header for
ARM emulator
Expansion board
connector
JTAG header for
TI emulator
System user button (left)
System reset button (right)
Above buttons:
User LED1 (left)
User LED2 (center)
Power LED (right)
Line-in stereo 3.5 mm jack (left)
Line-out stereo 3.5 mm jack (right)
SD card slot
(on bottom of baseboard)

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 3
Table 2.1: S7 DIP Switch Functions
Switch
OFF Position
ON Position
S7:1*
Baseboard LCD drive enabled.
Baseboard LCD drive disabled.
S7:2
Baseboard audio enabled. Associated
McASP lines connect to baseboard
audio only.
Baseboard audio disabled.
Associated McASP lines are available
on audio expansion connector.
S7:3
AM1808 I/O runs at 3.3V
AM1808 I/O runs at 1.8V
S7:4
No connection
S7:5
BOOT[1]
S7:6
BOOT[2]
S7:7
BOOT[3]
S7:8
BOOT[4]
*Note: S7:1 indicates slide 1 on the S7 DIP switch, S7:2 indicates slide 2 on
the S7 DIP switch, and so on.
A default boot mode has been defined by pulling all boot pins (BOOT[0:7]) to a default state on
the SOM. The default boot mode is SPI1 Flash; all available boot modes are described in Table
2.2.
Table 2.2: S7 DIP Switch Boot Modes
Boot Mode
DIP Switch Setting—S7[5:8]
BOOT[4]
BOOT[3]
BOOT[2]
BOOT[1]
S7:8
S7:7
S7:6
S7:5
NOR EMIFA
OFF
ON
ON
ON
NAND-8 EMIFA
OFF
OFF
OFF
ON
Default
SPI1 Flash
OFF
OFF
OFF
OFF
UART2
ON
ON
OFF
OFF
EMU Debug
ON
OFF
OFF
ON

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 4
3 Removing the AM1808 SOM-M1
The following steps will walk you through removing the AM1808 SOM-M1 from the eXperimenter
Kit baseboard and then reconnecting it. This may be necessary for troubleshooting purposes or if
you purchase a different AM1808 SOM-M1 that is compatible with your eXperimenter Kit.
1. IMPORTANT NOTE: A nylon screw keeps the LCD fastened to the baseboard during
shipment. Remove this screw from the bottom side of the baseboard before attempting
to eject the LCD.
Eject the 4.3” LCD by pulling the LCD ejector levers away from the LCD. Remove the LCD
from the baseboard and set aside.
2. Taking care not to bend the PCB, remove the AM1808 SOM-M1 by applying even pressure
beneath the PCB edges and pulling up.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 5
3. To connect the AM1808 SOM-M1, align the SOM over the three board-to-board connectors.
Using even pressure, press straight down over the connectors to mate boards. Visually verify
that all three connectors have fully mated.
4. Connect the 4.3” LCD by inserting into the baseboard LCD connector and pushing down over
the connector until the LCD ejector levers move to a vertical position. CAUTION: The solder
points on the LCD connector PCB may be sharp; use caution when connecting the LCD.
4 Connect Blackhawk Emulator
The AM1808 eXperimenter Kit includes a Blackhawk™ USB100v2 JTAG emulator.
1. IMPORTANT NOTE: A nylon screw keeps the LCD fastened to the baseboard during
shipment. Remove this screw from the bottom side of the baseboard before attempting
to eject the LCD.
If the 4.3” LCD in connected to the application baseboard, it must be removed prior to
connecting the Blackhawk emulator. Pull back on the ejector levers until the LCD board
connector moves up and disengages from the baseboard 60-pin LCD connector.
2. The Blackhawk emulator connects to the JTAG 20-pin header for ARM core on the
application baseboard. See Section 2.1 for diagram pointing to the location of this header.
3. Position the emulator so the ribbon cable extends away from the application baseboard. See
figure below.
4. Make sure all of the header pins line up with their respective holes on the PCB connector.
Press straight-down on the PCB until the header and connector fully mate. (To assist with
proper positioning of the emulator 20-pin connector, silkscreen printing on the bottom side of
the PCB calls out the location of pins 1, 2, 19, and 20; these can be used to verify the
connector holes matchup with their respective header pins on the application baseboard.)

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 6
5. The 4.3” LCD can now be reconnected to the application baseboard.
5 Installing Code Composer Studio
The Zoom AM1808 eXperimenter Kit includes a software DVD containing Code Composer Studio
(CCStudio).
1. Insert the Code Composer Studio v4 software DVD into your host PC.
2. Navigate to the DVD drive and open the files on the CCStudio DVD. Double-click on
setup_CCS_4.2.x.xxxxx.exe and a splash screen similar to the image below will appear. Click
the Next button.
3. Follow the on screen instructions until you arrive at the screen for Product Configuration,
select Platinum Edition.
4. On the next screen, leave the default ISA items checked. Click the Next button.
5. Leave the default Component items checked. Click the Next button.
USB mini-B
connector

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 7
6. Click the Next button to start copying files.
7. Wait for CCStudio to finish installing; this process can take some time, so please be patient.
8. Click the Finish button when the installation is complete. You may eject the CCStudio DVD
at this time.
6 Running Board Support Library (BSL) Sample Programs
The BSL sample programs are included to test the different features of the development kit and
diagnose any potential problems. In order to run these tests, you first have to connect your
development kit to a PC.
6.1 Connect eXperimenter Kit to Host PC
To communicate with the AM1808 eXperimenter Kit using CCStudio, you will need to connect the
included USB A to mini-B cable to the USB mini-B connector on the Blackhawk emulator (see
Section 4) and a USB A port on the host PC.
As soon as the USB cable connects to your host PC, Windows should automatically recognize
that new hardware has been connected and install the necessary drivers. Power on your AM1808
eXperimenter Kit, move the S7 DIP switches 7 and 8 to the on position, and continue with the
next section.
6.2 Copy BSL Files to PC
The Windows CE SD card included with the AM1808 eXperimenter Kit contains the GEL and BSL
files. These files need to be copied to your host PC.
1. Insert the SD card into the USB card reader and insert the card reader into a USB port on
your host PC.
2. Navigate into the SD card and locate the BSL files directory.
3. Extract the ZIP archive and save the files to your host PC. (NOTE:The files may be placed
anywhere on your host PC; however, the original file structure must remain intact.)
4. For the instructions in this User Guide, it is assumed the files were copied to the root C:\
drive. For example:
C:\AM1808_BSL
6.3 Launch Code Composer Studio
1. Launch Code Composer Studio by selecting Start Menu > All Programs > Texas
Instruments > Code Composer Studio v4.2.0 > Code Composer Studio v4.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 8
2. Select a workspace location and then click the OK button.
3. CCStudio will finish launching and a Welcome to Code Composer Studio window will open.
(NOTE: If you do not have the latest Adobe Flash Player installed on your machine, you will
be prompted to install. This is required for proper viewing of the Code Composer Studio
Welcome screen.)
4. If you do not have a license, select the Activate a License option and click the Use Free
Limited License button. (NOTE: If you do not have an active Internet connection, you can
select to Evaluate Code Composer Studio for 30 days. At any time during that period, you
can change to the Free Limited License by selecting Help > License Options... from the
CCStudio menu bar and then following the onscreen instructions.)

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 9
5. You will be redirected to TI’s website to login in with your myTI.com account. Follow all the
online instructions. After completing the online instructions, you will receive an email
containing an attachment that is your license file.
6. Save the license file to your host PC, then return to the Welcome to Code Composer Studio
window and under Step 2 - Install License File, browse to where you saved the license file.
Click the OK button.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 10
7. You will then be presented with the Code Composer Studio Welcome screen. Click on the
cube in the upper right-hand corner to go to the CCStudio workbench.
8. The CCStudio workbench will then appear.
6.4 Run Sample Test
As an example, we will run one feature test. In order to run a test program, you will have to select
the program, compile (or build) the program, and then load the compiled program. The following
steps will walk you through that process.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 11
1. From the menu bar, select Project > Import Existing CCS/CCE Eclipse Project.
2. Browse to the location where you saved the BSL files on your host PC and down to the
AM1808_BSL\src\bsl directory. Click the OK button. Verify the correct project exists in the
Discovered projects: window and then click the Finish button.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 12
3. Once again, select Project > Import Existing CCS/CCE Eclipse Project. This time browse
to the tests folder, AM1808_BSL\src\tests. Click the OK button. Verify the correct project
exists in the Discovered projects: window and then click the Finish button.
4. In the Projects window on the left, expand the AM1808 BSL folder and verify the .ccxml file is
set as Active/Default. If not, right-click on the .ccxml file name and select Set as Active
Target Configuration, then repeat to also Set as Default Target Configuration.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 13
5. Once again in the Projects window on the left, expand the AM1808eXp LED_DIP Test
project. Right-click on the file name and select Set as Active Project.
6. The test must now be compiled; from the CCStudio menu bar select Project > Build Active
Project.

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 14
7. Once the Console window prints the message “Build Complete,” select Target > Debug
Active Project from the menu bar. (NOTE: If you receive a message stating “Error
connecting to the target,” press the reset button on the baseboard and then click Retry.)
8. After the test finishes loading, you will see a message in the Console window stating
“Memory Map Setup Complete.”
9. To run the program, select Target > Run from the menu bar. (NOTE: If you receive a
message stating “Error during: Execution, Initialization, Control,” click Cancel, select Target
> Terminate All from the menu bar, press the reset button on the baseboard, and repeat
steps 7-9.)

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 15
10. The Console window provides a brief description of the test. If you move any of the S2 DIP
switches, output text will print the switch that was moved and its new position (ON or OFF)
and USER LED1 or USER LED2 will turn on or off in relation to the DIP switch position.
The steps in this section can be repeated to run any of the other tests for your eXperimenter Kit.
(NOTE: All of the tests in the “experimenter” folder can be run on both the AM1808 EVM and
eXperimenter Kit; the tests in the “evm” folder can only be run on the AM1808 EVM.)

Zoom™ AM1808 eXperimenter Kit User Guide
PN 1017844A Logic PD, Inc. All Rights Reserved. 16
Appendix A: Additional Documentation
Software Documentation
■The Windows CE SD card included with your AM1808 eXperimenter Kit includes Software
Developer Guides for Windows CE. Please see the setup.htm files on the SD card for
information.
■U-Boot documentation
http://www.denx.de/wiki/U-Boot/WebHome
■TI Code Composer Studio documentation
http://focus.ti.com/dsp/docs/dspsupportatn.tsp?sectionId=3&tabId=415&familyId=44&toolTyp
eId=30
Hardware Documentation
All of the following links are also available on your “My Account” page on the Logic PD website
(http://support.logicpd.com/auth/).
■Logic PD Zoom AM1808 eXperimenter Kit QuickStart Guide
http://support.logicpd.com/downloads/1294/
■Logic PD Zoom AM1808 eXperimenter Kit Hardware Design Files (BOMs, Schematics, and
Layout Files for all boards included in the eXperimenter Kit)
http://support.logicpd.com/downloads/1397/
■Logic PD AM1808 SOM-M1 Hardware Specification
http://support.logicpd.com/downloads/1324/
