GIGAIPC iTXL-Q370A User manual

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
1www.gigaipc.com
iTXL-Q370A (MQ37AT-SI)
Thin Mini-ITX Motherboard
User’s Manual 1st Ed

2
www.gigaipc.com
Copyright Notice
This document is copyrighted, 2018. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translat¬ed, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no respon¬sibility for its use, or for any
in¬fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy,
GIGAIPC assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
GIGAIPC reserves the right to make changes in the product design
without notice to its users.

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
3www.gigaipc.com
Acknowledgement
All other products’ name or trademarks are properties of their
respective owners.
• AMD® is trademark of Advanced Micro Devices.
• Microsoft Windows is a registered trademark of Microsoft Corp.
• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel
Corporation
• Core, Atom are trademarks of Intel Corporation
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

4
www.gigaipc.com
Packing List
Before setting up your product, please make sure the following items
have been shipped:
Item Quantity
iTXL-Q370A MB 1
SATA power cable 1
I/O Bracket 1
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
5www.gigaipc.com
About this Document
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware
and software features (if any), its specifications, dimensions, jumper/
connector settings/definitions, and driver installation instructions (if
any), to facilitate users in setting up their product.
Users may refer to the GIGAIPC.com for the latest version of this
document.

6
www.gigaipc.com
Safety Precautions
Please read the following safety instructions carefully. It is advised that
you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the
device.
3. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
4. Always completely disconnect the power before working on the
system’s hardware.
5. No connections should be made when the system is powered
as a sudden rush of power may damage sensitive electronic
components.
6. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before
cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray
detergents.
9. Make sure the device is installed near a power outlet and is
easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent
falls
12. Do not cover the openings on the device to ensure optimal heat
dissipation.

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
7www.gigaipc.com
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is
running
15. Never pour any liquid into the openings. This could cause fire or
electric shock.
16. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge
when installing the internal components. Use a grounding
wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please the contact our
service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S
PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO
PREVENT DAMAGE.

8
www.gigaipc.com
FCC Statement
This device complies with Part 15 FCC Rules. Operation
is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device
must accept any interference received including
interference that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant
et les directives gouvernementales de recyclage.

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
9www.gigaipc.com
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
GIGAIPC Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电
子组件
○ ○ ○ ○ ○ ○
外部信号
连接器
及线材
○ ○ ○ ○ ○ ○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此 产 品 所 标 示 之 环 保 使 用 期 限，系 指 在 一 般 正 常 使 用 状 况下。

10
www.gigaipc.com
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
GIGAIPC Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components O O O O O ○
Wires &
Connectors
for External
Connections
O O O O O O
O：The quantity of poisonous or hazardous substances or elements found in each
of the component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least
one of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this
product is applicable under normal usage only

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
11 www.gigaipc.com
Table Contents
Thin Mini-ITX Motherboard 1
User’s Manual 1st Ed 1
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List................................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement.............................................................................. 8
China RoHS Requirements (CN).................................................... 9
China RoHS Requirement (EN) ................................................... 10
Chapter 1 - Product Specifications 13
1.1 Specifications ............................................................... 15
Chapter 2 – Hardware Information 17
2.1 Jumpers and Connectors ............................................. 18
2.2.1 DC_IN (DC In Jack)......................................................... 21
2.2.2 ATX_19V (ATX 1x2 Pin Power Connector) .................... 22
2.2.3 Battery (Battery Connector) ......................................... 23
2.2.4 BL_SW (Brightness Switch Connector) ...................... 24
2.2.5 CLR_CMOS (Clear CMOS Jumper)................................. 25
2.2.6 COM1 (Seriel Port Header) .......................................... 26
2.2.7 CPU_FAN (CPU FAN Connector) ................................... 27
2.2.8 DMIC_CON (Digital MIC Connector) ............................ 28
2.2.9 SYS_PANEL (System Panel Header)............................... 29

12
www.gigaipc.com
2.2.10 F_USB2_1 (USB 2.0 Header).......................................... 30
2.2.11 F_USB2_2 (USB 2.0 Header).......................................... 31
2.2.12 F_USB2_3 (USB 2.0 Header).......................................... 32
2.2.13 F_USB2_4 (USB 2.0 Header).......................................... 33
2.2.14 FP_Audio (Front Panel Audio Header) .......................... 34
2.2.15 FPD (Front Panel Display Connector)............................ 35
2.2.16 FPD_PWR (Front Panel Display Power Connector) ....... 36
2.2.17 F_USB3 (USB 3.0 Header).............................................. 37
2.2.18 LCD_VCC (LCD_VCC Connector).................................... 38
2.2.19 LVDS (LVDS Connector) ............................................... 39
2.2.20 MON_SW (Monitor Switch Connector) ........................ 40
2.2.21 SATA _PWR (SATA Power Connector) .............................41
2.2.22 SPKR (Speaker Out Connector) ..................................... 42
2.2.23 SYS_FAN (System Fan)................................................... 43
2.2.24 TPM (Trusted Platform Module Connector)................. 44
2.2.25 SATA2, 3, 4, 5 (SATA 6 Gb/s Connector) ........................ 45
2.2.26 M2M (M.2 Slot, M-Key, SATA 6Gb/s & PCIe, Supports
NGFF-2260/2280 Cards)................................................ 46
2.2.27 M2E (M.2 Slot, E-Key, Supports NGFF-2230 CNVi Cards
Only).............................................................................. 46
2.2.28 SODIMM1, SODIMM2 (2 x DDR4 SO-DIMM Sockets)... 47
2.2.29 PCIe x4 (1 x PCIe x4 (Gen3 x 4 Bus) Slot)....................... 47
2.2.30 IO Connector Information............................................. 48

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
13 www.gigaipc.com
Chapter 1
Chapter 1 - Product Specifications

14
www.gigaipc.com

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
15 www.gigaipc.com
1.1 Specifications
Motherboard iTXL-Q370A (MQ37AT-SI)
Form Factor Thin Mini-ITX form factor
170W x 170D (mm)
CPU
Support for 8th/9th Generation Intel® Core™ i7 processors/
Intel® Core™ i5 processors/ Intel® Core™ i3 processors/
Intel® Pentium®processors/ Intel® Celeron® processors in
the LGA1151 package TDP under 65W
L3 cache varies with CPU
Socket 1 x LGA 1151
Chipset Intel® Q370 Express Chipset
Memory
2 x DDR4 SO-DIMM sockets supporting up to 32 GB of
system memory
Dual channel memory architecture
Support for DDR4 2666/2400 MHz memory modules
Ethernet 1 x GbE LAN port (Intel® i219LM)
Video
Integrated Graphics Processor - Intel® HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096 x
2160@30 Hz
1 x DP port, supporting a maximum resolution of 4096 x
2160@60 Hz
1 x LVDS port, supporting a maximum resolution of 1920 x
1080@60Hz
* Support up to 3 displays at the same time
* Support for HDMI 1.4 version
* Maximum shared memory of 1024MB
Audio Realtek ALC887 + ALC105 Amplifier
High Definition Audio
Storage 4 x SATA 6Gb/s ports
Raid Intel® SATA RAID 0/1/10/5
Expansion Slots
1 x PCIe x4 (Gen3 x 4 bus) slot
1 x M.2 slot:
- M-key
- SATA 6Gb/s & PCIe
- Supports NGFF-2260/2280 cards
1 x M.2 slot:
- E-key
- Supports NGFF-2230 CNVi cards only

16
www.gigaipc.com
Motherboard iTXL-Q370A (MQ37AT-SI)
Internal I/O
1 x 2-pin ATX main power connector
4 x SATA 6Gb/s connectors
5 x USB 2.0 headers
2 x USB 3.0 headers
1 x Front panel header
1 x Front panel audio header
1 x Speaker out header
1 x DMIC header
1 x LVDS connector
1 x FPD
1 x FPD_SW 1x3 (For Panel Power SW)
1 x LCD_VCC Pin header
1 x Back Light Switch
1 x System fan header
1 x CPU fan header
1 x COM Header (RS-232)
1 x SATA Power
Rear I/O
2 x Audio jacks (Line out, Mic in)
1 x HDMI 2.0
1 x Display Port
1 x RJ45
4 x USB3.1
1 x DC Jack (+12V/+19VDC )
TPM 1 x TPM Header
OS Compatibility Windows 10 (x64)
PSU Connectors 1 x DC-in (+12/ +19VDC)
1 x 2-pin ATX power connector
Operating Properties
Operating temperature: 0°C to 60°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -20°C to 70°C
Non-operating humidity: 0% - 95% (non-condensing)
Packing Content
BOX Packing Capacity: 10pcs
Carton size: 460 x 345 x 203 (mm)
Content: IO Shield x 1 (12AIO-MCH370-00R)
Order Information Motherboard: 9MCQ37AIMR-SI
Optional kit: TPM 1.2 module: 9CMUFLNR-00
TPM 2.0 module: 9CTM000NR-00

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
17 www.gigaipc.com
Chapter 2
Chapter 2 – Hardware Information

18
www.gigaipc.com
2.1 Jumpers and Connectors
1
2
23
32 33 3430 37
6
7
18
19 20
21
22
36
13
12
8
16
9
10
11
14
17
15
24
25
26
4
35
28
29
35
27

Thin Mini-ITX Motherboard iTXL-Q370A (MQ37AT-SI)
19 www.gigaipc.com
No Code Description
1DC_IN DC In Jack
2ATX_19V ATX 1x2 Pin Power Connector
3Battery Battery Connector
4BL_SW Brightness Switch Connector
5CLR_CMOS Clear CMOS Jumper
6COM1 Seriel Port Header
7CPU_FAN CPU FAN Connector
8DMIC_CON Digital MIC Connector
9SYS_PANEL System Panel Header
10 F_USB2_1 USB 2.0 Header
11 F_USB2_2 USB 2.0 Header
12 F_USB2_3 USB 2.0 Header
13 F_USB2_4 USB 2.0 Header
14 FP_ Audio Front Panel Audio Header
15 FPD Front Panel Display Connector
16 FPD_PWR Front Panel Display Power Connector
17 F_USB3 USB 3.0 Header
18 LCD_VCC LCD_VCC Connector
19 LVDS LVDS Connector
20 MON_SW Monitor Switch Connector
21 SATA_PWR SATA Power Connector
22 SPKR Speaker out Connector
23 SYS_FAN System Fan Connector

20
www.gigaipc.com
No Code Description
24 TPM Trusted Platform Module Connector
25 SATA2, 3, 4, 5 SATA 6 Gb/s Connector x 4
26 M2M M.2 Slot, M-Key, SATA 6Gb/s & PCIe, Supports
NGFF-2260/2280 Cards
27 M2E M.2 Slot, E-Key, Supports NGFF-2230 CNVi
Cards only
28 SODIMM1,
SODIMM2 2 x DDR4 SO-DIMM Sockets
29 PCIe x4 1 x PCIe x4 (Gen3 x 4 bus) Slot
30 IO Connector Information
31 MIC_IN MIC In Connector
32 LINE_OUT Line Out Connector
33 HDMI 2 HDMI Connector
34 DP Embedded Display Port Connector
35 USB31_1,
USB31_2, USB3.1 Type A Connector x 3
36 USB31 USB3.1 Type C Connector x 1
37 LAN Ethernet x 1
