CD Concept CD400 User manual

CD400
Tachograph programmer user manual
CD400 V2.0 r07 b10 (2/10/2020)

Index:
1. Introduction……………………. 3 4.1.4 Constant speed…………………15
1.1 What is a tachograph?......... 3 4.1.5 Draw-wire…………………………15
2. Description……………………... 3 4.1.6 Odometer…………………………16
2.1 Technical specifications…... 3 (only for digital tachographs.
2.2 Keyboard………………………… 4 4.3 Parameters…………………………. 17
2.3 Connections……………………. 4 4.4 Speed test……………………………17
3. Operation………………………...5 4.4.1 Manual……………………………. 17
3.1 Power supply and……………. 5 4.4.2 Automatic…………………………17
tachograph type detection 4.5 Odometer test………………………19
3.2 Menu trees……………………… 6 4.6 Read DTCs……………………………20
3.2.1 KTCO 13xx/1318…………….. 6 4.7 Erase DTCs…………………………...20
3.2.2 MTCO 1324/1390……………. 6 4.8 Sensor Pairing………………………21
3.2.3 Motomet.EGK100……………..7 (Kitas activation)
3.2.4 Kienzle 1319……………………8 4.9 Clock test……………………………..21
3.2.5 V.Root VR2400…………………9 4.10 PIN code…………………………….21
3.2.6 Digital VDO…………………….. 10 4.11 Select tachograph……………….23
3.2.7 Digital SE5000…………………11 4.12 Product info………………………..23
3.2.8 Digital ACTIA……………………12 4.13 Language……………………………23
3.2.8 Digital EFAS……………………..13 5. Software upgrade procedure…….23
4 Functions description……….14
4.1 Measure W……………………….14
4.1.1 Manual…………………………….14
4.1.2 Photo Sensor…………………….15
4.1.3 Rolling road……………………...15

1. Introduction
1.1. What is a tachograph?
Basically, a tachograph is a device that measures and records the speed and distance driven
by a vehicle. The data are recorded in the form of graphics on a paper disk.
The new digital tachographs record those data on its embedded memory and also on the
smartcard of the driver.
2. Description
2.1 Technical specifications
- Graphic FSTF LCD Display:
100 x 32 px (4 lines x 20 char)
White LED backlight
- Size: 150 x 100 x 45 mm
- Supply voltage: 9 to 30 VDC
- Supply current: 12mA
- Case: green-blue ABS (IP40)
- Operating temp: -20…+70°C
- Weight: 155g

2.2. Keyboard
- Alternate function keys 'F1', 'F2' & 'F3' are active when a
function in inverted video appears on the bottom line of the
display.
F1= MODIFY, F3=OK
- Alternate function key '↑' & '↓' are used for example to
navigate the menus.
- Alternate function key '←' & '→' are used to select the digit
in some parameters.
- 'Ent' (=Enter) is used to select a function or enter a value.
- 'Esc' key is used to go back in the menu, leave a function, to
erase the last digit entered and to switch the programmer
ON & OFF when powered by the battery.
2.3. Connections
- Left connector:
Serial port for software upgrade
(upgrade cable).
- Center connector:
Connection for crocodile clip cable
(K13xx/K1318).
- Right connector:
Connection for tachograph cable.
Track leng th
0020m
MODIFY OK
12345678901234567

3. Operation
3.1. Power supply and tachograph type detection
For all tachograph types, except for the K13xx/1318 and the FTCO1319, the programmer is
powered by the tachograph itself. An automatic tachograph type detection is executed on
power ON, so don't switch the programmer ON, simply connect it to the tachograph with the
appropriate cable. The programmer will switch ON and detect the tachograph type.
In the case of the K13xx/1318 and the FTCO1319, switch the programmer ON pressing the
'I/O' key.
If the FTCO1319 is connected, the programmer will detect it.
To switch the programmer OFF, press and hold the 'I/O' key.
If no tachograph is detected, the K13xx/1318 will be selected by default.
On power ON, the programmer will display the product information (Software version, Serial
number, etc...), then the menu for the tachograph type detected.
3.2. Menu trees
The functions available in the main menu depend on tachograph model detected (or selected
manually).
The tachograph model appears on the top line.
3.2.1. KTCO 13xx/1318
KTCO 13xx/1318
1.Me asure W
1.Ma nual
2. Photo s ensor
2.Me asure K
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Cl ock t est
6. Select T acho.
7. Pr oduct info.
8.Language.

3.2.2. MTCO 1324/1390
MTCO 1324/1390
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.K Fact or
2.Odometer
3. Instal. Date
4. Calibr. Date
5. Time & Date
6.O/P shaft
7. Service delay
8. CAN p riority
9. Binary code
10. Product Cod e
11.VIN
12.N- RPM Factor
13.L- Tyr e
14.Serial number
15.M aximum sp eed (1390 only)
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Erase DTCS
6. Sensor pa iring
7. Cl ock t est
8. Select T acho.
9. Pr oduct info.
10.La nguage.

3.2.3. Motometer EGK100
Motometer EGK10 0
1.Me asure W
1.Ma nual
2. Photo sens or
2. Parameters
1.K Fact or
2.Kn
3. U1
4. U2
5. U3
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Select T acho.
6. Pr oduct info.
7.Language.

3.2.4. Kienzle 1319
Kienzle 1319
1.Me asure W
1.Ma nual
2. Photo s ensor
2.Me asure K
3. Parameters
1.K factor
2.Odometer
3.Instal. Date
4.Calibr. Date
5.Odometer Unit
6.Speed W arning
7.Fitter Number
8.Clock Sp eed
9.Kn ON /OFF
10.K n Max
11.K n Warning
12. Code
13.M ercedes ID
14. EEC Ta cho.
15.SWISS ABZ
16. Driver change
17.4imp/m output
18.Note
19.Service
20.Tot. distance
21.M odel
22.Serial number
23. Electronics
24. Code SO
25. Code M E
26. Code PR
4. Speed test
1.Ma nual
2.Aut omatic
5.Odometer test
6. Cl ock t est
7. Select T acho.
8. Pr oduct info.
9.Language.

3.2.5. V.Root VR2400
V.Root VR2400
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.K factor
2.Odometer
3.Pulse per rev.
4.Idle rpm
5.Economy rpm
6.Poor Econ. rpm
7.CANBus RPM
8.RPM Display
9.Dist displ.0s
10. DTCs Disp lay
11.Overspd F las h
12.Overspeed
12.Time & Date
13.O/P s haft
14.4th Chart Tr
15. CANBus enab le
16. CAN Type
17. Dual Axle
18. D.Axle Ratio
19. D6 p in funct.
20.Speedo.OP fact
21.Serial Comms
22.Ignit.On re c.
23. Driver 2 Duty
24. Reset H eartBt
25. Eject pin code
26.Sensor type
27.Service De lay
28.Installat.date
29. Calibrat. date
30. Repair Shop ID
31.Vehicle I D n°
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Erase DTCS
6. Sensor pa iring
7. Cl ock t est
8. Select T acho.
9. Pr oduct info.
10.La nguage.

3.2.6. Digital VDO
DIGITAL VDO
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
3.Manufacturer
1.Part number
2.Drv1 ign.ON
3.Drv2 ign.ON
4.Drv1 ign.OFF
5.Drv2 ign.OFF
6.D1D2 Record
7.RPM Record
8.Speed Record
9.Install. date
10.ResetHeartbeat
11.CAN error
12.CAN2 TC01 mess
13.CAN2 WakeUp D3
14.CAN2RemoteDown
15.RD interface
16.Speed Warning
17.Illum.mode
18.IMS Activation
19.IMS source
20.IMS factor
21.VDO Counter
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Read DTCS
6. Erase DTCS

7. Sensor pa iring
8. Cl ock t est
9. PIN code
10.Select T acho.
11. Product info.
12.La nguage.
3.2.7. Digital SE5000
DIGITAL S E5000
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Manufacturer
1.Part number
2.CanBus activat
3.Speed Corr.
4.D6
5.D4
6.Light input
7.RPM input
8.Default lang.
9.Serial Output
10.D1D2 Record
11.RPM Record
12.Speed Record
13.Kn factor
14.Install.date
15.IMS Source
16.IMS Gain
17.IMS Factor
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number

4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Read DTCS
6. Erase DTCS
7. Sensor pa iring
8. Cl ock t est
9. PIN code
10.Select T acho.
11. Product info.
12.La nguage.
3.2.8. Digital ACTIA
DIGITAL ACTIA
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Specific
1.Default Lang
2.Card Language
3.Backlight conf.

4.Drv1 ign.ON
5.Drv2 ign.ON
6.Drv1 ign.OFF
7.Drv2 ign.OFF
8.Install. date
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number
3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Read DTCS
6. Erase DTCS
7. Sensor pa iring
8. Cl ock t est
9. PIN code
10.Select T acho.
11. Product info.
12.La nguage.

3.2.8. Digital EFAS
DIGITAL EFAS
1.Me asure W
1.Ma nual
2. Photo s ensor
2. Parameters
1.Calibration
1.W factor
2.K factor
3.L (Tyre Circ.)
4.Tyre Size
5.Max.Auth.Speed
6.Odometer
7.Time & Date
8.Next Cal. Date
9.Veh.Reg.Nation
10.Veh.Reg.Number
11.Veh.Id.Number
12.O/P shaft
2.Other param.
1.ResetHeartbeat
2.TCO1 priority
3.O/P shaft
4.CAN rep.rate
5.Part number
3.Specific
1.CAN-A activat.
2.CAN-A tr.rate
3.CAN-A ID mode
4.CAN-A sample
5.CAN-A pro.tach
6.CAN-A pro.diag
7.Trip Reset
8.ExtSerial act.
9.ExtSerial prot
10.Illumination
11.Engine Speed
12.N Factor
13.EngSpdThreshold
14.SpeedThresholds
15.Lang.Handling
16.PrtLocalTimeEn
17.CAN-C activat.
18.CAN-C tr.rate
19.CAN-C ID mode
20.CAN-C sample
21.RemoteDataTrans
4.Information
1.Supplier Id
2.Manufact. Date
3.Serial number
4.Hardware number
5.Hardware vers.
6.Software number
7.Software vers.
8.License number

3. Speed test
1.Ma nual
2.Aut omatic
4.Odometer test
5. Read DTCS
6. Erase DTCS
7. Sensor pa iring
8. Cl ock t est
9. PIN code
10.Select T acho.
11. Product info.
12.La nguage.
4 Functions description
4.1. Measure W
4.1.1. Manual
1. Check the track length.
Press F3 (OK) to go on, or press F1(MODIFY) to change the track length.
(optional)
to set the 'Track length', enter the new value and press 'Ent'.
2. Press F3 (START) and drive the vehicle along the track.
The pulse count will start.
3. At the end of the track, press F3 (STOP).
The W factor will be calculated as a function of the pulse count and the
track length.
4. Press F3 (K FACTOR) to access K factor setting.
Trac k length
0020m
MODIFY OK
12345678901234567
Trac k length
0020m
[50 ]
12345678901234567
Puls e counter
0000.0
ST AR T
12345678901234567
Puls e counter
0123.0
STOP
12345678901234567
W factor
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567

5. The closest value from the K factor
table of the 1318 is displayed with the
corresponding switches positions.
Press 'Esc' to go back to main menu.
5. Present K factor will be read from the tachograph and displayed. 'NEW K'
is the W factor that has been measured and should be recorded as the new
K factor.
Press F2 (YES) to record it or F3 (NO) to leave it unchanged.
6. If 'YES' has been selected previously, the new K factor will be read back
from the tachograph.
This factor can modified manually if required pressing F3 (MODIFY).
4.1.2. Photo Sensor
The W measure with a photo sensor is exactly the same as in manual mode, except that the
'START' and 'STOP' pulses are generated by the sensor. In photo sensor mode, the 'F3' (START
& STOP) will not be active.
You can connect any photo sensor using a MiniDIN 4-pins connector connected to the left
connector of the CD400.
- Shielding: Ground (GND 0V).
- Pin n°2: photo sensor signal (the signal should be low when the reference object/reflector is
not detected).
4.1.3. Rolling road.
[Under development]
4.1.4. Constant speed.
[Under development]
4.1.5. Draw-wire.
[Under development]
K Factor
K = 05347p/km
MOD IF Y
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
W=6150p /k m
K TABLE:06147p/km
SWITCHES:1_3_5_7_9 _
12345678901234567
K F A C T O R: 05347p/km
NE W K : 05347p/km
RECO RD NEW K ?
YES NO
12345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
K131
8
Other
tachograph
ss

4.1.6. Odometer (only for digital tachographs).
[Under development]
Using the odometer parameter to measure the W factor does not require the workshop card.
Therefore, this function can be useful for transport companies or for the authorities.
The latest is calculated by measuring the distance driven by a vehicle when the high
resolution odometer is incremented by 5m.
Drive slowly, the CD400 will detect the Start Point
within +/- 5m.
Mark the Start Point on the ground.
Drive slowly, the CD400 will detect the Stop Point in
around 5m (depending on last calibration accuracy).
Measure the driven distance using a decameter and
enter the value in centimeter into the CD400.
As a result, the CD400 will display the K factor of the
tachograph, the W factor of the vehicle and the
calibration error in %.
Start point
Stop point
t
Driven distance to be measured (+/- 5m)
No workshop card required!
Star t Point
detection
Driv e slowly...
Mark
Star t Point
OK
Stop Point
detection
Driv e slowly...
Ente r distance:
[ 503 ]cm
K: 5546 p/ km
W: 5512 p/ km
Erro r: + 000.6 %
OK

4.2 Measure K
This function is available only for the K1314/1318 and the FTCO 1319.
Measuring the K factor takes a few seconds.
The value is updated every time the progress bar is completed.
4.3. Parameters
The parameter list is available at: 3.2. Menu trees
4.4. Speed test
4.4.1 Manual
For the K1314/1318 the K reference is set to the last K measured if available,
otherwise it is set to 8000. For the other tachographs the K reference is set to the K
factor programmed in the tachograph.
If required, the K reference can be adjusted manually pressing 'F1' (MODIFY).
By default the speed is set to 60 km/h.
Press F1 (ON/OFF) to start/stop speed simulation.
The text "km/h" is blinking when the speed is currently simulated.
Pressing the '↑' and '↓' keys, will increase/decrease the speed by 1km/h steps.
Pressing the '←' and '→' keys, will increase/decrease the speed by 0.1km/h steps.
Press F1(MODIFY) to insert a new speed value.
K Factor
K = 8000 p/km
MODI FY OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Me asu re K
K:0020p/km
1234567890123456
7
060.0km/ h
K:8 000 p/km
MODI FY ON
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
060.0km/ h
K:8 000 p/km
MODI FY OF F
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567

4.4.2 Automatic
Select the speed diagram to be executed and press 'Ent'.
For the K1314/1318 the K reference is set to the last K measured if available,
otherwise it is set to 8000.
For the other tachographs the K reference is set to the K factor programmed in the
tachograph.
If required, the K reference can be adjusted manually pressing 'F1' (MODIFY).
Press 'F3' (OK) if you agree with the K factor value.
Using the '↑' and '↓' keys, you can check the speed and duration of each step of the
automatic test.
Press 'F3' (START) to start the test.
The 'EDIT' function (F1) is available only for the custom diagram to edit the speed
and duration of current step of the automatic test. The automatic test will end at the
first step at which the duration is set to zero.
A count down will show the time left for present step.
Press 'F3' (STOP) to stop the bench test
Bench test completed.
Press 'F3' (OK) to go back to the menu.
Select diagram
→1.Custom diag.
2.Tacho.
100km/h
3.Tacho.
125km/h
4.Tacho.
140km/h
5.Tacho.
160km/h
6.Tacho.
180km/h
7.Tacho.
Digital
K = 8000 p/km
MODI FY OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Cu sto m diag.
Kre f= 08000 p/ km
MOD IFY OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Custom diag.
Step:01/23
180 km/h - 010s
EDI T ST AR T
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Custom diag.
Bench test
Compleleted
OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Custom diag.
Step:01/23 - 007s
180 km/h -010s
K:05000 START
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567

4.5. Odometer test
The programmer will automatically simulate a speed of 50km/h on 1000m distance and
check if the odometer as been incremented by 1000m.
For the K1314/1318 the K reference is set to the last K measured if
available, otherwise it is set to 8000.
For the other tachographs the K reference is set to the K factor
programmed in the tachograph.
If required, the K reference can be adjusted manually pressing 'F1'
(MODIFY).
KTCO1318/FTCO1319/EGK100
MTCO/VR2400/DIGITAL
Press 'F2' to adjust the position of the start point.
Press 'F3' (START) to start the test.
The initial value of the odometer (D1) will be read.
Press 'F3' (START) to start the test.
Wait until the progress bar is completed.
The test can be aborted pressing 'F3' (STOP).
Wait until the progress bar is completed.
The test can be aborted pressing 'F3' (STOP).
At the end of the test, the final odometer value will
be read (D2). The difference between D2 and D1 will
be calculated (D2-D1). If the difference equals
1000m, the test has been successful.
Od ome ter test
Kre f= 08000 p/ km
MOD IFY OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Odom ete r test
1000m
+ START
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Od om eter t e s t
0 10 00m
STOP
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Odom ete r test
D1:0041728740m
START
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
Odometer test
D1:0041728740m
STOP
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:01 23.0 K FACTOR
FACTORTOP
12345678901234567
Odom ete r test
D1:0041728740m
D2:0041729740m
(-) 1000m OK
2345678901234567
NEW K:
06150p/km
RECO RD NEW K ?
6150.0
P:0123.0 K FA CT OR
FACTORTOP
12345678901234567
