Logic L7DUAMM16 User manual

Instruction Manual
7˝ Dual
Portable DVD Player
L7DUAMM16
L7DUAMM16_IB_160729.indd 1 29/7/2016 4:44 PM

L7DUAMM16_IB_160729.indd 2 29/7/2016 4:44 PM

Contents
Safety Warnings.....................................................................................................................................5
Unpacking..............................................................................................................................................7
Product Overview..................................................................................................................................8
DVD Players A & B..............................................................................................................................................................8
Remote Controls A & B ..........................................................................................................................9
Removing the Plastic Strips from the Remote Controls ...................................................................11
Battery Replacement for the Remote Control...............................................................................................11
Remote Control Operation Range......................................................................................................12
In-Car Use .............................................................................................................................................13
Using the DVD Players A and B Together (in-car use)........................................................................................13
Mounting the DVD in a Car .........................................................................................................................................14
Installation Guide............................................................................................................................................................15
Using the DVD Players A and B Indoors.............................................................................................16
Using the Mains Adapter (for indoor use)..............................................................................................................16
Charging the battery...........................................................................................................................17
Connections .........................................................................................................................................17
Watching a DVD on the DVD Player A and B ........................................................................................................17
Connecting to a TV.........................................................................................................................................................18
Connecting to a Stereo Receiver or Amplier......................................................................................................18
Using Earphones.............................................................................................................................................................19
Using The Stand For Indoor Use .........................................................................................................20
Using a USB Device.................................................................................................................................................20
Compatible Disc Types ........................................................................................................................21
Supported Formats........................................................................................................................................................21
Region Code .....................................................................................................................................................................21
Turning On the DVD Player.................................................................................................................22
Basic Playback......................................................................................................................................22
Basic DVD Playback........................................................................................................................................................22
Playback Pausing ............................................................................................................................................................22
Selecting Chapter / Title time / Chapter time (for DVD) ...................................................................................23
Selecting Disc GOTO / Track GOTO / Select Track (for CD) ...............................................................................23
Stop Playback...................................................................................................................................................................23
Previous and Next...........................................................................................................................................................23
Fast Forward and Fast Rewind ...................................................................................................................................23
Repeat Mode ....................................................................................................................................................................23
Slow Playback...................................................................................................................................................................24
Angle Selection ...............................................................................................................................................................24
Audio Channel .................................................................................................................................................................24
Subtitle Language ..........................................................................................................................................................24
Info .......................................................................................................................................................................................24
L7DUAMM16_IB_160729.indd 3 29/7/2016 4:44 PM

Programmable Memory...............................................................................................................................................25
Zoom Selection ...............................................................................................................................................................25
Title ......................................................................................................................................................................................25
Menu ...................................................................................................................................................................................25
Customising the General Settings......................................................................................................26
Customising the Audio Settings.........................................................................................................28
Customising the Video Settings .........................................................................................................29
Customising the Preference Settings.................................................................................................29
Customising the Password Settings...................................................................................................31
Maintenance ........................................................................................................................................32
Cleaning the Unit............................................................................................................................................................32
Handling Discs.................................................................................................................................................................32
Cleaning Discs..................................................................................................................................................................32
Storing Discs.....................................................................................................................................................................32
Hints and Tips ......................................................................................................................................33
Specications.......................................................................................................................................35
L7DUAMM16_IB_160729.indd 4 29/7/2016 4:44 PM

5
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include this
manual.
• Check that the voltage marked on the
rating label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about its normal function,
or if it is damaged in any way - switch o,
withdraw the mains adapter and consult
your dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
• Attention should be drawn to the use of
apparatus in moderate climates.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases,
should be placed on the unit. Do not
operate the unit with wet hands, near water
or other liquid.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
adapter and consult your dealer.
Safety Warnings
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do not
obstruct the ventilation vents.
• A minimum distance of 5cm around the
unit should be maintained to allow for
sucient ventilation.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/ disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
before a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption,
never leave the unit switched on while
unattended for long periods of time, e.g.
overnight, while on holiday or while out of
the house. Switch it o and disconnect the
mains plug from the mains socket.
Mains Adapter
• The mains adapter will continue to draw
electricity from the mains supply when
plugged in the mains socket. In the
interests of safety and to avoid unnecessary
energy consumption, never leave the
adapter plugged in the mains socket
while unattended for long periods of time.
Disconnect the adapter from the power
supply.
Mains Adapter Cable
• Make sure the unit is not resting on top of
the mains adapter cable, as the weight of
the unit may damage the cable and create a
safety hazard.
Use only power supplies listed in the
user instructions.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the operating performance of the
unit, and cause a distorted picture or sound.
L7DUAMM16_IB_160729.indd 5 29/7/2016 4:44 PM

6
Earphones
• Listening to loud sounds for
prolonged periods of time may
permanently damage your hearing.
• Before putting on earphones, turn the
volume down then put the earphones on
and slowly increase the volume until you
reach a comfortable listening level.
Batteries
• Batteries used in the remote control for this
unit are easily swallowed by young children
and this is dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the remote control.
Seek medical advice if you believe a cell has
been swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct sunlight
or sources of excessive heat.
• Attention should be drawn to the
environmental aspects of battery disposal.
Supervision
• Children should be supervised to ensure
that they do not play with the unit and the
remote control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.
Class 1 Laser Product
• This unit utilises a
laser. Use of controls,
adjustments or
performance of
procedures other than those specied
herein may result in hazardous radiation
exposure.
• Before moving the unit, ensure the disc tray
is empty.
• Always remove the disc when the unit is
not in use.
• Failure to do so will risk severely damaging
the disc and the unit.
• Do not stack devices; heat from other
devices may aect the performance of the
unit.
CLASS 1
LASER PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the unit’s enclosure
that may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose to dangerous voltages.
Maintenance
• Ensure to unplug the unit from the power
supply before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.
L7DUAMM16_IB_160729.indd 6 29/7/2016 4:44 PM

7
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
DVD Player A DVD Player B Remote Control A & B
Mains Adapter × 2
Earphones × 2
Car Power Adapter 3.5mm to 3.5mm Stereo
Audio Cable
Mounting support × 2
Instruction Manual
Screws × 4 (ø4 × 25 mm) Quick Start Guide
SETUP ENTER S OURCE
\\VOL+\ S ETUP ENTER SO URCE \\VOL+\
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+ DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL- VOL +
REPEAT SLOW
PROGRAM ZOOM
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+ DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL- VOL +
REPEAT SLOW
PROGRAM ZOOM
Instruction
Manual
Quick Start Guide
Thank youfor purchasing your new product.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction
manual in order that you fully understand all the operational features
it oers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
L7DUAMM16_IB_160729.indd 7 29/7/2016 4:44 PM

8
Product Overview
DVD Players A & B
1. Display
2. Speakers
3. Remote Control Sensor
Receive signals from the remote control.
4. Setup Button
Display the Setup menu.
5. Cursor Button
Move up and down in the menu screen.
Button: previous track
Skip backwards to the beginning of the
track or to the previous track.
Button: next track
Skip forwards to the next track.
6. Power Indicator
Light up red when the unit is on.
7. ENTER Button
Conrm selection on a menu screen.
8. Cursor Button
Move left and right in the menu screen.
VOL + / – Button
Adjust the volume.
9. Battery Indicator
• Flash green when charging.
• Light up green when fully charged.
10. SOURCE Button
Select the desired input signal source:
DVD / AV In / Media.
11. OPEN Latch
Switch right to open the disc door.
12. ON / OFF Switch
13. USB Slot
14. Earphones Socket
15. AV OUT Socket
16. AV IN Socket
17. DC IN 9-12V Socket
18. Stand
SET UP ENT ER S OUR CE
\\VOL +\
1
2
103 4 65 8 97
Front View
18
Rear View
11
OPEN
Top View
12 13 14 15 16 17
ON OFF AV OUT AV IN DC IN 9-12V
Left Side View
L7DUAMM16_IB_160729.indd 8 29/7/2016 4:44 PM

9
Remote Controls A & B
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL - VOL +
REPEAT SLOW
PROGRAM ZOOM
1
2
3
5
8
9
11
10
12
6
4
7
1. STEP Button
Frame Advance in DVD mode.
2. SEARCH Button
Search and start playback from a selected
point on the disc.
3. 0-9, 10+ Number Buttons
Create programme or locate a title/
chapter/track or specic time.
4. SUBTITLE Button
Selects one of the subtitle languages
programmed on a DVD (if available).
5. ANGLE Button
Switch between multiple camera angles
when the DVD you are playing has been
programmed with multiple camera
angles.
6. TITLE Button
Return to DVD Title Menu.
7. Cursor Buttons
Navigate between selections on a menu
screen and adjust certain settings.
ENTER Button
Conrm selection on a menu screen.
8. SETUP Button
Display the GENERAL SETUP PAGE.
9. REPEAT Button
• Repeat a DVD chapter or title.
• Repeat a CD track or the entire disc.
10. SLOW Button
Enter slow playback, and cycle between
dierent speeds (1/2, 1/4, 1/8, 1/16 and
normal).
11. PROGRAM Button
• Programmes the playback of favourite
titles/chapters/tracks from the disc in
DVD / CD mode.
• Select the slide show mode for scrolling
through JPEG pictures.
12. ZOOM Button
Zooms in during DVD playback. (2×, 3×, 4
×, 1/2 ×, 1/3 ×, 1/4 ×)
L7DUAMM16_IB_160729.indd 9 29/7/2016 4:44 PM

10
13.SOURCE Button
Selects an input source: DVD / AV In /
Media.
14.MUTE Button
Mute or restore the sound output.
15.DISPLAY Button
Display the playtime and shows the status
information on the screen.
16.MENU Button
Enter and exit the main DVD menu.
17.AUDIO Button
Select one of the audio sound tracks on
a DVD (if more than one is available) or
select the audio output mode on a CD.
18. Button
Start/Pause/Resume playback.
19. STOP Button
Stop playing a disc.
20.MODE Button
Press to show the VIDEO SETUP PAGE for
adjusting BRIGHTNESS, CONTRAST, HUE
and COLOUR of the display.
21.VOL + / – Buttons
Adjust the volume.
22. Buttons
Move forward to the next or backward to
the previous titles/chapters/tracks.
23. Buttons
Start fast forward/reverse playback at 5
speed levels (2×, 4×, 8×, 16×, 32×).
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL - VOL +
REPEAT SLOW
PROGRAM ZOOM
13
16
17
19
18
20
22
21
23
14
15
L7DUAMM16_IB_160729.indd 10 29/7/2016 4:44 PM

11
Battery Replacement for the Remote Control
The remote control requires a CR2025, 3V Lithium battery.
1. Slide and hold the battery release tab in the
direction of the arrow.
2. Pull out the battery compartment and remove the
old battery.
3. Replace with a new battery.
4. Insert the battery compartment back into the
remote control.
Removing the Plastic Strips from the Remote
Controls
Remove the plastic strips from the batteries if
the batteries are being used for the rst time. It
is located at the bottom rear side of the remote
controls.
L7DUAMM16_IB_160729.indd 11 29/7/2016 4:44 PM

12
Remote Control Operation Range
Point the remote control at the DVD Player no more than 2
metres from the remote control sensor and within 40° from
the front of the DVD Player. The operating distance may vary
depending on the brightness of the room.
20° 20°
Within about 2 m
STEP SEARCH MUTE SOURCE
1234
5678
9 0 10+
DISPLAY
SUBTITLE ANGLE AUDIO MENU
TITLE
ENTER MODE
SETUP VOL- VOL+
REPEAT SLOW
PROGRAM ZOOM
SETU P EN TER S OURC E
\\VOL+ \
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage,
which could cause re, personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and –) indications in
the battery compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in
accordance with the local regulations.
• Small button cell batteries such as the one used in the remote control are
easily swallowed by young children and this is dangerous. Keep loose button
cells away from young children and make sure that the battery holder tray is
secure in the remote control. Seek medical advice if you believe a cell has been
swallowed.
Handling the Remote Control
• If you are nding it dicult to pull out the battery compartment, use a paper
clip to slide the battery release tab.
• Take care of your ngernails when you slide and pull the battery release tab.
• Do not drop or cause impact on the remote control.
• Do not spill water or liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources of
excessive heat.
• Remove the battery from the remote control when not in use for a long
period of time, as it could cause corrosion or battery leakage and may result in
physical injury and/or property damage including re.
L7DUAMM16_IB_160729.indd 12 29/7/2016 4:44 PM

13
ON OFF AV OUT AV IN DC IN 9-12V
ON OFF AV OUT AV IN DC IN 9-12V
Car Power
Adapter
(included)
To DC IN
9-12V socket To DC IN
9-12V socket
11
DVD player A
left side
DVD player B
left side
To the cigarette
lighter socket
2
In-Car Use
Using the DVD Players A and B Together (in-car use)
To playback on both DVD players A and B together, use the car power adapter (included) to
connect both units to the car’s cigarette lighter socket.
For optimum charging, switch the unit o.
• Before plugging in the car adapter, check the output rating
of your car cigarette lighter.
• The included 12V car power adapter is designed for use with
vehicles that have a 12V negative ground electrical system.
• Before plugging in this car adapter, please check the output rating of your car
cigarette lighter rst.
• Disconnect the car power adapter when not in use. Not for use in 24V vehicles.
• Use the provided 12V car power adapter only. Using other car power adapters
could damage the unit.
• In the interest of trac safety, do not operate this unit or view videos while
driving.
• Make sure the unit is securely fastened to prevent it from falling or ying
through the air in the event of an accident.
• When the inside of the cigarette lighter socket is dirty with ash or dust, the
plug section may become hot due to poor contact. Be sure to clean the
cigarette lighter socket before use.
• After use, disconnect the 12V car power adapter from both the unit and the
cigarette lighter socket.
L7DUAMM16_IB_160729.indd 13 29/7/2016 4:44 PM

14
1. Align the angled support’s bolt to the screw
hole at the back of the DVD unit. Turn the bolt
clockwise and secure the support.
Mounting the DVD in a Car
Use the supplied mounting kit to install the DVD players at the back of the vehicle’s
headrests.
2. For car headrests which can be removed, use the following method:
Lift the headrest o its leg supports. Align the horizontal support bar with the headrest
leg slots and ensure the horizontal support bar rests securely on top of the car seat. Re-
attach the headrest.
Headrest
Support
Leg
support
Horizontal
support bar
Horizontal
support bar
3. For car headrests which cannot be removed, use the following method to secure the car
mount:
Unscrew the bolts holding the horizontal support bar together. Slip both halves of the
support bar around the headrests’ leg supports. Screw in the bolts, loosely. Ensure that
the support bar is level. Tighten the bolts.
If the set of 4 × screws (ø4 × 20mm) is not long enough to secure the horizontal
support bar to leg supports, please use the longer set of screws (ø4 × 25mm).
L7DUAMM16_IB_160729.indd 14 29/7/2016 4:44 PM

15
Installation Guide Mounting Kits
(hidden by DVD units)
1 2 34
56 7 8
9 0 10+
REPEAT
TITLE
SUBTITLE
AUDIO
MUTE
SOURCE
STEP
DISPLAY
MENU
VOL+VOL-
SLOW
ZOOM
B
1 2 34
56 7 8
9 0 10+
REPEAT
TITLE
SUBTITLE
AUDIO
MUTE
SOURCE
STEP
DISPLAY
MENU
VOL+VOL-
SLOW
ZOOM
A
SETUP ENT ER SOURCE
\\VOL+\ SETUP ENTER SOURC E
\\VOL+\
DVD Player A DVD Player B
Car Power
Adapter
Remote Control BRemote Control A
6. To remove the DVD from the horizontal support
bar, support the DVD unit with one hand. Firmly
squeeze and pull the release button on either
side of the angled support with the other hand.
4. Grip the DVD rmly with both hands and slot the
angled support rmly into the support bar. It will
click. Ensure the entire unit is secure.
5. Adjust the angle of the DVD unit, then secure by
tightening the bolt to the right.
• This unit should never be used by the vehicle’s driver or left unsecured in the
vehicle while driving.
• If this unit is being used in your vehicle, be sure that it is securely xed to the
headrests’ leg supports or held safely, and does not obstruct any safety device,
including air bags or seat belts, or it may cause injury in case of accidents.
Ensure all rear passengers are correctly restrained when this product is in use
in the car.
• All passengers should always wear seat belts when using this unit in a moving
vehicle.
• If in doubt, please contact your vehicle manufacturer for further advice.
L7DUAMM16_IB_160729.indd 15 29/7/2016 4:44 PM

16
Using the DVD Players A and B Indoors
Using the Mains Adapter (for indoor use)
The two mains adapters (DC9V, 1A output) supplied are for using and charging the DVD
players A and B.
Using the DVD Player A and B with Separate Mains Adapter
First Mains Adapter
(included)
Second Mains
Adapter (included)
To the mains
socket
To the mains
socket
2
2
ON OFF AV OUT AV IN DC IN 9-12V ON OFF AV OUT AV IN DC IN 9-12V
DVD player B
left side
DVD player A
left side
To DC IN 9-12V
socket
To DC IN 9-12V
socket
1
1
• Turn o the unit before unplugging the mains adapter from the unit to avoid
damaging the unit.
• When the unit will not be used for a long period of time, disconnect the mains
adapter from the mains socket.
• The mains socket must be located near the unit and should be easily
accessible. If a malfunction occurs, disconnect the plug from the mains socket
at once.
• When the mains adapter is plugged in, the unit is not completely disconnected
from the main power source even when the unit is turned o.
L7DUAMM16_IB_160729.indd 16 29/7/2016 4:44 PM

17
Connections
Watching a DVD on DVD Player A and B
You can watch the same DVD on DVD player A and B at the same time.
1. Connect DVD player A and B by using the included 3.5mm to 3.5mm Stereo Audio Cable
(included). Plug the 3.5mm to 3.5mm Stereo Audio Cable into AV OUT socket on the
DVD player in which the DVD is inserted; plug the other end of the 3.5mm to 3.5mm
Stereo Audio Cable into AV IN socket of the other DVD player.
2. Turn on DVD player A with DVD inserted.
3. Turn on DVD player B and then press SOURCE button. Press the button to select AV
IN, and then press ENTER to conrm.
4. Operate the controls of the DVD player in which the DVD is inserted.
ON OFF AV OUT AV IN DC IN 9-12V
DVD player B
left side
DVD player A
left side
(DVD inserted)
Charging the battery
1. Connect with mains adapter or car power adapter.
2. The charging indicator ashes when the battery is in charging mode. When the battery
is charged to full capacity, the LED indicator lights up.
3. Remove the adapter. The battery is now fully charged and the unit is ready to use.
* Battery Operation time from fully
charged battery = Approx. 2 hours
ON OFF AV OUT AV IN DC IN 9-12V
• The battery is partially charged at shipment. We suggest that for rst time use
fully charge the battery. It may take up to 4 hours to fully charge the battery.
• Every time you see the Low battery indication on the screen, connect your
mains adapter to the unit and the mains socket. The battery will now start to
recharge.
• The battery will charge slower when the DVD player is in use.
• It is recommended to turn o the power while the battery is charging.
3.5mm to 3.5mm Stereo
Audio Cable (included)
L7DUAMM16_IB_160729.indd 17 29/7/2016 4:44 PM

18
Connecting to a Stereo Receiver or Amplier
The DVD player can play two channels Dolby Digital.
Stereo Receiver
/ Amplier
ON OFF AV OUT AV IN DC IN 9-12V
ON OFF AV OUT AV IN DC IN 9-12V
DVD player
left side
3.5mm to RCA AV
Converter
(not included)
RCA stereo
audio Cable
(not included)
Red White
YellowRedWhite
DO NOT CONNECT
To AV OUT
socket
Connecting to a TV
If your TV has Audio/Video inputs, you can connect the DVD player to your TV by using a
standard AV cable (not included).
Watching a DVD on your TV
1. Connect your TV to the DVD player by using a 3.5mm to RCA AV Converter and a
standard AV Cable (not included).
2. Turn on the DVD player.
3. Turn on the TV and follow the instructions included with it to play the DVD.
DVD player
left side
3.5mm to RCA
AV Converter
(not included)
To AV OUT
socket
RCA AV Cable
(not included)
TV
Yellow Red White
YellowRedWhite
• Make sure the correct Audio/Video cable is used. Connecting the plugs
incorrectly may cause a weak signal.
• If your TV does not have Audio/Video inputs, you will need to purchase an
RF modulator (sold separately) and follow the instructions included with it to
connect the unit to your TV.
L7DUAMM16_IB_160729.indd 18 29/7/2016 4:44 PM

19
Using Earphones
Turn down the volume before connecting the headphones/earphones. Slowly raise
the volume of the headphones/earphones until you reach your desired volume. When
headphones/ earphones are connected, the speaker is automatically disabled.
DVD player
left side
Earphones
ON OFF AV OUT AV IN DC IN 9-12V
Long-term exposure to loud music
may cause hearing damage. It
is best to avoid extreme volume
when using earphones, especially
for extended periods of time.
EARPHONES VOLUME WARNING
Maximum output voltage < 150mV
L7DUAMM16_IB_160729.indd 19 29/7/2016 4:44 PM

20
ON OFF AV OUT AV IN DC IN 9-12V
Using The Stand For Indoor Use
You can stand the DVD player on a desk or table by using the stand.
ON OFF AV OUT AV IN DC IN 9-12V
DVD player
left side
Using a USB Device
You can play or view picture les (JPEG) or music les (MP3) from a USB device.
1. Connect the USB device directly to the USB slot on the DVD player.
DVD player
left side view
2. Press the SOURCE button to access the data in the drive.
3. Use the button to select “Media“.
4. Press the button, and then press the button to highlight “USB” depending on the
type of device you have connected and then press the ENTER button to start playback.
5. To remove the USB device, press the button on the remote control to stop playback
and then press the SOURCE button followed by the ENTER button to exit the USB
menu. The DVD player will return to disc mode.
L7DUAMM16_IB_160729.indd 20 29/7/2016 4:44 PM
