Toshiba SD-P2600 User manual

PORTABLE DVD PLAYER
SD-P2600
OWNER’S MANUAL
GX1C00025310
2
19
43
51
65
N-2-2 Ultra + NHP
Introduction
Function setup
Basic playback
Advanced
playback
Quick control
VIDEO
/
AUDIO
S
© 2003 TOSHIBA CORPORATION
77
Connections
89
Others
DIGITAL VIDEO
TM
Downloaded From Disc-Player.com Toshiba Manuals

2
Introduction
SAFETY PRECAUTIONS
CAUTION: This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
FCC NOTICE “Declaration of Conformity Information”
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
WARNING: Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
CLASS 1 LASER PRODUCT
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
ADDITIONAL SAFETY INSTRUCTIONS
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
“
”
’
’
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
On handling discs
On cleaning discs
On storing discs
Yes
No NoNo
Yes No
Structure of disc contents
“ ” “ ” “
” “ ”
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes on region numbers
1
ALL
On VIDEO CDs
•
•
’
About this owner’s manual
’
“”
“”
Playable discs
•
•
•
“ ”
93
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
Audio
CDs
DVD
audio
discs
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
’
’
On disposal
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Main unit
20
17
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
27
22
–
66
66
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
+10 T
–
–
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
24
24
–
66
66
28
Remote control
“ ”
27
“ ”
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
1
2
3
85
Caution
•
•
•
•
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
CAUTION
•
•
•
•
Basic playback
1
2
3
Turn on the power.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select “ ” and
press the ENTER button.
Open the disc cover.
Set a disc.
Close the disc cover.
Preparations
•
18 85
•
•
•
17
• “
”
80
4
2
1
5
4
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
–
Basic playback (continued)
To pause playback (still mode)
PAUSE/STEP
PLAY
•
To stop playback
STOP
To turn off the power
POWER
To remove the disc
CAUTION
To change LCD brightness
DIMMER
Note
To adjust the volume of the speakers or the
connected headphones
VOLUME + VOLUME –.
–
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Still pictures included on DVD audio discs
•
•
PAGE SHIFT
Basic playback (continued)
–
–
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
PLAY
Notes
•
•
•
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
Press PLAY.
1
2
PLAY
•
Notes
• ’
–
72
70
– “ ”
“ ”
74
•
•
DVD-V
DVD-A
CD
VCD
To start playback from the beginning regardless
of the location where you stopped playback
STOP
’
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
Press / to select a section you want
to locate.
Press / to enter a number of the
section.
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
1
2
3
Notes
•
•
Playing bonus groups of DVD audio discs
“ ”
number buttons
ENTER
Notes
•
•
T
DVD-V
4
5
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
To stop playback, press STOP.
1
2
3
To pause playback
PAUSE/STEP
Selecting a track (file name) in the disc
3
Notes
•
•
• “ ”
69
•
•
29 55 56
Preparation
•
31
• “ ” “ ”
74
Downloaded From Disc-Player.com Toshiba Manuals

3
Introduction
Location of the required label
P2600
3A
Downloaded From Disc-Player.com Toshiba Manuals
5
Introduction
22.When you use this product in an airplane,
follow the instructions of the airline.
Disregarding them may cause harmful
interference to radio communication.
23.Do not look close to the pick-up lens or stare
into laser beam. Doing so may cause damage
to eyesight.
24.Do not use this product while walking or
driving. Neglecting this may cause a traffic
accident.
25.Should the LCD monitor be broken and liquid
leaks out, do not inhale or swallow it. Doing so
may cause poisoning.
If you have got it into your mouth, wash it out
and consult your doctor. If your hands or
clothes have touched it, wipe them with
alcohol and a cleaning cloth and then wash
them well.
26.Do not allow children to scratch, lick or put the
memory card into their mouth.
Keep the memory card out of the reach of
children. Injury to the child or malfunction may
result.
27.Battery Pack
a) Never throw the battery pack into a fire, as that
could cause the battery pack to explode.
Never heat the battery pack, as that could
cause leakage of alkaline solution or other
electrolytic substance.
b) Never disassemble the battery pack, as that
could cause leakage of alkaline solution or
other electrolytic substance.
c) Never short-circuit the battery pack by either
accidentally or intentionally bringing the
terminals in contact with another metal object.
This could cause personal injury or a fire, and
could also damage the battery pack.
d) Never drive a nail into the battery pack.
Never strike the battery pack with a hammer.
Never step or tread on the battery pack.
e) If you ever detect the emission of an
extraordinary odor, excessive heat,
discoloration, or deformation of the battery
pack, remove it from the player after confirming
safety, and discontinue use of it. Take the
battery pack to an authorized Toshiba service
provider.
f) Keep the battery pack away from heat or fire, if
you detect the emission of an extraordinary
odor or leakage of alkaline solution or other
electrolytic substance.
g) Never dispose of used battery packs with other
ordinary solid wastes, since they contain toxic
substances. Always dispose of used battery
packs in accordance with community
regulations that apply to the disposal of
batteries. Cover the metal terminals with
insulating tape, in order to prevent accidental
short-circuiting.
h) Always confirm that the battery pack is
compatible with your player, before attaching
the battery pack to the player.
i) Never expose the terminals of the battery pack
to any other metal object. Wrap the battery or
place it in a protective plastic bag, whenever
transporting it.
j) Always confirm that the temperature is
between 5 and 35 C (41 F and 95 F) before
you charge the battery. Leakage, excessive
heat, or deterioration of the battery pack may
occur if this warning is not heeded.
k) Never immerse the battery pack in any liquid.
l) Never expose the battery pack to direct
sunlight. Never store or use the battery pack in
a locked and unventilated vehicle. (where
excessive internal temperatures may be
encountered.)
m) Always keep the battery pack out of reach of
infants or small children.
n) Never shock the battery pack by dropping or
throwing it.
o) If the liquid contained within the battery pack
leaks, use a large amount of water and
immediately wash off any liquid which may
accidentally contact any part of the body.
Remove any liquid that has contacted your
clothing by washing it immediately with a
detergent.
p) Always confirm that a click sound has
resulted, when attaching the battery pack to
the player. This sound confirms that the
battery pack has been properly attached.
28.Coin-shaped Battery
a) Keep coin-shaped batteries out of children s
reach. Be careful not to ingest internally,
especially by children, as doing so may cause
poisoning.
b) Do not load a battery into the remote control
with the wrong side out.
c) Do not charge, heat, open, or short-circuit the
batteries. Do not throw the batteries into a
fire.
Downloaded From Disc-Player.com Toshiba Manuals

2
Introduction
SAFETY PRECAUTIONS
CAUTION:
FCC NOTICE “Declaration of Conformity Information”
WARNING:
CAUTION:
WARNING:
Wash hands after handling
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN .
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called title number , chapter number , group
number or track number respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner s manual may not
work with all discs.
About this owner’s manual
This owner s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
may appear on the screen during operation.
A means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
You cannot play discs other than those listed above.
You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
How to Obtain Service
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( /+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in Locating a title using the top menu.
27
*buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
Be careful not to catch your fingers in the disc holder.
Do not use a cracked, deformed, or repaired disc.
Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select “ ” and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
Connect the AC adapter
18
or the battery pack
85
to the
player.
When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
If you use the supplied remote control, make sure that
batteries are loaded in it.
17
If you use the headphones, see Connecting to
Headphones .
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME –.
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE /
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
The sound is muted during slow-motion playback.
The playback speed may differ depending on the disc.
When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
The player s memory is also cleared when:
you change the parental lock setting
72
or select a disc
menu language
70
.
you use a PBC-featured VIDEO CD while PBC is set to
On
74
.
There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called Bonus group .
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
Some discs may not permit this operation.
WMA tracks copy-protected cannot be played.
The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current Audio Out Select
selection.
69
If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
Make sure that a disc you want to play is compatible with this player.
31
Set Priority Contents 2 to Audio from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

3
Introduction
Location of the required label
P2600
3A
Downloaded From Disc-Player.com Toshiba Manuals
5
Introduction
22.When you use this product in an airplane,
follow the instructions of the airline.
Disregarding them may cause harmful
interference to radio communication.
23.Do not look close to the pick-up lens or stare
into laser beam. Doing so may cause damage
to eyesight.
24.Do not use this product while walking or
driving. Neglecting this may cause a traffic
accident.
25.Should the LCD monitor be broken and liquid
leaks out, do not inhale or swallow it. Doing so
may cause poisoning.
If you have got it into your mouth, wash it out
and consult your doctor. If your hands or
clothes have touched it, wipe them with
alcohol and a cleaning cloth and then wash
them well.
26.Do not allow children to scratch, lick or put the
memory card into their mouth.
Keep the memory card out of the reach of
children. Injury to the child or malfunction may
result.
27.Battery Pack
a) Never throw the battery pack into a fire, as that
could cause the battery pack to explode.
Never heat the battery pack, as that could
cause leakage of alkaline solution or other
electrolytic substance.
b) Never disassemble the battery pack, as that
could cause leakage of alkaline solution or
other electrolytic substance.
c) Never short-circuit the battery pack by either
accidentally or intentionally bringing the
terminals in contact with another metal object.
This could cause personal injury or a fire, and
could also damage the battery pack.
d) Never drive a nail into the battery pack.
Never strike the battery pack with a hammer.
Never step or tread on the battery pack.
e) If you ever detect the emission of an
extraordinary odor, excessive heat,
discoloration, or deformation of the battery
pack, remove it from the player after confirming
safety, and discontinue use of it. Take the
battery pack to an authorized Toshiba service
provider.
f) Keep the battery pack away from heat or fire, if
you detect the emission of an extraordinary
odor or leakage of alkaline solution or other
electrolytic substance.
g) Never dispose of used battery packs with other
ordinary solid wastes, since they contain toxic
substances. Always dispose of used battery
packs in accordance with community
regulations that apply to the disposal of
batteries. Cover the metal terminals with
insulating tape, in order to prevent accidental
short-circuiting.
h) Always confirm that the battery pack is
compatible with your player, before attaching
the battery pack to the player.
i) Never expose the terminals of the battery pack
to any other metal object. Wrap the battery or
place it in a protective plastic bag, whenever
transporting it.
j) Always confirm that the temperature is
between 5 and 35°C (41°F and 95°F) before
you charge the battery. Leakage, excessive
heat, or deterioration of the battery pack may
occur if this warning is not heeded.
k) Never immerse the battery pack in any liquid.
l) Never expose the battery pack to direct
sunlight. Never store or use the battery pack in
a locked and unventilated vehicle. (where
excessive internal temperatures may be
encountered.)
m) Always keep the battery pack out of reach of
infants or small children.
n) Never shock the battery pack by dropping or
throwing it.
o) If the liquid contained within the battery pack
leaks, use a large amount of water and
immediately wash off any liquid which may
accidentally contact any part of the body.
Remove any liquid that has contacted your
clothing by washing it immediately with a
detergent.
p) Always confirm that a “click”sound has
resulted, when attaching the battery pack to
the player. This sound confirms that the
battery pack has been properly attached.
28.Coin-shaped Battery
a) Keep coin-shaped batteries out of children’s
reach. Be careful not to ingest internally,
especially by children, as doing so may cause
poisoning.
b) Do not load a battery into the remote control
with the wrong side out.
c) Do not charge, heat, open, or short-circuit the
batteries. Do not throw the batteries into a
fire.
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

7
Introduction
Notes on handling
Do not shock the LCD monitor. It may cause unit
damage and malfunction.
Do not use the player in a place subject to vibration.
Neglecting this may cause malfunction of the player
or damage to the disc.
Do not leave the player in a vehicle. Rise or drop in
temperature may result in malfunction of the player.
When transporting the player, the original shipping
carton and packing materials come in handy. For
maximum protection, repack the unit as it was
originally packaged at the factory.
Do not use volatile liquids, such as insect spray, near
the player. Do not leave rubber or plastic products in
contact with the player for a long time. They will leave
marks on the finish.
The player may become warm after a long period of
use. This is not a malfunction.
When the player is not in use, be sure to remove the
disc and turn off the power.
If you do not use the player for a long period, the unit
may not function properly in the future. Turn on and
use the player occasionally.
Notes on locating
When you place this player near a TV, radio, or VCR,
the playback picture may become poor and the sound
may be distorted. In this case, move the player away
from the TV, radio, or VCR.
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe
it dry.
Do not use any type of solvent, such as thinner and
benzine, as they may damage the surface of the
player.
If you use a chemical saturated cloth to clean the unit,
follow that product’s instructions.
When cleaning the LCD monitor, use a soft, dry cloth.
To obtain a clear picture
The player is a high technology, precision device. If the
optical pick-up lens and disc drive parts are dirty or worn
down, the picture quality becomes poor. To obtain a
clear picture, we recommend regular inspection and
maintenance (cleaning or parts replacement) every
1,000 hours of use depending on the operating
environment. For details, contact your nearest dealer.
Precautions
Notes on moisture condensation
Moisture condensation damages the player. Please
read the following carefully.
Moisture condensation occurs, for example, when you
pour a cold drink into a glass on a warm day. Drops of
water form on the outside of the glass. In the same way,
moisture may condense on the optical pick-up lens
inside this unit, one of the most crucial internal parts of
the player.
Moisture condensation occurs during the
following cases.
When you transport the player directly from a cold
place to a warm place.
When you use the player in a room where you just
turned on the heater, or a place where the cold air
from the air conditioner directly hits the unit.
In summer, when you use the player in a hot and
humid place just after you move the unit from an air
conditioned room.
When you use the player in a humid place.
Do not use the player when moisture
condensation may occur.
If you use the player in such a situation, it may
damage discs and internal parts. Remove the disc,
connect the AC adapter, turn on the player, and leave
it for two or three hours. After two or three hours, the
player will have warmed up and evaporated any
moisture.
E
x
a
m
p
l
e
o
f
m
o
i
s
t
u
r
e
c
o
n
d
e
n
s
a
t
i
o
n
!
Optical pick-up
lens
It’s too
warm!
Wait!
Wall outlet
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

9
Introduction
Notes on copyright
It is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public, and rent copyrighted
material without permission.
DVD video discs are copy protected, and any recordings
made from these discs will be distorted.
This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Downloaded From Disc-Player.com Toshiba Manuals

2
Introduction
SAFETY PRECAUTIONS
CAUTION: This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
FCC NOTICE “Declaration of Conformity Information”
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
WARNING: Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner’s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select “ ” and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME –.
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

11
Introduction
Playable memory cards
This player can play the following memory cards.
•SDTM is a trademark.
Notes on memory cards
Memory cards available for this player are MMC and
SD
TM
Memory Card.
Some memory cards may not be played back due to its
capacity and/or manufacturer, etc.
Other memory cards are not supported. Do not insert
any cards apart from MMC/SDTM Memory Card as this
may cause a malfunction of the player or cards.
* MMC is a MultiMediaCard.
Saving data
It is recommended that you copy and backup any and
all important information to a disk (MO disk, floppy
disk, hard disk, etc.)
Recorded data may be lost or damaged in the below
cases. Toshiba Corporation accepts no responsibility
whatsoever for lost or damaged data.
•You or a third party does not use the memory card
correctly.
•The memory card incurs damage from static
electricity or electrical interference.
•The memory card is ejected while in use.
Card Mark Contents
SD
Memory
Card
Multi
Media
Card
Photograph
(JPEG files)
Cautions for use
Ensure that you insert the memory card correctly into
this player.
Do not eject the memory card while it is in use. If
ejected while in use information on the memory card
may be lost.
This memory card is a precision electrical instrument.
Do not bend, drop or apply strong force to it.
Do not use or store the memory card in an environment
of high static electricity or electrical interference.
Avoid using or storing in areas of high temperature and
humidity.
Be careful not to touch with your fingers, nor allow
foreign objects to come in contact with nor dirt to
accumulate on the metal area (gold-colored area) of the
memory card. Wipe off any dirt with a soft, dry cloth.
When carrying or storing the memory card always place
it inside of its antistatic case to avoid any effects from
static electricity. If there is a storage case, place the
memory card in the antistatic area of the storage case.
If you place a memory card that has been exposed to
static electricity in this player, there is a chance that this
player could malfunction.
Do not place the memory card in your pants pocket. The
memory card may break if any strong force is applied,
such as when sitting.
When ejecting the memory card after extended use it
may feel warm to the touch. This is normal. The memory
card is not malfunctioning.
The memory card is designed to have a long life but
after extended use you will not be able to delete from or
write to it. Please purchase another.
Write Protection of SD Memory Card
Switch the write protect tab at the side of the SD card to
“LOCK”.
Write protection
state
Write protection
tab
LOCK LOCK
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

13
Introduction
Introduction
SAFETY PRECAUTIONS .......................... 2
IMPORTANT SAFETY INSTRUCTIONS ... 4
Precautions ............................................... 7
Notes and Information ............................. 8
Notes on region numbers ............................... 10
Table of Contents ................................... 13
Identification of Controls ....................... 14
Main unit ......................................................... 14
Side view ........................................................ 15
Rear view........................................................ 15
Remote control ............................................... 16
Loading a battery ............................................ 17
Operating with the remote control .................. 17
Power Connection .................................. 18
Basic playback
Playing a Disc ......................................... 20
Basic playback ................................................ 20
Variable Speed Playback ....................... 25
Playing in fast reverse or fast forward directions ... 25
Playing frame by frame ................................... 25
Playing in slow-motion .................................... 26
Resuming playback from the stopped location .. 26
Locating a Specific Title, Chapter, or
Track ........................................................ 27
Locating a title using the top menu ................. 27
Locating a desired section by entering its
corresponding number ................................. 28
Locating a specific chapter or track ................ 29
Playing MP3/WMA Files ......................... 30
Playing MP3/WMA files .................................. 30
Viewing JPEG Files
- Digital Photo Viewer - .......................... 32
Viewing JPEG files ......................................... 33
Photo Album ................................................... 34
Photo View ..................................................... 35
Slide Show ..................................................... 38
Advanced playback
Accessing a Specific Location Directly .. 44
Entering the time counter of the desired location ... 44
Zooming a Picture .................................. 45
Zooming a picture ........................................... 45
Selecting a Camera Angle...................... 46
Changing the camera angle ........................... 46
Selecting Subtitles ................................. 47
Selecting a subtitle language ......................... 47
Selecting a Language............................. 48
Selecting a playback audio setting ................. 48
Quick control
Using the Virtual Remote Control
- V-REMOTE - .......................................... 52
Using the virtual remote control ..................... 52
Selecting the Playback Function
- QUICK - .................................................. 53
Selecting the playback function ...................... 53
Playing in the selected mode.......................... 54
Accessing Features
- NAVI - ..................................................... 58
NAVI menu items ............................................ 58
Function setup
Customizing the Function Settings ...... 66
Setting procedure ........................................... 66
Setting details ................................................. 68
Table of Languages ................................ 75
Table of languages and their abbreviations .... 75
Connections
Connecting to a TV ................................. 78
Connecting to Headphones ................... 80
Viewing Pictures from Connected
Video Equipment .................................... 80
Connecting to Audio Equipment ........... 81
Connecting to an amplifier equipped with a
Dolby Digital decoder ................................... 82
Connecting to an amplifier equipped with
Dolby Surround Pro Logic ............................ 82
Connecting to an amplifier equipped with a
DTS decoder ................................................ 83
Connecting to an amplifier equipped with an
MPEG2 audio decoder ................................. 83
Connecting to an amplifier equipped with a
digital audio input ......................................... 84
Using the Battery Pack........................... 85
Using the automobile/vehicle adapter
or power port .......................................... 87
Others
Before Calling Service Personnel ......... 90
Specifications ......................................... 91
LIMITED WARRANTY PORTABLE DVD
PLAYER ................................................... 92
Table of Contents
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

15
Introduction
Side view
Rear view
80
80
Headphone jack 1
Headphone jack 2
AV IN AV OUT
S VIDEO
BITSTREAM/PCM
COMPONENT VIDEO
DC IN 12V
78
S VIDEO jack
18
DC IN jack
79
COMPONENT VIDEO
connector
78
AV OUT jack
8382 84
BITSTREAM/PCM jack
80
AV IN jack
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

17
Introduction
While pushing the holder in direction
1, simultaneously slide it out in
direction 2.
Place a coin-shaped battery (CR2025)
with the side up on the holder.
Keep the holder horizontal so that the battery
does not fall through.
Push the holder back into its
receptacle.
Notes on coin-shaped batteries
•If the remote control does not function correctly or if the
operating range becomes reduced, replace the battery
with new one.
•See
6
for safety use of coin-shaped batteries.
•Inserting a battery other than the specified one or an
object may damage the remote control.
1
Operating with the remote control
Point the remote control at the remote
sensor and press the buttons.
Distance: About 3 m (9.9 feet) from the front of the
remote sensor
Angle: About 30°in each direction of the front of
the remote sensor
* Do not expose the remote sensor of the player to a
strong light source such as direct sunlight or other
illumination. If you do so, you may not be able to
operate the player via the remote control.
Notes on the remote control
•Direct the remote control at the remote sensor of the
player.
•Do not drop or give the remote control a shock.
•Do not leave the remote control near an extremely hot or
humid place.
•Do not spill water or put anything wet on the remote
control.
•Do not disassemble the remote control.
2
3
Loading a battery
Backside
Backside
1
2
CR2025
3V
C
R
2
0
2
5
3V
Within about 3 m (9.9 feet)
30°
30°
Downloaded From Disc-Player.com Toshiba Manuals

This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME .
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals

Basic playback
Begin your operation.
Playing a Disc
Variable Speed Playback
Locating a Specific Title,
Chapter, or Track
Playing MP3/WMA Files
Viewing JPEG Files
- Digital Photo Viewer -
About this manual
•The numbers indicated by lines on the illustrations
correspond to the associated steps of the operation.
•Aside from the section “Playing a Disc”, explanations
of operations only include illustrations of the
corresponding buttons on the remote control. The
buttons sharing the same name on the main unit can
also be used in the identical manner.
Downloaded From Disc-Player.com Toshiba Manuals
Advanced playback
Customizing the performance of your player.
Accessing a Specific Location
Directly
Zooming a Picture
Selecting a Camera Angle
Selecting Subtitles
Selecting a Language
Downloaded From Disc-Player.com Toshiba Manuals
Quick control
Simple use of a single button and the cursor control
enables you to direct your playback, without manipulating
many actual buttons.
Using the Virtual Remote
Control - V-REMOTE -
Selecting the Playback Function
- QUICK -
Accessing Features
- NAVI -
Downloaded From Disc-Player.com Toshiba Manuals
Function setup
You can change the default settings to customize
performance to your preference.
Customizing the Function
Settings
Table of Languages
Downloaded From Disc-Player.com Toshiba Manuals
Connections
You can connect the player to a TV or audio system.
Also, you can connect a battery pack to power the
player.
Connecting to a TV
Connecting to Headphones
Viewing Pictures from
Connected Video Equipment
Connecting to Audio Equipment
Using the Battery Pack
Using the automobile/vehicle
adapter or power port
Downloaded From Disc-Player.com Toshiba Manuals
Others
Before Calling Service
Personnel
Specifications
LIMITED WARRANTY
PORTABLE DVD PLAYER

2
Introduction
SAFETY PRECAUTIONS
CAUTION: This equipment employs a Laser System.
To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
FCC NOTICE “Declaration of Conformity Information”
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING: Only peripherals complying with the FCC class B limits may be attached to this equipment.
Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to
result in interference to radio and TV reception.
Changes or modifications made to this equipment, not expressly approved by Toshiba, or parties
authorized by Toshiba, could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock do not perform any servicing other than that contained in the operating
instructions unless you are qualified to do so.
WARNING: Handling the cord on this product or cords associated with accessories sold with this product,
will expose you to lead, a chemical known to the State of California to cause birth defects or
other reproductive harm.
Wash hands after handling .
In the spaces provided below, record the Model and Serial No. located on the bottom of your player.
Model No. Serial No.
Retain this information for future reference.
Downloaded From Disc-Player.com Toshiba Manuals
4
Introduction
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER’S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
FUTURE REFERENCE.
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
8. Do not insert any foreign objects into the
memory card slot. Heat build-up or fire may
result.
9. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
10.Only use attachments/accessories specified by
the manufacturer.
11.Unplug this apparatus during lightning storms
or when unused for long periods of time.
However, while it is thundering or lightning, do
not touch the apparatus and any connected cable
and/or equipment. This will prevent you from
receiving the electric shock by an electric surge.
12.Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally, or has been dropped.
ADDITIONAL SAFETY INSTRUCTIONS
13.When you use headphones, keep the volume
at a moderate level. If you use the headphones
continuously with high volume sound, it may
cause hearing damaged.
14.Do not overload wall outlets; extension cords,
or integral convenience receptacles as this can
result in a risk of fire or electric shock.
15.Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids,
such as vases, shall be placed on the
apparatus and/or around it.
16.Be careful not to catch your fingers in the disc
holder when closing the lid. It may cause
personal injury.
17.Do not put a vessel containing liquid such as a
vase, or a metal object on the apparatus. If
liquid or a foreign metal object is let into the
apparatus, it may cause fires or electric shock.
18.Do not use a cracked, deformed, or repaired
disc. These discs are easily broken and may
cause serious personal injury and apparatus
malfunction.
19.Do not touch a spinning disc. When you open
the disc holder, the disc may have not stopped
spinning. Touching a spinning disc may cause
personal injury or damage to the product.
20.Do not rest the product on your lap or other
parts of body, as it may become heated. Even
low temperature may cause inflaming or
blistering, if touched for a prolonged period.
21.Use the supplied AC adapter to operate the
product. Substitute devices not specified by the
manufacturer may result in fire or product
malfunction. Do not cover the AC adapter with
a blanket or place it near heating or on electric
carpet when it is in use.
Downloaded From Disc-Player.com Toshiba Manuals
6
Introduction
IMPORTANT SAFETY INSTRUCTIONS
d) Do not leave a dead or exhausted battery in
the remote control.
e) If you do not use the remote control for a long
period of time, remove the battery to avoid
possible damage from battery corrosion.
29.After unpacking coin-shaped batteries, store them
in poly bags, etc. separately one by one when
unused. If you leave them unwrapped, they may
be short-circuited by contact with metal objects,
resulting in battery leakage, heat or bursting.This
may cause burns or injury.
The batteries must be completely discharged
when they are deposited in collection containers
for old batteries. If a charge remains,
countermeasures to prevent short circuits must
be taken.
30.To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
31.Following mark means “CAUTION - RISK OF
ELECTRIC SHOCK - DO NOT OPEN”.
32. Vehicle adapter and operation in a car
a) NEVER operate the apparatus or view a DVD
Video while operating an automobile or other
vehicle. Note: doing so is illegal in many
jurisdictions.
NEVER place a apparatus within the eyesight
of a driver while he/she is driving an
automobile/vehicle. Note: an apparatus
located in the front seating section of a vehicle
is illegal in many jurisdictions.
Failure to observe the above instructions
could result in the driver’s inattention to and/
or distraction from road hazards.
b) NEVER place an apparatus in a location
where it could interfere with the proper
deployment and/or performance of an air bag.
Failure to observe this instruction could result
in the prevention of an air bag to properly and/
or effectively deploy.
c) Do not use a vehicle adapter other than the
model supplied, to power the apparatus. Do
not use the supplied vehicle adapter to power
an apparatus other than this apparatus.
Neglecting these may cause smoke, fire or
electrical shock to human body.
d) This adapter is intended for exclusive use in
automobiles/vehicles with a DC 12V negative
ground electrical system.
NEVER use this adapter with a DC 24V
configured automobile/vehicle.
Consult your vehicle owner’s manual before
using this adapter.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
e) When handling, using or storing the adapter
power cord NEVER:
- Place or locate near any apparatus that
produces heat.
- Disassemble, splice or extend the cord.
- Pull, force or place any heavy objects on the
cord.
- Bend, twist or bind the cord.
f) Keep away from the driving device (such as
brake pedal, etc.) and the moving equipment
(such as a seat rail, car windows, door, etc.).
g) NEVER disassemble or alter this adapter in any
manner.
h) ALWAYS use caution when touching the
adapter, cigarette lighter socket or power port.
The adapter, lighter socket and power port may
become heated after prolonged use.
i) ALWAYS remove the adapter from the cigarette
lighter socket or power port when not in use.
j) Do not charge the battery pack which is
attached to the apparatus by the adapter. Doing
so may cause smoke, fire or electrical shock to
human body. Whenever you use the adapter,
be sure to remove the battery pack from the
apparatus to prevent it from being charged by
the adapter.
k) Some cars may not have a compatible socket.
NEVER modify this adapter to fit an
incompatible cigarette lighter socket and/or
power port. NEVER modify an incompatible
cigarette lighter socket and/or power port to
accept this adapter.
Failure to observe the above warnings could
cause smoke, fire, burns and/or electric shock.
l) ALWAYS locate the apparatus on a level and
secure surface. If placed on an uneven, shaky,
unsecured or unstable surface, apparatus may
fall.
Failure to observe the above warning could
result in the apparatus striking a person.
m) When using the adapter, insert the plug of the
adapter into the cigarette lighter socket or power
port fully.
The incomplete insertion will cause smoke or
fire.
n) Do not touch the adapter with wet hands. Do
not liquid over the adapter.
Downloaded From Disc-Player.com Toshiba Manuals
8
Introduction
Notes and Information
On handling discs
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
On cleaning discs
Fingerprints and dust on the disc may cause picture
and sound deterioration. Wipe the disc from the
center outwards with a soft cloth. Always keep the
disc clean.
If you cannot wipe off the dust with a soft cloth, wipe
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth.
Do not use any type of solvent such as thinner,
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc.
On storing discs
Do not store discs in a place subject to direct sunlight
or near heat sources.
Do not store discs in places subject to moisture and
dust such as a bathroom or near a humidifier.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
warping.
Playback side
Yes
No NoNo
Yes No
Group 1
Structure of disc contents
Normally, DVD video discs are divided into titles, and the
titles are sub-divided into chapters. DVD audio discs are
divided into groups, and the groups are sub-divided into
tracks. VIDEO CDs/audio CDs are divided into tracks.
Each title, chapter, group, or track is assigned a number,
which is called “title number”, “chapter number”, “group
number”or “track number”respectively.
There may be discs that do not have these numbers.
Group 2
Title 2
DVD video disc
Title 1
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Track 1 Track 2 Track 1 Track 2 Track 3
DVD audio disc
Track 1 Track 2 Track 3 Track 4 Track 5
VIDEO CD/Audio CD
Downloaded From Disc-Player.com Toshiba Manuals
10
Introduction
Notes and Information (continued)
Notes on region numbers
The region number of this player is 1. Region numbers,
corresponding to specific geographical playback area,
are printed on your DVD video disc. If you do not find
1or
ALL
, disc playback will not be allowed by the
player. (In this case, the player will display a message
on-screen.)
On VIDEO CDs
This player supports VIDEO CDs equipped with the PBC
(Version 2.0) function. (PBC is an abbreviation for
Playback Control.)
You can enjoy two playback variations depending on
types of discs.
•VIDEO CD not equipped with PBC function
(Version 1.1)
Sound and movie can be played on this player in the
same way as an audio CD.
•VIDEO CD equipped with PBC function
(Version 2.0)
In addition to operation of a VIDEO CD not equipped
with the PBC function, you can enjoy playback of
interactive software with search function by using the
menu displayed on the screen (Menu Playback). Some
functions described in this owner’s manual may not
work with all discs.
About this owner’s manual
This owner’s manual explains the basic instructions of
this player. Some DVD video discs are produced in a
manner that allows specific or limited operation during
playback. As such, the player may not respond to all
operating commands. This is not a defect in the player.
Refer to instruction notes of discs.
“”may appear on the screen during operation.
A “”means that the operation is not permitted by the
player or the disc.
Playable discs
This player can play the following discs.
•You cannot play discs other than those listed above.
•You cannot play discs of DVD-RAM or
non-standardized discs, etc., even if they may be
labeled as above.
•This player uses the NTSC color system.
Because of problems and errors that can occur during
the creation of DVD software and/or the manufacture of
DVD discs, Toshiba America Consumer Products, L.L.C.
and Toshiba of Canada, Ltd. cannot guarantee that this
player will play every feature of every DVD bearing the
DVD logo. As one of the creators of DVD technology,
Toshiba DVD players are manufactured to the highest
standards of quality and, as a result, such
incompatibilities are very rare. If you happen to
experience and difficulty playing a DVD on a Toshiba
DVD player, please feel free to call our Contact listed in
“How to Obtain Service”
93
.
DVD
video
discs
Disc Mark Contents Disc
Size
VIDEO
CDs
8 cm
12 cm
8 cm
12 cm
Video
(moving
pictures)
+
Audio
Audio
CDs 8 cm
(CD single)
12 cm
The following discs are also available.
DVD-R discs of DVD video format
CD-R/CD-RW discs of CD-DA or VIDEO CD format
Some of these discs may be incompatible.
DVD
audio
discs
Video
(moving
pictures)
+
Audio
Audio
+
Video
Audio
8 cm
12 cm
DIGITAL VIDEO
Downloaded From Disc-Player.com Toshiba Manuals
12
Introduction
Exemptions
Toshiba Corporation is not liable for any damage
caused by fire, natural disaster (such as thunder,
earthquake), acts by a third parties, accidents,
owner’s intentional or unintentional misuse, or uses in
other improper conditions.
Toshiba Corporation is not liable for incidental
damages (such as profit loss or interruption in
business, etc.) caused by use or inability to use of this
player.
Toshiba Corporation is not liable for any damage
caused by neglect of the instructions described in the
owner’s manual.
Toshiba Corporation is not liable for any damage
caused by misuse or malfunction through joint use of
this player and connected equipment or software.
On disposal
This product contains mercury. Disposal of this material
may be regulated due to environmental considerations.
For disposal or recycling information, please contact
your local government or the Consumer Electronics
Association.
Notes and Information (continued)
Downloaded From Disc-Player.com Toshiba Manuals
14
Introduction
Identification of Controls
See the page in for details.
Main unit
NAVI QUICK
VOLUME
POWER
TOP MENU MENU
ENTER
RETURN
PAUSE
SKIP
AV SOURCE
MONITOR
STOP PLAY
Disc cover
Remote sensor
20
17
Memory card slot
33
20
53 20
23
25
21
29
58
33
21
66
22
22
25
85
LCD
Speakers
POWER/CHG (Power/Charge) indicator
Disc cover open button
27
TOP MENU button
AV SOURCE button
NAVI button
22
VOLUME buttons
QUICK button
RETURN button
STOP button
PAUSE/STEP button
ENTER button
SKIP buttons
PLAY button
POWER button
MONITOR button
MENU button Direction buttons
( / / / )
( / )
( –/+ )
66
66
While holding the player base, push the top
of the LCD screen unit and lift up to open.
Downloaded From Disc-Player.com Toshiba Manuals
16
Introduction
CLEAR
FWD
RETURN
REV
ANGLE
AUDIO SLOWSLOW
PLAYSTOP
PAUSE/STEP
V-REMOTE
SETUP
VOLUME
NAVI
+10 T
0
SHIFT ZOOM
QUICK
SUBTITLE
PAGE
+ PAGE –
TOP MENU MENU POWER
AV SOURCE
DIMMER
123
456
789
+
–
SKIP SKIP
ENTER
/
/
/
/
/
/
27
25 29
25
26
22
22
28
28
45
22
53
52
58
66
21
66
46
48
25
26
47
46
25 29
20
22
33
25
DIMMER button
AV SOURCE button
*
ANGLE button
24
PAGE + button
*
SUBTITLE button
TOP MENU button
RETURN button
SLOW button
*
REV button
24
PAGE –button
*
PLAY button
SKIP button
STOP button
ZOOM button
Direction buttons
( / / / )
Number buttons /
MENU button (see below)
CLEAR button
*
ENTER button
PAUSE/STEP button
SLOW button
*
FWD button
SKIP button
T button
*
SHIFT button
POWER button
V-REMOTE button
*
QUICK button
SETUP button
*
NAVI button
AUDIO button
VOLUME buttons
/
66
66
+10
*
28
Remote control
Identification of Controls (continued)
The instructions in this manual describe the functions of the remote control. See the page in for details.
MENU button
Use the MENU button to display the menu included on
many DVD video discs. To operate a menu, follow the
instructions in “Locating a title using the top menu.”
27
“*”buttons
Operate these buttons while simultaneously pressing
the SHIFT button.
Downloaded From Disc-Player.com Toshiba Manuals
18
Introduction
BITSTREAM/PCM
AVIN
COMPONENT VIDEO
S VIDEO
AV OUT
DC IN 12V
1
2
3
Power Connection
Connect the supplied AC adapter to power the player.
For outdoor use, the battery pack (supplied) is also available.
When using the battery pack, follow the instructions on page
85
.
Caution
•Do not connect the power plug to a power outlet other than that indicated on the label, as this can result in a risk of fire
or electric shock.
•Do not connect or disconnect the power plug with wet hands. Doing so may cause electric shock.
•Do not use an AC adapter other than one specified, as it can cause a fire or damage to the player.
•When the AC adapter is in use, its temperature may increase. However, it is not a malfunction. Make sure that the power
cord is disconnected and the temperature decreases before carrying it.
To the DC IN jack
AC adapter
Connect the supplied AC adapter
and the power cord firmly.
Follow steps 1 to 3 to connect.
When disconnecting, reverse this order.
Power cord
Power plug
To wall outlet
Downloaded From Disc-Player.com Toshiba Manuals
20
Basic playback
DVD-V
VCD
DVD-A
CD
Playing a Disc
This section shows you the basics on how to play a disc.
indicates a reference page of this manual.
See the page in for details.
CAUTION
•Keep your fingers clear of the disc as it is spinning.
Neglecting to may cause serious personal injury.
•Be careful not to catch your fingers in the disc holder.
•Do not use a cracked, deformed, or repaired disc.
•Do not tilt, shake or move the main unit while playing. It
may damage the disc.
Basic playback
1
2
3
Turn on the power.
Press POWER.
The player turns on and the POWER/CHG
indicator on the player illuminates in green.
When the player is turned on for
the first time, an on-screen display will appear
to provide initial setup. Move the cursor
control ( / ) to select an item, and press the
ENTER button. See the pages in below,
and make a selection moving the cursor
control ( / ), then press the ENTER button.
On-Screen Language
70
TV Shape
68
After making all the settings, select “ ” and
press the ENTER button.
Open the disc cover.
Press OPEN on the main unit.
The disc cover opens.
The cover is designed to stop at 2 positions.
Do not force the cover open further, as it may
cause damage to the player.
Set a disc.
Place a disc with the playback side down, and
push gently on the center of the disc to affix it to
the spindle.
Close the disc cover.
Press CLOSE on the left corner.
Preparations
•Connect the AC adapter
18
or the battery pack
85
to the
player.
•When you want to view a disc on a connected TV or monitor,
turn on the equipment and select the video input connected
to the player.
•When you want to enjoy the sound of discs from an audio
system, turn the audio system on and select the input
connected to the player.
•If you use the supplied remote control, make sure that
batteries are loaded in it.
17
•If you use the headphones, see “Connecting to
Headphones”.
80
4
TOP MENU MENU
ENTER STOP
2
1
5
4
POWER/CHG indicator
/
Do not forcibly open
the LCD panel to
avoid damaging
this panel.
While holding the player base,
push the top of the LCD screen unit
and lift up to open.
POWER
OPEN
POWER
Downloaded From Disc-Player.com Toshiba Manuals
22
Basic playback
Playing a Disc (continued)
PLAY
DIMMER
STOP
PAUSE/STEP
POWER
VOLUME +
VOLUME –
Basic playback (continued)
To pause playback (still mode)
Press PAUSE/STEP during playback.
To resume normal playback, press
PLAY.
•Sound is muted during still mode.
To stop playback
Press STOP.
To turn off the power
Press POWER.
To remove the disc
Press the disc cover open button on the main unit to
open the disc cover.
Remove the disc from under the rim
while gently pressing down on its
center.
Close the disc cover after removing
the disc.
CAUTION
Do not touch the spindle immediately after prolonged play,
as it may have become hot.
Be careful in loading/removing a disc.
To change LCD brightness
Press DIMMER on the remote control.
4 pre-selected brightness levels are
provided.
Note
Only 2 brightness levels are available when using the battery
pack.
To adjust the volume of the speakers or the
connected headphones
Press VOLUME + or VOLUME –.
PAUSE
PAUSE/STEP
STOP
STOP
POWER
OPEN
POWER
Disc cover open button
MONITOR
VOLUME +
/
–
POWER
PAUSE/STEP PLAY
STOP
AV SOURCE
DIMMER
VOLUME
VOLUME
+
–
Downloaded From Disc-Player.com Toshiba Manuals
24
Basic playback
Playing a Disc (continued)
Still pictures included on DVD audio discs
DVD audio discs may include still pictures, which are
classified into two large groups.
•Slideshow: Still pictures appear one after another
automatically consistent with the disc
program. Their order, or viewing time
cannot be modified.
•Browsable pictures:
You can display your favorite still picture
selected via the remote control. Some of
those may change automatically.
: Press PAGE while pressing SHIFT to select a
picture. (The order of pictures vary depending
on the disc)
: To return to a specific picture programmed on
the disc.
Basic playback (continued)
SHIFT
PAGE –/
+
RETURN
CLEAR
RETURN
ENTER
PAGE + PAGE –
SHIFT
Downloaded From Disc-Player.com Toshiba Manuals
26
Basic playback
DVD-V
VCD
DVD-A
CD
DVD-V
VCD
DVD-A
CD
Playing in slow-motion
Press SLOW while pressing SHIFT during
playback.
To resume normal playback
Press PLAY.
Notes
•The sound is muted during slow-motion playback.
•The playback speed may differ depending on the disc.
•When using a DVD audio disc that includes pictures, this
operation may be permitted in some picture segments.
Resuming playback from the stopped location
Press STOP at the location where you
want to interrupt playback.
The player memorizes the location
where playback is stopped.
Press PLAY.
The player resumes playback from
the location where you stopped
playback.
1
2
2 Press PLAY.
Playback starts from the
beginning of the current title.
Playback starts from the
beginning of the current group.
Playback starts from the
beginning of the disc.
•If you want to return to the beginning of a DVD video/
audio disc, turn the power off and on by pressing the
POWER button, and then start playback.
Notes
•The player’s memory is also cleared when:
–you change the parental lock setting
72
or select a disc
menu language
70
.
–you use a PBC-featured VIDEO CD while “PBC”is set to
“On”
74
.
•There may be a difference in the location where playback
resumes depending on the disc. Especially when using a
DVD audio disc, playback may resume from the beginning of
the current track.
•Settings you changed using the on-screen displays while the
player stores a location in its memory may function only after
the memory is cleared.
SHIFT
REV
SLOW
PLAY
STOP
PLAY
PLAY
SHIFT
FWD
SLOW
DVD-V
DVD-A
CD
VCD
Each time you press the SLOW
button, the slow-motion speed
changes.
If you press the SLOW button
during playback, you can view the
picture in reverse slow-motion.
(Only when using a DVD video
disc.)
Each time you press the SLOW
button, the slow-motion speed
changes.
Variable Speed Playback
(continued)
To start playback from the beginning regardless
of the location where you stopped playback
1 Press STOP twice.
The player’s memory is cleared.
STOP
PLAY
SHIFT
SLOW
STOP
Downloaded From Disc-Player.com Toshiba Manuals
28
Basic playback
DVD-V
VCD
DVD-A
CD
Locating a Specific Title, Chapter, or Track
(continued)
Locating a desired section by entering its corresponding number
Press T while pressing SHIFT.
If you are using a VIDEO CD/audio CD, skip steps 1
and 2. Then at step 3, enter the number for the track
you want using the number buttons.
e.g.
Press / to select a section you want
to locate.
e.g. When you want to locate a
chapter.
Press / to enter a number of the
section.
Also the number buttons are available.
e.g. To enter 25
or
Repeat steps 2 and 3 if necessary.
Press PLAY or ENTER.
Playback starts from the selected
section.
1
2
3
Notes
•Pressing the CLEAR button while pressing SHIFT button
resets the numbers. To clear the display, press the T button
while pressing SHIFT button several times.
•This method of locating a title/group is available only on a
disc that contains title/group numbers.
Playing bonus groups of DVD audio discs
Some DVD audio discs may include an extra content
called “Bonus group”.
If you select it to play, a display appears to enter a key
number. Press the number buttons to enter the key
number, then press ENTER.
When the number is entered correctly, playback of the
bonus group starts.
To get key numbers, refer to instruction notes of discs.
Notes
•A key number may be cleared in some cases such as when
removing the disc. Enter the key number again if necessary.
•When you use a bonus group in a programmed play such as
memory playback, enter the key number beforehand.
SHIFT
T
ZOOM
DVD-V
ENTER
+10
SHIFT
2 5
0
+10
SHIFT
0 5
4
PLAY
ENTER
5
ENTER
PLAY
SHIFT
ENTER
CLEAR
T
/ / /
Number buttons
Downloaded From Disc-Player.com Toshiba Manuals
30
Basic playback
Playing MP3/WMA Files
You can play MP3/WMA files on this player.
Playing MP3/WMA files
Place a CD that contains MP3/WMA
files on the disc holder and close the
disc cover.
Press PLAY.
Playback starts.
To stop playback, press STOP.
1
2
3
To pause playback
Press PAUSE/STEP during playback.
To resume normal playback, press the
PLAY button.
Selecting a track (file name) in the disc
1 Press the MENU button.
A list of file names appears.
The current file name being played is highlighted in
green.
2 Press the / / / buttons to select a file name
you want to play.
The selected file name is highlighted in blue.
3 Press the ENTER button to begin playback of the
selected file name.
STOP
PAUSE/STEP
PLAY
/ / /
ENTER
PLAY
PAUSE/STEP
3
MENU
Notes
•Some discs may not permit this operation.
•WMA tracks copy-protected cannot be played.
•The BITSTREAM/PCM jack outputs MP3/WMA sounds in the linear PCM format regardless of the current “Audio Out Select”
selection.
69
•If you stop playback by pressing the STOP button, and then press the PLAY button, playback will start from the beginning of
the track.
•The SKIP
29
, REPEAT
55
and RANDOM
56
functions are also available.
Preparation
•Make sure that a disc you want to play is compatible with this player.
31
•Set “Priority Contents 2”to “Audio”from the on-screen display.
74
Downloaded From Disc-Player.com Toshiba Manuals
