Lokatoo A900 Series Installation manual

- 1 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Version 1.11
A900 Series GPS Navigator Hardware User
AMTEL CELLULAR SDN BHD
No. 5, Jalan PJS 7/19,
Bandar Sunway, 46150,
Petaling Jaya, Selangor,
Malaysia
www.lokatoo.com
Notes:
i) ‘Lokatoo’ and ‘… getting you there’ are trademarks of Amtel Cellular Sdn Bhd
ii) All other trademarks belongs to each registered companies.
iii) The contents of the manual may be modified without further notice.
… getting you there

- 2 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
TERMS & CONDITIONS
1. The maps data and/or preloaded software (“Software”) in this device are licensed by
third parties to Amtel Cellular Sdn Bhd (“The Company”). The Software is sub-licensed
on a limited, non-exclusive, non-transferable and revocable basis for use by you solely
on this device only and is not sold together with the device. If upgrades, updates or
supplements to the Software are obtained, the use of such upgrades, updates or
supplements is governed by these Terms and Conditions and any amendments that may
accompany them and may be subject to additional payments and conditions. You must
not reproduce, distribute, publish, transmit, modify, adapt, translate, display, distribute,
sell, license, publicly perform, prepare derivative works based upon, or otherwise use or
exploit the Software. The foregoing limited right does not give you any ownership of
Software and nothing contained in this Agreement may be construed as conferring to
you any licence or right to the Software under any copyright or any other intellectual
property right.
2. The Software is provided by the copyright holders "AS IS" and any express or implied
warranties, including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose, are disclaimed. In no event shall the copyright owner be
liable for any direct, indirect, incidental, special, exemplary, or consequential damages
however caused and on any theory of liability, whether in contract, strict liability, or tort
(including negligence or otherwise) arising in any way out of the use of the Software,
even if advised of the possibility of such damage.The entire risk to the quality and
performance of the Software is borne by you. This disclaimer of warranty constitutes
and essential part of the licence granted to you to use the Software.
3. The trademarks, logos, and service marks (“Trademark”) displayed on this Software and
device, are owned by the Company and third parties. All Trademarks not owned by the
Company are the property of their respective owners, and are used with permission.
Nothing contained herein may be construed as granting any right or licence to use any
Trademark.

- 3 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
4. The maps and any information stored in this device is strictly a navigation guide for
reference use only. It is the sole responsibility of the User’s to use this device prudently.
Information provided may change over time and you should decide the route based on
the actual road conditions and traffic laws. The Company makes no representation or
warranty, whether expressly or impliedly as to the accuracy, completeness, timeliness,
reliability or fitness for any particular purpose of the maps stored therein.
5. The planned, shortest, quickest routes and estimated time to desired destinations are
obtained from optimal route calculations based on the map database and should be used
as a reference only. This device must not be used for any purpose requiring precise
measurement of direction, distance, location or topography.
6. Do not fix or mount the device on such part of the windscreen that will interfere with
driving of the motor vehicle or be hazardous or dangerous to the driver or occupants in
the motor vehicle. User shall be responsible for his/her use of the maps stored therein
and the device, and shall at all times comply with all traffic laws and regulations of the
country of usage.
7. The usage of this device is dependent on the Global Positioning System (GPS) which is
operated by the United States government and is solely responsible for its accuracy and
maintenance. The system is subject to changes which may affect the performance and
accuracy of the GPS navigator devices.
8. The use of the device is at the User’s own risk. Lokatoo and the company is not liable
for any fines, penalties, damages or loss whether direct, indirect, incidental, special,
exemplary, or consequential damages however caused and on any theory of liability,
whether in contract, strict liability, or tort (including negligence or otherwise) arising in
any way out of the use of the device.

- 4 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Lokatoo A900 Series GPS Navigator Product User Manual
This User Manual describes the settings and functions of your A900 Series
GPS navigator. Read this guide in its entirety before attempting to use or
configure the device.
Before getting started, check that each item listed below in the package
contents is accounted for and observe the outward features of the device.
Package contents
Standard Package:
The Lokatoo A900 Series GPS navigator
Stylus
Holder
In-Car Charger
Travel Adaptor
USB cable
Map & manual CD
1GB SD/MMC Card containing navigating system software and map data

- 5 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Precautions and Notices
For your own safety, do not operate the controls of the product while
driving.
When you get off the car, do not leave your device on the dashboard that
is subject to direct sunlight. The overheating of the battery can cause
malfunction and/or danger.
Global Positioning System (GPS) is operated and managed by the United
States of America Department of Defense, which is solely responsible for
the performance of GPS. Any change or modification may affect the
accuracy of the GPS and its related systems.
GPS satellite signals cannot pass through solid materials (except glass).
When you are inside a tunnel or building, GPS positioning is not available.
A minimum of 3 GPS satellite signals is needed to determine current GPS
position. Signal reception can be affected by situations such as bad
weather or dense overhead obstacles (e.g. trees and tall buildings).
Other wireless devices in the vehicle might interfere with the reception of
satellite signals and cause the reception to be unstable.
A car holder is needed when using the device in a car. Be sure to place the
device in an appropriate place, so as not to obstruct the driver’s view, or
deployment of airbags.
Please remove SD/MMC card only when the device is in power off status.
When USB transmitting, Do Not disconnect the USB cable. When other
applications are operating, Do Not connect USB cable.
The navigation software may be updated from time to time. If the
description shown in this manual is different, please follow the software
version currently on hand.

- 6 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
CONTENTS
Usage Guideline for Extended Battery Life 07
Getting to know your Lokatoo A900 Series GPS navigator 08
Connecting External Antenna (Optional) 10
Connecting the In-Car Charger 11
Connecting to USB and charging the device 12
Connecting to Travel Adaptor and Charging the Battery 13
Using Your Device in a Vehicle 14
Using A900 Series GPS Navigator 16
Navigation 16
Using the Music player 16
Using the Video player 18
Using the Photo viewer 19
E-book 20
System Setting 21
Volume Setting 21
Power Setting 21
Backlight Setting 21
Time Setting 21
Language Setting 22
System Information 22
System Specifications 23
Troubleshooting 24

- 7 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Usage Guideline for Extended Battery Life
For optimal performance of the Li-polymer battery, take note of the following:
This unit contains a non user replaceable internal Li-polymer battery. The
battery can inflate and release hazardous chemicals. To reduce the risk of
fire or burns, do not disassemble, crush, puncture, or dispose of in fire or
water.
The icon at the top right corner on the main interface of system
indicates the current remaining power.
Disconnect device from charger when it is fully charged. Battery may
damage if it is over charged.
Do not immediately turn on your device after connecting the Travel
Adaptor to charge a power-depleted battery. If you need to turn on the
device again, wait for at least one minute.
Do not charge the battery where the temperature is high. This may be
harmful to the battery. (e.g. in direct sunlight).
There is no need to fully discharge the battery before charging. You can
charge the battery even if it is only partially discharged.
If you do not use the product for a long period of time, charge the battery
at least once every two weeks. Over discharge battery can affect the
charging performance.
Only connect the In-Car Charger to the device after starting the
car. Failure to do so may cause irreversible damage to the device.

- 8 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Getting to know your Lokatoo A900 Series GPS navigator

- 9 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Component Description
[1] Power button Press the power button for a few seconds to turn on and off
your device.
When you press the power button to turn off the unit, your
device actually enters a suspend state and the system stops
operating. Once you turn on the system again, it resumes.
[2] Master Power
Switch The main power/battery cutoff switch. When switch off the master power, the date and time will be
reset.
When the system is not responding, slide the master power
switch off and on back to restart the system.
[3] External
Antenna
Connector
(TMC)
This connector allows the use of an optional external antenna
with magnetic mount, which may be positioned on top of the
car for better signal reception in areas with poor reception.
[4] Mini-USB
Connector Connects to the USB cable.
[5] Charge
Indicator
Static red to indicate that external power is connected and
charging. Static green indicate a fully charged battery.
[6] Headphone
Connector Connects to stereo headphones
[7] SD/MMC Card
Slot Accepts a SD (Secure Digital) card for accessing data such as
MP3 music.
[8] Speaker Sends out music, sounds and voice.
[9] Stylus To enter input via touch screen.
[10] Holder
bracket slot To attach the device to the holder.
[11] Display
screen The display screen is also a touch screen for inputting.
[12] Microphone To enter input via voice. (dependent on software capability)

- 10 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Connecting External Antenna (Optional)
Place the device in such a way that the external antenna wire is routed
conveniently out the driver's side window. The magnetized antenna casing
will attach firmly to the roof of your car.
Connecting external GPS active antenna (Optional Accessory)

- 11 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Connecting the In-Car Charger
Connecting the In-Car Charger
The car charger supplies power to your device when you are using the device
in a car.
CAUTION: In-Car charger output is 12V DC, do not use this car charger for
other device.
1. Connect one end of the In-Car charger to the power connector of your
device.
2. Connect the other end to the cigarette lighter in the car to power and
charge your device.
Important
Only connect the In-Car Charger to the device after starting the car.
Failure to do so may cause irreversible damage to the device.

- 12 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Connecting to USB and charging the device
You can charge battery through USB connector. Connect your device as below
picture. For short charging time, please turn off device while charging
through USB connector.
Connecting the USB Cable
Connect to USB port.

- 13 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Connecting to Travel Adaptor and Charging the Battery
Connecting Travel Adaptor
When charging the battery for the first 3 consecutive times, you should
charge it for at least 8 hours.
1. Connect the adaptor cable to the mini-USB connector.
3. Plug the Travel Adaptor into a wall outlet.
The charge indicator display static red when charging is in progress. Static
green will indicate a fully charged battery.
NOTE:
Do not immediately turn on your device after connecting the Travel
Adaptor to charge a power-depleted battery. If you need to turn on the
device again, wait for at least one minute.
CAUTION: For optimal performance of the Li-polymer battery, take note
of the following:
Do not charge the battery where the temperature is high (e.g. in direct
sunlight).
There is no need to fully discharge the battery before charging. You can
charge the battery before it is discharged.
If you will not use the product for a long period of time, be sure to fully
charge the battery at least once every two weeks. Over discharge of the
battery can affect the charging performance.

- 14 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Using Your Device in a Vehicle
Using the Holder
Mounting on the Windshield
1. Clean the windshield where you will apply the suction cup. Then, attach the
suction cup firmly to the windshield and turn the locking tab to secure the
cup.
3. Carefully fit your navigator into the Holder.
CAUTION:
After the suction cup is secured to the windshield, never try to pull or
wriggle the arm. Always adjust the arm of the car holder for the best
viewing angle BEFORE driving. Do not adjust the device with one hand
while driving.
Using the Holder
Use the Holder to fix your device in a vehicle. Make sure that the device has
a clear view of the sky.
For initial positioning, remain at the same spot with a clear view of the sky.
The GPS may take a few minutes to find its current location initially.

- 15 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
CAUTION:
Select an appropriate location for the Holder. Never place the Holder
where the driver’s field of vision is blocked.
If the car’s windshield is tinted with a reflective coating, an external
antenna (optional) may be needed to route the antenna to the top of the
car through a window. When closing the car window, be careful not to
pinch the antenna cable. (Cars with an anti-jam window design may
automatically leave adequate space as needed.)

- 16 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Using Lokatoo A900 Series GPS Navigator
The device supports Navigation, Music and Video playback, E-book,
Photo viewing, outer TMC and system setting functions. The Main menu is
as follows:
Navigation
On the Main menu, tap Navigation to launch the navigation software.
Using the Music player
Click Music icon to access music file(s).
The function of each icon is as below:
Return to Main menu
Scroll up
Scroll down
Up to root folder and Main menu
Click the music file that you intend to play and the Music player will be
launched.

- 17 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
The function of each icon is as follow:
Return to Main menu
Play
Pause
Stop playing
Repeat all the songs
Shuffle all the songs
Play previous song
Play next song
Volume control
Playback progress bar
To display folder
Lyric
Song title
[Tips] Music player contains the function of lyric
synchronization. Please copy both the music and lyric
files (LRC format) to the same folder in the SD card,
and make sure their file names are the same.

- 18 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Using the Video player
1. Click the Video icon on the Main menu to access video file(s).
2. Click the video file that you intend to play.
The function of each icon is as follow:
Return to Main menu
Play
Pause
Increase playback speed
Stop
Up to root folder and Main menu
Volume control
Playback progress bar
Playback time
Video title
[Tips] Double click the video area to switch between
full screen and normal playback mode.

- 19 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
Using the Photo viewer
Click the Photo icon on the Main menu to access photo file(s). The function of
each icon is as follows:
Return to Main menu
Scroll up
Scroll down
Up to root folder and Main menu
Run Photo browser
Run Photo browser by clicking the photo file.
The function of each icon is as below:
Return to Main menu
Zoom Out
Zoom In
Rotate photo
Slide show (in full screen)
Previous photo
Next photo
Up to root folder
[Tips]
Under the full screen mode, double click the photo to
return to normal mode.

- 20 -
A900 Series GPS Navigator
Customer Service Hotline: [phone]
www.lokatoo.com
E-book
Click E-book on the Main menu to access E-book file(s).
Return to Main menu
Scroll up
Scroll down
Up to root folder and Main menu
Click E-book folder to open the reader
Return to Main menu
Page up
Page down
Up to root folder and Main menu
To enter specific page number
File name
Page number
Click to enter into the page selecting page.
Display entered page number
Backspace
Clear
Move to the preferred page number
