LORD F6 User manual

User manual
Návod kobsluze
Návod na obsluhu
Freezer
Mraznička
Mraznička
F6

User manual............................................................................... page 3
Návod k obsluze ..................................................................... strana 23
Návod na obsluhu................................................................... strana 43

Safety information
3
In the interest of your safety and to ensure the correct use, before installing and first
using the appliance, read this user manual carefully, including its hints and warnings.
To avoid unnecessary mistakes and accidents, it is important to ensure that all people
using the appliance are thoroughly familiar with its operation and safety features. Save
these instructions and make sure that they remain with the appliance if it is moved or
sold, so that everyone using it through its life will be properly informed on appliance
use and safety.
For the safety of life and property keep the precautions of these user‘s instructions as
the manufacturer is not responsible for damages caused by omission.
Children and vulnerable people safety
yThis appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given super vision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
yChildren aged from 3 to 8 years are allowed to load and unload this appliance.
yChildren should be supervised to ensure that they do not play with the appliance.
yCleaning and user maintenance shall not be made by children unless they are aged
from 8 years and above and supervised.
yKeep all packaging well away from children. There is risk of suffocation.
yIf you are discarding the appliance pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the door to
prevent playing children to suffer electric shock or to close themselves into it.
ylf this appliance featuring magnetic door seals is to replace an older appliance
having a spring lock (latch) on the door or lid, be sure to make that spring lack
unusable before you discard the old appliance. This will prevent it from becoming a
death trap for a child.
General safety
WARNING! Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING! Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
WARNING! Do not use other electrical appliances (such as ice cream makers)
inside of refrigerating appliances, unless they are approved for this purpose by the
manufacture.
WARNING! Do not touch the light bulb if it has been on for a long period of
time because it could be very hot.1)
Safety information
1) If there is a light in the compartment.

Safety information
4
WARNING! When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING! Do not locate multiple portable socket-outlets or portable power
suppliers at the rear of the appliance.
yDo not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.
yThe refrigerant isobutane (R-600a) is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of environmental compatibility, which is
nevertheless flammable.
yDuring transportation and installation of the appliance, be certain that none of the
components of the refrigerant circuit become damaged.
– avoid open flames and sources of ignition
– thoroughly ventilate the room in which the appliance is situated
yIt is dangerous to alter the specifications or modify this product in any way. Any
damage to the cord may cause a short circuit, fire and/or electric shock.
yThis appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type
environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
WARNING! Any electrical components (plug, power cord, compressor and
etc.) must be replaced by a certified service agent or qualified service personnel.
WARNING! The light bulb supplied with this appliance is a„special use lamp
bulb“ usable only with the appliance supplied. This„special use lamp“ is not usable
for domestic lighting.1)
yPower cord must not be lengthened.
yMake sure that the power plug is not squashed or damaged by the back of the
appliance. A squashed or damaged power plug may overheat and cause a fire.
yMake sure that you can come to the mains plug of the appliance.
yDo not pull the mains cable.
yIf the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
yYou must not operate the appliance without the lamp.
yThis appliance is heavy. Care should be taken when moving it.
yDo not remove nor touch items from the freezer compartment if you hands are
damp/wet, as this could cause skin abrasions or frost/freezer burns.
yAvoid prolonged exposure of the appliance to direct sunlight.
1) If there is a light in the compartment.

Safety information
5
Daily use
yDo not put hot on the plastic parts in the appliance.
yDo not place food products directly against the rear wall.
yFrozen food must not be re-frozen once it has been thawed out.1)
yStore pre-packed frozen food in accordance with the frozen food manufactu re·s
instructions.1)
yAppliance’s manufactures storage recommendations should be strictly adhered to.
Refer to relevant instructions.
yDo not place carbonated of fizzy drinks in the freezer compartment as it creates
pressure on the container, which may cause it to explode, resulting in damage to
the appliance.1)
yIce lollies can cause frost burns if consumed straight from the appliance.1)
yTo avoid contamination of food, please respect the following instructions.
yOpening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
yClean regularly surfaces that can come in contact with food and accessible drainage
systems.
yClean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
yStore raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
yTwo-star frozen-food compartments (if they are presented in the appliance) are
suitable for storing pre-frozen food, storing or making ice-cream and making ice
cubes.
yOne-, two- and three -star compartments (if they are presented in the appliance) are
not suitable for the freezing of fresh food.
yIf the appliance is left empty for long periods, switch off, defrost, clean, dry and
leave the door open to prevent mount developing within the appliance.
Care and cleaning
yBefore maintenance, switch off the appliance and disconnect the mains plug from
the mains socket.
yDo not clean the appliance with metal objects.
yDo not use sharp objects to remove frost from the appliance. Use a plastic scraper.1)
yRegularly examine the drain in the refrigerator for defrosted water. If necessary,
clean the drain. If the drain is blocked, water will collect in te bottom of the
appliance. 2)
1) If there is a freezer compartment.
2) lf there is fresh-food storage compartment.

Safety information
6
Installation
IMPORTANT! For electrical connection carefully follow the instructions given in
specific paragraphs.
yUnpack the appliance and check if there are damages on it. Do not connect the
appliance if it is damaged. Report possible damages immediately to the place you
bought it. In that case retain packing.
yIt is advisable to wait at least four hours before connecting the appliance to allow
the oil to flow back in the compressor.
yAdequate air circulation should be around the appliance, lacking this leads to
overheating. To achieve sufficient ventilation follow the instructions relevant to
installation.
yWherever possible the spacers of the product should be against a wall to avoid
touching or catching warm parts (compressor, con-denser) to prevent possible burn.
yThe appliance must not be located close to radiators or cookers.
yMake sure that the mains plug is accessible after the installation of the appliance.
Service
yAny electrical work required to do the servicing of the appliance should be carried
out by a qualified electrician or competent person.
yThis product must be serviced by an authorized Service Center, and only genuine
spare parts must be used.
Energy saving
yDon‘t put hot food in the appliance;
yDon‘t pack food close together as this prevents air circulating;
yMake sure food don‘t touch the back of the compartment(s);
yIf electricity goes off, don‘t open the door(s);
yDon‘t open the door(s) frequently;
yDon‘t keep the door(s) open for too long time;
yDon‘t set the thermostat on exceeding cold temperatures;
yAll accessories, such as drawers, shelves balconies, should be kept there for lower
energy consumption.
Environment Protection
This appliance does not contain gasses which could damage the ozone layer,
in either its refrigerant circuit or insulation materials. The appliance shall not be
discarded together with the urban refuse and rubbish. The insulation foam contains
flammable gases: the appliance shall be disposed according to the appliance
regulations to obtain from your local authorities. Avoid damaging the cooling unit,
especially the heat exchanger. The materials used on this appliance marked by the
symbol are recyclable.

Safety information
7
The symbol on the product or on its packaging ,U indicates that this
product may not be treated as household waste. Instead it should be
taken to the appropriate collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling
of this product. For more detailed information about recycling of this product, please
coctact your local council, your household waste disposal service or the shop where
you putchased the product.
Packaging materials
The materials with the symbol are recyclable.
Dispose the packaging in a suitable collection containers to recycle it.
Disposal of the appliance
1. Disconnect the mains plug from the mains socket.
2. Cut off the mains cable and discard it.)
WARNING! During using, service and disposal the appliance, please
pay attention to symbol similar as left side, which is located on rear of
appliance (rear panel or compressor) and with yellow or orange color.
It’s risk of fire warning symbol. There are flammable materials in
refrigerant pipes and compressor.
Please be far away fire source during using, service and disposal.

Overview
8
Electronic control plate
Freezer
Drawers
Leveling Feet
Overview
Note: Above picture in for reference only, the actual number of dravers will different from dlfferent rnodels.

Reverse Door
9
1. Remove the 2 screws on the back.
Unscrew
2. Carefully lift the top cover 5cm away
from the freezer, then pull out the
terminal, Then removethe top cover
away.


3. Remove the three screws, then remove
the upper hinge that holds the door
in place. Lift the door and place it on
a padded surface to prevent it from
scratching.
Unscrew
4. Remove the screws and bottom hinge.
Then remove the adjustable feet from
both side.
Unscrew
Reverse Door
Note: Above pictures are for reference only.

Overview
10
5. Unscrew and ramove the bottom
hinge pin, lum the bracket over end
raplace il.
Unscrew
Screw
6. Relit lhe bracket fltting the bDltom
hinge pin. Replace both adjustable
feel. Screw
7. Detach the Fridge and the Fl88zer door
gaskets and then attach them artsr
rotallng.
Note: Above pictures are for reference only.

Overview
11
8. Place the door back on. Ensure the
door is aligned horizontally and
vertically so that the seals are closed
on all sides before finally tightening
the top hinge.
Screw
9. Connect the terminals onto the display
board, then put top cover back.


10. Screw the 2 screws on the back.
Screw
11. With the door closed, check that
the door is aligned horizontally and
vertically and that the seals are closed
on all sidesbefore Knally tightening the
bottom hinge. Re-adjust the levelling
feet as needed.
Note: Above pictures are for reference only.

Installation
12
Install door handle *
* Depends on models and its equipment
Space Requirement
yKeep enough space of door open.
yIt is advisable to keep at least 50 mm gap at two sides.
A
B
C
D min=50
E min=50
F min=50
G
H
I 135°
1420
1130
960
550
F F
F
Leveling the unit
To do this adjust the two levelling feet of the unit.
If the unit is not level, the doors and magnetic seal
alignments not be covered properly.
Lengthen Shorhten
Installation

Installation
13
Positioning
Install this appliance at a location where the ambient temperature corresponds to the
climate class indicated on the rating plate of the appliance:
For refrigerating appliances with climate class:
– extended temperate: this refrigerating appliance is intended to be used at
ambient temperatures ranging from 10 °C to 32 °C (SN);
– temperate: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C (N);
– subtropical: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C (ST);
– tropical: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C (T):
Location
The appliance should be installed well away from sources of heat such as radiators,
boilers, directsunlight etc. Ensure that air can circulate freely around the back
ofthe cabinet. To ensure best performance, if the appliance is positioned below an
overhanging wall unit, the minimum distance between the top of the cabinet and
the wall unit must be at least 100 mm. Ideally, however, tha appliance should not ba
positioned below overhanging wall units. Accurate laveling is ensured by one or mora
adjustable feet at tha base of the cabinet. This refrigerating appliance is not intended
to be used as a built-in appliance.
WARNING! It must ba possible to disconnect the appliance from the mains
power supply; the plug must therefore be easily accessible after Installation.
This refrigerating appliance is not intended to be used as a built-in appliance.
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate
correspond to your domestic power supply. The appliance must be earthed. The
power supply cable plug is provided with a contact for this purpose. If the domestic
power supply socket is not earthed, connect the appliance to a separate earth in
compliance with current regulations, consulting a qualified electrician.
The manufacturer declines all responsibility if the above safety precautions are not
observed.
This appliance complies with the E. E. C. Directives.
Installation

Daily Use
14
First use
Cleaning the interior
Before using the appliance for the firsttime, wash the interior and all internal
accessories with lukewarm water and some neutral soap so as to remove the typical
smell of a brand new product, then dry thoroughly.
IMPORTANT! Do not use detergents or abrasive powders, as these will damage
the Knish.
Turn on
Plug in the appliance, LED lighting.
Daily use
energy class
Energy saving indication light
Mode button
Setting button
Lock indication light
Display“SF”,“SE”,“ht” and
setting temperature.
Super freezing
indication light
Mode
When firstly push“Mode”button, the lamp of “Super freezing“”is lighted on, and the
appliance would be fast freezing and the LED displays“SF” (super freezing).
yWhen secondly push“Mode”button, the supper freezing lamp black out, and the
“Eco“ lamp is lighted on, the appliance would go into“Eco“ mode, the appliance will
run with the setting at -16 °C and the LED will display“SE“ (save energy).
yWhen you thirdly push“mode“ button, both of lamps of “Super freezing“ and“Eco“
black out, the appliance would be back to setting mode by user.
The mode is cycling to change during“Super freezing”,“Eco”, and“Setting”.
Super
freezing
Eco
(energy saving
function)
Setting
(the normal
status)
1st
push
2nd
push
3rd
push
Daily Use

Daily Use
15
Temperature Setting
Push“setting” button, the LED number would be glistening, you could adjust the
temperature by pushing “setting”button. The setting is cycling to change from -16 °C
to -22 °C. After 5 seconds, the setting temperature is confirmed.
1st push2nd push3rd push4th push
6th push
7th push5th push
Normal
setting
choices
Energy
setting
choices
Lock
When push“mode“ and“setting“ buttons at the same time for 3 seconds, buttons will
be locked and the lamp of lock is lighted on. If you want to unlock the buttons, please
push“mode“ and“setting“ buttons at the same time for 3 seconds again.
Turn off
Push and hold“setting“ button for 5 seconds and switch off the machine. If you want
to switch on the machine, please push and hold“setting“ buttons for 5 seconds again.
Displayed temperature
IMPORTANT! LED always displays the setting temperature, not real
temperature.
Door Open Alarm
If miss to close door for 5 minutes, the door open alarm wi ll give out alarm sound
which will be three times each 5 seconds and last 5 minutes and then stop 5 minutes
and again give out alarm sound till you close door.
High temperature alarm
After running for 3 hours and if the temperature is more than -8 °C, the LED will
alternately display ”ht“ and real temperature (”ht“ means high temperature) and give
out alarm sound with frequency of 1Hz, till you push any button to stop.
Daily Use

Daily Use
16
Freezing fresh food
yThe freezer compartment is suitable for freezing fresh food and storing frozen and
deep-frozen food for a long time.
yIn order to get bigger freezing capacity, please put fresh food into freezing
compartment after you have started super freezing function for 26 hours.
yThe maximum amount of food that can be frozen in 24 hours is speciKed on the
rating plate.
yThe supper freezing process lasts 52 hours.
Storing frozen food
When first starting-up or after a period out of use. Before putting the product in the
compartment let the appliance be set in super freezing mode.
Temperature setting recommendation: -18 °C is recommended.
Under recommended setting, the best storage time of freezer is no more than 1
month.
The best storage time may reduce under other settings.
IMPORTANT! In the event of accidental defrosting, for example the power
has been off for longer than the value shown in the technical
characteristics chart under ”rising time“ , the defrosted food must
be consumed quickly or cooked immediately and then re-frozen
(after cooked).
Thawing
Deep-frozen or frozsn food, prior to be used, can be thawed in the fridge
compartment or at room tampereture, depending on the time available for this
oparation.
Small piecas may avan ba cooked still frozen, directly from tha freezer. In this casa,
cooking will take longar.
Ice-cube
This appliance may be equipped with one or more trays for the production of ice-
cubes.
Helpful hints and tips
To help you make the most of the freezing pro-cess, here are some important hints:
ythe maximum quantity of food which can be frozen in 24 hrs. is shown on the rating
plate;
ythe super freezing process that was set by software in appliance takes 26 hours. No
further food to be frozen should be added during this period;
yonly freeze top quality, fresh and thoroughly cleaned, foodstuffs;

Daily Use
17
yprepare food in small portions to enable it to be rapidly and completely frozen and
to make it possible subsequently to thaw only the quantity required;
ywrap up the food in aluminium foil or polythene and make sura that the packages
are airtight;
ydo not allow fresh, unfrozen food to touch food which is already frozen, thus
avoiding a rise in temperature of the latter;
ylean foods store better and longer than fatty ones; salt reduces the storage life of
food;
ywater ices, if consumed immediately after removal from the freezer compartment,
can possibly cause the skin to be freeze burnt;
yit is advisable to show the freezing in date on each individual pack to enable you
removal from the freezer compartment, can possibly cause the skin to be freeze
burnt;
yit is advisable to show the freezing in date on each individual pack to enable you to
keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this appliance, you should:
ymake sure that the commercially frozen foodstuffs were adequately stored by the
retailer;
ybe sure that frozen foodstuffs are transferred from the food store to the freezer in
the shortest possible time;
ynot open the door frequently or leave it open longer than absolutely necessary.
yOnce defrosted, food deteriorates rapidly and cannot be refrozen.
yDo not exceed the storage period indicated by the food manufacture.
Position different food in different compartments according to be below table.
Refrigerator
compartments
Type of food
Freezer drawer(s)/shelf yFoods for long-term storage.
yBottom drawer/shelf for raw meat, poultry, fish.
yMiddle drawer/shelf for frozen vegetables, chips.
yTop drawer/shelf for ice cream, frozen fruit, frozen
baked goods.

Daily Use
18
Cleaning
For hygienic reasons the appliance interior, including interior accessories, should be
cleaned regularly.
CAUTION! The appliance may not be connected to the mains during
cleaning. Danger of electrical shock! Before cleaning switch the appliance off and
remove the plug from the mains, or switch off or turn out the circuit breaker or
fuse. Never clean the appliance with a steam cleaner. Moisture could accumulate
in electrical components, danger of electrical shock! Hot vapors can lead to the
damage of plastic parts. The appliance must be dry before it is placed back into
service.
IMPORTANT! Ethereal oils and organic solvents can attack plastic parts, e.g.
lemon juice or the juice form orange peel, butyric acid, cleanser
that contain acetic acid.
yDo not allow such substances to come into contact the appliance parts.
yDo not use any abrasive cleaners
yRemove the food from the freezer. Store them in a cool place, well covered.
ySwitch the appliance off and remove the plug from the mains, or switch off or turn
out the circuit breaker of fuse.
yClean the appliance and the interior accessories with a cloth and lukewarm water.
After cleaning wipe with fresh water and rub dry.
yAccumulation of dust at the condenser increases energy consumption. For this
reason carefully clean the condenser at the back of the appliance once a year with a
soft brush or a vacuum cleaner. 1)
yAfter everything is dry place appliance back into service.
Defrosting of the freezer
The freezer compartment, however, will become progressively covered with frost.
This should be removed. Never use sharp metal tools to scrape off frost from the
evaporator as you could damage it. However, when the ice becomes very thick on the
inner liner, complete defrosting should be carried out as fellows:
ypull out the plug from the socket;
yremove all stored food , wrap it in several layers of newspaper and put it in a cool
place;
ykeep the door open, and placing a basin underneath of the appliance to collect the
defrost water;
ywhen defrosting is completed, dry the interior thoroughly
yreplace the plug in the power socket to run the appliance again.
1) If the condenser is at back of appliance.

Daily Use
19
Troubleshooting
CAUTION! Before troubleshooting, disconnect the power supply. Only a
qualified electrician of m competent person must do the troubleshooting that is
not in this manual.
IMPORTANT! There are some sounds during normal use (compressor,
refrigerant circulation).
Problem Possible cause Solution
Appliance does
not work
Mains plug is not plugged in oris
loose.
Insert mains plug and turn on the
appliance.
Fuse has blown or is defective Check fuse, replace If necessary.
Socket is defective. Mains malfunctions are to be
corrected by an alactrician.
Appliance freezes
too much
Temperature is set too cold or the
appliance runs at MAX setting.
Turn the temperature ragulatorto
a warmer setting temporarily.
The food is not
frozen enough.
Temperatura is not properly adjusted. Please look in the initial
Temperature Setting section.
Door was open for an extended
period.
Open the door only as long as
necessary.
A large quantity of warm food was
placed in the appliance with in the
last 24 hours.
Turn the tam perature regulation
to a coldar setting tamporarily.
The appliance is near a heat source. Please look in the installation
location section.
Heavy build-up
of frost on the
door seal.
Door seal is not air-tight.
Carefully warm the leaking
sections of the door seal with a
hair dryer (on a cool setting). At
the same time shape the warmed
door seal by hand such that it sits
correctly.
Unusual noises
Appliance is not laval. Re-adjust the feet.
The appliance is touching the wall or
other objects. Move th a appliance slightly.
A component, e.g. a pipa, on the rear
ofthe appliance is touching another
part of the appliance or the wall.
If necessary, carefully bend the
component out of the way.
If the fault reappears, contact an authorized service center.
Contact the authorized service can be found at www.lord.eu.
Spare parts can also be ordered from the authorized service center.

Daily Use
20
You will receive spare parts in accordance with the relevant ecodesign regulation from
an authorized service center for a period of min. 7 or 10 years (depending on the type
of spare part) since the last piece of the appliance model was placed on the market in
the European Economic Area.
Before contacting an authorized service center, please have the model identification
mark and serial number ready.
You will find the model identification number and product serial number on the rating
plate located on the outside back of the appliance.
To quickly find the data of your appliance, we recommend that you note the data on
the rating plate in this manual before placing the appliance on the site.
