LSA LSA1 OW User manual

L S A 1 O W
M O N I T O R S P E A K E R
P R O D U C T M A N U A L
L S A 1 O W
On Wall Speaker
7620 HW 70 S · Nashville, TN 37221 · USA · www.thelsagroup.com · [e-mail]

Warranty Information
The LSA Group warrants this product to be free of manufacturing defects for five (5)
years from the original date of purchase. A valid serial number and an original, dated
bill of sale from an authorized LSA Group dealer is required for warranty coverage.
The balance of this warranty is transferable only if the used product is traded with the
original bill of sale through an authorized LSA Group dealer. Used products traded from
person to person, or through an unauthorized dealer, will not retain warranty coverage.
The LSA Group does not honor warranties on products, new or used, from any person or
business, when traded over the internet.
This warranty is only valid within the United States, its territories, and Canada and does
not apply to products purchased elsewhere. Outside of the United States, its territories,
and Canada, please contact an authorized LSA Group distributor for warranty and
service information.
This warranty is considered void if a defect, malfunction or failure of the product or any
component part was caused by abuse while in the possession of the customer,
tampering by persons other than factory-authorized service personnel, or failure to
comply with the LSA Group’s operating instructions.
Any implied warranties relating to LSA Group products shall be limited to the duration of
this warranty. This warranty does not extend to any incidental or consequential costs or
damages to the purchaser. Freight is not covered under warranty. This warranty gives
you specific legal rights. You may also have other rights which vary from state to state.
7
L S A 1 O n W a l l S p e a k e r

6
L S A 1 O n W a l l S p e a k e r
Technical Specifications
Finishes…………………………………… Black Ash / Rosewood Veneer
Tweeter……………………………...……..3 x 1” Silk Dome
Mid-bass……………………………..…….6 1/2” Treated Paper
Frequency response………………..…….85—20K Hz
Crossover Point…………………….……..2.6KHz
Impedance…………………………..……..6Ω
Efficiency…………………………..……….88dB
Recommended power…………………….20-100W
Dimensions (Imperial)……………….…...13.6” (H) x 5.51” (D) x 14.8” (W)
Dimensions (Metric)…………...………….34.5 cm (H) x 14 (D) x 36 (W)
Weight……………………………….……..13.2lb / 6Kg each
Warranty…………………………………...5 years
L S A 1 O n W a l l S p e a k e r
Dear Music Lover,
Thank you for choosing LSA to bring music and movies to life again in your
home. The LSA1 On Wall is easily hung on a wall as a surround speaker or
as front speakers next to a flat-screen monitor. The ’front, bipole and dipole’
selections on the front of the speaker will allow it to blend seamlessly into
your LSA music or theater system, and to convey musical instruments,
movie sound effects and the human voice with the most natural tonality.
As you enjoy the sound of this fine product, please take care of your ears.
Use good judgment when selecting the volume level for your music or
movie. Our products have a smooth, clear sound, lacking harshness
caused by distortion. But this gentle approach does not mean that high
volume levels are safe. Please avoid loud volumes for sustained periods so
as to prevent damage to your hearing.
We at LSA want you to enjoy your recorded music for many years to come.
Warmest Regards,
Brian Warford
LSA President

L S A 1 O n W a l l S p e a k e r
Contents:
Main Features, Safety Instructions 1
Accessories / Installation 2
Connection / Configuration 3
Front View 4
Rear View 5
Specifications 6
Warranty 7
Rear View
*Note:
Make all connections before
turning on the amplifier power.
Engage STANDBY before dis-
connecting the speaker.
Adhesive
spacer pads
L S A 1 O n W a l l S p e a k e r
Keyhole hanger
Binding posts Terminal Plate
5
Adhesive
spacer pads

Front View
Silk dome tweeter
Mid/bass driver
L S A 1 O n W a l l S p e a k e r
4
Tuned Ports
Main Features:
Three-way selectable configuration: direct / bipole / dipole
3 x 1” Silk dome tweeters
6.5” treated paper mid-bass driver
Tuned ports for enhanced low frequency performance
5 1/2” low profile depth for flexibility in placement
No compromise, high fidelity design
Real wood veneer
L S A 1 O n W a l l S p e a k e r
Safety Instructions:
Place the speaker in a cool, clean, dry place.
Avoid direct sunlight, extreme heat or cold, and chemical solvents.
Avoid water and moisture, which can cause finish damage and electrical shorting.
Clean speaker with a clean, dry cloth as chemical solvents can damage the finish.
Keep away from CRT TV’s or items which may be affected by magnetic fields.
Secure speaker wire to terminals before turning on the connected amplifier.
Turn off amplifier when connecting or disconnecting speakers.
Do not force binding posts.
Avoid extreme volume levels as this can cause speaker and hearing damage.
1
LSA Onwall Switch Labels

Supplied Accessories
Please check for the following items:
1 manual
8 adhesive spacer pads (4 per speaker)
Installation
A. Sets easily on shelf
B. Hangs easily on wall by rear key hole slot. Take necessary
measures to ensure that the mounting screw is set securely in
the wall, either by mounting to a stud or using a drywall anchor.
L S A 1 O n W a l l S p e a k e r
2
L S A 1 O n W a l l S p e a k e r
Connections: Standard Wiring
1. Make sure amplifier is off.
2. Prepare one length of speaker (with + and - leads) wire per speaker.
3. Connect negative (-) speaker wire to the negative (black) speaker binding post.
4. Connect positive (+) speaker wire to the positive (red) speaker binding post.
5. Be sure there are no stray metal strands.
6. Connect positive and negative speaker wire leads to amplifier binding posts.
7. Turn on amplifier.
Configuration
A. Choose ‘front’ if the speakers are mounted flanking a wall-mounted flat screen
TV, or if you prefer a directional sound for your surround speakers. Only the
front-firing tweeter will play, and the two side tweeters will be disabled, as will
the ‘bipole/dipole’ switch.
B. Choose ‘sides’ if you prefer a more diffused sound—this is ideal for use as a
surround speaker. The side-firing tweeters will play and the front-firing tweeter
will be disabled.
C. IF you chose ‘sides’, you may select between ‘bipole’ and ‘dipole’.
D. Bipole offers some diffusion. The side tweeters will be in-phase.
E. Dipole offers maximum diffusion. The side tweeters will be out-of-phase.
Note:
We offer these three selections as a sort of ‘seasoning’ for your audio or theater
system. Our suggestions above are well-grounded, but you will do no harm by ex-
perimenting and seeing which settings you prefer.
3
