LSS SF15DC User manual

PROFESSIONAL AUDIO SYSTEM
SF15DC
OPERATING MANUAL
Ver. SF15DC-EN-1.0
LSS Advanced Speaker Systems
Via On. Longo 53-89024 Polistena (RC) ITALY Tel [phone] – Fax [phone] Email: [email protected] - Internet: www.lss.it

SF15DC_______________________________________________________________________________
2| Operating Manual ver. SF15DC-EN-1.0
NOTICE:
LSS products are manufactured for use according to proper procedures by a
qualified operator and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in
this manual. Always heed the information provided with them. Failure to
heed precautions can result in injury to people or damage to property.
© LSS, 2014
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior
written permission of LSS.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because
LSS is constantly
striving to improve its high-quality products, the information contained in this manual is subject to change
without notice. Every precaution has been taken in the preparation of this manual. Nevertheless, LSS assumes
no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of
the information contained in this publication.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |3
SUMMARY
INTRODUCTION ............................................................................................................................................ 4
SAFETY AND WARNING .............................................................................................................................. 5
APPLICATION ................................................................................................................................................. 6
PHYSICAL DESCRIPTION ........................................................................................................................... 6
TECHNICAL SPECIFICATIONS .................................................................................................................. 7
INSTALLATION AND WIRING ..................................................................................................................... 8
WEEE DIRECTIVE ....................................................................................................................................... 14
TROUBLESHOOTING ................................................................................................................................. 15
DIMENSIONS ................................................................................................................................................ 16
NOTES ........................................................................................................................................................... 17

SF15DC_______________________________________________________________________________
4| Operating Manual ver. SF15DC-EN-1.0
INTRODUCTION
Congratulation on the purchase of your new LSS loudspeaker.
Quality innovation and versatility, this is a summary of the new system
developed by LSS for professional sound users.
LSS produces professional audio products – the result of exceptional
engineering and meticulous craftsmanship.
This manual is intended for use with LSS loudspeaker. This includes: safety
precautions; installation, set-up and operating instruction.
Please read this manual plus any accompanying manual and follow all
relevant precautions and instructions. This should allow you to obtain the
maximum performance from your new loudspeaker.
Where there are conflicts or overlaps, the information in any accompanying
manual supersedes the information in this manual.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |5
SAFETY AND WARNING
IMPORTANT! SAFETY WARNING!
In the interest of their own and others' safety and to prevent voiding the
warranty, we recommend a careful reading of this section before using the
product.
- This product was designed and manufactured to be used as a speaker system in
the context of a typical sound reinforcement system.
The use for any purpose other than these is not provided by the manufacturer and is
therefore under the direct responsibility of the user / installer.
- This device complies with class I (must be connected to the outlet with a protective
earthing connection).
TO AVOID THE RISK OF FIRE AND / OR ELECTRIC SHOCK*:
- Do not expose this system to rain or moisture. Do not expose the apparatus to
dripping or splashing water. Do not place objects filled with liquids, such as drinks, on
the apparatus.
- Before connecting the system, be sure the mains voltage corresponds to that stated
on the product.
- Connect this appliance to a power outlet with earth contact, according to national
security force, via a power cable of adequate section ends with a plug or connector
that meets the applicable safety regulations.
- The unit is connected to the network even when the power switch is in position '0'
(OFF). Before any maintenance, disconnect the power cable from the outlet.
*Risk of electric shock only for self-powered system.
IMPORTANT! SAFETY PRECAUTIONS!
Read This First.
Read and heed all warnings and safety instructions in this Manual before using the
product.
Failure to follow all precautions can result in equipment damage and / or personal
injury.
1. Read these instructions.
2. Keep these instructions
3. Heed all warnings and follow all instructions.
4. Use only attachments/accessories specified by the manufacturer.
5. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
6. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
7. LSS loudspeakers can produce sound levels capable of causing permanent
hearing damage from prolonged exposure. The higher the sound level, the less
exposure needed to cause such damage
CAUTION: This product is energized as long as it is connected to the AC.
CAUTION: Allow at least six inches of free space all around the amplifier for sufficient
ventilation.

SF15DC_______________________________________________________________________________
6| Operating Manual ver. SF15DC-EN-1.0
APPLICATION
LSS's SF15DC is a 2-way self-powered loudspeaker system that provides
high output, low distortion sound reinforcement for the entire range of pro
audio applications. SF15 uses a 380 mm (15") low frequency cone with 75
mm (3") voice coil and Neodymium magnet and 75 mm (3") voice coil high
frequency compression Titanium/Neodymium driver. SF15 is ideal for better
performance in both touring and permanently installed applications. The
SF15A digital amplifier with DSP controller allows the pilotage in BI-AMP
mode 750W for LF woofer + 200W for HF driver.
LSS's SF15DC was designed as main speaker in live events, as monitor
system, front or delay fill and can be used stand alone or with one or more
other loudspeaker to create horizontal array.
PHYSICAL DESCRIPTION
FRONT
TOP
BOTTOM
SIDE REAR
[B]
[E]
[F]
[G]
[C] [D]
[H]
[I]
[J]
[A]
[A] Handle [F] Woofer
[B] Mounting Hardware Guide [G] Enclosure Cabinet
[C] Steel Protection Grid [H] Connection Panel
[D] Reflex [I] Handle
[E] HF Driver on Wave Guide [J] Pole Mount Cup
Materials and construction meet the highest professional standards to ensure maximum reliability.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |7
TECHNICAL SPECIFICATIONS
PHYSICAL
Dimensions mm (±1 mm)
[Inches]
Height 810 [31.89"]
Front Width 480
[18.89’’]
Rear Width 235 [9.25’’]
Depth 575 [22.64’’]
Trapezoidal Angles 13°
Weight Kilograms Net Weight: 38
Shipping Weight: 41
SYSTEM PERFORMANCE
Frequency Response ±5 dB 50 Hz ~ 18 KHz
-10 dB 40 Hz
Sensitivity (1 Watt @ 1 m) LF 99 dB
HF 106 dB
Max SPL Calculated LF 128 dB
HF 129 dB
Nominal Input Impedance (Ω) LF 4 Ω
HF 16 Ω
Power Handling SF15A (Watt EIAJ) Bi-Amp 750+200
LF 750
HF 200
Nominal Dispersion (@ -6 dB) Horizontal 40°
Vertical 60°
MECHANYCAL
Enclosure material Birch Plywood of 18 mm
[0.71 inches]
Finish Texture poliuretanic
black paint
Suspension Hardware Mounting
Suspension
Grille Powder coated
perforated steel with
anti-dust foam
Connectors Neutrik Powercon +
XLR
Optional Accessories Fly Clip with Ring,
Flight Case, Bumper,
Hardware Array

SF15DC_______________________________________________________________________________
8| Operating Manual ver. SF15DC-EN-1.0
INSTALLATION AND WIRING
SF15 speaker can be mounted on the floor, on a pole or suspended through
the dedicated hardware.
For installation on a pole, use the pole mount plate in the bottom of the case,
speaker can be mounted on a tripod or on another speaker like a sub.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |9
Mounting hardware for SF15DC is composed from:
Name Component
BUMPER SF15
LIFTBAR SF15
ALUBAR SF15
GRILLO16 SF15
JOINT SF15
BOLT M8 X 40

SF15DC_______________________________________________________________________________
10| Operating Manual ver. SF15DC-EN-1.0
SF15DC speaker can be mounted on the floor, on a pole or suspended
through the dedicated hardware.
For installation on a pole, use the pole mount cup in the bottom of the case.
For suspended installation, follow the procedure below:
Insert ALUBAR SF15 in the guide slots on the sides of the case. If one
speaker must be mounted, insert only the ALUBAR in the upper side.
Install the LIFTBAR SF15 on the ALUBAR, then lock them with a M8 BOLT.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |11
Install BUMPER SF15 and connect it with the LIFTBARs using four
GRILLO16. Another GRILLO16 can be used to hook the BUMPER.
Choising different holes in the LIFTBAR, allow to have different degrees of
inclination. Inclination depends too from the way and the number of
speakers installed.
To install more SF15 speaker suspended in horizontal configuration, mount
ALUBAR SF15 in the upper and lower guide slots on the sides of two
adjacent cases.
Install BUMPER SF15 as previously explained and connect it with the
LIFTBARs using four GRILLO16. Another GRILLO16 can be used to hook
the BUMPER

SF15DC_______________________________________________________________________________
12| Operating Manual ver. SF15DC-EN-1.0
For suspended installation in vertical configuration, mount the ALUBAR in
the cases of speakers.
To connect a case with the lower one use the JOINT SF15, then lock them
with the locking pin.
It is possible to install a maximum of three speaker in horizontal
configuration and three in vertical configuration.
Use plugs suitable to support the weight of the entire apparatus.

______________________________________________________________________________
Choose a safe mounting location, so as to prevent the cables can be
stepped on or create tripping hazards.
Before making
mixer volume is turned down.
Connection are made via 3
Before making connection between mixer and active speaker, make sure all
the switches of the speakers are turned off and the mixer volume is turned
down. To avoid a s
first and then the speakers. Turn on the amplifier by the power switch to
position 1 (on).
When the system will start turn on 3 LEDs, after a few seconds will stay on
only two or three if the input si
start with the preset the previously loaded.
You can now use the system.
If necessary, adjust the volume by adjusting the potentiometer.
If you want to change the preset, follow the instruction below.
LOADING A
The active preset is indicated by the corresponding LED. It is possible to
change presets by pressing the center pushbutton
P1
–
P2
–
P3
–
P4
–
______________________________________________________________________________
Operating Manual ver.
Choose a safe mounting location, so as to prevent the cables can be
stepped on or create tripping hazards.
Before making
connections between mixer and speakers, make sure
mixer volume is turned down.
Connection are made via 3
-pin XLR connector.
Before making connection between mixer and active speaker, make sure all
the switches of the speakers are turned off and the mixer volume is turned
down. To avoid a s
udden signal, making connection, then turn on the mixer
first and then the speakers. Turn on the amplifier by the power switch to
position 1 (on).
When the system will start turn on 3 LEDs, after a few seconds will stay on
only two or three if the input si
gnal is present, when the amplifier turn on,
start with the preset the previously loaded.
You can now use the system.
If necessary, adjust the volume by adjusting the potentiometer.
If you want to change the preset, follow the instruction below.
LOADING A
PRESET
The active preset is indicated by the corresponding LED. It is possible to
change presets by pressing the center pushbutton
P
.
–
preset 1 (green): indicates the factory presets
SMOOTH
–
preset 2 (green): indicates the factory presets
VOCAL
–
preset 3 (green): indicates the factory presets
LOUD
–
preset 4 (green): indicates the factory presets
FLAT
______________________________________________________________________________
Operating Manual ver.
SF15DC-EN-1.0 |13
Choose a safe mounting location, so as to prevent the cables can be
connections between mixer and speakers, make sure
the
Before making connection between mixer and active speaker, make sure all
the switches of the speakers are turned off and the mixer volume is turned
udden signal, making connection, then turn on the mixer
first and then the speakers. Turn on the amplifier by the power switch to
When the system will start turn on 3 LEDs, after a few seconds will stay on
gnal is present, when the amplifier turn on,
If necessary, adjust the volume by adjusting the potentiometer.
If you want to change the preset, follow the instruction below.
The active preset is indicated by the corresponding LED. It is possible to
.
SMOOTH
VOCAL
LOUD
FLAT

SF15DC_______________________________________________________________________________
14| Operating Manual ver. SF15DC-EN-1.0
WEEE DIRECTIVE
WEEE Directive
Warning!
The product is marked with this symbol which indicates not to discard
electrical and electronic equipment via the normal procedure for disposal of
household waste. For these products there is a diverse collection system in
accordance with legislation that requires proper treatment, recovery and
recycling of used products. For more information please contact the
appropriate local authority.
The black bar underneath indicates that the product was placed on the
market after 13 August 2005.
INFORMATION FOR PROPER DISPOSAL
For home users
In the European Union
Warning: To dispose of this equipment, do not use the ordinary dust bin!
The electrical and electronic equipment must be treated separately and in
accordance with legislation that requires proper treatment, recovery and
recycling of used products. Following the implementation by member states,
private households within the EU can give free electrical and electronic
equipment to designated collection facilities *.
In some countries (*), your local retailer may withdraw the old product for
free if you purchase a new one of similar type.
* For more information please contact the appropriate local authority.
In countries outside the EU: please contact your local authorities and ask
for the correct method of disposal.
In Switzerland: Used electrical or electronic equipment can be returned free
of charge to the dealer, even if you do not purchase a new product.
Further collection facilities are listed on the homepage or www.swico.ch.
www.sens.ch.
For professional users
In the European Union
Warning: If the product is used for business purposes, the following steps to
delete it:
contact your LSS dealer for information about the product recall.
Might be charged for the costs of collection and recycling. Small products
(and amounts) might be taken back by your local collection facilities.
In Spain: contact the established collection system or the local authority for
collection of used products.
In countries outside the EU: please contact your local authorities and ask
for the correct method of disposal.

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |15
TROUBLESHOOTING
Problem Possible cause (s) Action
1. No Sound
Amplifier
Connect a known working test speaker to the amplifier outputs. If
there is no sound, check that all the electronics are on, the signal
routing is correct, the source is active, the volume is turned up,
and so on. Correct/repair/replace as necessary. If there is sound,
the problem is in the wiring.
Check the amplifier is On, the green LED is On and SIGNAL
LED blink. Then control Volume Knobs is open.
Wiring
Verify that you have connected the correct XLR connector to the
amplifier. Play something at low level through the amplifier (for
example, from a CD player or tuner). If the sound level has gone
or is very weak, the line has a short in it (possibly a severe
scrape, pinch, or staple puncture). If the sound level is normal,
the wire is open (possibly a cut wire or a missed connection).
2. Poor Low
Frequency
Response
Speakers wired out-
of-polarity
When two speakers are connected out of polarity observe the
wire markings on your XLR connector. Verify that pin 2 is +
terminal and pin 1is - negative.
3. Intermittent
output such as
crackling or
distortion
Faulty Connection Check all connections to ensure they are all clean and tight. If the problem persists, it may be in the amplifier or wiring. See
Problem 1 above.
4. Constant
noise such as
buzzing,
hissing,
humming
Defective amplifier or
other electronic
Devices
If the noise is present but no program material is playing, the
likely cause is the signal chain in the electronics. Evaluate each
component as necessary to isolate the problem.
Poor system
grounding or ground
loop Check and correct the system grounding, as required.
If these suggestions do not solve your problem, contact your nearest LSS dealer or LSS distributor.

SF15DC_______________________________________________________________________________
16| Operating Manual ver. SF15DC-EN-1.0
DIMENSIONS
FRONT
TOP
BOTTOM
SIDE
23cm
57,5cm
8
1
c
m
REAR
48,5cm

______________________________________________________________________________
Operating Manual ver. SF15DC-EN-1.0 |17
NOTES

SF15DC_______________________________________________________________________________
18| Operating Manual ver. SF15DC-EN-1.0
CONTACT INFORMATION:
LSS Advanced Speaker Systems
Via On. Longo 53
89024 Polistena (RC) ITALY
Tel [phone] – Fax [phone]
Email: [e-mail] - Internet: www.lss.it
