Knowledge Base Text: Jimmy Wang
KB –Door Bell Camera Setup Guide
*Support Mechanical Doorbell system & Door Chime. May not work for musical door chime. Not compatible with Wireless Doorbell & Door Chime.
Key Features:
•Replacing to the existing doorbell button,
no extra wire needed*
•2.1MP 1080P Full HD @30fps with audio
•180° panoramic view
•See/hear/speak to visitors via phone APP
•Support Day/Night view with WDR image,
built-in IR Light (up to 15ft)
•Connect/record to LTS NVR (Exclusive)
•MicroSD Storage support up to 128GB
(SD card not included)

Page | 2
Index
Key Features Page 1
Doorbell Camera Setup Requirement / Release Cover Page 2
Hardware Connections / LTS Connect App Page 3
First-time setup / Pairing WIFI Network Page 4
Register / Login account & Viewing Page 5
Adding the Doorbell Camera into the LTS Connect App Page 6
Basic Operation –Starting up & Push to Call Page 7
Basic Operation –Live View Page 8
Basic Operation –Playback Page 9
Others -- Device List / Setting / Logout Page 9
Insert MicroSD card / Initialize / Check Update Page 10
Camera Specifications / Reset Page 11
Advance Operation –Find Camera IP address / Activate / Connect to LTS NVR Page 12
Doorbell Camera Setup Requirement:
1. Internet Connection
2. Wi-Fi Router (2.4G or Dual Band)
3. Smart Phone (Android / iPhone)
4. Existing Wire Door Chime System
(16~24VAC)
5. NVR (Optional)
Releasing the Case Cover:
Make sure doorbell secure screw remain unlocked.
There are two hidden clips on each side to secure the cover.
Use nail to release the secure clips or insert thin cardboard to unlock.
Hold the cover and push down the button should be easy to release it.

Page | 3
Hardware Connections:
1. Without Door Chime System
2. With the existing Door Chime System (Wired)
Download & Install the App LTS Connect (Android / iPhone)
Please download the LTS Connect app for the
Android / iPhone first before everything.
Note:
Please make sure the Smartphone connected to the
local Wi-Fi network first. (Support 2.4GHz WIFI, 802.11b/g)
(Double check the Wi-Fi signal strength is strong from your smartphone
first, and remember connects to the correct Wi-Fi network.
Please don’t use the Wi-Fi Guest network)

Page | 4
First-time Setup / Pairing WIFI Network
Agenda: use the Smartphone to Generate QR code (the WIFI setting) & let the camera to scan & program it.
For the first time, please check the backlight status.
If you see no light, please check the wiring.
Open LTS Connect App
More > Settings > Wi-Fi Settings > (Enter WIFI SSID & Password) > click Generate
Scanning: While the camera indicator is still flickering Blue & Red light. Put the phone (the QR Code) at front of the doorbell
camera. Keep distance between doorbell and phone around 4 inches. Let the camera scan the QR code generated from APP.
Once the doorbell detected the QR code (about 2-5 seconds). It will come out a “De” sound.
Connect Success: After hearing the “De” sound, wait about 5-10 seconds. It will try to connect the Wi-Fi Router.
If it is connected, the camera indicator will turn to Solid Blue color and it will respond “the WIFI is connected”.
Connect Fail: vice versa, If it connects fail, the doorbell will respond “the WIFI is not connected”or no Sound.
If failed, most likely could be the wrong password or the SSID cannot be found. You need to double check the setting again and start
over again. If Doorbell is far away from the Wi-Fi router, please confirm the Wi-Fi signal strength from your smartphone and then try
scan couple times.
Blue & Red flicker alternately. It indicates
Ready for the Wi-Fi configuration (by default).

Page | 5
Register / Login Account for the LTS Connect App
Remember to press the Home button, always can go back to the Homepage.
If you registered the account already, just enter the ID and Login.
Select the Doorbell Camera,
and choose Start Live View
to view at the bottom.
If you forgot the password,
click the forgot password.
Follow the recovery procedure to
get the password back.
Register
The first-time user, please create
your account before login.
Register > Read & Agree > Register
by Email Address > Select Region >
Finish > Input Email Address > Input
Verification Code > Create Login ID
and Password > Finish
Notice: Each doorbell only can
register once. If you already
registered, you just need to log in the
account. If you want to re-register
again, please unbind the camera
from the previous account first.
Please check your
email & enter the
Verify code in
60sec.
Create easy login ID.
*Avoid using
the Dot symbol.

Page | 6
Adding the Doorbell Camera into the LTS Connect.
For the first time, there is no existing device. We need to add the Doorbell camera into this account.
Press the (+) sign to Scan the QR Code.
Open the doorbell camera case cover and Scan the QR Code from the sticker.
Or, you can scan the QR code Card (Included inside the bag).
The default username & password
is before the Activation
Adding Completed.
Back to the Home

Page | 7
Basic Operation –Starting up & Push to Call
When the doorbell camera power up and start to check your WIFI status, it will prompt the message as follows:
The doorbell is running
WIFI connected
The server has been registered.
Hello

Page | 8
Basic Operation –Live View
Device List is for manage the device setting.
(See Advance Operation Section)
Playback –Playback the recorded video
If you have more doorbell camera to add, click + button
Scan QR code to scan (same step as page 6).
Or, using Manual Adding by SN number
Online Device provides Scanning IP camera from WIFI.
Favorite List –Save current selected to my favorite.
So, the next time you don’t need to select one by one again.
Operation:
1. Select Device
2. Select Start Live View
Live View
Settings: If you want to adjust the camera setting, click the Settings button.
Contains Date / Time, Alarm Notification (Motion Detect Notification), Speaker Volume Adjustment, Microphone
Volume Adjustment and More.
Important:
Setup correct Time Zone first. This will affect your video recording.
Settings
Playback
Play/Stop All Speaker / Mute
Play/Stop 1ch Zoom (8x max)
Display Layout
Snapshot Record Video
Two-Way Audio Basic / HD
Device List
Playback
Green = Selected
Favorite List Clear Selection
Setup Time Zone
First

Page | 9
Basic Operation –Playback
Basic Operation -- More Settings
Pictures and Videos are the places to keep
your snapshot clips and video files.
You may click to review or delete to save space
from here.
Manage Sharing Settings
Account management (For the advanced user, check
Settings the advance operation guide)
Logout –exit current account and back to the Login Screen.
Exit –Exit this app but next time will automatic resume from the previous login
without asking login. Unless you’re already logout.
Play/Stop All Speaker / Mute
Play/Stop 1ch Zoom (8x max)
Snapshot Quality
Record Video Speed (8x Max)
Playback Time

Page | 10
Basic Operation –Push Notification
Open Setting from the camera Live View page. Enable Alarm Notification
When there is motion detected, the camera will send a
Push Alarm notification to your Smartphone.
If you are the iPhone user, make sure iPhone
Notification setting is turn ON before you enable this
feature.
Advance Settings:
More > Settings
Auto-receive Alarm after Powering on
If enabled this function, the client will be launched in the background and receive alarm
messages automatically while the phone is powered on. This may consume more
power.
