User Operation Manual
8-VSB Modulator
AMIGO™
>> Fourth Edition
LUMANTEK Co., Ltd
http://www.lumantek.com
Head Office : # 1208, Woolim Lion’s Valley II, Gasan-Dong Geuncheon-Gu SEOUL, KOREA (150-803)
TEL: [phone] FAX:[phone] Email : [email protected]om

Trademarks and copyright
COPYRIGHT © 2009, LUMANTEK Unit 1208, Woolim Lion’s Valley II, 680 Gasan-Dong, Gumcheon Gu,
Seoul Korea (153-830), Tel: [phone], Fax: [phone] All rights reserved.
This document contains information that is proprietary to LUMANTEK. No part of this publication may
be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, electronically,
mechanically, by photocopying, or otherwise, without the prior written permission of LUMANTEK. Nationally
and internationally recognized trademarks and trade names are the property of their respective holders and are
hereby acknowledged.
Portions of this software are © 1996-2006 LUMANTEK Ltd. All intellectual property rights in such portions of
the Software and documentation are owned by LUMANTEK and are protected by United States copyright laws,
other applicable copyright laws and international treaty provisions. LUMANTEK and its suppliers retain all
rights not expressly granted.
Disclaimer
The information in this document is furnished for informational purposes only, is subject to change without prior
notice, and should not be construed as a commitment by LUMANTEK.
The information in this document is believed to be accurate and reliable; however LUMANTEK assumes
no responsibility or liability for any errors or inaccuracies that may appear in this document, nor for any
infringements of patents or other rights of third parties resulting from its use. No license is granted under any
patents or patent rights of LUMANTEK.
This document was written by the Technical Support Department of LUMANTEK, Korea. We are committed to
maintaining a high level of quality in all our documentation. Towards this effort, we welcome your comments
and suggestions regarding the content and structure of this document. Please fax or mail your comments and
suggestions to the attention of:
LUMANTEK Attn: Product Support Department Unit 1208, Woolim Lion’s Valley II, 680 Gasan-Dong,
Gumcheon Gu, Seoul Korea (153-830), [phone], Fax: [phone]
Environmental Issues
Thank you for buying a product which contributes to a reduction in pollution and thereby helps save the
environment.
Our products reduce the need for travel and transport and thereby reduce pollution. Our products have either no
or few consumable parts (chemicals, toner, gas, paper). Our products are low energy consuming products.
Waste handling:
There is need to send material back to LUMANTEK. Please contact your local dealer for information on
recycling the product by sending the main parts of the product for disassembly at local electronic waste stations.
Production of products:
Our factories employ the most efcient environmental methods for reducing waste and pollution by ensuring that
the products are recyclable.

Contents
1. AMIGO™ System Overview•5
2. Key Feature •5
3. Product Description •7
1-1 Product Appearance•7
1-2 Front Panel•7
1-3 Rear Panel •8
1-4 Side Panel•8
4. Product Contents •8
5. Precautions •9
6. AMIGO™ Operation• 10
7. Hyper Terminal (RS 232C Port) • 12

AMIGO™ 8-VSB Modulator >> 4
User Manual
1. AMIGO™ System Overview
AMIGO™ is 8-VSB Modulator which has been applied to ATSC standard. Its Input Interface
supports SMPTE-310M (Society of Motion Picture and Television Engineers) and DVB-ASI
Input.AMIGO™ receives MPEG2 TS (Transport Stream) through DVB ASI Input or SMPTE-
310M Input Interface.And it modulates with 8-VSB and makes RF Signal by built-in RF Up
Converter.
2. Key Feature
Basic Structure ATSC (8-VSB) Modulator
Input Interface DVB-ASI over BNC-75 Ohm
• Comply with EN50083-9
• 188-byte / 204 byte
• 1 to 100 Mbps
SMPTE-310M over BNC-75 Ohm
• 19.39 Mbps Input
REFERENCE 10Mhz
• 10Mhz Input (except 75 Ω)
IF Output IF Modulator Output
• 44MHz (+, - 500 Khz)
• Digital Tuning resolution : 1Hz
• Channel Bandwidth 6MHz
• Connector 50 Ω BNC
RF Output VHF/UHF Output
• Frequency : 50 ~ 860 Mhz 1Khz Step
• Level : -15.0dBm ~ 7.0 dBm
• Attenuation : 0.5dB step
• Phase noise(UHF) : Better than < -98dBc @ 10Khz,
Better than < -104dBc @ 20Khz
• EVM(before equalizer) : <3% RMS(at RF)
• MER(measured at RF) : >35dB
• RF Spurious Tones : Better than -60 dBc below output
signal
• RF Harmonics : Better than -55 dB below output signal
• IF Input : 50 Ω BNC connector or 75 Ω F-type connector
• RF Output connector : BNC, 50 Ω or 75 Ω
• -20dB TP output
Modulation Method Standard
• ATSC A.53
Modulation Scheme
• 8-VSB
Symbol rate
• Symbol rate : 10.762MSps

AMIGO™ 8-VSB Modulator >> 5
User Manual
Key Feature Return Loss ≤ -15dB
• Linear pre-distortion
• Non-linear pre-distortion
• Null Packet Insertion
• Null Packet Extract
• PCR Re-stamping
• TS Rate Monitoring (option)
• PID Filtering (option)
• PID Remapping (option)
• PID Monitoring (option)
• RS232 control port to remote management
• User friendly LCD UI (with 4 line LCD)
Dimension
&
Power
Dimension
• 1 RU ( 19 inches Rack Mount)
• 483 X 44 X 380 m
• Weight : 3.15 kg
• Sash : Aluminum
Power
• Voltage : 90-260 V
• Power Consumption : 60W Max
Monitoring Front
• 4 line - 16 character LCD display
• 4 cursor keys + 2 function keys
Remote Control
• RS 232 - 9 pin DIN

AMIGO™ 8-VSB Modulator >> 6
User Manual
3. Product Description
1-1 Product Appearance
1-2 Front Panel
Bellowing picture shows the front panel of 8-VSB MODULATOR.
u x y z { | } ~ tvw
j POWER LED : Turn on when power supply
k MPEG LED : Blink when Modulation is working
l ALARM LED : Turn on when system is error
m LCD : User input window
n UP BUTTON : Move up
o LEFT BUTTON : Move left
p DOWN BUTTON : Move down
q RIGHT BUTTON : Move right
r SET BUTTON : Conrm Setting
s ESC BUTTON : Exit from Menu
i RF TP(-20dB) : RF Output Port
1-3 Rear Panel
Bellowing picture shows the rear panel of 8-VSB MODULATOR.









AMIGO™ 8-VSB Modulator >> 7
User Manual
j RF OUTPUT : RF Output Port
k IF INPUT : IF Input Port (50 Ω, 75 Ω)
l IF OUTPUT : IF Output Port (50 Ω, 75 Ω)
m RS-232 : RS-232 Port for system management
n REFERENCE 10Mhz : REFERENCE 10Mhz Port (except 75 Ω)
o ASI/SMPTE-310M IN : ASI / SMPTE-310M IN Port, Select on Menu
p POWER INPUT : Power Input and Switch
q POWER SW : Power(on/off)
1-4 Side Panel
Radiant heat ventilating opening
4. Product Contents
AMIGO™
RS 232 CABLE 50Ω Cable (BNC) : IF LOOP
<- 75Ω Cable (F-type): IF Loop

AMIGO™ 8-VSB Modulator >> 8
User Manual
5. Precautions
Please read all safety and operating instructions before using this product. For best results,
be aware of all warnings on the product and follow these operating instructions. Retain these
safety and operating instructions for future reference.
1. Power Source
Connect this product only to the power source described in the operating instructions
or as marked on the product itself.
2 Power Cable Protection
Route all power cables safely. Ensure the power cables can neither be walked upon nor
pinched by items placed near or against the cables. Pay particular attention to locations
near AC receptacles, AC outlet strips and points of entry to the product.
3. Electrical Shocks
Take care not to drop objects or spill liquids into the product through enclosure
openings. Metal objects, such as hairpins or needles, inserted into the product may
contact voltages resulting in serious electrical shocks. Never permit children to insert
any objects into this product.
4. Ventilation
Locate the product so as not to interfere with its ventilation. Do not place books or
other equipment on the product that may impede the free movement of air. Allow a
minimum of 4 inches (10 cm) between the rear of the product and the wall or operating
desk shelf.
5. Abnormal Odors
The presence of an unusual odor or smoke is often a sign of trouble. Immediately turn
the power OFF and remove the power cable. Contact a dealer or the nearest Service
Center for advice.
6. Servicing
Remove the product’s enclosure only to do accessory installations described by this
manual or accessory manuals. Follow provided instructions carefully to avoid electrical
shocks. If unfamiliar with this type of work, seek assistance from an experienced
individual, or have a professional technician do the task.
7. Damage Requiring Service
Enlist the services of qualied personnel in the following cases:
a) The power supply or plug is damaged.
b) Objects have fallen or liquid has spilled into the product.
c) The product has been exposed to rain.
d) The product is operating abnormally or performance has degraded seriously.
e) The product has been dropped or the enclosure damaged.

AMIGO™ 8-VSB Modulator >> 9
User Manual
6. AMIGO™ Operation
Basic Button Function
LCD Display Window
• Set Menu and Function
• Basic Information is shown
Move Curser and change value
• Move Setting Value (number) Curser to left
• Move Setting Value (number) Curser to right
• Increase Setting Value, Move Curser to Up
• Decrease Setting Value, Move Curser to Down
Set Value
Exit Menu
1. Power On
Bellowing LCD Display may appear when power is supplied.
- LumanTek 2.0.7-
RF : 579 Mhz, 0 dBm
Ts: 0.00Mbps
Current Setting Center Rf & Display real-time rate of the TS
If Rate is 0 then LCD Display show TS: No Input!!, and show Alarm signal.
2. Starting Menu
* 1. Rf Ch/Freq.
2. RF Power
3. Input Port
4. Spec Inv.
After initialization, press [SET] Button. Menu will be shown.
Main Menu are RF Ch/Freq, RF Power, Input Port, Spec Inv, Ref 10Mhz, Linear, and Non-
lin.
Select Menu by Up / Down Buttons and Press SET Buttons.
1. RF Freq : RF output signal setting
2. RF Power: RF output level setting
3. Input Port : Input port setting
4. Input Format : Input format setting
5. Ref 10Mhz : 10Mhz Signal setting ( except # 75Ω)
6. Linear : Set up a linear displacement

AMIGO™ 8-VSB Modulator >> 10
User Manual
3. RF Ch/Freq
Press [SET] Button from starting menu. On Set By Menu, select Cable Ch, Terre Ch,
Frequency and change Frequency by Up / Down Buttons.
You can change Number by Left / Right Buttons.
1. RF Ch/Freq
-> Set By : Freqeuncy
Freq : 579.0Mhz
< Signal Range : 50 ~ 860 MHz >
4. RF Power
Choose ‘2.RF Power’ from starting menu, then press [SET] Buttons
Change RF Output Level by Up / Down Buttons.
You can change Number by Left / Right Buttons.
2. RF Power
0 dBm
(+7 ~ -15 dBm/0.5)
< Output Range : +7~ -15 dBm >
5. Input Port
Choose ‘3.Input Port’ from starting menu, then press [SET] Buttons.
Press Setting Buttons( ) to change input port.
Input port is supported by ASI - 188, ASI - 204, SMPTE - 188.
3. Input Port
ASI In
(ASI/SMPTE)
< Input Port :ASI – 188,ASI – 204, SMPTE - 188>
6. Spec Inv.
Choose ‘4.Input Formant’ from starting menu, then press [SET] Buttons.
Press Setting Buttons ( ) to change input port.
You can change Number by Left / Right Buttons.
4. Spec Inv.
Invert.
(Inv/Nor)
< Spec Inv. : Inv / Nor >

AMIGO™ 8-VSB Modulator >> 11
User Manual
7. Ref 10Mhz. (except # 75 Ω)
Choose ‘number 5’ from starting menu, then press [SET] Buttons.
Press Setting Buttons( ) to change Ref 10Mhz setting.
10MHZ reference setting supportes Int, and Ext. However, the 75Ω Type is non- xiable.
5. Ref 10Mhz.
Internal
[Int/Ext]
< Rf 10Mhz : 10Mhz: Int / Ext >
8. Linear
Choose ‘number 6' from starting menu, then press [SET] Buttons.
Press Setting Buttons ( ) to change Linear displacement compensation.
Linear displacement compensation supports Off, Defalut, and User.
6. Linear
Default
(Off / *Default/User)
< Linear: Off / *Default / User >
1. Off : A linear displacement compensation is turn off.
2. Default : Factory applied to perform linear displacement compensation.
(Built-in upconverter Compensation
3. User : Value entered by the user to perform a linear displacement compensation.
The initial value is Default.
9. Non - lin
2 Non-linearity inside AMIGO.
Choose ‘number 7' from starting menu, then press [SET] Buttons.
Press Setting Buttons ( ) to change Linear displacement compensation.
Nonlinear compensation prepositive is supported by A, B, Off.
7. Non-lin
Off
[A/B/off]
< Non-lin:A / B / Off >
A : Perform Linear compensation prepositive in saved A area.
B : Perform Linear compensation prepositive in saved B area.
Off : Does not work Linear compensation prepositive

AMIGO™ 8-VSB Modulator >> 12
User Manual
7. Hyper Terminal (RS 232C Port)
Check computer’s COM for using RC-232C Port
Control Panel System Device Manager  Ports (COM & LPT)
After check ‘Ports (COM & LPT)’, run RS-232C Ports Access program
(Hyper Terminal, Secure CRT...).
1. Start Program Accessories Communications  Hyper Terminal
Input ‘Amigo’ in Name, then click OK.

AMIGO™ 8-VSB Modulator >> 13
User Manual
2. When you click the OK button in the Serial Port Settings window appears below.
Section Setting Value
Baud Rate 19,200
Data Format 8 bit
Stop Bit 1
Parity No
Flow Control None
<Port Settings>
3.Setting
1) Set/Change Frequency : (Unit : KHz)
Instructions : > To change the value
Example : > RF 123456 [enter]
 Set 123456KHz
> RF ? [Enter] : Conrm changed value
123456
Example : > CC 4 [enter]
 Set ch 4
> CC ? [Enter] : Conrm changed value
Cable ch: 4
Example : > CT 5 [enter]
Set ch 5
> CT ? [Enter] : Conrm changed value
Terrestrial ch: 5

AMIGO™ 8-VSB Modulator >> 14
User Manual
2) Set / Change Output Power Level (Unit : dBuV)
Instructions : > To change the value
Example : > PW 20 [enter]
 Set 20 x 0.1 dBm
> PW ?[Enter] : Conrm changed value
3) Setting
Instruction : Input port (ASI/SMPTE) Byte
Example : >IN ASI188 [enter]
Set Input port is ASI and Format is 188 Byte
> IN ASI204 [enter]
 Set Input port is ASI and Format is 204 Byte
> IN SMPTE [enter]
Set Input port is SMPTE and Format is 188 Byte
> IN ? [Enter]
   ASI204/ASI188/SMPTE
4) Spectrum Inversion
Instruction : SP NORMAL/INVERT [enter]
Example : > SP NORMAL [enter]
Set spectrum Normal set
> SP INVERT [enter]
Set spectrum Invert set
> SP ?[Enter]
5) Ref 10Mhz (75 Ω Internal is non -xiable)
Instruction : REF INTERNAL/EXTERNAL [enter]
Example : > REF INTERNAL [enter]
set reference Internal 10Mhz set
> REF EXTERNAL [enter]
 set reference External10Mhz set
> REF ?

AMIGO™ 8-VSB Modulator >> 15
User Manual
6) Linear
7) Non-lin.
Instruction : Using the utility to apply PD.exe
Using matlab simulation results if the following, PD.exe can get by using the
improved results.
<Amplitude> : Before
<Group Delaye> : Before
Using the measured value, enter PD.exe as follows
For the Port Click Select and Send, to transfer the AMIGO
If you choose Fine-Tune, it will apply the previous values.
If you did not choose Fine-Tune, it will previous applies regardless.

AMIGO™ 8-VSB Modulator >> 16
User Manual

AMIGO™ 8-VSB Modulator >> 17
User Manual
<Amplitude> : After
<Group Delaye> : After

AMIGO™ 8-VSB Modulator >> 18
User Manual
If you are Non-Linear type, select the port.
Click A Block Send or B Block Send to transfer to the AMIGO.

IMPORTANT NOTICE
LUMANTEK Incorporated and its subsidiaries (LMT) reserve the right to make corrections,
modications, enhancements, improvements, and other changes to its products and services at any time
and to discontinue any product or service without notice. Customers should obtain the latest relevant
information before placing orders and should verify that such information is current and complete.
All products are sold subject to LMT’s terms and conditions of sale supplied at the time of order
acknowledgment.
LMT warrants performance of its hardware products to the specications applicable at the time of sale
in accordance with LMT’s standard warranty. Testing and other quality control techniques are used
to the extent LMT deems necessary to support this warranty. Except where mandated by government
requirements, testing of all parameters of each product is not necessarily performed.
LMT assumes no liability for applications assistance or customer product design. Customers are
responsible for their products and applications using LMT components. To minimize the risks associated
with customer products and applications, customers should provide adequate design and operating
safeguards.
LMT does not warrant or represent that any license, either express or implied, is granted under any
LMT patent right, copyright, mask work right, or other LMT intellectual property right relating to any
combination, machine, or process in which LMT products or services are used. Information published
by LMT regarding third–party products or services does not constitute a license from LMT to use such
products or services or a warranty or endorsement thereof. Use of such information may require a license
from a third party under the patents or other intellectual property of the third party, or a license from LMT
under the patents or other intellectual property of LMT.
Reproduction of information in LMT data books or data sheets is permissible only if reproduction is
without alteration and is accompanied by all associated warranties, conditions, limitations, and notices.
Reproduction of this information with alteration is an unfair and deceptive business practice. LMT is not
responsible or liable for such altered documentation.
Resale of LMT products or services with statements different from or beyond the parameters stated by
LMT for that product or service voids all express and any implied warranties for the associated LMT
product or service and is an unfair and deceptive business practice. LMT is not responsible or liable for
any such statements.
Mailing Address:
LUMANTEK Unit 1208, Woolim Lion’s Valley II, 680 Gasan-Dong, Gumcheon Gu, Seoul Korea
Copyright © 2006, LUMANTEK Incorporated

User Operation Manual
8-VSB Modulator
AMIGO™
LUMANTEK Co., Ltd
http://www.lumantek.com
Head Office : # 1208, Woolim Lion’s Valley II,
Gasan-Dong, Geuncheon-Gu, SEOUL, KOREA (150-803)
TEL : [phone]
FAX: [phone]
e-Mail : [email protected]
