Lumberjack XP LIM150 Operation instructions

Original Manual
IMPACT DRIVER
Read this manual before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
LIM150

INDEX IM150
Owner’s Manual & Safety Instructions
Impact driver
1.Work Area Safety
2.Electrical Safety
3.Personal Safety
4.Power Tool Use and Care
5.Battery Tool Use and Care
6.Specific Safety Rules for Drills/Drivers
7.Symbols
8.Assembly
9.Maintenance
10.Transport
11.Meaning of crossed –out wheeled dustbin
12.After-Sales Service Hot-mail
01
01
02
02
03
04
04
06
07
08
08
09

.01.
Owner’s Manual & Safety Instructions
Impact driver
General Power Tool Safety Warnings
: Read all safety warnings and instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term ″ power tool ″ in the warnings refers to your mains-operated (corded)
power tools or battery-operated (cordless) power tools.
1.Work Area Safety
a.Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b.Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c.Keep children and bystanders away while operating a power tool. Distrac-
tions can cause you to lose control.
2.Electrical Safety
a.Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with grounded power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b.Avoid body contact with grounded surfaces such as pipes,radiators,
ranges and refrigerators. There is an increased risk of electric shock if your
body is grounded.
c.Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d.Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e.When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of elec-
tric shock.
f.If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply.Use of a RCD reduces the risk of elec-
tric shock.

.02.
Owner’s Manual & Safety Instructions
Impact driver
:The term residual current device (RCD) may be replaced by
the term ground fault circuit interrupter (GFCI) or earth leakage circuit
breaker (ELCB).
3.Personal Safety
a.Stay alert, watch what you are doing and use common sense when operating
a power tool. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b.Use personal protective equipment.Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions will reduce personal injuries.
c.Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that
have the switch on invites accidents.
d.Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e.Do not overreach.Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
f.Dress properly.Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g.If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used.Use of dust collection
can reduce dust-related hazards.
4.Power Tool Use and Care
a.Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
b.Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
c.Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing

.03.
Owner’s Manual & Safety Instructions
Impact driver
power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
d.Store idle power tools out of the reach of children and do not allow persons un-
familiar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e.Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools opera-
tion. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
f.Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g.Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
5.Battery Tool Use and Care
a.Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with an-
other battery pack.
b.Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c.When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
d.Under abusive conditions, liquid may be ejected from the battery; avoid con-
tact. If contact accidentally occurs, flush with water. If liquid contacts eyes, addi-
tionally seek medical help. Liquid ejected from the battery may cause irritation or
burns.
e.Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is main-
tained.
f.Always push the gear selector and turn the operating mode selector switch
through to the stop. Otherwise, the machine can become damaged.
g.Apply the power tool to the screw only when it is switched off. Rotating tool

.04.
Owner’s Manual & Safety Instructions
Impact driver
inserts can slip off. An auxiliary tool can be used to remove the screwdriver bit or
universal bit holder.
h.Working in especially dusty environments can lead to failure of the power tool.
If the power tool suddenly fails, remove the carbon brushes and check them.
i.Do not open the battery. Protect the battery against heat, continuous intense
sunlight, fire, water, and moisture. Take care of danger of explosion and
short-circuiting.
6.Specific Safety Rules for Drills/Drivers
a. Hold power tool by insulated gripping surfaces when performing an operation
where the cutting accessory or fastener may contact hidden wiring. Cutting ac-
cessory and fasteners contacting a “live” wire may make exposed metal parts of
the power tool “live” and could give the operator an electric shock.
b. Use auxiliary handle(s), if supplied with the tool. Loss of control can cause
personal injury.
c. Use appropriate detectors to determine if utility lines are hidden in the work
area or call the local utility company for assistance. Contact with electric lines
can lead to fire and electric shock. Damaging a gas line can lead to explosion.
Penetrating a water line causes property damage.
d. Switch off the power tool immediately when the tool insert jams. Be prepared
for high reaction torque that can cause kickback. The tool insert jams when:
– the power tool is subject to overload or
– it becomes wedged in the workpiece.
e. Hold the machine with a firm grip. High reaction torque can briefly occur
while driving in and loosening screws.
f. Secure the workpiece. A workpiece clamped with clamping devices or in a vice
is held more secure than by hand.
g. Always wait until the machine has come to a complete stop before placing
it down. The tool insert can jam and lead to loss of control over the power tool.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is main-
tained.
7.Symbols

.05.
Owner’s Manual & Safety Instructions
Impact driver
a.Some of the following symbols may appear on this product. Study these
symbols and learn their meanings. Proper interpretation of these symbols
will allow for more efficient and safer operation of this product.
b.Technical Specifications
c.Function Description
SYMBOL DESCRIPTION
Read the manual before set-up and/or use.
Wear safety glasses, ear protection and respiratory protection.
Use dust mask. Dust which is injurious to health can be
generated when working on wood and other materials.
Never use the device to work on any materials
containing asbestos.
Do not dispose with house-hold waste.
Conforms to relevant safety standards.
Voltage:
No Load Speed:
DC-20V
0-2900RPM
Impact Rate:
Max.Torque:
Chuck Type:
0-3300 BPM
150N.m
1/4’’ Hex Shaped Socket
8
5
2
3
4
6
7
1
1.Impact driver bit
2.Tool holder
3.Battery pack
4.Battery unlocking button
5.LED Work light
6.Rotational direction switch
7.On/Off switch
8.Handle

.06.
Owner’s Manual & Safety Instructions
Impact driver
8.Assembly
Installing the Battery
Press the unlocking button of the battery,and then insert the charged battery
from the front into the base of the power tool.Push the battery completely into
the base until the stripe can no longer be seen and the battery is securely
locked.
: Use only original batteries with the voltage listed on the name-
plate of your power tool.Using other batteries can lead to injuries and pose a fire
hazard.
Removing the Battery
Press the unlocking button of the battery,and then pull the charged battery from
the front into the base of the power tool.
: Please remove battery from the machine before operate the fol-
lowing installations.
Installing the Bit
Pull the outer ring of chuck to the front position,and insert the bit to the deepest
position.
: Have a pull to the bit and check if the bit has been fastened firmly
and correctly.
Removing the Bit
Pull the outer ring of chuck to the front position,and take the bit out of the chuck.
Operation
: Set the rotational direction switch to the centre position in order
to avoid unintentional starting.
Switch On and Off
To start the machine, press the On/Off switch and keep it pressed.
To switch off the machine, release the On/Off switch, and the machine stops.
: When you release the button, the light will be keep working about
3-5s.The LED lights up when the On/Off switch is halfway or fully pressed, and is
intended to illuminate the power tool’ s direct area of working operation.

.07.
Owner’s Manual & Safety Instructions
Impact driver
Rotational Direction Switch
: Before adjust rotational direction
switch,the tool must be switch off.
Right Rotation:For drilling forward,push the rota-
tional direction switch left to the stop.
Left Rotation:For drilling backward,push the
rotational direction switch right to the stop.
: The rotational direction switch is
used to reverse the rotational direction of the ma-
chine. However, this is not possible with the
On/Off switch actuated.
Adjusting the Speed
The speed of the switched-on power tool can be variably adjusted, depending on
how far the On/Off switch is pressed. Light pressure on the On/Off switch results
in a low rotational speed. Further pressure on the switch results in an increase in
speed.
Protection System
This system automatically cuts off power to the motor extend tool and battery
life.The tool will automatically stop during operation if the tool or battery is placed
under one of the following conditions:
Overload Protection
When the tool is operated in a manner that causes it to draw an abnormally high
current, the tool automatically stops without any indications.In this situation, turn
the tool off and stop the application that caused the tool to become overloaded.
Then turn the tool on to restart.
Overheat Protection
When the temperature of the machine is overheated, the machine stops auto-
matically. In this situation, let the machine cool before turning on again.
9.Maintenance
a.To prevent accidents, always switch off the tool before cleaning or performing
any maintenance the saw may be cleaned most effectively using compressed
air. Always wear safety goggles when using compressed air. If compressed air is
not available, use a brush to remove dust and chips from the tool.

.08.
Owner’s Manual & Safety Instructions
Impact driver
b.Motor ventilation vents and switch levers must be kept clean and free of for-
eign matter. Do not attempt to clean by inserting pointed objects through open-
ings.
c.Never use any caustic agents to clean plastic parts. Such as: gasoline, carbon
tetrachloride, chlorinated cleaning solvents, ammonia and household cleaners
containing ammonia. Do not use any of these to clean the tool.
d.Have an authorized service center examine and/or replace the worn carbon
brushes in the event of excessive parking.
e.Keep the machine clean all the time.
f.If you discover any damage, consult the exploded drawing and parts list to de-
termine exactly which replacement part you need to order from our customer
service department.
g.Clean the housing only with a damp cloth. Do not use any solvents! Dry thor-
oughly afterwards.
h.If the supply cord of this power tool(or battery) is damaged, it must be replaced
by a similar cord(battery) available through the service organization or a qualified
authoritative technician.
: Do not use cleaning agents to clean the plastic parts of
the tool. A mild detergent on a damp cloth is recommended. Water must
never come into contact with the tool.
10.Transport
Turn the motor off and disconnect the mains plug(remove the battery). While
transporting, be careful not to drop, or shock the machine. For transport, the ma-
chine has to be fixed against slipping and tipping over. Do not place objects on
the machine.
11.Meaning of crossed –out wheeled dustbin:
Do not dispose of electrical appliances as unsorted municipal waste, use sepa-
rate collection facilities. Contact your local government for information regarding
the collection systems available. If electrical appliances are disposed of in land-
fills or dumps, hazardous substances can leak into the groundwater and get into
the food chain,damaging your health and well-being.

.09.
Owner’s Manual & Safety Instructions
Impact driver

LUMBERJACK TOOLS
UNIT C MANDERS INDUSTRIAL ESTATE
WOLVERHAMPTON WV1 2RP
WWW.LUMBERJACKTOOLS.CO.UK
Popular Impact Driver manuals by other brands

RS Components
RS Components 754-1927 Original instructions

Chicago Pneumatic
Chicago Pneumatic T019799 Operator's manual

Sumake
Sumake ST-C589 quick start guide

Bosch
Bosch GDR18V-1800C Operating/safety instructions

Sidchrome
Sidchrome SCMTTA-050 Operation and maintenance manual

Bosch
Bosch GSR ProDrive Professional Original instructions
