Congratulations!
You are now the proud owner of a BOOM™BUDDY. Prepare to experience your entertainment on a whole new level.
BOOM™BUDDY allows you to HEAR the sound and FEEL the excitement. You’ll experience every crash, bang, and boom
while enjoying your favorite game, music, or movie. BOOM™BUDDY is also a great game seat built to endure the rigors of
today’s gaming environment. Take a moment to review your owner’s manual before connecting your BOOM™BUDDY. Set-up and
operation of the BOOM™BUDDY is simple.
If you need further assistance visit us at www.BoomChair.com or www.LumiSource.com
BOOM™BUDDY, a LumiSource®product.
LumiSource, Inc.
2950 Old Higgins Road, Elk Grove Village, IL 60007
PATENTS PENDING
BoomChair™, BoomChair 2.0™, BoomCube™ and Boom™Buddy are trademarks of LumiSource, Inc. Other trademarks are properties of their respective owners.
©2006 LumiSource, Inc. All rights reserved. www.BoomChair.com & www.LumiSource.com
READ BEFORE USE
• DO NOT wash or soak with water. If BOOM™BUDDY gets wet, disconnect power immediately and
do not use until completely dry.
• Switch power off (0) and unplug BOOM™BUDDY when not in use.
• Children under 5 years old should not use this product without parental supervision.
• For INDOOR use only/ DO NOT expose to direct sunlight, moisture, or extreme temperatures.
• DO NOT use on slippery or uneven ooring.
• Excessive exposure to audio equipment at high volume may lead to hearing loss.
• DO NOT open the BOOM™BUDDY (see warning below).
Internal
• DO NOT OPEN
Caution: To reduce the risk of electric shock and re, do not open the BOOM™BUDDY. There are no user serviceable parts inside.
Refer to your warranty for service information
#!54)/.
FCC CERTIFICATIONS
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Power rating: 12 Volts at 1000/mA
Multimedia Pillow with Built-In SPEAKERS
Boom™Buddy
SET-UP GUIDE DASHBOARD CONTROL PANEL
The BOOM™BUDDY comes with the following:
PARTS LIST:
Dimensions: 32” W x 18” L x 19” H
Weight: 12 lbs.
2 - 3” coaxial mid-high speakers @ 5W 4 Ohms
1 - 12v AC/DC UL listed power adapter
SYSTEM SPECIFICATIONS
1) BOOM™BUDDY
2) AC/DC POWER SUPPLY
3a) RCA CORD
(headphone jack to audio left & right channel connectors)
3b) RCA AUDIO COUPLER
4) RECEPTACLE
5) STORAGE POCKET (on left arm)
6) DASHBOARD CONTROL PANEL
7) SPEAKERS
8) BUILT-IN HANDLE
VOLUME
POWER
INPUT
R L
+
™
(A) POWER SWITCH / VOLUME CONTROL
(B) LED POWER INDICATOR
(C) RCA AUDIO INPUTS
3a
3b
2
8
1
6
7
4
5
Step 1: Insert receptacle (4) into adapter cord (2).
Step 2: Plug adapter (2) into outlet.
Step 3: Turn Power/Volume Control (A) clockwise.
STEP 1
DAISY CHAINING PILLOWS TOGETHER : up to 4 PILLOWS
Step 1:
Step 2:
Step 3:
Step 4:
Connect single end of rst “Y” adapter to RED RCA plug coming from media device. (Fig.1)
Connect single end of second “Y” adapter to WHITE RCA plug coming from media device. (Fig.2)
Cord A (Fig.3): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of rst BOOM™BUDDY.
Cord B (Fig.4): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of second BOOM™BUDDY.
Media Device or TV IN
IN
RCA “Y” ADAPTER
(sold separately)
RCA CORD
(sold separately)
FIRST BUDDY
SECOND BUDDY
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Note: You will need two RCA “Y” adapters (sold separately) and two RCA cords (sold separately) to connect two Boom™Buddys
Audio OUT
Plug the single end of the RCA cord (3a)
into the headphone jack of your device.
Plug the pair of RCA cords into RCA
INPUT (C) on the BOOM™BUDDY.
3a = headphone jack to audio left & right
channel connectors.
CONNECTING TO HAND-HELD GAMES, MP3 PLAYERS & CD/DVD PLAYERS
VOLUME
POWER
INPUT
R L
+
™
COMPUTER
HAND-HELD GAMES
MP3 PLAYERS
CD/DVD PLAYERS
3a
Step 1:
Step 2:
LIMITED WARRANTY: LumiSource, Inc. (“LumiSource”) warrants this product against defects in materials and workmanship for a period of ninety (90) days from the
date of original consumer purchase. If a covered warranty claim is timely made, LumiSource®will, at its sole discretion: (a) repair the product, using new and/or
refurbished replacement parts or (b) replace the product with an identical (or comparable) product, without charge to you other than the initial shipping cost to return the
product. LumiSource®will only pay return shipping charges for destinations within the 48 continguous U.S.A., if the returned product is covered by the limited warranty.
WHAT THIS WARRANTY DOES NOT COVER: This warranty does not cover defects resulting from accidents, alterations, unauthorized repair, failure to follow
instructions, misuse, commercial use, re, ood, or acts of God.
WHAT WE ASK YOU TO DO: If there is a covered defect, please write or email us within 90 days of the date of purchase at the address noted to obtain instructions and
authorization to return the product to LumiSource®. You will need to pack the product securely in packaging providing at least the degree of protection of the original
carton and packing materials and ship it to us at your expense. You will also need to include with the product (a) a copy of your original proof of purchase (retail receipt)
showing the date of purchase and (b) a detailed explanation of the problem(s) requiring service.
TO THE EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH
ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS,
ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE EXTENT PERMITTED BY LAW, LUMISOURCE®
HEREBY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT APPLICABLE
STATE LAW EXCLUDES SUCH DISCLAIMERS, THEN TO THE EXTENT ALLOWED BY LAW, THE TIME
FOR ANY CLAIMS FOR SUCH IMPLIED WARRANTIES SHALL EXPIRE 90 DAYS FROM THE DATE OF
ORIGINAL CONSUMER PURCHASE. TO THE EXTENT PERMITTED BY LAW, LUMISOURCE®IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT
NOT LIMITED TO LOSS OF TIME, INCONVENIENCE, LOSS OF USE OF YOUR PRODUCT, OR PERSONAL
INJURY OR PROPERTY DAMAGE, CAUSED BY YOUR PRODUCT OR ITS FAILURE TO WORK.
This limited warranty gives you specic legal rights. Some states do not allow the exclusion or limitation of incidental or consequential damages, and applicable law
may not permit the exclusion of certain implied warranties. You may also have their rights, which vary, from state to state.
LUMISOURCE, INC. LIMITED WARRANTY
CLEANING/CARE INSTRUCTIONS
Fabric: Use a clean cloth to dab lightly with soap and water. DO NOT rub.
DO NOT immerse in water. DO NOT use detergent.
TROUBLESHOOTING BOOM™BUDDY
If a problem occurs while using this product, please contact us. DO NOT open unit or attempt to repair on your own. It may result in
serious injury from electric shock and void your product warranty.
Q: Why isn’t there sound coming from any of my speakers?
A: Ensure your Boom™Buddy is connected as described in the Setup Guide. Check that the power to the unit is on and the volume is
turned up. Also, make sure your audio device is not set to “MUTE” and volume is turned up.
Q: Why isn’t there sound coming from one of the speakers?
A: Ensure the audio cord to the Boom™Buddy is securely connected as described in the Setup Guide.
Make sure that both the left and right channel audio inputs are securely connected to the Boom™Buddy and audio device.
Q: Where can I get more information?
A: Visit us at www.BoomChair.com or www.LumiSource.com
Contact information: LumiSource, Inc. 2950 Old Higgins Road, Elk Grove Village, IL 60007
E-mail: [email protected]
NOTE: PLEASE DO NOT USE ON HARDWOOD FLOORS, IT MAY CAUSE SCRATCHING.
MAINTENANCE AND REPAIR
CONNECTING TO POWER SUPPLY
2
4
VOLUME
POWER
INPUT
R L
+
™
CONNECTING TO GAME CONSOLES
Step 1:
Step 2:
Plug yellow composite video cable from game
console into video input of TV. (Fig. 1)
Plug Red/White RCA cord from game console into
RCA INPUT (C) of BOOM™BUDDY. (Fig. 2)
Step 1:
Step 2:
Step 3:
Connect Audio Coupler (3b) to Red/
White RCA cord from game console.
Connect one end of RCA cord (sold
separately) into other end of Audio
Coupler (3b).
Connect other end of RCA cord into
RCA INPUT (C) of BOOM™BUDDY .
IN
Note: All game consoles are supplied with a custom connector with
yellow video out and RCA red/white audio out.
3b
GAME CONSOLE TV BOOM™BUDDY
Fig. 1
Fig. 2
Cable supplied with game console
Fig. 3
Alternate Connection:
Connect directly from the TV Audio Out to the Boom™Buddy
Audio Input using RCA audio cords (sold separately).
Note: It may be necessary to extend your Boom™Buddy
further away from your TV or console. Here’s how. (Fig.3)
AUDIO COUPLER (3b)
Cable sold separately
