Lumix DMC-LZ6P User manual

© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
ORDER NO. DSC0702007CE
B26
Digital Camera
DMC-LZ6P
DMC-LZ6PC
DMC-LZ6PL
DMC-LZ6EB
DMC-LZ6EE
DMC-LZ6EF
DMC-LZ6EG
DMC-LZ6EGM
DMC-LZ6GK
Vol. 1
Colour
(S)...........Silver Type
(K)...........Black Type (only P)

2
TABLE OF CONTENTS PAGE PAGE
1 Safety Precaution-------------------------------------------------3
1.1. General Guidelines ----------------------------------------3
1.2. Leakage Current Cold Check ---------------------------3
1.3. Leakage Current Hot Check (See Figure 1.)--------3
1.4. How to Discharge the Capacitor on Flash Top
PCB------------------------------------------------------------4
2Warning--------------------------------------------------------------5
2.1. Prevention of Electro Static Discharge (ESD)
to ElectrostaticallySensitive (ES) Devices-----------5
2.2. How to Replace the Lithium Battery-------------------6
3 Service Navigation------------------------------------------------7
3.1. Introduction --------------------------------------------------7
3.2. General Description About Lead Free Solder
(PbF) ----------------------------------------------------------7
3.3. Important Notice 1:(Other than U.S.A. and
Canadian Market)------------------------------------------7
3.4. How to Define the Model Suffix (NTSC or PAL
model)---------------------------------------------------------8
4 Specifications---------------------------------------------------- 11
5 Location of Controls and Components------------------12
6 Service Mode-----------------------------------------------------13
6.1. Error Code Memory Function -------------------------13
6.2. Confirmation of Firmware Version -------------------16
7 Service Fixture & Tools ---------------------------------------17
7.1. Service Fixture and Tools------------------------------17
7.2. When Replacing the Main PCB ----------------------18
7.3. Service Position ------------------------------------------18
8 Disassembly and Assembly Instructions---------------19
8.1. Disassembly Flow Chart--------------------------------19
8.2. PCB Location----------------------------------------------19
8.3. Disassembly Procedure --------------------------------20
8.4. Disassembly Procedure for the Lens ---------------24
8.5. Assembly Procedure for the Lens -------------------26
8.6. Removal of the CCD Unit ------------------------------27
9 Measurements and Adjustments --------------------------28
9.1. Matrix Chart for Replaced Part and Necessary
Adjustment-------------------------------------------------28
10 Maintenace--------------------------------------------------------29
10.1. Cleaning Lens and LCD Panel -----------------------29

3
1 Safety Precaution
1.1. General Guidelines
1. IMPORTANT SAFETY NOTICE
There are special components used in this equipment
which are important for safety. These parts are marked by
in the Schematic Diagrams, Circuit Board Layout,
Exploded Views and Replacement Parts List. It is essen-
tial that these critical parts should be replaced with manu-
facturer’s specified parts to prevent X-RADIATION,
shock, fire, or other hazards. Do not modify the original
design without permission of manufacturer.
2. An Isolation Transformer should always be used during
the servicing of AC Adaptor whose chassis is not isolated
from the AC power line. Use a transformer of adequate
power rating as this protects the technician from acci-
dents resulting in personal injury from electrical shocks. It
will also protect AC Adaptor from being damaged by acci-
dental shorting that may occur during servicing.
3. When servicing, observe the original lead dress. If a short
circuit is found, replace all parts which have been over-
heated or damaged by the short circuit.
4. After servicing, see to it that all the protective devices
such as insulation barriers, insulation papers shields are
properly installed.
5. After servicing, make the following leakage current
checks to prevent the customer from being exposed to
shock hazards.
1.2. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed metal-
lic cabinet part on the equipment such as screwheads,
connectors, control shafts, etc. When the exposed metal-
lic part has a return path to the chassis, the reading
should be between 1 MΩand 5.2 MΩ. When the exposed
metal does not have a return path to the chassis, the
reading must be infinity.
1.3. Leakage Current Hot Check
(See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5 kΩ, 10 W resistor, in parallel with a 0.15 μF
capacitor, between each exposed metallic part on the set
and a good earth ground, as shown in Figure 1.
3. Use an AC voltmeter, with 1 kΩ/V or more sensitivity, to
measure the potential across the resistor.
4. Check each exposed metallic part, and measure the volt-
age at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 V RMS.
A leakage current tester (Simpson Model 229 or equiva-
lent) may be used to make the hot checks, leakage cur-
rent must not exceed 1/2 mA. In case a measurement is
outside of the limits specified, there is a possibility of a
shock hazard, and the equipment should be repaired and
rechecked before it is returned to the customer.
Figure. 1

4
1.4. How to Discharge the Capacitor on Flash Top PCB
CAUTION:
1. Be sure to discharge the capacitor on FLASH TOP PCB.
2. Be careful of the high voltage circuit on FLASH TOP PCB when servicing.
[Discharging Procedure]
1. Refer to the disassemble procedure and Remove the necessary parts/unit.
2. Put the insulation tube onto the lead part of Resistor (ERG5SJ102:1kΩ/5W).
(an equivalent type of resistor may be used.)
3. Put the resistor between both terminals of capacitor on FLASH TOP PCB for approx. 5 seconds.
4. After discharging confirm that the capacitor voltage is lower than 10V using a voltmeter.
Fig. F1

5
2Warning
2.1. Prevention of Electro Static Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices.
The following techniques should be used to help reduce the incidence of component damage caused by electro static discharge
(ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an antistatic solder removal device. Some solder removal devices not classified as "antistatic (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
CAUTION :
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) suf-
ficient to damage an ES device).

6
2.2. How to Replace the Lithium Battery
2.2.1. Replacement Procedure
1. Remove the MAIN PCB. (Refer to Disassembly Procedures.)
2. Unsolder the each soldering point of electric lead terminal for Lithium battery (Ref. No. “B9101” at foil side of Main PCB) and
remove the Lithium battery together with electric lead terminals. Then replace it into new one.
NOTE:
The Type No. ML614S/F9FE includes electric lead terminals.
NOTE:
This Lithium battery is a critical component.
(Type No.: ML614S/F9FE Manufactured by Matsushita Battery Industrial Co.,Ltd.)
It must never be subjected to excessive heat or discharge.
It must therefore only be fitted in requirement designed specifically for its use.
Replacement batteries must be of same type and manufacture.
They must be fitted in the same manner and location as the original battery, with the correct polarity contacts observed.
Do not attempt to re-charge the old battery or re-use it for any other purpose.
It should be disposed of in waste products destined for burial rather than incineration.
NOTE:
Above caution are also applicable for below batteries which is for DMC-LZ6 all series, as well.
1. AA Oxyride batteries
2. AA Alkaline batteries
3. AA Rechargeable Ni-MH (nickel-metal hydride) batteries

7
3 Service Navigation
3.1. Introduction
This service manual contains technical information, which allow service personnel’s to understand and service this model.
Please place orders using the parts list and not the drawing reference numbers.
If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual.
3.2. General Description About Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the
normal solder.
Distinction of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30°C
(662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn) 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
3.3. Important Notice 1:(Other than U.S.A. and Canadian Market)
1. The service manual does not contain the following information, because of the impossibility of servicing at component level
without concerned equipment/facilites.
a. Schematic diagram, Block Diagram and PCB layout of MAIN PCB.
b. Parts list for individual parts for MAIN PCB.
When a part replacement is required for repairing MAIN PCB, replace as an assembled parts. (Main PCB)
2. The following category is/are recycle module part. please send it/them to Central Repair Center.
• MAIN PCB (VEP56042B) : Excluding replacement of Lithium Battery

8
3.4. How to Define the Model Suffix (NTSC or PAL model)
There are four kinds of DMC-LZ6, regardless of the colours.
• a) DMC-LZ6P/PC
• b) DMC-LZ6EB/EF/EG/EGM
• c) DMC-LZ6EE
• d) DMC-LZ6PL/GK
What is the difference is that the “INITIAL SETTINGS” data which is stored in Flash ROM mounted on Main PCB.
3.4.1. Defining methods:
To define the model suffix to be serviced, refer to the nameplate which is putted on the bottom side of the Unit.
NOTE:
After replacing the MAIN PCB, be sure to achieve adjustment.
The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site
in “TSN system”, together with Maintenance software.

9
3.4.2. INITIAL SETTINGS:
When you replace the Main PCB, be sure to perform the initial settings after achieving the adjustment by ordering the following pro-
cedure in accordance with model suffix of the unit.
1. IMPORTANT NOTICE:
Before proceeding Initial settings, be sure to read the following CAUTIONS.
2. PROCEDURES:
• Preparation. Proceed the picture back up from the unit (Refer to above "CAUTION 2")
•Step 1. The temporary cancellation of initial setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
While keep pressing [ E.ZOOM ] and “[ UP ] of Cross key” simultaneously, turn the Power on.
•Step 2. The cancellation of initial setting:
Set the mode dial to “[ Playback ]”.
Press [ E.ZOOM ] and “[ UP ] of Cross key” simultaneously, then turn the Power off.
•Step 3. Turn the Power on:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”, and then turn the Power on.
•Step 4. Display the INITIAL SETTING:
While keep pressing [ MENU ] and “[ RIGHT ] of Cross key” simultaneously, turn the Power off.

10
•Step 5. Set the INITIAL SETTING: (Refer to “CAUTION 1”)
[Caution for befor settings]
Once "NONE(JAPAN)" (Area for Japan) or "P" (Area for Noth America) is selected with "INITIAL SETTINGS", other areas will
not displayed even if "INITIAL SETTINGS" menu is displayed again, thus, the area can not be changed.
Select the area carefully.
Select the area with pressing “[ UP ] / [ DOWN ] of Cross key”, and then press the “[ RIGHT ] of Cross key”.
The only set area is displayed, and then press the “[ RIGHT ] of Cross key” after confirmation.
(The unit is powered off automatically.)
Confirm the display of “PLEASE SET THE CLOCK” in English when the unit is turned on again.
•Step 6. CONFIRMATION:
The display shows “PLEASE SET THE CLOCK” when turn the Power on again.
When the unit is connected to PC with USB cable, it is detected as removable media.
(When the “GK” model suffix is selected, the display shows “PLEASE SET THE CLOCK” in Chinese.)
1) As for your reference Default setting condition is given in the following table.
•Default setting (After “INITIAL SETTINGS”)
MODEL VIDEO OUTPUT LANGUAGE DATE REMARKS
a) DMC-LZ6P/PC/PL NTSC English Month/Date/Year
b) DMC-LZ6EB/EG/EGM PAL English Date/Month/Year
c) DMC-LZ6EF PAL French Date/Month/Year
d) DMC-LZ6EE PAL Russian Date/Month/Year
e) DMC-LZ6GK PAL Chinese (simplified) Year/Month/Date

11
4 Specifications

12
5 Location of Controls and Components

13
6 Service Mode
6.1. Error Code Memory Function
1. General description
This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the
latest. When the error is occurred more than 16, the oldest error is overwritten in sequence.
The error code is not memorized when the power supply is shut down forcibly (when the unit is powered on by the battery, the
battery is pulled out) because the error code is memorized to FLASH ROM when the unit is powered off.
2. How to display
The error code can be displayed by the following procedure:
Before perform the error code memory function, connect the AC adaptor or insert the battery.
(Since this unit has built-in memory, this error code memory function can be performed without inserting SD memory card.)
•1. The temporary cancellation of initial setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
While keep pressing [ E.ZOOM ] and “[ UP ] of Cross key” simultaneously, turn the Power on.
•2. The display of error code:
Press [ E.ZOOM ], [ MENU ] and “[ LEFT ] of Cross key” simultaneously with the step 1 condition.
The display is changed as shown below when the above buttons is pressed simultaneously.
Normal display →Error code display →Operation history display →Normal display →.....
Example of Error Code Display
•3. The change of display:
The error code can be memorized 16 error codes in sequence, however it is displayed 5 errors on the LCD.
Display can be changed by the following procedure:
“[ UP ] or [ DOWN ] of Cross key” : It can be scroll up or down one.
“[ LEFT ] or [ RIGHT ] of Cross key” : It can be display last 5 error or another 5 error.
•4. How to read the error date:
The error date code is displayed from the left in order at the year, month, day, time.
Error date information is acquired from "Clock setting" information when the error occurs. When the clock is not setting, it is
displayed as “00000000”.

14
•5. How to read the error code:
One error code is displayed for 8 bit, the contents of error codes is indicated the table as shown below.
Attribute Main item Sub item Error code Contents (Upper)
High 4 bits Low 4 bits Check point (Lower)
LENS Lens drive OIS 18*0 1000 PSD (X) error. Hall element (X axis) position detect error in OIS unit.
OIS Unit
2000 PSD (Y) error. Hall element (Y axis) position detect error in OIS unit.
OIS Unit
3000 GYRO (X) error. Gyro (IC7101: X axis) detect error on Main P.C.B..
IC7101 (Gyro element) or IC6001 (VENUS 3)
4000 GYRO (Y) error. Gyro (IC7102: Y axis) detect error on Main P.C.B..
IC7102 (Gyro element) or IC6001 (VENUS 3)
5000 MREF error (Reference voltage error).
IC7001 (LENS drive) or IC6001 (VENUS 3)
6000 Drive voltage (X) error.
VENUS 3 AD value error, LENS Unit, LENS flex breaks etc.
7000 Drive voltage (Y) error.
VENUS 3 AD value error, LENS Unit, LENS flex breaks etc.
C.B./Zoom 0100 HP Low detect error (C.B. encoder (full retract) always Low detect).
FP9001-(2,10) signal line or IC6001 (VENUS 3)
0200 HP High detect error (C.B. encoder (full retract) always High detect).
FP9001-(1,12) signal line or IC6001 (VENUS 3)
0300 ENC1 detect error (C.B. motor encoder detect error).
FP9001-(2) signal line or IC6001 (VENUS 3)
0400 ENC2 detect error (C.B. motor encoder detect error).
FP9001-(10) signal line or IC6001 (VENUS 3)
Focus 0001 HP Low detect error (Focus encoder always Low detect error).
FP9001-(27) signal line or IC6001 (VENUS 3)
0002 HP High detect error (Focus encoder always High detect error).
FP9001-(27) signal line or IC6001 (VENUS 3)
Lens 18*1 0000 Power ON time out error.
Lens drive system
18*2 0000 Power OFF time out error.
Lens drive system
Adj.History OIS 19*0 2000 OIS adj. Yaw direction amplitude error (small)
3000 OIS adj. Pitch direction amplitude error (small)
4000 OIS adj. Yaw direction amplitude error (large)
5000 OIS adj. Pitch direction amplitude error (large)
6000 OIS adj. MREF error
7000 OIS adj. time out error
8000 OIS adj. Yaw direction off set error
9000 OIS adj. Pitch direction off set error
A000 OIS adj. Yaw direction gain error
B000 OIS adj. Pitch direction gain error
C000 OIS adj. Yaw direction position sensor error
D000 OIS adj. Pitch direction position sensor error
E000 OIS adj. other error

15
About "*" indication in the above table:
The third digit from the left is different as follows.
- In case of 0 (example: 18001000)
When the third digit from the left shows "0", this error occurred under the condition of INITIAL SETTINGS has been
completed.
It means that this error is occurred basically at user side.
- In case of 8 (example: 18801000)
When the third digit from the left shows "8", this error occurred under the condition of INITIAL SETTINGS has been
released.
(Example; Factory assembling-line before unit shipment, Service mode etc.)
It means that this error is occurred at service side.
•6. How to returned to Normal Display:
Turn the power off and on, to exit from Error code display mode.
NOTE:
The error code can not be initialized.
HARD VENUS A/D Flash 20*0 0000 Flash charging error.
IC6001-(247) signal line or Flash charging circuit
FLASH ROM
(EEPROM
Area)
FLASH ROM
(EEPROM
Area)
2B*0 0001 EEPROM read error
IC6002 (FLASH ROM)
0002 EEPROM write error
IC6002 (FLASH ROM)
SYSTEM RTC 2C*0 0001 SYSTEM IC initialize failure error
Communication between IC6001 (VENUS 3) and IC9101 (SYSTEM)
SOFT CPU Reset 30*0 0001
|
0007
NMI reset
Non Mask-able Interrupt
(30000001-30000007 are caused by factors)
Card Card 31*0 0001 Card logic error
SD memory card data line or IC6001 (VENUS 3)
0002 Card physical error
SD memory card data line or IC6001 (VENUS 3)
0004 Write error
SD memory card data line or IC6001 (VENUS 3)
39*0 0005 Format error
CPU,
ASIC hard Stop 38*0 0001 Camera task finish process time out.
Communication between Lens system and IC6001 (VENUS 3)
0002 Camera task invalid code error.
IC6001 (VENUS 3)
0100 File time out error in recording motion image
IC6001 (VENUS 3)
0200 File data send error in recording motion image
IC6001 (VENUS 3)
0300 Single or burst recording brake time out.
Operation Power on 3B*0 0000 FLASHROM processing early period of camera during movement.
Zoom Zoom 3C*0 0000 Inperfect zoom lens processing.
Zoom lens
35*0 0001
|
0007
Software error.
(0-7bit : command, 8-15bit : status)
35*1 0000 Though record preprocessing is necessary, it is not called.
35*2 0000 Though record preprocessing is necessary, it is not completed.
3C*0 0000 Inperfect zoom lens processing.
Attribute Main item Sub item Error code Contents (Upper)
High 4 bits Low 4 bits Check point (Lower)

16
6.2. Confirmation of Firmware Version
The Firmware version can be confirmed by ordering the following steps:.
•Step 1. The temporary cancellation of initial setting:
Set the mode dial to “[ Normal picture mode ] (Red camera mark)”.
Insert the SD memory card which has a few photo data.
While keep pressing [ E.ZOOM ] and “[ UP ] of Cross key” simultaneously, then turn the power on.
•Step 2. Confirm the version:
Set the mode dial to “[ Playback ]” and then press [ DISPLAY ] to switch to LCD with indication. (Fig. A)
Press [ E.ZOOM ] and “[ DOWN ] of Cross key” simultaneously. (No need to keep pressing.)
(The version information is displayed on the LCD with light blue colour letters.) (Fig. B)
CAUTION:
The version information does not display if the LCD has switched to LCD with indication already.
In this case, press [ DISPLAY ] to switch to LCD with indication.
<Point>
• The firmware version and EEPROM version can be confirmed with the information (1).
• The information (2), (3) are just reference.

17
7 Service Fixture & Tools
7.1. Service Fixture and Tools
The following Service Fixture and tools are used for checking and servicing this unit.

18
7.2. When Replacing the Main PCB
After replacing the MAIN PCB, be sure to achieve adjustment.
The adjustment instruction is available at “software download” on the “Support Information from NWBG/VDBG-PAVC” web-site in
“TSN system”, together with Maintenance software.
7.3. Service Position
This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.
Table S1 Extension Cable List
CAUTION-1. (When servicing FLASH TOP PCB)
1. Be sure to discharge the capacitor on FLASH TOP PCB.
Refer to “HOW TO DISCHARGE THE CAPACITOR ON FLASH TOP PCB”.
The capacitor voltage is not lowered soon even if the AC Cord is unplugged or the battery is removed.
2. Be careful of the high voltage circuit on FLASH TOP PCB.
3. DO NOT allow other parts to touch the high voltage circuit on FLASH TOP PCB.
No. Parts No. Connection Form
1 VFK1951 FP9001 (MAIN) - LENS UNIT 39PIN 0.3 FFC
2 VFK1978 FP9002 (MAIN) - CCD UNIT 31PIN 0.3 FFC
3 VFK1950 FP9003 (MAIN) - LCD UNIT 33PIN 0.3 FFC
4 VFK1974 FP9004 (MAIN) - LCD UNIT 4PIN 0.5 FFC
5 VFK1870 PP9001 (MAIN) - PS8001 (FLASH TOP) 30PIN B to B

19
8 Disassembly and Assembly Instructions
8.1. Disassembly Flow Chart
8.2. PCB Location

20
8.3. Disassembly Procedure 8.3.1. Removal of the Rear Case Unit
Fig. D1
No. Item Fig Removal
1 Rear Case Unit Fig. D1 Card
Battery
6 Screws (A)
Side Ornament
FP9003(Flex)
FP9004(Flex)
2 Locking tabs
Rear Case Unit
2 LCD Unit Fig. D2 1 Screw (B)
LCD Holder B
LCD Frame
LCD Unit
3 SD Cover Fig. D3 Rear Knob
SD Earth Plate
Shaft
Earth Plate
LED Panel R
SD Cover
4 Front Case Unit Fig. D4 1 Screw (C)
FP9001(Flex)
FP9002(Flex)
Front Case Unit
5 Top Case Unit Fig. D5 1 Screw (D)
PP9001(Connector)
Top Case Unit
6 Flash Top P.C.B. Fig. D6 3 Screws (E)
2 Locking tabs
Flash Top P.C.B.
Fig. D7 NOTE (When Installing)
7 AF Assist LED P.C.B.
Main P.C.B. Fig. D8 2 Locking tabs
AF Panel
Solder (2 points)
3 Screws (F)
AF Assist LED P.C.B.
Main P.C.B.
8 Lens Unit Fig. D9 3 Screws (G)
Lens Unit
