Lyrix Powerball User manual

User Guide

Package Contents:

Lyrix PowerBall Protective Lid

Charging Cable (USB to Micro-USB)

7" Lanyard User Guide

Specifications:

Bluetooth: v3.0 with AVRCP and

A2DP Support

Output Power: 1.6 RMS

Speaker: 3 Ohm 3 Watt sealed chamber

passive radiator design with

neodymium magnet

Frequency Response: 40Hz-20kHz (-10dB)

Battery: Li-ion rechargeable 3.7v 500mAh

Audio Jack: 3.5mm Line-in

Range: 30+ feet (10+ meters) line-of-sight

Operating Time: 12 hours under normal

playing conditions

Charging Standard: DC 5V, 500mA

Charging Time: Less than four hours

Attach Lanyard Here

On/Off Switch

Audio- n Jack

Micro-USB

Charging Port

Play/Pause

Button

ncrease Volume/Skip

Ahead Button Decrease Volume/Skip

Back Button

Bluetooth

ndicator LED

Battery Charge

ndicator LED

Important: Make sure that your Lyrix PowerBall is fully charged before first use.

Charging Your Lyrix PowerBall

nsert the Micro-USB end of the Charging Cable into the Micro-USB Charging Port and then

insert the USB end of the Charging Cable into a USB port on your computer or a UL/ETL

Approved 5V/1A USB wall adapter.

The Battery Charge ndicator LED will glow red while the battery is charging. t will turn green

when the battery is fully charged.

The Battery Charge ndicator LED will blink red when the battery charge is low and it is time

to recharge your Lyrix PowerBall.

At A Glance:

Pairing Your Lyrix PowerBall with a Bluetooth Device

Remove the protective lid and slide the On/Off Switch to the “ON” position. The Bluetooth

ndicator LED will blink on and off. Activate the Bluetooth function on the device you want to

pair with your Lyrix PowerBall and select “Lyrix PowerBall” from the list of available Bluetooth

devices. The Bluetooth ndicator LED will stop blinking and glow steadily when the device

has successfully paired with your Lyrix PowerBall.

Playing Music

Once you have paired your Bluetooth device with your Lyrix PowerBall, start the music playing

on your Bluetooth device. f the music does not start playing through your Lyrix PowerBall,

press the Play/Pause Button on the PowerBall. To pause the music, press the Play/Pause Button

again. To turn the volume up, press and release the ncrease Volume/Skip Ahead Button multiple

times. To turn the volume down, press and release the Decrease Volume/Skip Back Button

multiple times. To skip to the next song, press and hold the ncrease Volume/Skip Ahead Button.

To skip back to the beginning of the song that is playing, press and hold the Decrease

Volume/Skip Back Button. To skip back to the previous song, quickly release and then press

and hold the Decrease Volume/Skip Back Button a second time. Note: When you are done

playing music, slide the On/Off Switch to the “OFF” position to conserve battery power.

Connecting Your Lyrix PowerBall to a Non-Bluetooth Device

Remove the protective lid and slide the On/Off Switch to the “ON” position. Use a 3.5mm

audio cable (not included) to connect Your Lyrix PowerBall to your non-Bluetooth device. Sart

the music playing on the connected device. Note: When you are done playing music, slide

the On/Off Switch to the “OFF” position to conserve battery power.

Troubleshooting

The Lyrix PowerBall should work well within the effective range of approximately 30 feet

(10 meters). f it does not, please try the following:

1) Make sure that your Lyrix PowerBall is charged up and turned on.

2) Make sure that the device with which you want to pair has its Bluetooth setting in the

“On” position and is within the effective range of 40 feet (12 meters).

3) Move your Lyrix PowerBall and/or Bluetooth Device away from sources of electromagnetic

interference such as cordless phones, microwave ovens, wireless network routers, or

other Bluetooth devices.

4) f you have difficulty connecting your device with your Lyrix PowerBall after it has been

paired with your device, delete it from your device and re-pair.

5) f you have too many Bluetooth devices listed under “Devices” the pairing process

may take longer or be unsuccessful. Delete one or more of the devices to improve

pairing performance.

Caution

1) Use only with USB version 2.0 or higher. Do not use with “Power USB.”

2) Contains no user-serviceable parts. Do not disassemble.

3) Do not expose to water or damp conditions.

4) Do not expose to heat or high temperatures.

How to Properly Dispose of Batteries

This product contains a lithium-ion battery. To properly dispose of expired batteries, view your

city’s website or newsletter to find what guidelines, if any, should be followed and to make

note of their hazardous waste collection days.

Technical Support

f you have any questions about the operation and/or performance of this product that were

not covered in this user guide, please email support+lyrixpowerball@pctreasures.com or

call (248) 236-0061, Mon.-Fri., 9:30am-5:30pm for assistance.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. f this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures: a) Reorient or relocate the receiving antenna b) ncrease the separation between the equipment and receiver c) Consult the dealer or an

experienced radio/TV technician for help.

Note 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate

the equipment.

Important Note

FCC Radiation Exposure Statement:

1. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the

specific operating instructions for satisfying RF exposure compliance.

2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

One (1) Year Limited arranty

PC Treasures, nc. warrants this product to be free from defects in materials and workmanship. This warranty covers the original purchaser only, and

is not transferable to anyone who subsequently buys, leases, or otherwise obtains from you. Your One Year Limited Warranty begins on the date of

purchase. Your original purchase invoice or sales receipt, showing date of purchase, is your proof of warranty period. The duration of this warranty

does not extend beyond the initial period of coverage should any repairs or replacements be made or performed.

This warranty does not extend to any product not purchased from PC Treasures, nc., or an authorized PC Treasures, nc. reseller. This warranty does

not extend to product that has been damaged or rendered defective as a result of use for which the product is not intended, is contrary to instructions

provided in the user guide, as a result of the use of parts not manufactured or sold by PC Treasures, nc., or due to any misuse, abuse, negligence,

modification, or improper packing when returning product to PC Treasures, nc.

EXCEPT FOR THE WARRANTY SET FORTH HERE N, PC TREASURES, NC. D SCLA MS ALL OTHER WARRANT ES, EXPRESSED OR MPL ED OR STATUTORY,

NCLUD NG BUT NOT L M TED TO THE MPL ED WARRANT ES OF MERCHANTAB L TY OR F TNESS FOR A PART CULAR PURPOSE. ANY MPL ED WAR-

RANT ES THAT MAY BE MPOSED BY APPL CABLE LAW ARE L M TED TO THE TERM OF TH S WARRANTY. N NO EVENT SHALL PC TREASURES, NC. BE

L ABLE FOR ANY NC DENTAL, SPEC AL OR CONSEQUENT AL DAMAGES, NCLUD NG BUT NOT L M TED TO LOSS OF BUS NESS, PROF TS, DATA OR USE,

WHETHER N AN ACT ON N CONTRACT OR TORT OR BASED ON A WARRANTY, AR S NG OUT OF OR N CONNECT ON W TH THE USE OR PERFORMANCE

OF THE PRODUCT. YOU AGREE THAT REPA R, AND (UPON AVA LAB L TY) REPLACEMENT, AS APPL CABLE, UNDER THE WARRANTY SERV CES DESCR BED

HERE N S YOUR SOLE AND EXCLUS VE REMEDY W TH RESPECT TO ANY BREACH OF THE PC TREASURES, NC. L M TED WARRANTY SET FORTH HERE N.

How Do I Obtain arranty Service?

n the event that you require warranty service, please email to warranty+lyrixpowerball@pctreasures.com or contact PC Treasures, nc. directly at

(248) 236-0061 to report a claim, at which time PC Treasures, nc. technicians will attempt to solve any issues. f unable to resolve your issue, you

will be issued an RMA to authorize the return of the item for repair/replacement. All charges incurred while returning product, including postage,

duties, export taxes, and customs duties, are the responsibility of purchaser, and purchaser assumes all risk of loss during shipment.

Models Covered Under This arranty: 08940, 08944, 08945, 08946, 08947, 09005

Digital Treasures is a division of PC Treasures, nc., 3720 Lapeer Rd., Auburn Hills, M 48326 • (248) 236-0061• www.digitaltreasures.com • Made in China
