136-174 MHz, 110 WATT POWER AMPLIFIER
19D902797G1
DESCRIPTION
The VHF Power Amplifier Assembly is awide band RF
power amplifier operating over the entire 136 to 174 MHz
range without tuning or band splitting. Its main function is
to amplify the 10 mW FM signal from the Transmitter
SynthesizertotheratedRFoutputof110 watts at theantenna
port. The output of the Power Amplifier Assembly is adjust-
able from 65 to 135 watts at the PA output J104. This
corresponds to a rated RF output of 55 to 110 watts at the
antenna.
The assembly consists of a printed wiring board (A1)
and associated components, including a power module and
three RF power transistors, mounted to the heat sink assem-
bly. The printed wiring board (A1) contains both the power
amplifier circuitry (100 series components) and the power
control circuitry (200 series components).
Unfiltered supply voltage, A+, for the power amplifier
circuits enters the assembly via feedthrough capacitor, C1.
Power cable W4 routes the A+ from CI to J103 on the PWB.
Filtered A+ voltage for the power control circuit enters the
assembly via control cable W13 which connects to the PWB
at J201.
The Power Control circuitry sets the output power level
by adjusting the PA Power Set level. It keeps the output
power constant despite variations in input power, power
amplifier gain, or temperature through the use of a feedback
control loop in the PA assembly.
Maintenance Manual
LBI-38531G
M/A-COM Wireless Systems
3315 Old Forest Road
Lynchburg, Virginia 24501
(Outside USA, 434-385-2400) Toll Free 800-528-7711
www.macom-wireless.com Printed in U.S.A.

CIRCUIT ANALYSIS
POWER AMPLIFIER
The power amplifier section of the PA Board consists of
an Exciter, a Low Level Amplifier, a Driver, and the Power
AmplifierFinals.Allthesegainstageshaveaninputandoutput
impedance of 50 ohms. Figure 1 is a block diagram showing
the signal flow within the Power Amplifier Assembly.
Exciter (UIOI)
The Exciter stage uses a broadband silicon monolithic
microwave integrated circuit (MMIC) amplifier. The signal
from transmitter synthesizer, typically 10 dBm (10 mW), is
input to the Exciter through a 10 dB resistive pad (R100 &
R102). The Exciter amplifies the resulting 0 dBm (1 mW)
signal to 20 dBm (100 mW). Following the Exciter is a 3 dB
resistive pad (R104 & R106). This attenuator reduces the
MMIC output power to 17 dBm (50 mW).
The MMIC requires a 5 volt supply source. The 8 volt
regulator (U100) provides the 5 volts to the MMIC via a
dropping resistor R103.
Low Level Amplifier(U1O2)
TheLowLevelAmplifier(LLA)stage usesa50 ohm thick
film RF Power Module to amplify and control of the output
power. Internally, the module is a two stage amplifier. The
power control circuitry controls the gain of the first stage by
varying the collector voltage of Q203. The second stage gain
remains constant with A + providing the DC supply voltage.
The signal from the Exciter stage, typically 17 dBm (50
mW), is input into the LLA. Under maximum Power Set
conditions, the LLA amplifies the signal to a typical output
level of 40 dBm (10 W).
Driver (Q101)
The driver is a 6 dB RF amplifier. Anetwork consisting of
C114, C117 and C139 and L103 and L105 provides interstage
impedance matchingbetween U102 andQ101.The signal from
the LLA, typically 40 dBm (10 W), is amplified to 46 dBm (40
W). Impedance matching between the driver output and the
input to U103 is provided by C145, C148, C152, C153, and
L108. The splitter, U103, is a quadrature 90° hybrid coupler. It
divides the signal and applies equal power to the two Power
Amplifier Finals, Q102 and Q103.
