M-Elec LOX User manual

• Same price as standard connections
• Maintenance Free connections
• Fast & easy snap install
• Fits up to 4mm2cable
Product information
  
Solid conductor 0.2-4mm/ 24-12AWG
Stranded conductor 0.2-4mm/ 24-12AWG
Fine stranded conductor 0.14-4mm/ 24-12AWG
Strip length 11mm
Voltage 240V
Current 20A
Temperature range (-40°C~+105°C)
Dimensions: 19.97x14x10.42mm 19.97x19.6x10.42mm 19.97x30.8x10.42mm
Weight: 0.002kg 0.003kg 0.0046kg
Warranty: 3 Years
TECHNICAL INFORMATION Data subject to change, please visit our website for upto date specications: melec.com.au
 For further information about our Warranties please go to: 
10.2
3
year warranty

 For further information about our Warranties please go to: 
INSTALLATION GUIDE
1. Strip the wire back by 11mm.
2. Lift up the lever of the LOX connector to open the port.
3. insert the wire ensuring that it is pushed all the way in.
4. After the wire is inserted, push the lever back down. Repeat steps 1 to 3 for additional connections. To remove the wire push the
lever up and pull the wire back out.
PLEASE NOTE: ENSURE THAT THE CABLE IS PUSHED ALL THE WAY INTO THE CONNECTOR FOR A PROPER AND SECURE CONNECTION
