Overview
This document explains how to connect the TRC-8543.
Note Before you begin, complete the soware and hardware installation
procedures in your chassis documentation.
Note The guidelines in this document are specific to the TRC-8543. The
other components in the system might not meet the same safety ratings.
Refer to the documentation for each component in the system to
determine the safety and EMC ratings for the entire system.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation.
Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises
en garde de la documentation d'utilisation. L'utilisation du produit de
toute autre façon que celle spécifiée risque de l'endommager et de
compromettre la protection de sécurité intégrée.
Safety Guidelines for Hazardous Locations
The TRC-8543 is suitable for use in hazardous locations; , and hazardous locations;
and nonhazardous locations only. Follow these guidelines if you are installing the
TRC-8543 in a potentially explosive environment. Not following these guidelines
may result in serious injury or death.
© National Instruments 3
TRC-8543

Caution Do not disconnect bus-side connector unless power has been
switched o or the area is known to be nonhazardous.
Caution Do not unplug the TRC-8543 unless power has been switched o
or the area is known to be nonhazardous.
Caution Substitution of components may impair suitability for Class I,
Division 2, or Zone 2.
Caution The system must be installed in an enclosure certified for the
intended hazardous (classified) location, having a tool secured cover/door,
where a minimum protection of at least IP54 is provided.
Caution For Zone 2 applications, install a protection device between the
CAN bus and the TRC-8543CAN pins. The device must prevent the CAN
Port-to-COM voltage from exceeding 55 V if there is a transient overvoltage
condition.
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The TRC-8543 has been evaluated as equipment under DEMKO ATEX and is IECEx
certified. Each TRC-8543 is marked and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C.
Caution Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value of 85 V at the supply
terminals to the equipment.
Caution The system shall only be used in an area of not more than
Pollution Degree 2, as defined in IEC/EN 60664-1.
ni.com
4
TRC-8543

Caution The system shall be mounted in an ATEX/IECEx-certified
enclosure with a minimum ingress protection rating of at least IP54 as
defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the
use of a tool.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits
for electromagnetic compatibility (EMC) stated in the product specifications. These
requirements and limits provide reasonable protection against harmful interference
when the product is operated in the intended operational electromagnetic
environment.
This product is intended for use in industrial locations. However, harmful
interference may occur in some installations, when the product is connected to a
peripheral device or test object, or if the product is used in residential or
commercial areas. To minimize interference with radio and television reception and
prevent unacceptable performance degradation, install and use this product in strict
accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved
by National Instruments could void your authority to operate it under your local
regulatory rules.
Notice To ensure the specified EMC performance, operate this product
only with shielded cables and accessories. Do not use unshielded cables or
accessories unless they are installed in a shielded enclosure with properly
designed and shielded input/output ports and connected to the product
using a shielded cable. If unshielded cables or accessories are not properly
installed and shielded, the EMC specifications for the product are no
longer guaranteed.
© National Instruments 5
TRC-8543

Mounting the TRC-8543
Caution The TRC-8543 is a thermally active device that dissipates heat.
Refer to the user manual of the host this device directly connects to for
specific information regarding thermal management. Not following
mounting requirements may aect the system ambient temperature
and/or the measurement accuracy of modules in the system.
Caution To meet thermal management requirements, do not zip tie more
than six cables in a bundle, and allow for air flow around the bundle. If
used with a cRIO or cDAQ chassis, mount all cables at least 152 mm
(6.0 in.) from the chassis and do not mount more than six cables directly
beneath the chassis.
You can route and strain relieve the TRC-8543 similarly to ordinary cables. You also
can panel mount it using its removable jackscrews, zip tie, or screw mount it. The
screw mounting holes support #6 and M3 screws spaced 35.56 mm (1.400 in.)
center-to-center, with minimum length of 23 mm (7/8 in.). The TRC-8543 supports
zip ties up to 5.33 mm (0.210 in.) wide.
The following figure shows jackscrews, zip tie mounting slots, and screw mounting
holes on the TRC-8543.
Figure 1. TRC-8543 Mounting Features
Panel Mounting the TRC-8543
The recommended panel mounting cutout dimensions are shown below.
ni.com
6
TRC-8543

Figure 2. Recommended Cutout Dimensions
The jackscrews included with the TRC-8543 work with panel thicknesses up to
2.21 mm (0.087 in.).
Caution Tighten the jackscrews to a maximum torque of 0.56 N · m
(5.0 lb · in.).
If your panel is thicker than 2.21 mm (0.087 in.), you can mill out a recessed pocket
for the TRC-8543. The following figure shows the recommended pocket dimensions
and cutout position.
Figure 3. Recommended Pocket Dimensions
Wiring to the TRC-8543
The TRC-8543 is used with an NI-XNET interface host port.
Figure 4. TRC-8543 Connections
The TRC-8543 has one 9-pin male D-Sub connector that provides connections to a
CAN bus. The TRC-8543 has pins for CAN_H and CAN_L, to which you connect the
CAN bus signals. Connect these signals using twisted-pair cable.
The port has two common pins (COM) that are internally connected to the TRC-8543
isolated reference and serve as the reference ground for CAN_H and CAN_L. You can
© National Instruments 7
TRC-8543

connect the CAN bus reference ground (sometimes referred to as CAN_V-) to one or
both COM pins.
The D-Sub connector shell connects through the TRC-8543 shielding to the
connector on the host port end. The shielding does not electrically connect to the
COM signals.
Caution When tightening the D-Sub connector jackscrews, do not exceed
the maximum jackscrew torque of 0.56 N · m (5.0 lb · in.).
The TRC-8543 receives power from the NI-XNET host port, but also requires an
external power supply of +9 V to +30 V to operate in Low-Speed/Fault-Tolerant
mode. Supply power from the CAN bus to the VSUP pin.
Note Power on VSUP is required for Low-Speed/Fault-Tolerant CAN
operation, but is not required for High-Speed CAN operation.
The TRC-8543 features soware-selectable bus termination for both CAN High-
Speed/Flexible Data-Rate and Low-Speed/Fault-Tolerant transceivers. For High-
Speed/Flexible Data-Rate mode, you can enable 115 Ω of termination resistance
between CAN_H and CAN_L through an API call. For Low-Speed/Fault-Tolerant
mode, you can select either 1.11 kΩ or 4.99 kΩ of termination resistance for RTH and
RTL through an API call (refer to the Termination Resistors section for more
information). If you choose to use external termination, Table 4 lists recommended
termination resistor values.
The following table lists the TRC-8543 pinout.
Table 5. Pin Assignments for the TRC-8543
Connector Pin Signal Name
1 No Connection (NC)
2 CAN_L
3 COM
4 NC
5 NC
6 COM
7 CAN_H
ni.com
8
TRC-8543

Connector Pin Signal Name
8 NC
9 VSUP
CAN Bus Topology and Termination
A CAN bus consists of two or more CAN nodes cabled together. The CAN_H and
CAN_L pins of each node are connected to the main CAN bus cable through a short
connection known as a “stub.” The pair of signal wires, CAN_H and CAN_L,
constitutes a transmission line. If the transmission line is not terminated, each
signal change on the bus causes reflections that may cause communication errors.
High-Speed/Flexible Data-Rate CAN
Because the CAN bus is bidirectional, both ends of the cable must be terminated.
However, this requirement does not mean that every node on the bus should have a
termination resistor; only the two nodes at the far end of the cable should have
termination resistors.
The following figure shows a simplified diagram of a CAN bus with multiple CAN
nodes and proper termination resistor (Rt) locations.
Figure 5. CAN HS/FD Bus Topology and Termination Resistor Locations
Low-Speed/Fault-Tolerant CAN
Every device on a low-speed/fault-tolerant CAN network requires a termination
resistor for each CAN data line: RRTH for CAN_H and RRTL for CAN_L.
The following figure shows a simplified diagram of a low-speed/fault-tolerant CAN
bus with termination resistor placements.
© National Instruments 9
TRC-8543

Figure 6. CAN LS/FT Bus Topology and Termination Resistor Locations
High-Speed/Flexible Data-Rate CAN
You can connect the TRC-8543 port to any location on a CAN bus. The following
figure shows one example of connecting the TRC-8543 directly to one CAN node.
Figure 7. Connecting the TRC-8543 to a CAN Device
Low-Speed/Fault-Tolerant CAN
You can connect the TRC-8543 to any location on a Low-Speed/Fault-Tolerant CAN
bus. The following figure shows one example of connecting the TRC-8543 directly to
one CAN node.
Figure 8. Connecting the TRC-8543 to a CAN Device
Cable Specifications
Cables should meet the physical medium requirements specified in ISO 11898,
shown in the following tables. Belden cable (3084A) meets all these requirements
and should be suitable for most applications.
ni.com
10
TRC-8543

High-Speed/Flexible Data-Rate CAN
Table 5. ISO 11898 Specifications for Characteristics of a CAN_H and CAN_L Pair of
Wires
Characteristic Value
Impedance 95 Ω min, 120 Ω nominal, 140 Ω max
Length-related resistance 70 mΩ/m nominal
Specific line delay 5 ns/m nominal
Low-Speed/Fault-Tolerant CAN
Table 3. ISO 11898 Specifications for Characteristics of a CAN_H and CAN_L Pair of
Wires
Characteristic Value
Length-related resistance 90 mΩ/m nominal
Length-related capacitance: CAN_L and ground, CAN_H and ground, CAN_L
and CAN_H
30 pF/m nominal
High-Speed/Flexible Data-Rate CAN
The termination resistors (Rt) should match the nominal impedance of the CAN
cable and therefore comply with the values in the following table. The onboard,
soware-selectable termination has a nominal value of 115 Ω. If you are not using
the onboard termination, use the values listed in the following table.
Table 5. Termination Resistor Specification
Characteristic Value Condition
Termination resistor, Rt100 Ω min, 120 Ω nominal,
130 Ω max
Minimum power dissipation: 220 mW
Low-Speed/Fault-Tolerant CAN
Unlike High-Speed/Flexible Data-Rate CAN, Low-Speed/Fault-Tolerant CAN requires
termination at the Low-Speed/Fault-Tolerant CAN transceiver instead of on the
cable itself. Termination requires two resistors, RTH for CAN_H and RTL for CAN_L.
© National Instruments 11
TRC-8543

This configuration allows the NXP fault-tolerant CAN transceiver to detect and
recover from bus faults. It is important to determine the overall termination of the
existing network, or the termination of the individual device, before connecting it to
a low-speed/fault-tolerant port. NXP recommends an overall RTH and RTL
termination of 100 Ω to 500 Ω (each) for a properly terminated low-speed network.
You can determine the overall network termination as follows:
1
RRTHoverall
=1
RRTHnode1
+1
RRTHnode2
+1
RRTHnode3
+1
RRTHnoden
NXP also recommends an individual device RTH and RTL termination of 500 Ω to
16 kΩ. Aer determining the existing network or device termination, you can use the
following formula to indicate which nearest value the termination property needs to
be set to produce the proper overall RTH and RTL termination of 100 Ω to 500 Ω
upon connection of the card:
where RRTH overall should be 100 Ω to 500 Ω
NI-XNET Low-Speed/Fault-Tolerant CAN hardware features soware selectable bus
termination resistors, allowing you to adjust the overall network termination
through an API call. In general, if the existing network has an overall network
termination of 125 Ω or less, you should select the 5 kΩ option for your NI-XNET
device. For existing overall network termination above 125 Ω, you should select the
1 kΩ termination option for your NI-XNET device.
Onboard termination on the low-speed/fault-tolerant ports of the TRC-8543 is set
through the NI-XNET soware to either 1.11 kΩ or 4.99 kΩ.
Cable Lengths
The cabling characteristics and desired bit transmission rates aect the allowable
cable length. You can find detailed cable length recommendations in the ISO 11898,
CiA DS 102, and DeviceNet specifications.
ISO 11898 specifies 40 m total cable length with a maximum stub length of 0.3 m for
a bit rate of 1 Mb/s. The ISO 11898 specification says that significantly longer cable
ni.com
12
TRC-8543

lengths may be allowed at lower bit rates, but you should analyze each node for
signal integrity problems.
High-Speed/Flexible Data-Rate CAN
The maximum number of nodes depends on the electrical characteristics of the
nodes on the network. If all nodes meet the ISO 11898 requirements, you can
connect at least 30 nodes to the bus. You can connect higher numbers of nodes if
the nodes’ electrical characteristics do not degrade signal quality below ISO 11898
signal level specifications.
The TRC-8543 electrical characteristics allow at least 110 CAN ports on a network.
Low-Speed/Fault-Tolerant CAN
The maximum number of nodes depends on the electrical characteristics of the
nodes on the network. If all of the nodes meet the requirements of Low-Speed/
Fault-Tolerant CAN, up to 32 nodes may be connected to the bus.
TRC-8543 Hardware Overview
The TRC-8543 has one full-featured CAN port that is isolated from the host it is
plugged into. Soware can select between either an NXP TJA1043T High-Speed CAN
transceiver or NXP TJA1055T Low-Speed/Fault-Tolerant CAN transceiver by
controlling on-board relays. The TJA1043T is fully compatible with the ISO 11898
standard and supports baud rates up to 2 Mbps. The NI-XNET driver enables baud
rates up to 8 Mbps. The TJA1055T is fully compatible with the ISO 11898 standard
and supports baud rates up to 125 Kbps.
Figure 9. TRC-8543 Hardware Overview
© National Instruments 13
TRC-8543

Inserting and Removing the TRC-8543
The TRC-8543 connects to a host device with an active latching connector. To
connect the TRC-8543 to a host device, push the connector assembly into the host
receptacle until the internal latch snaps into position. The latch emits an audible
click when engaged. To remove the TRC-8543, push the lock ejector forward to
disengage the latch and simultaneously pull the TRC-8543, as shown in the
following figure.
Figure 10. Inserting and Removing the TRC-8543
TRC-8543 LEDs
The TRC-8543 includes two LEDs to help you monitor hardware and bus status. LED
1 primarily indicates whether the hardware is currently in use. LED 2 primarily
indicates the activity information of the connected bus. Each LED can display two
colors (red or green), which display in the following four patterns:
Table 5. LED Pattern Definitions
Pattern Meaning
O No LED illumination
Solid LED fully illuminated
Blink Blinks at a constant rate of several times per second
Activity Blinks in a pseudo-random pattern
Table 6. LED Pattern Indications
Condition/State LED 1 LED 2
Port identification Blinks green Blinks green
NI-XNET catastrophic error Blinks red Blinks red
No open session on hardware O O
Open session on hardware, port is properly
powered, and hardware is not communicating
Solid green O
ni.com
14
TRC-8543

Condition/State LED 1 LED 2
Hardware is communicating, and controller is in
Error Active state
Solid green Activity green (returns to
idle/o one second aer last
TX or RX)
Hardware is communicating, and controller is in
Error Passive state
Solid green Activity red (returns to idle/o
one second aer last TX or RX)
Hardware is running, and controller transitioned to
bus o
Solid green Solid red
TRC-8543 Specifications
The following specifications are typical for the range -40 °C to 70 °C unless otherwise
noted.
High-Speed/Flexible Data-Rate CAN Characteristics
Transceiver NXP TJA1043T
Max certified baud rate 5 Mbps [1]
Input voltage limits CAN_H, CAN_L bus lines -27 VDC to +40 VDC
Output voltage limit CAN_H, CAN_L bus lines 5 VDC
MTBF Contact NI for Bellcore MTBF specifications
at other temperatures or MIL-HDBK-217F
specifications.
Low-Speed/Fault-Tolerant CAN Characteristics
Transceiver NXP TJA1055T
Max baud rate 125 Kbps
CAN_H, CAN_L bus lines voltage -27 VDC to +40 VDC
CAN Supply voltage range (VSUP)+9 VDC to +30 VDC
MTBF Contact NI for Bellcore MTBF specifications at other
temperatures or for MIL-HDBK-217F specifications.
© National Instruments 15
TRC-8543

Power Requirements
Thermal dissipation (at 70 °C) 700 mW maximum (Low-Speed/Fault-Tolerant fault
condition)
550 mW maximum (High-Speed active mode)
440 mW typical (High-Speed active mode)
333 mW typical (Low-Speed/Fault-Tolerant active mode)
Power consumption from
TRC-8543 host
550 mW maximum (High-Speed active mode)
440 mW typical (High-Speed active mode)
310 mW maximum (Low-Speed/Fault-Tolerant active mode)
245 mW typical (Low-Speed/Fault-Tolerant active mode)
Power consumption from VSUP 320 mW maximum (Low-Speed/Fault-Tolerant fault
condition)
90 mW typical (Low-Speed/Fault-Tolerant active mode)
Note Power on VSUP is required for Low-Speed/Fault-Tolerant CAN
operation.
Physical Characteristics
Weight 70 g (2.5 oz)
Length 447 mm to 462 mm (17.6 in. to 18.2 in.)
D-Sub connector jackscrew maximum torque 0.56 N · m (5.0 lb · in.)
Safety
Maximum Voltage[2]
Connect only the voltages that are within these limits.
Port-to-COM -27 V DC to +40 V DC maximum, Measurement Category I
ni.com
16
TRC-8543

Isolation Voltage
Port-to-earth ground
Continuous 60 V DC, Measurement Category I
Note The TRC-8543 COM signals are not connected to the host port
ground.
Caution Do not connect the product to signals or use for measurements
within Measurement Categories II, III, or IV.
Attention Ne pas connecter le produit à des signaux dans les catégories
de mesure II, III ou IV et ne pas l'utiliser pour eectuer des mesures dans
ces catégories.
Warning Do not connect the product to signals or use for measurements
within Measurement Categories II, III, or IV, or for measurements on MAINs
circuits or on circuits derived from Overvoltage Category II, III, or IV which
may have transient overvoltages above what the product can withstand.
The product must not be connected to circuits that have a maximum
voltage above the continuous working voltage, relative to earth or to
other channels, or this could damage and defeat the insulation. The
product can only withstand transients up to the transient overvoltage
rating without breakdown or damage to the insulation. An analysis of
the working voltages, loop impedances, temporary overvoltages, and
transient overvoltages in the system must be conducted prior to making
measurements.
Mise en garde Ne pas connecter le produit à des signaux dans les
catégories de mesure II, III ou IV et ne pas l'utiliser pour des mesures dans
ces catégories, ou des mesures sur secteur ou sur des circuits dérivés de
© National Instruments 17
TRC-8543

surtensions de catégorie II, III ou IV pouvant présenter des surtensions
transitoires supérieures à ce que le produit peut supporter. Le produit
ne doit pas être raccordé à des circuits ayant une tension maximale
supérieure à la tension de fonctionnement continu, par rapport à la
terre ou à d'autres voies, sous peine d'endommager et de compromettre
l'isolation. Le produit peut tomber en panne et son isolation risque
d'être endommagée si les tensions transitoires dépassent la surtension
transitoire nominale. Une analyse des tensions de fonctionnement, des
impédances de boucle, des surtensions temporaires et des surtensions
transitoires dans le système doit être eectuée avant de procéder à des
mesures.
Measurement Category I is for measurements performed on circuits not directly
connected to the electrical distribution system referred to as MAINS voltage. MAINS
is a hazardous live electrical supply system that powers equipment. This category is
for measurements of voltages from specially protected secondary circuits. Such
voltage measurements include signal levels, special equipment, limited-energy
parts of equipment, circuits powered by regulated low-voltage sources, and
electronics.
Note Measurement Categories CAT I and CAT O are equivalent. These test
and measurement circuits are for other circuits not intended for direct
connection to the MAINS building installations of Measurement Categories
CAT II, CAT III, or CAT IV.
Safety and Hazardous Locations Standards
This product is designed to meet the requirements of the following electrical
equipment safety standards for measurement, control, and laboratory use:
■IEC 61010-1, EN 61010-1
■UL 61010-1, CSA 61010-1
■EN 60079-0:2012, EN 60079-15:2010
■IEC 60079-0: Ed 6, IEC 60079-15; Ed 4
■UL 60079-0; Ed 6, UL 60079-15; Ed 4
ni.com
18
TRC-8543

■CSA 60079-0:2011, CSA 60079-15:2012
Note For UL and other safety certifications, refer to the product label or
the Online Product Certification section.
Hazardous Locations
U.S. (UL) ; ,
Canada (C-UL) ; ,
Europe (DEMKO)
Environmental Characteristics
Refer to the manual for the host you are using for more information about meeting
these specifications.
Temperature[3]
Operating -40 °C to 70 °C
Storage temperature -40 °C to 85 °C
Humidity
Operating 10% RH to 90% RH, noncondensing
Storage 5% RH to 95% RH, noncondensing
Ingress protection IP40
Pollution Degree 2
Maximum altitude 5,000 m
Shock and Vibration
To meet these specifications, you must securely mount the product and ensure all
cables and connectors have proper strain relief.
© National Instruments 19
TRC-8543

Operating vibration
Random 5 g RMS, 10 Hz to 500 Hz
Sinusoidal 5 g, 10 Hz to 500 Hz
Operating shock 30 g, 11 ms half sine; 50 g, 3 ms half sine; 18 shocks at 6 orientations
Shock and Vibration
To meet these specifications, you must securely mount your TRC-8543 and ensure
all cables and connectors have proper strain relief.
Operating vibration
Random (IEC 60068-2-64) 5 grms, 10 Hz to 500 Hz
Sinusoidal (IEC 60068-2-6) 5 g, 10 Hz to 500 Hz
Operating shock (IEC 60068-2-27) 30 g, 11 ms half sine; 50 g, 3 ms half sine;
18 shocks at 6 orientations
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for electrical
equipment for measurement, control, and laboratory use:
■EN 61326-1 (IEC 61326-1): Class A emissions; Industrial immunity
■EN 55011 (CISPR 11): Group 1, Class A emissions
■ EN 55022 (CISPR 22): Class A emissions
■EN 55024 (CISPR 24): Immunity
■AS/NZS CISPR 11: Group 1, Class A emissions
■AS/NZS CISPR 22: Class A emissions
■FCC 47 CFR Part 15B: Class A emissions
■ICES-001: Class A emissions
ni.com
20
TRC-8543
