M8-TECH CITY M8 User manual

1
M8-TECH LLC,
ARIZONA USA
OPERATOR’S MANUAL

2 |CITY M8 Operator’s Manual
General SAFETY
M8-TECH manufactures 100% electric Sport Mopeds with zero emissions and
zero fuel at a great price. Whether you’re a novice or experienced motorcycle
rider, you can easily use these fun little bikes to commute to your oice, run
errands about the city, or visit the supermarket. All of this at a low cost with
stylish looks, while helping to save the planet in one great bike.
Electric powered motorcycles are getting a lot more popular these days
because people are tired of the high cost of getting around town, tired of the
stop and go traic, and want to be environmentally friendly. We at M8-Tech
believe in this thinking. We figure, why not save money, help save the planet,
and look good doing it--come along for the ride!
INTRODUCTION
[e-mail]
m8-tech.com
WARNING! Please read and understand all sections of this
manual before operating your new electric vehicle. Do not
attempt to charge or operate this vehicle until you fully
understand and have adequate knowledge of its features and
controls. Failure to do so could result in injury or damage to
the vehicle and/or denial of warranty coverage.
USE ONLY M8-TECH approved chargers specifically designed
for your exact type and voltage of battery pack - severe
damage may otherwise result.
WARNING! Risks Inherent to Operation: Operating an
electric moped involves risks and dangers that may cause
bodily injury. These inherent risks may be the result of
purchaser’s own actions or non-actions involving themselves,
others, specific circumstances of the activity, and/or the
negligence of themselves or others. There may be other
risks known and/or unknown to the operator. The operator
assumes all risks and responsibility for events that may not be
foreseeable including economic loss, social distress, losses,
costs, and damages caused as a result of operating the vehicle.
CAUTION! In our constant eorts to improve and upgrade our
products, your vehicle may incorporate updated components
and/or features that are not specifically covered by this version
of the Owner’s Manual. If you are not clear on how to operate
or make use of any components or features, contact your
local dealer for clarification. Product design, features, and
specifications are subject to change without notice.

3
• DO NOT switch on ignition until properly seated and ready to ride. WHEN BIKE IS TURNED ON—THE THROTTLE IS
LIVE AND WILL ACCELERATE THE REAR WHEEL!
• DO NOT attempt to walk bike or place the bike on its stand with ignition on.
• DO NOT ride on sidewalks or pedestrian-only pathways—consult your local ordinances for current laws.
• DO NOT operate the bike at speeds in excess of 20 mph or whatever your local traic laws dictate for Mopeds.
• DO NOT ride on sand, grass, gravel, or on bumpy, rough or loose unpaved surfaces, this can void your warranty.
• DO NOT ride without both hands on the handle bars.
• DO NOT operate while not properly seated.
• DO NOT jump ramps, curbs, or otherwise attempt any form of stunt-riding.
• DO NOT attempt to open batteries - no servicing is required or possible and will void warranty.
• DO NOT operate the bike if it is materially defective in operation, dam¬aged, or missing safety-related equipment.
• ALWAYS DO pre-ride checks.
PROTECTIVE APPAREL:
• Always wear DOT approved helmet.
• Always wear full protective clothing.
• DO NOT ride barefoot or with open-toed, high-heel, platform, loose and/or slip-on footwear.
• DO NOT wear or carry anything that obstructs your vision or interferes with your complete control of the vehicle or
which could become en¬tangled in moving parts.
BIKE CARRYING CAPACITIES:
• Cargo and accessories MUST BE SECURELY ATTACHED OR STOWED, kept as low on and as close to the centerline of
the bike as possible, and weight distributed evenly to avoid imbalance or instability.
• Total payload, including the rider, NOT TO EXCEED 181.4kg (400lbs).
• FREQUENTLY CHECK all mounts and cargo restraints. NEVER ATTACH heavy items to the front fork, fender, or
handlebar as poor handling and instability may result.
• DO NOT carry more than 6.8kg (15lbs) of cargo in the tail rack/box.
NOTICE BEFORE USING:
NOTE: YOUR INSURANCE POLICES MAY NOT PROVIDE COVERAGE FOR ACCIDENTS
INVOLVING USE OF THIS E-MOPED. TO DETERMINE IF COVERAGE IS PROVIDED--YOU
SHOULD CONTACT YOUR INSURANCE AGENT.

4 |CITY M8 Operator’s Manual
Rider CONDUCT
• Always assume you are invisible to all other road users, regardless
of the lights and reflectors you may have. Your life depends on it.
• Share the road or path with others: motorists, pedestrians, and
cyclists alike. Respect their rights and try to be forgiving if they
infringe on yours. Remember, you’re probably the smallest vehicle
on the road.
• Ride defensively. You, and only you, are responsible for the safe
operation of your vehicle.
• Constantly scan from 15 feet in front of you to 200 feet ahead of
where you are, so you may anticipate and be ready to avoid road
surface hazards as well as other vehicles. Such hazards include:
vehicles slowing or turning in front of you, entering the road
ahead, or coming up behind you, car doors opening in front of
you, pedestrians stepping out in front of you, children or dogs
playing near the road, potholes, sewer gratings, railroad tracks,
expansion joints, road or sidewalk construction, debris and other
road hazards that could cause you to swerve, catch a wheel, lose
traction, or otherwise have a crash.
• Always signal when turning and stopping.
• Ride in a calm, smooth, predictable manner. Don’t weave through
traic or make sudden moves that may startle, provoke, or require
evasive action from other road users or pedestrians.
• Never hitch a ride by holding on to another vehicle.
M 8 - T E C H
CODE OF
R I D E R
CONDUCT:
In the interest of harmonious
co-existence with other road
users, M8-TECH suggests the
following common-sense
code of conduct be followed-
-in addition to any local traic
laws of the road.

5
Pre-OPERATION
BEFORE EVERY RIDE:
• Charge batteries
• ALWAYS: only turn the ignition on once you are seated and ready
to ride
• Walk-around inspection: Make sure all parts are securely fastened,
and in operating order.
• Check brake operation front and rear; make sure there is no
leakage of brake fluid.
• Check for smooth throttle operation.
• Check signals, lights, and horn.
• Ensure wheels spin freely and are aligned.
• Check tire pressure and condition.
AFTER EVERY RIDE:
• Be sure the ignition is turned o before you get o the bike.
• Let bike rest 10 minutes then plug the charger in; check for red
light and fan—this will prolong battery life.
• Be sure the charger will stay dry during operation.
• If stored outside, cover the bike and charger. Remember to arm
the alarm.
WARNING! Failure to perform
checks on a regular basis could
result in un-safe and/or unreliable
vehicle, leading to injury to you
and the vehicle and/or denial of
warranty coverage.

6 |CITY M8 Operator’s Manual
Charging INFO
• USE ONLY M8-Tech approved charger to charge your bike!
DO NOT plug an ordinary power cable directly into the
charging socket on the bike.
• Aer each ride, let bike rest for 10 minutes before plugging
in charger—this will prolong the life of the battery
• Plug Charger to wall socket—the charger light will be RED.
Plug charger into bike; light will remain RED until charged.
If you plug Charger into bike and the light flashes GREEN
and RED, there is an error in the system, or the battery has
failed.
• Once battery is charged, and the charger light is green,
unplug charger and store in cool safe place.
• Risk of overheating: Maintain air-flow around the charger
at all times. DO NOT enclose it in a storage compartment
or other unventilated space when charging. The charger is
designed for indoor / dry-area use only.
• DO NOT expose charger to water. If absolutely necessary,
place the charger on a raised area and drape the bike with
its cover allowing for suicient ventilation to protect the
bike and charger during adverse weather. You do so at your
own risk.
CONNECTING
THE CHARGER:
1 When you first receive your new bike, make sure the
bike’s main circuit breaker is ON (breaker located
under the seat). To charge the battery pack, the bike’s
main circuit breaker must be ON. If the breaker is o,
the charger will only seem like it is charging the battery.
SEAT
LOCK
MAIN
BREAKER
OFF
ON
OPEN SEAT TO ACCESS BREAKER
MAIN BREAKER OPERATION

7
2In the rear wheel well (on le side) you will find
charging port.
CHARGING
PORT
CHARGING PORT IN REAR WHEEL
WELL ON LEFT SIDE
3Flip open the door on the charge port and insert the
charger’s plug (note orientation of plug and socket for
proper fit).
4Aer plug is inserted to bike port, plug charger into the
wall socket.
5Max charging time is 8 hours for completely drained
battery. Once battery is charged the charger cuts o.
Remove charger from bike and store in cool dry place.
It’s best not leave charger plugged in for long durations
aer the charge is completed.
6Once charger is plugged in, charger indicator light
will be red. Once charged, the light will turn green
indicating the battery is charged. Aer green light is
indicated, unplug charger and store in safe place.

8 |CITY M8 Operator’s Manual
INSTRUMENTATION PANEL LAYOUT:
INSTRUMENT PANEL
HANDLEBAR - LEFT SIDE CONTROLS HANDLEBAR - RIGHT SIDE CONTROLS
KEY IGNITION
POSITIONS
NOTE: SPEED MODE HAS THREE SETTINGS I-II-III
I = Street Mode, used for public streets, limited to 19mph.
II = Eco Mode, conserves battery power for o-road use/ non-street use.
III = Track Mode, use only for non-street use or check your local moped laws for speed limit listings.
Operation INFO
A Battery Indicator
B Speedometer
C Trip Odometer
D USB Power Port
E Key Ignition
F Mirror Mount
G Rear Brake
H High / Low Beam
J Turn Indicator
K Horn
L Front Brake
M Headlight Adjustment
N Forward / Reverse
P Speed Mode (see note)
Handlebar Lock
O Position
On for Key Fob use only
On for Key use only
A
B
C
DE
F F
G
H
J
KK
L
M
N
P

9

10 |CITY M8 Operator’s Manual
Weighing in at just 90.7kg/200lbs and measuring 69”(L) x 31”(W) x 39”(H), the CityM8 Sport Moped is a great
choice for both novice and seasoned riders. Its frame is made with carbon steel, dressed in stylish plastic
paneling for aerodynamics and style. It arrives completely built, or if crated, the handlebars only need to
be re-attached. Other great features of the CityM8 include, easy to read LED display, LED headlights and
indicator lights. If you’re looking for a Sport Moped that can take you places quickly with utmost safety,
and without breaking the bank, the CityM8 Sport Moped is what you need.
Bike FEATURES
FEATURES OF THE CITYM8 SPORT MOPED:
• Brushless Max 2000-watt motor—Factory set
750watt for street use
• Maximum speed of 40mph (Track use only)
• 72v lithium battery provides up to 40 miles riding
distance per charge
• Disc brakes front and rear
• Tubeless 12 inch tires
• Fully Tunable Rear Shock
• 100 percent LED lights throughout the bike
• Hub Drive Motor provides more torque from the
rear / practically maintenance free
BIKE DESCRIPTION:
Key Features - Zero Emissions / Zero Fuel
Necessary / Low Maintenance / Ride around
Town in Style!

11
SPECIFICATIONS:
• Type: Sport Moped
• Fuel: Electric
• Power: > 750W - 2000W
• Voltage: 72V / 20AH
• Motor: Brushless Hub-Drive
• Max. Speed: 19 (street use mode) – 30 +mph
(closed course use only)
• Certification: CE
• Condition: New
• Brand Name: CityM8
• Place of Origin: Parts - Wuxi, China /
Assembled USA
• Model Number: CityM8
• Brake(F/R): Hydraulic Disc
• Max Power: 2000W
• Battery: 72V20AH lithium-ion
• Weight: 200 lbs
• Front Suspension: USD spring/oil,
120mm/4.72 inch
• Rear Suspension: Coil over spring, air/
oil with compression/rebound setting,
120mm/4.72 inch
• Measurements: 69”(L) x 31”(W) x 39”(H),
• Average Range: 30 miles (moderate use)
• Incline Climbing: 12 - 25 degree
• Charge time: 6 to 8 hours (Fully Drained
battery)
• Tire: 120/70-12 tubeless
• Color option: RED/ BLUE/ BLACK/ WHITE/
GREEN/ YELLOW

NOTICE:
Your insurance policies may not provide coverage for
accidents involving the use of this bicycle.
To determine if coverage is provided you should contact
your insurance company or agent.
For Warranty or Service contact your local dealer or contact
M8Tech at: Email: [e-mail] / Website: m8-tech.com
