macaroon M1 User manual

macaroon M1 Quick Start guide
Beijing Ulink Technology Co.Ltd.
www.umacaroon.com
About macaroon
1. LCD screen
2. Power Key
3. Operation Key
4. USB Cable
5. Interface for Extended Device
6. Direction Mark for SIM card insertion
7. SIM Card Slot

8. Micro USB Interface
9. Storage Slot for USB Cable Type A terminal
10. Micro USB Plug for USB Cable
11. Type A USB Plug for USB Cable
1. WLAN
2. Network
3. Mark for Inserting SIM Card
4. Battery Level
5. Battery
6. Mark for Charging Status
7. Menu
The Advantages of Macaroon

·Qualcomm MDM9x07 Chip and LTE CAT4 High-speed network
·16-band 4G network frequency that means it covers the globe
·2.4G WLAN IEEE802.11b/g/n that means it sets up a Stable network connection
and let up to 10 users share the network
·3000mAh High-density Lithium Polymer Battery that means it allows smart
Energy-saving technology and makes battery active for Up to 12 hours
·A standard modular structure that means it lets random combination and limitless
expansion potential to enhance the possibility of our life
·Simplify the complex with a revolutionary app. Recharge the device and monitor the
usage with just one tap
How to use macaroon
1. USB Cable
1) Take out USB cable: It is available once you take it out from the location
shown in Pic 1. If necessary, take out of the whole piece of USB cable for the
use of charging other devices.
2) Withdraw USB cable: Take the reverse procedure of step 1).
2. Key
1) Power Key: Long press the Power Key for more than 3 seconds to boost the device.

When the screen displays, long press the power key for more than 3 seconds to
shut down the device.
2) Operation Key: Click to select the menu or flip the screen, etc.
3) Lock the Screen: When you do not press the key within 40 seconds, the
device will be in the sleeping mode and the screen will be locked
automatically. Or click the power key twice to manually lock the screen.
4) Unlock the Screen: Click the power key to make the screen come alive, and
then click operation key to unlock the screen according to tips on the screen.
5) Forced shutdown: Long press Operation Key for more than 8 seconds. (Without the
guidance of customer service, please do not operate it yourself.)
3. Menu
1) After power-on and entering into the first page, it displays the operation
information of the device. Then click any key to enter into menu operation mode.
2) Use power key or Operation Key to activate the function in need.
3) If you do not press the key within 5 seconds in the menu operation, the
device will flip into the first page and display the operation information.
4. Connect WLAN
1) During power-on status, use cell phone/pad or other terminals to search
WLAN signal, find SSID (Username) of the device, and enter the KEY
(password). Then you can connect to the WLAN network.
5. Use of SIM card
1) No support for hot-swap purpose. If it is required to use SIM card, please
reboot the device after inserting or extracting of SIM card in the slot of SIM card.
6. Device management:
1) Scan QR code to download macaroon APP, go to register a new account after the
set-up.

2) Use macaroon APP to scan the barcode on the device to add and lock the device.
3) Purchase the suitable package in the data mall and ready to use it!
7. About WebUI
1) Connect your macaroon M1 device with your mobile phone or PC device.
2) Enter the address "192.168.225.1" in the browser, the default password is:
12345678
3) After logging in, you can use web UI to change your password and set APN, etc.

The Parameters of macaroon
Technical features and characteristics for EU
WLAN
Operation Frequency:
2412MHz~2472MHz
802.11b/802.11g/802.11n(H20)
2422MHz~2462MHz 802.11n(H40)
Maximum Power Level(2.4GHz):
16.67dBm(E.I.R.P.)
GSM
Operation Frequency:
E-GSM 900: 880~915MHz
DCS 1800: 1710~1785MHz
Product Name
Ulink 4G LTE mobile router
Model
macaroon M1
Size
85mm*20.6mm
Weight
110g
Bands
FDD-LTE
B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20
TDD-LTE B38/B39/B40/B41
WCDMA B1/B2/B4/B5/B8
GSM B2/B3/B5/B8
WLAN
Support 2.4G WLAN IEEE 802.11 b/g/n
LCD Screen
1.54 inch
LCD Pixels
240*240 Pixels
Battery type
Lithium polymer battery
Cell capacity
3000mAh
Continuous Working Hrs
12 H
USB Port
Input 5V1A, Micro USB

Maximum Power Level(E-GSM
900):
29.36dBm
Maximum Power Level(DCS 1800):
24.65dBm
WCDMA
Operation Frequency:
Band 1
TX:1922.4MHz~1977.6MHz,RX:2112.4MHz~2167.6
MHz
Band 8
TX: 882.4MHz~912.6MHz,RX:927.4MHz~957.6MHz
Maximum Power Level
(WCDMA Band 1):
24.24dBm
Maximum Power Level
(WCDMA Band 8):
23.81dBm
FDD LTE
Operation Frequency:
Band 1
TX:1922.5MHz~1977.5MHz,RX:2112.5MHz~2167.5
MHz
Band 3
TX:1710.7MHz~1784.3MHz,RX:1805.7MHz~1879.3
MHz
Band 7
TX:2502.5MHz~2567.5MHz,RX:2622.5MHz~2687.5
MHz
Band 8
TX:880.7MHz~914.3MHz,RX:925.7MHz~959.3MHz
Band 20
TX:834.5MHz~859.5MHz,RX:793.5MHz~818.5MHz
Maximum Power Level (Band 1):
23.51dBm
Maximum Power Level (Band 3):
22.89dBm

Maximum Power Level (Band 7):
22.74dBm
Maximum Power Level (Band 8):
23.85dBm
Maximum Power Level (Band 20):
23.74dBm
TDD LTE
Operation Frequency:
Band 38
TX:2572.5MHz~2617.5MHz,RX:2572.5MHz~2617.5
MHz
Band 40
TX:2302.5MHz~2397.5MHz,RX:2302.5MHz~2397.5
MHz
Maximum Power Level (Band 38):
23.85dBm
Maximum Power Level (Band 40):
23.77dBm
FAQ
1. How long does it take to have the device fully charged?
It takes around 4 hours for the device from the state of the low battery to have been
fully charged.
2. How long does it take to connect to the internet after power-on?
Normally, it takes 1-3 minutes. It may take a longer time for the network to make a
connection for the first time when arriving at a new country.
3. What should I do when my Phone/Pad cannot connect with the device?
(1) Make sure Phone/Pad's WLAN is turned on.
(2) Refresh the network list. Search the corresponding SSID of the device.
(3) Make sure you input the correct password to get internet connected.
4. What should I do when all the devices cannot get internet connections at
present?
(1) Make sure the device is in normal status. The signal of the device is weak
when you use the device at the airport, mountain area, high way, harbor, basement,
rural area, and islands. Please change your location and reboot the device to try

again.
(2) If you still cannot get the internet connection, please contact us through
email at [email protected] and Facebook at
www.facebook.com/macaroon.fans
5. What should I do if my device is lost?
If your device has been lost incidentally, please contact customer service to
freeze your account to avoid making extra expenses.
Warning
·Please use the original accessories. If you use the unauthorized charger or other
accessories, it may cause damage to the device and even cause a fire disaster,
explosion, or other hazards.
·Do not make the device wet. Keep it in the dry and cool environment. If the device
is situated at the conditions, the temperature of which is too high or too low, it may
be damaged.
·Please do not expose the device to high-temperature environment or heating
surroundings, such as sunlight, warmer, microwave, oven, heater or water-heater etc.
The overheated battery may cause the explosion.
·When charging is complete, or the device is not in the process of charging, please
disconnect the charger from the device and unplug the charger from the power
outlet.
·The built-in battery is non-removable. Please do not change or disassemble battery
by yourself to avoid causing the damage to the battery or the device. The battery can
only be replaced by the officially authorized service provider.
Notice: Change with the wrong model of the battery may cause the explosion,
please make sure to dispose of the exhausted battery as instructed.
Working Temperature: 0℃- 45℃. For user's safety, please avoid using the device
at the high-temperature environment for a long time, otherwise, it will shorten

the lifespan of the device. The device will stop charging automatically when the
battery temperature is up to 50℃; it will shut down automatically when the
battery temperature is more than 60℃.
When using external SIM card, you should cut the SIM card by yourself. The
non-standard SIM card cannot be used.
We are only responsible for the official system and updating system while any
other system operation from the unofficial third party may cause security risks.
EU Regulatory Conformance
Hereby, Beijing ULINK Technology Co., Ltd. declares that this radio equipment type is
in compliance with the Directive 2014/53/EU. For the full text of the EU declaration
of conformity, visit this website: www.umacaroon.com
Notice: The operating temperature of the device is between 0℃to 45℃.
This product can be used across EU member states.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This device complies with FCC SAR exposure limits set forth for an uncontrolled
environment. SAR compliance for using the equipment in close proximity to the
human body has been evaluated at 5mm. This equipment must not be co-located or
operated in conjunction with any other antenna or transmitter. End-users and
installers must be provided with antenna installation instructions and consider
removing the non-collocation statement.
This device complies with Part 15 of the FCC Rules. The operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Caution!
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
RF EXPOSURE INFORMATION (SAR)
This device meets the government’s requirements for exposure to radio
waves.
The SAR limit set by the FCC is 1.6W/kg.
The highest reported SAR values under the FCC regulations for your device
are listed below:
Body SAR: 1.169 W/kg
The SAR limit set by the CE is 2.0W/kg
The highest reported SAR values under the CE regulatory for your device are

listed below:
Body SAR: 0.794 W/kg
Contact Us
www.umacaroon.com
BEIJING ULINK TECHNOLOGY CO., LTD
Email: [email protected]
Facebook: www.facebook.com/macaroon.fans
Address of Sales Department: The 5th Floor, East Area, Sinoma International, No. 16
Wangjing North Road, Chaoyang District, Beijing, People's Republic of China
Copyright Notice
BEIJING ULINK TECHNOLOGY CO., LTD reserves the right of final interpretation of the
device regarding the trademark of Ulink and macaroon.
For more details
Please visit- www.umacaroon.com
