Maestro MR402 User manual

Model/Модель: MR402
Сerticated in Ukraine
Виріб сертифіковано в Україні
091
Owner’s manual. Coffe maker
Bedienungsanleitung. Kaffeemaschine
Instrukcja obsługi. Ekspres do kawy
Manualul proprietarului. Cafetiera
Руководство по эксплуатации. Кофеварка
Керівництво з експлуатації. Кавоварка
EN
DE
PL
UA
RU
RO

2
Pictures/ Bilder/Rysunki/ Figuri/ Рисунки/ Малюнки 1
Description of the appliance___________________________________________4
Gerät_______________________________________________________________12
Konstrukcja urządzenia_______________________________________________21
Structura produsului____________________________________________________27
Устройство прибора____________________________________________________36
Склад приладу________________________________________________________44
EN
DE
PL
UA
RU
RO

3
Dear customer, we thank you for purchase of goods
Functionality, design and conformity to the quality standards
guarantee to you reliability and convenience in use of this device.
Please read and comply with these original instructions prior to the
initial operation of your appliance and store them for later use of
subsequent owners.
Coffee Maker is designed only for making drinks, such as coffee or
tea in the household (home) environment.
Under condition of observance of user regulations and a special-
purpose designation, a parts of appliance do not contain unhealthy
substances.
Technical specications
Model MR402
Electrical supply:
Alternating current- AC;
Rated voltage 220-240V;
Rated frequency 50Hz;
Power consumption 600W
Protective class I
Protection class IPX0
EN

4
Description of the appliance
Picture1 (page2)
1. Case (the teapot lter is under the cover inside the case)
2. Cover of the container for water
3. Minimal 1MIN and maximal 2MAX water level marks
(are inside the container)
4. Switch with a light power-on indicator
5. Ceramic cups (125 ml)
6. Excessive water discharge hole
Safety instructions
When using your appliance, basic safety precautions should
always be followed,including the following:
SPECIAL INSTRUCTIONS
ATTENTION!
- Do not allow the ingress of water and moisture on the internal
electric parts of the device located outside the container for water.
- Always unplug the coffee maker from the mains for lling with
water, cleaning.
- Do not take the appliance with wet hands.
- Only plug the appliance into an outlet with an earthed (ground)
contact.
Failure to observe these rules may result in electric shock!
- DO NOT let children or untrained persons use the appliance
without supervision.
- DO NOT leave the appliance unnecessarily plugged in. Disconnect
the plug from the mains when the appliance is not being used.
- DO NOT use the power cord or the appliance in order to pull the
plug out of the socket.

5
- DO NOT leave the appliance exposed to the weather (rain,
sun, etc.).
- DO NOT leave the appliance without supervision when it is
connected to the power supply.
- Close supervision is necessary when the appliance is used near
children.
- Always use the appliance on a dry, level surface.
- Always unplug from the plug socket when not in use and before
cleaning.
- Do not operate the appliance if damaged, after an appliance
malfunctions or it has been damaged in any manner, return to at
authorized service engineer for repair.
- In the interest of safety, regular periodic close checks should be
carried out on the supply cord to ensure no damage is evident.
Should there be any signs that the cord is damaged in the slightest
degree, the entire appliance should be returned be authorized
service engineer.
- Do not let the cord hang over the edge of a table or counter or
touch hot surfaces. Allow unit to cool before storage.
- Do not touch any hot surfaces, do not store or cover the appliance
until it has full cooled down.
- Do not use harsh abrasives, caustic cleaners or oven cleaners
when cleaning this appliance.
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.
EN

6
ATTENTION!
- Do not open the cover when the device is in operation.
Disconnect the coffee machine from the mains and leave it to
cool for at least 5 min. when it is necessary to pour some water or
change the coffee powder or tea.
- Do not move around a switched on device when in operation.
- Do not ll the machine with water to the level above the MAX.
- Place the machine only on a dry, even, stable, slip-proof surface.
- Be careful with cups full of hot drinks.
In case of failure to observe the above mentioned rules there
arises the danger of burning!
- Do not place the appliance on heating devices.
- Do not switch the appliance on without water.
- Switch on the machine only when the teapot with the lter is
placed in position.
- Before making each new portion of the drink, unplug the Coffee
Maker and allow it to cool for at least 5 minutes.
- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT USE
THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED USE.
Purchase industrial devices for commercial use.
Actions in extreme situations:
- If a device tumbled into water, immediately, unplug the device, not
touching to the device or water.
- In case of appearance from appliance of smoke, sparkling, strong
smell of a burn isolation, immediately stop use the device, unplug
the device, appeal to the nearest service center.
Operation
Before the rst use:
- Remove packing and advertising materials and stickers.

7
EN
- Inspect the appliance and make sure that there are no
damages appliance, power line cord and plug.
- Unwind the power line cord completely.
CAUTION! Is required on surfaces where heat may cause a
problem – an insulated heat pad is recommended.
It is recommended to perform 1-2 working cycles with water but
without coffee.
For this purpose:
- place the coffee machine on a stable even surface;
- install the lter in the teapot case or check that it is installed
correctly;
- open the cover and ll the machine with clean cold water
controlling the level by marks MIN, MAX inside the container.
ATTENTION. If the water level in the container exceeds the mark
MAX, water shall begin to drain from the holes situated on the back
side of the case.
- close the cover;
- place the cups on the tray;
- connect the plug to the socket and switch on the machine by
positioning the switch to position «1»-ON. The indicator will light up
and the machine will start operating.
- After there remains no water in the teapot, switch off the machine
with the switch by placing it in position «0»- OFF. The indicator will
go out and the device will be disconnected. The heating of water
can be stopped at any moment by pressing the switch.
Let it cool for 5 minutes, pour out the water from the container.
Repeat the above mentioned procedure for 1-2 times.

8
Making coffee
The process of coffee making consists of passing hot drops of water
and vapor particles through ground coffee. This technology ensures
making tasty and fragrant drink without excessive boiling which
makes the drink too bitter.
It is recommended to use well roasted and freshly ground coffee
and cold water for making coffee.
To make coffee:
- pour the required quantity of ground coffee on the lter without
tramping down. It is enough to put about 6-7 g of coffee for a 100
ml cup.
- place the lter in the teapot case;
Fill the container with water to the necessary level, approximately
100 ml for a cup of drink;
- close the cover of the container;
- switch the machine as described earlier, the machine will start the
operation and the drink will begin collecting in the cups after a little
while.
When the coffee is ready, switch off the machine with the switch.
After the use place the switch in position «0» - OFF and disconnect
the plug from the mains.
This machine can be also used for making tea.
The process of making tea is similar to that of making coffee as
described above except the use of the brew.
Scale removal
When using the device, the so-called «scale», lime deposits
are formed in its inner parts. Regular cleaning improves the
performance of the device.
The quantity and the speed of forming the scale, and consequently,
the necessity of cleaning depend on the water hardness in your
region and the intensity of the device usage.

9
EN
If the Coffee Maker is used 1-2 times a day, depending on the
water quality, it is recommended to clean the instrument at least:
- Soft water – I time every 6 months;
- Medium self-scaling - 1 time / 2-3 months;
- Hard - 1 time / 6-8 weeks.
Regular descaling will only improve the device performance.
To remove the deposits using special means which can be bought
in retail store chain.
Cleaning and maintenance
ATTENTION!
- Never clean the appliance connected to mains.
- Before cleaning, disconnect the appliance and let it cool down.
- Do not use abrasive and aggressive detergents.
- Never submerge the appliance, power line cord and plug in water
or other liquids.
For regular cleaning of the device wash all removable parts with
water (lter) using a soap solution or a mild detergent, rinse it
carefully under running water.
Clean the lter from residues of coffee thoroughly. The purication is
conveniently performed using a small brush.
Clean and dry all parts of the device prior to assembly and use.
Storage
- Switch off the appliance and let it completely cool before storage.
- Wipe and dry the appliance before storage.
- Store the appliance in a cool, dry and clean place beyond the
access of children and people with limited physical and mental
abilities.

10
Environmental protection
Old appliances contain valuable materials that can be recycled.
Please arrange for the proper recycling of old appliances. Please
dispose your old appliances using appropriate collection systems.
Subject to technical modications!
