Maestro A5135-H User manual

GPS+GLONASS Receiver A5135-H
A Description of Maestro’s
GPS+GLONASS Antenna Receiver Module A5135-H
User’s Manual
Version 1.0

V1.0 - Dec-16
User’s Manual
Page 2 of 38
Revision History
Rev.
Date
Description
0.1
04-14-14
First release
0.2
29-01-15
Pin assignment updated
0.3
17-02-15
Updated figures
1.0
11-25-16
Updated FW release

V1.0 - Dec-16
User’s Manual
Page 3 of 38
Disclaimer
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF MAESTRO
WIRELESS SOLUTIONS LIMITED. IT MAY NOT BE COPIED OR TRANSMITTED
BY ANY MEANS, PASSED TO OTHERS, OR STORED IN ANY RETRIEVAL
SYSTEM OR MEDIA, WITHOUT PRIOR CONSENT OF MAESTRO OR ITS
AUTHORIZED AGENTS.
THE INFORMATION IN THIS DOCUMENT IS, TO THE BEST OF OUR
KNOWLEDGE, ENTIRELY CORRECT. HOWEVER, MAESTRO CAN NEITHER
ACCEPT LIABILITY FOR ANY INACCURACIES, OR THE CONSEQUENCES
THEREOF, NOR FOR ANY LIABILITY ARISING FROM THE USE OR
APPLICATION OF ANY CIRCUIT, PRODUCT, OR EXAMPLE SHOWN IN THE
DOCUMENT.
THE PRODUCT (HARD- AND SOFTWARE) DESCRIBED IN THIS
DOCUMENTATION IS NOT AUTHORIZED FOR USE IN LIFE SUPPORT
DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF
MAESTRO.
THIS DOCUMENT MAY PROVIDE LINKS TO OTHER WORLD WIDE WEB SITES
OR RESOURCES. BECAUSE MAESTRO HAS NO CONTROL OVER SUCH SITES
AND RESOURCES, MAESTRO SHALL NOT BE RESPONSIBLE FOR THE
AVAILABILITY OF SUCH EXTERNAL SITES OR RESOURCES, AND DOES NOT
ENDORSE AND IS NOT RESPONSIBLE OR LIABLE FOR ANY CONTENT,
ADVERTISING, PRODUCTS, OR OTHER MATERIALS ON OR AVAILABLE FROM
SUCH SITES OR RESOURCES. MAESTRO SHALL NOT BE RESPONSIBLE OR
LIABLE, DIRECTLY OR INDIRECTLY, FOR ANY DAMAGE OR LOSS CAUSED
OR ALLEGED TO BE CAUSED BY OR IN CONNECTION WITH USE OF OR
RELIANCE ON ANY SUCH CONTENT, GOODS OR SERVICES AVAILABLE ON
OR THROUGH ANY SUCH SITE OR RESOURCE.
MAESTRO RESERVES THE RIGHT TO CHANGE, MODIFY, OR IMPROVE THIS
DOCUMENT OR THE PRODUCT DESCRIBED HEREIN, AS SEEN FIT BY
MAESTRO WITHOUT FURTHER NOTICE.

V1.0 - Dec-16
User’s Manual
Page 4 of 38
Table of Contents
1 Introduction .........................................................................................................6!
1.1 Feature Overview...............................................................................................6!
1.2 Characteristics Overview ...................................................................................7!
1.3 RoHS and Lead-Free Information......................................................................7!
1.4 Label ..................................................................................................................8!
1.5 Characteristics ...................................................................................................9!
1.5.1 GPS+GLONASS Characteristics................................................................................ 9!
1.5.2 Mechanical Characteristics ........................................................................................ 9!
1.6 Handling Precautions.........................................................................................9!
2 Ordering Information ........................................................................................10!
2.1 GPS+GLONASS Receiver A5135-H................................................................10!
2.2 Packing ............................................................................................................10!
2.3 Additional Equipment .......................................................................................13!
3 Quick Start.........................................................................................................14!
3.1 Minimum Configuration ....................................................................................15!
3.2 Antenna............................................................................................................17!
3.3 Serial Port Settings ..........................................................................................17!
3.4 Improved TTFF ................................................................................................17!
3.5 Self-start configuration .....................................................................................17!
4 Mechanical Outline ...........................................................................................19!
4.1 Details Component Side A5135-H ...................................................................19!
4.2 Details Solder Side A5135-H ...........................................................................20!
5 Pin-out Information...........................................................................................21!
5.1 Layout A5135-H ...............................................................................................21!
5.2 Description A5135-H Signals ...........................................................................22!
6 Electrical Characteristics .................................................................................24!
6.1 Operating Conditions .......................................................................................24!
6.2 Absolute Maximum Ratings .............................................................................24!
6.3 DC Electrical Characteristics............................................................................25!
7 Mounting............................................................................................................26!
7.1 Proposed Footprint for Soldering .....................................................................26!
7.2 PCB Design Guide...........................................................................................26!
7.3 Recommended Profile for Reflow Soldering ....................................................28!
8 Use of External Antenna...................................................................................29!
8.1 Connection of RF Signal ..................................................................................29!
8.2 External Antenna .............................................................................................30!
8.2.1 Recommended Parameters ..................................................................................... 30!
8.2.2 Hints ......................................................................................................................... 30!
9 Quality and Reliability ......................................................................................31!

V1.0 - Dec-16
User’s Manual
Page 5 of 38
9.1 Environmental Conditions ................................................................................31!
9.2 Product Qualification........................................................................................31!
9.3 Production Test................................................................................................31!
10 Applications and Hints ...................................................................................32!
10.1 Initial Module Start .........................................................................................32!
10.2 SiRFawareTM Support ....................................................................................32!
10.3 Push-to-Fix Mode...........................................................................................32!
10.4 Hibernate Mode .............................................................................................33!
10.5 Extended Ephemeris......................................................................................33!
10.6 TM_GPIO5 pin (1 pulse per second pin)........................................................33!
10.7 5 Hz Navigation Update Rate ........................................................................34!
11 Evaluation Kit EVA5135-H..............................................................................35!
12 Related Information ........................................................................................36!
12.1 Contact...........................................................................................................36!
12.2 Related Documents .......................................................................................36!
12.3 Related Tools.................................................................................................36!
13 List of Figures .................................................................................................37!
14 List of Tables...................................................................................................38!

V1.0 - Dec-16
User’s Manual
Page 6 of 38
1 Introduction
A5135-H is an antenna module with SiRFstarV Flash based chip and an on-board
patch antenna (15mm x 15mm x 4mm). RF switch was implemented so as to sup-
port external active antenna for performance enhancement if required. In order to
have an easier migration for existing customers using A2235-H, we decided to keep
same pin assignment as that of A2235-H. Additional pins for supporting external
antenna won’t affect this drop-in replacement property. Since there is an RF feed
point underneath the module, special PCB design is required on user’s application.
The A5135-H is a module designed for a 3.3V environment.
1.1 Feature Overview
The A5135-H is a new module with the following outstanding features.
•Fast, responsive location experience
oHigh-sensitive navigation engine with tracking down to -165dBm
o52 track verification channels
oSBAS (WAAS, EGNOS, MSAS, GAGAN)
oConcurrent tracking of multiple constellations of the GPS and
GLONASS systems
•Breakthrough micro power technology
oRequires only 50 – 500µA to maintain hot start capability
•Active jammer remover
oRemoves in-band jammers up to 80dB/Hz
oTracks up to eight CW (continuous wave) jammers
•Size: 17.8mm (L) x 16.5mm (W) x 7.1mm (H)
•Operating voltage: 3V3
•Extremely low power consumption by using DC/DC converter
•No back-up battery required
•TCXO is used for providing stable 26MHz system clock
•Support external active antenna
•Support SGEE and CGEE
•Build-in LNA with close to 20dB for the integrated patch antenna

V1.0 - Dec-16
User’s Manual
Page 7 of 38
1.2 Characteristics Overview
The module’s most important characteristics are:
•A5135-H
oOperable at 3.3V / 34mA @ 1fix per second
oUART interface at CMOS level
oV_BAK at 3.0V / 60uA (typ.)
•Internal Power-On-Reset (POR) reset chipset to prevent memory corruption if
main power removal abruptly
•Internal 4 Mb SPI Flash
•Small form factor of 17.78 x 16.51 mm²(0.7” x 0.65”)
•Supported temperature range: -40°C to +85°C
•Single-sided SMT component, for reflow soldering
•RoHS compliant, lead-free
•Tape & reel packaging
•Excellent antenna support
oOn-module patch antenna
oAntenna input for direct connection of external active antenna
oRF switch to select between antennas
The antenna receiver module is available as an off-the-shelf component, 100%
tested and shipped in tape-and-reel packaging.
1.3 RoHS and Lead-Free Information
Maestro’s products marked with the lead-free symbol either on the module or the
packaging comply with the "Directive 2002/95/EC of the European Parliament
and the Council on the Restriction of Use of certain Hazardous Substances in
Electrical and Electronic Equipment" (RoHS).
All Maestro GPS+GLONASS receiver modules, GPS+GLONASS antenna receiver
module and telematics units are RoHS compliant.

V1.0 - Dec-16
User’s Manual
Page 8 of 38
1.4 Label
The A5135-H label (size: 12.0x 4.0 mm²) contains the following information:
TBA
Figure 1: A5135-H label
The label is placed on the side of the GPS+GLONASS antenna. The data matrix
code holds the product type, part number, software release, hardware release, fac-
tory code, year & week of assembly and a 6-digit serial number. Due to limited
space on module label, only product type, year & week of assembly and 6-digit serial
number will be printed on it.
Representing
Factory
location
Product
Number
Part
Number
Software
Release
Hardware
Release
Assembly
Year/Week
Serial
Number
Number of
digits
(16)
XX
XXXXXXX
XXXX
XX
XX
XXXX
XXXXXX
2
6
4
2
2
4
6
Example
TF
A5135H
9333
01
01
1211
000005
Meaning
TF
Given
Given
Given
Given
Year=12
Week=11
Increment
from
000001
up to
999999
Example of MID#: TFA5135H933301011211000005

V1.0 - Dec-16
User’s Manual
Page 9 of 38
1.5 Characteristics
The module is characterized by the following parameters.
1.5.1 GPS+GLONASS Characteristics
Channels
52, parallel tracking
Correlators
～400,000
Frequency
GPS
L1 (= 1,575 MHz)
GLONASS
FDMA L1 (=1,602 MHz)
Tracking Sensitivity
On-module antenna
GPS+GLONASS
-165 dBm
Horizontal Position Accuracy
Stand alone
< 2.5 m CEP (SA off)
Time To First Fix – TTFF
(theoretical minimum values;
values in real world may differ)
Obscuration recovery (1)
0.1 s
Hot start (2)
< 1 s
Warm (3)
< 30 s
Cold (4)
< 35 s
Table 1: A5135-H GPS+GLONASS characteristics
(1) The calibrated clock of the receiver has not stopped, thus it knows precise time (to the µs level).
(2) The receiver has estimates of time/date/position and valid almanac and ephemeris data.
(3) The receiver has estimates of time/date/position and recent almanac.
(4) The receiver has no estimate of time/date/position, and no recent almanac.
Note: Performance (sensitivity and TTFF) might slightly decrease below -30°C.
1.5.2 Mechanical Characteristics
A5135-H Mechanical dimensions
Length
Width
Height
17.78±0.20 mm, 0.7±0.008”
16.51±0.20 mm, 0.65±0.008”
7.11 mm, 0.28”(Max)
A5135-H Weight
4.0 g, 0.14 oz
Table 2: A5135-H dimensions and weight
1.6 Handling Precautions
The GPS+GLONASS receiver module A5135-H is sensitive to electrostatic dis-
charge (ESD). Please handle with appropriate care.

V1.0 - Dec-16
User’s Manual
Page 10 of 38
2 Ordering Information
2.1 GPS+GLONASS Receiver A5135-H
The order number is built as follows:
•A5135-Hxxxx
A5135-H is the model name. The “xxxx” refers to the current part number on the
module.
2.2 Packing
The A5135-H GPS+GLONASS modules come in a tape and reel package suitable
for pick and place machines.
Figure 2: A5135-H tape specifications (1)
