Magic Chef MCCF10WMD User manual

10.0 Cu.Ft. CHEST FREEZER
INSTRUCTION MANUAL
Model No.: MCCF10WMD
To ensure proper use of this appliance and your safety, please read the
following instructions completely before operating this appliance.

1
TABLE OF CONTENTS
NAMES OF THE PARTS……………………………………………………… 2
SPECIFICATIONS…………………………………………………………….. 3
IMPORTANT SAFETY INSTRUCTIONS…………………………………… 4
INSTALLATION INSTRUCTIONS
BEFORE USING YOUR FREEZER…………………………………. 4
INSTALLING YOUR FREEZER ……………………………………… 4 - 5
ELECTRICAL CONNECTION………………………………………… 5
OPERATING YOUR FREEZER
TEMPERATURE CONTROL………………………………………….. 6
THE FAST FREEZE SWITCH ………………………………………… 6
DEFROSTING YOUR FREEZER………………………………….….. 6 - 7
THE FREEZER COMPARTMENT…………………………….……… 7
CARE AND MAINTENANCE
CLEANING YOUR FREEZER………………………………………… 8
VACATION TIME………………………………………………………. 8
MOVING YOUR FREEZER…………………………………………… 8
ENERGY SAVING TIPS………………………………………………. 8
TROUBLESHOOTING GUIDE………………………………………………. 9 - 10
CHEST FREEZER WARRANTY……………………………………………… 11

2
NAMES OF THE PARTS
MODEL NO. MCCF10WMD


WARNING

: Never touch the interior of the Freezer Chamber or frozen foods in the
compartment with wet hands as this could result in frost bite.

3
SPECIFICATIONS – Model # MCCF10WMD
Product Description Magic Chef Chest Freezer
Model No. MCCF10WMD
Capacity 10.0 Cu. Ft.
Width Height Depth Unit Dimensions
( inches )
44.0” 34.0” 27.0”
Net Weight ( lbs) 114 ( lbs )

4
IMPORTANT SAFETY INSTRUCTIONS


WARNING


To reduce the risk of fire, electrical shock,
or injury when using your freezer, follow
these basic precautions:
•Read all instructions before using the freezer.
•DANGER or WARNING: Risk of child entrapment.
To avoid the possibility of child entrapment, please take the following precautions:
Remove the freezer top and DO NOT remove the internal basket.
•Before you throw away your old freezer: Take off the top. Leave the basket in
place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the freezer.
•Refrigerants: All refrigeration products contain refrigerants, which under the
guidelines of federal law must be removed before disposal of product. It is the
consumer’s responsibility to comply with federal and local regulations when
disposing of this product.
•Never clean freezer parts with flammable fluids. The fumes can create a fire hazard
or explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other freezer. The fumes can create a fire hazard or an explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
Before Using Your Freezer
•Remove the exterior and interior packing.
•Check to be sure you have all of the following parts:
1 Storage Basket
1 Divider
1 Instruction Manual
•Before connecting the freezer to the power source, let it stand upright for approximately 4 hours.
This will reduce the possibility of a malfunction in the cooling system from improper handling
during transportation.
•Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page 8)
Installing Your Freezer
•This appliance is designed to be free standing only, and should not be recessed or built-in.
•Place your freezer on a floor that is strong enough to support the freezer when it is fully loaded.
•Allow 5 inches of space between the back and sides of the freezer, which allows the proper air
ventilation. Adjust the feet to keep the freezer level.
•Locate the freezer away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Ambient temperature below 50°F or above 85°F will hinder the performance of this
appliance. This unit is not designed for use in a garage or any other outside installation.
•Avoid locating the freezer in moist areas.
•Plug the freezer into dedicated, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an

5
authorized service center. This unit is not designed to be installed in an RV or used with an
inverter.
•After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for
2~3 hours under before placing food in the freezer compartment.
Electrical Connection
This freezer should be properly grounded for your safety. The power cord of this freezer is equipped
with a three-prong plug which mates with standard three prong wall outlets to minimize the possibility
of electrical shock.
Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.
This freezer requires a standard 115/120 Volt A.C. ~/60Hz electrical outlet with three-prong ground.
This freezer is not designed to be used with an inverter.
The cord should be secured behind the freezer and not left exposed or dangling to prevent accidental
injury.
Never unplug the freezer by pulling the power cord. Always grip the plug firmly and pull straight out
from the receptacle.
Do not use an extension cord with this appliance. If the power cord is too short, have a qualified
electrician or service technician install an outlet near the appliance. Use of an extension cord can
negatively affect the performance of the unit.
The “POWER” light (Green) indicates that the freezer is properly connected to the electrical power.
The "FAST FREEZE" light (Red), while the switch is pressed, the light is on. The compressor works
ceaselessly, in order to get a best freezing effect.
The “COMPRESSOR” light (Orange) will not illuminate when the unit is operating below freezing.
The “COMPRESSOR” light will illuminate when the temperature inside the unit increases above
freezing. Please be advised that the “COMPRESSOR” light may come on for a period of time when
the lid is opened, when new items are stored inside the unit or when the lid is forced open by irregular
contents.
Do not call for service unless the “COMPRESSOR” light has remained on for 6 hours or more. If this
light stays on continuously for a period of 6 hours, please contact our Customer Service Dept. to
consult with a representative at 888 775-0202 or visit our website to request warranty service at
www.mcappliance.com.


WARNING


Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized service center.

6
OPERATING YOUR FREEZER
Temperature Control
•Your freezer has one control for regulating the
temperature. The temperature control is located on the
lower right hand corner.
•The first time you turn the unit on, adjust the
temperature control knob to “4” and run for at least 2
hours before putting frozen foods inside. This will
ensure the cabinet is thoroughly chilled before food is
put in.
•The range of the FREEZER temperature control is
from position "1" the warmest to "6" the coldest. Adjust
the temperature control to the setting that best suits your needs. The setting of “4” should be
appropriate for home or office freezer use.
•To turn the freezer off, turn the temperature control to "OFF".
But the freezer will not stop working if you turn the control to "OFF" position when the fast
freezing light is on.
•NOTE：
：：
：
•If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the
unit. If you attempt to restart before this time delay, the freezer will not start.
•Large amounts of food will lower the cooling efficiency of the appliance.
•If you choose to change the thermostat setting, adjust thermostat control by one
numerical increment at a time. Allow several hours for temperature to stabilize between
adjustments.
The Fast Freeze Switch
•The light glows while the Fast Freeze switch is in the ‘ON’ position.
•The switch overrides the thermostat and will make the compressor operate continuously, lowering
the cabinet temperature still further than the thermostat setting.
•This switch is used to freeze unfrozen food in appreciable quantities.
•When loading the freezer, freeze only three pounds of fresh food per cubic foot of freezer space
at one time.
•Distribute packages to be frozen evenly throughout the freezer.
•It is not necessary to adjust the thermostat setting when using the Fast Freeze switch.
•The Fast Freeze switch should be left on for a maximum of 2 hours.
Defrosting Your Freezer
•When? For the most efficient operation and minimum energy consumption, defrost the freezer
when the frost on the freezer walls is excessive or ¼ to ½ inch thick.
•Choose a time when the stock of frozen food is low.
CAUTION
Do not use boiling water because it may damage the plastic parts. In addition, never
use a sharp or metallic instrument to remove frost as it may damage the cooling coils
and will void the warranty.
•Remove the frozen food from the freezer and place it in a cooler to protect the food.
•Unplug the freezer. The Power Supply light should be off (green light out).
•During defrosting, the ice melts into the cabinet.

7
•Remove the drain plug on the inside floor of the freezer by pulling straight out.
•Place a shallow pan outside drain outlet. The defrost water will drain out.
•Check the pan occasionally so the water does not overflow.
•Clean the interior of the freezer.
•Replace the plug on the inside floor.
•Plug the unit (green light on)
•Adjust the temperature control knob to “3”.
•Allow the cabinet to cool for one hour.
•Return food to the freezer.
HELPFUL HINT:
Defrosting usually takes a few hours. Leaving the door open will help speed the
process. Also, pouring warm water (not boiling) on the ice/frost will help speed
melting.


WARNING


Scraping ice from the freezer compartment can damage the unit.
The Freezer Compartment
•This compartment is designed for the long-term storage of frozen food. Storage time period is up
to three months.
•The storage life of frozen foods varies and the recommended storage time should not be
exceeded. The instructions regarding the care of frozen foods should be followed when
defrosting the freezer.
•Pre-packed commercially frozen food should be stored in accordance with the frozen foods
manufacturers’ instructions for a three star frozen food storage compartment or home freezer.
•Place frozen food into the freezer as quickly as possible after purchase. If there are instructions
on the packet, carefully follow these instructions regarding storage times.
•The freezer lid is susceptible to breaking due to excessive ice build up. Be sure to defrost when
the ice reaches ¼ to ½ inch thick.
•A storage basket is provided for the organization of odd-shaped items. To reach other packages
in the freezer, just slide the basket to one side, or lift it out. Additional storage baskets can be
purchased via our website at www.mcappliance.com.

8
CARE AND MAINTENANCE
Cleaning Your Freezer
•Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.
•Unplug the freezer; remove the food and storage basket.
•Wash the inside with a damp warm cloth soaked in lukewarm water and baking soda solution.
The solution should be about 2 tablespoons of baking soda to a quart of water.
•Wash the storage basket with a mild detergent solution.
•Be sure to keep the door gasket (seal) clean to keep the unit running efficiently.
•The outside of the freezer should be cleaned with mild detergent and warm water.
•Dry the inner parts of the cabinet and exterior with a soft cloth.
•It is recommended that the unit be cleaned each time it is defrosted to help keep the unit odor free
and running efficiently.
Vacation Time
•Short vacations: Leave the freezer operating during vacations of less than three weeks.
•Long vacations: If the appliance will not be used for several months, remove all food and unplug
the power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the door open slightly: blocking it open if necessary or have the door removed.
Moving Your Freezer
•Unplug the freezer.
•Remove all the food.
•Securely tape down all loose items inside your freezer.
•Remove the rollers to prevent damage.
•Tape the doors shut.
•Be sure the freezer stays in the upright position during transportation.
Energy Saving Tips
•The freezer should be located in the coolest area of the room, away from heat producing
appliances or heating ducts, and out of the direct sunlight.
•Let hot foods cool to room temperature before placing in the freezer. Overloading the freezer
forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
•Be sure to wrap foods properly, and wipe containers dry before placing them in the freezer. This
cuts down on frost build-up inside the freezer.
•Freezer storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the freezer less efficient.
•Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the door as soon as possible.

9
TROUBLESHOOTING GUIDE
You can solve many common freezer problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling for
service.
PROBLEM POSSIBLE CAUSE
Freezer does not operate. Not plugged in.
The circuit breaker tripped or a blown fuse.
Compressor turns on and off frequently. The room temperature is hotter than normal.
A large amount of food has been added to the
freezer.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The freezer does not have the correct
clearances.
The freezer has recently been disconnected for a
period of time. 4 hours are required for the
freezer to cool down completely.
Temperature inside the freezer is too warm. Temperature control is set too warm. Turn the
control to a cooler setting and allow several hours
for the temperature to stabilize.
Door is kept open too long or is opened too
frequently. Warm air enters the freezer every
time the door is opened. Open the door less
often.
The door is not closed completely.
The door gasket does not seal properly.
A large amount of warm or hot food might have
been stored recently. Wait until the freezer has
had a chance to reach its selected temperature.
The freezer has recently been disconnected for a
period of time. 4 hours are required for the
freezer to cool down completely.
Temperature inside the freezer is too cold. Temperature control is set too cold. Turn the
control to a warmer setting and allow several
hours for the temperature to stabilize.
Temperature of external freezer surface is warm. The exterior freezer walls can be as much as
30οF warmer than room temperature. This is
normal while the compressor works to transfer
heat from inside the freezer cabinet.
Popping or cracking sound when compressor
comes on.
Metal parts undergo expansion and contraction,
as in hot water pipes. This is normal. Sound will
level off or disappear as freezer continues to run.
Bubbling or gurgling sound, like water boiling. Refrigerant (used to cool freezer) is circulating
throughout the system. This is normal.
Vibrations. Check to assure that the freezer is on a level
surface.
Floor is uneven or weak. Freezer rocks on the
floor when it is moved slightly. Be sure floor can
adequately support freezer. Level the freezer by
putting wood or metal shims under part of the

10
freezer.
The freezer is touching the wall. Re-level the
freezer and move it from the wall.
See “Installation Instructions”.
Moisture forms on inside freezer walls. Weather is hot and humid, which increases
internal rate of frost build-up. This is normal.
Door is slightly open.
Door is kept open too long, or is opened too
frequently. Open the door less often.
The door is not sealed properly.
Moisture forms on outside of freezer. Door is slightly open, causing cold air from inside
the freezer to meet warm moist air from outside.
The door will not close properly. The freezer is not on a level surface.
The gasket is dirty.
The storage basket is out of position.

11
Chest Freezer Warranty
MC Appliance Corporation warrants each new Freezer to be free from defects in
material and workmanship and agrees to remedy any such defect or to furnish a new
part(s) (at the company’s option) for any part(s) of the unit that has failed during the
warranty period. Parts and labor expenses are covered on this unit for a period of
one year after the date of purchase. In addition, MC Appliance Corporation
warrants the compressor (parts only) to be free from defects in material and
workmanship for a period of 5 years. The consumer is responsible for all labor and
transportation expenses related to the diagnosis and replacement of the compressor
after the initial one-year warranty expires. A copy of the dated sales receipt /
invoice is required to receive warranty service.
This warranty covers appliances in use within the continental United States, Puerto
Rico and Hawaii. The warranty does not cover the following:
Damages due to shipping damage or improper installation.
Damages due to misuse or abuse.
Content losses due to failure of the unit.
Inside components such as door panels, door shelves, racks, chest freezer
lid liners, light bulbs, etc.
Punctures to the evaporator system due to improper defrosting of the unit.
Repairs performed by unauthorized service agents.
Service calls that do not involve defects in material and workmanship such as
instruction on proper use of the product, door reversal or improper installation.
Replacement or resetting of house fuses or circuit breakers.
Failure of this product if used for other than for its intended purpose.
Disposal costs for any failed unit not returned to our factory.
Any delivery costs incurred as the result of a unit that fails to perform as
specified.
This warranty is in lieu of all warranties expressed or implied and no representative
or person is authorized to assume for us any other liability in connection with the sale
of this product. Under no circumstances is the consumer permitted to return this unit
to the factory without prior written consent from MC Appliance Corporation.
Model Parts Labor Compressor (Part Only) Type of Service
MCCF10WMD One-Year One-Year Five Years In-Home
For Service or Assistance please call 888 775-0202. Or visit us on the web at
www.mcappliance.com to request warranty service.
