Magrini
Viva Espresso Machine
with GTV
USER GUIDE
Hot Beverage Guide
‘the Perfect Serve’

Magrini VIVA GTV Espresso Machine
ESPRESSO
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Espresso Cup
Finished Espresso Drink
››
Place the cup under the handle
››
Press the single button if single handle or double
coffee button if double handle
››
When the machine stops pouring place the cup on
a saucer
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
Single Coffee Pod Double Coffee Pod
Knockout Bar
››
Remove the old coffee pod by knocking the
handle against the plastic bar in the knockout box
››
Remove the correct handle from the machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group
››
Place the handle into the machine
››
REMEMBER: SINGLE HANDLE, SINGLE POD - DOUBLE HANDLE, DOUBLE POD
Single Coffee Button
1
2
3
4
5
6
Single Coffee Button

Magrini VIVA GTV Espresso Machine
AMERICANO
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Americano Cup
Finished Americano Drink
››
Place the cup under the hot water nozzle and press the
hot water button once
››
Place the cup still with water in under the handle
››
Press the single button if single handle or double
coffee button if double handle
››
If using a double handle place a cup under each
spout of double handle
››
When the machine stops pouring place the cup on
a saucer
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
Single Coffee Pod Double Coffee Pod
Knockout Bar
››
Remove the old coffee pod by knocking the
handle against the plastic bar in the knockout box
››
Remove the correct handle from the machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group
››
Place the handle into the machine
››
REMEMBER: SINGLE HANDLE, SINGLE POD - DOUBLE HANDLE, DOUBLE POD
Single Coffee Button
1
2
3
4
5
6
Hot Water Nozzle
Single Coffee Button

Magrini VIVA GTV Espresso Machine
LATTE using Milk Autofrother
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Place the milk jug next to the Autofrother
››
Fill with milk to at least just above the bottom of
autofrother and no more than 2/3
(This will make 1-2 drinks) Mik Jug Pour Milk Into Jug
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
››
REMEMBER: SINGLE HANDLE, SINGLE POD -
DOUBLE HANDLE, DOUBLE POD
Single Coffee Pod Double Coffee Pod
Knockout Bar
››
Remove the old coffee pod by knocking the handle
against the plastic bar in the knockout box
››
Remove the correct handle from machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group.
››
Place the handle into the machine
››
Press the autofrother button on and off to purge
the steam wand
››
Ensure that the autofrother cover is on
››
Place the jug with milk under the autofrother
››
Press the button to start the autofrother Purge Steam Wand Jug Under Autofrother
1
2
3
4
5
6
Single Coffee Button

Magrini VIVA GTV Espresso Machine
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Latte Cup
Finished Latte Drink
››
Place the cup under the handle
››
Press the single button if single handle or double coffee
button if double handle.
››
When the machine stops pouring place the cup on a saucer
Single Coffee Button
››
Place the coffee cup on a saucer
››
Pour the milk into the centre of the espresso,
shake the jug slightly as the drink is finished
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
››
Remove the milk jug from the autofrother when it automatically
finishes
Remove Jug from
Autofrother
››
Press the autofrother button on and off to purge
the steam wand
››
Remove the autofrother sleeve and run through with
hot water
››
Wipe the stainless steel arm
Wipe Stainless Steel Arm
Pour Milk Into Centre of
Espresso
Clean Sleeve Under
Hot Water
LATTE using Milk Autofrother
7
8
9
10
11

Magrini VIVA GTV Espresso Machine
CAPPUCCINO using Milk Autofrother
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Place the milk jug next to the Autofrother
››
Fill with milk to just above the bottom of autofrother
(This will make 1-2 drinks) Mik Jug Pour Milk Into Jug
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
››
REMEMBER: SINGLE HANDLE, SINGLE POD -
DOUBLE HANDLE, DOUBLE POD
Single Coffee Pod Double Coffee Pod
Knockout Bar
››
Remove the correct handle from the machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group.
››
Place the handle into the machine
››
Press the autofrother button on and off to purge
the steam wand
››
Ensure the autofrother cover is on
››
Place the jug with milk under the autofrother
››
Press the button to start the autofrother Purge Steam Wand Jug Under Autofrother
1
2
3
4
5
6
››
Remove thr old coffee pod by knocking the handle
against the plastic bar in the knockout box
Single Coffee Button

Magrini VIVA GTV Espresso Machine
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Cappuccino Cup
Finished Cappuccino Drink
››
Place the cup under the handle
››
Press the single button if single handle or double coffee
button if double handle.
››
When the machine stops pouring place the cup on a saucer
Single Coffee Button
››
Place the coffee cup on a saucer
››
Take the milk jug and knock on bar top 3 times
››
Swirl to mix milk and foam
››
Pour thick milk into the centre of the espresso
››
Dust with chocolate
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
››
Press the autofrother button on and off to purge
the steam wand
››
Remove the autofrother sleeve and run through with
hot water
››
Wipe the stainless steel arm
Pour Milk Into Centre of
Espresso
CAPPUCCINO using Milk Autofrother
7
8
››
Remove the milk jug from the autofrother when it automatically
finishes
Remove Jug from
Autofrother
9
10
11
Wipe Stainless Steel Arm Clean Sleeve Under
Hot Water
Knock Jug on Bar Top
then Swirl

Magrini VIVA GTV Espresso Machine
HOT CHOCOLATE using Milk Autofrother
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Place the milk jug next to the Autofrother
››
Fill with milk to at least just above bottom of
autofrother and no more than 2/3
(This will make 1-2 drinks) Mik Jug Pour Milk Into Jug
››
Place the cup under the hot water outlet
››
Press the hot water button on and off to dispense
enough water to make a paste
››
Mix the powder and water together
Dispense Hot Water Mix to Make Paste
››
Press the autofrother button on and off to purge
the steam wand
››
Ensure the autofrother cover is on
››
Place the jug with milk under the autofrother
››
Press the button to start the autofrother Purge Steam Wand Jug Under Autofrother
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Hot Chocolate Cup
››
Put 2 teaspoons of hot chocolate powder into the cup
Powder & Cup
Finished Hot Chocolate Drink
››
Place the cup on a saucer
››
Pour the milk into the centre of the drink and stir
with a teaspoon
››
Serve
Stir to Mix
1
2
3
4
5
6

Magrini VIVA GTV Espresso Machine
TEA
››
Select teapot
››
CHECK: No cracks or chips
››
CHECK: Pot is clean and dry
Teapot
››
Fill milk jug with cold milk and serve with
teapot and cup
››
Place teabag in pot
Place Teabag in Pot
››
Place teapot under hot water outlet and press hot
water button twice to fill teapot - levels may vary
Press Hot Water Button
twice to Fill Teapot
››
Remove teapot and replace lid
Replace Lid
Serve Milk Jug, Teapot & Cup
1
2
3
4
5

Magrini VIVA GTV Espresso Machine
LATTE using Manual Milk Arm
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Fill with milk to no more than 1/2 full -
(This will make 1-2 drinks)
››
Attach the thermometer to the milk jug Mik Jug Jug & Thermometer
››
Put the jug under the steam arm so the tip of the steam
arm is just below the surface of the milk
››
Turn the steam arm on fully
Tip of Steam Arm Just
Below Surface of Milk
Turn Steam Arm on
Fully
Steam Arm Position
››
Make sure the manual steam arm tip is
pointed towards the drip tray
››
Turn the black steam tap 1/4 turn on and off
again to purge the steam arm
››
Using the black rubber grip position steam arm
as shown Point Tip to Drip Tray &
Purge Steam Arm
Keep Jug in Same
Position
››
Keep the jug in the same position until the milk
temperature reaches 140°
››
Turn off the black steam tap
››
Remove the jug from the steam arm
1
2
3
4
5
6
Turn Off Steam Tap
››
Wipe the steam arm with the probe wipes & turn the
black steam tap to purge the arm
››
Ensure the tip of the steam arm is pointed towards the
drip tray
Steam Arm Over Tray
Wipe Steam Arrm
››
Remove correct handle from machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
7
Knockout
Bar
››
Remove old coffee pod by knocking handle against plastic
bar in knockout box

Magrini VIVA GTV Espresso Machine
Finished Latte Drink
››
Remove the thermometer from the jug
››
Bang the jug 3 times on a flat surface keeping the
base of the jug on the surface swirl the milk until it
shines
››
Place the coffee cup on a saucer
››
Pour the milk into the centre of the espresso, shake
the jug slightly as drink is finished
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
LATTE using Manual Milk Arm
8
9
10
11
12
Pour Milk Into Centre of
Espresso
Knock Jug on Bar Top
then Swirl
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
››
REMEMBER: SINGLE HANDLE, SINGLE POD - DOUBLE HANDLE, DOUBLE POD
Single Coffee Pod Double Coffee Pod
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group.
››
Place the handle into the machine
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Latte Cup
››
Place the cup under the handle
››
Press the single button if single handle or double coffee
button if double handle.
››
When the machine stops pouring place the cup on a saucer
Single Coffee Button
Single Coffee Button

Magrini VIVA GTV Espresso Machine
CAPPUCCINO using Manual Milk Arm
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Fill with milk to no more than 1/2 full -
(This will make 1-2 drinks)
››
Attach the thermometer to the milk jug Mik Jug Jug & Thermometer
››
Put the jug under the steam arm so the tip of the steam
arm is just below the surface of the milk
››
Turn the steam arm on fully
Tip of Steam Arm Just
Below Surface of Milk
Turn Steam Arm on
Fully
Steam Arm Position
››
Make sure the manual steam arm tip is
pointed towards the drip tray
››
Turn the black steam tap 1/4 turn on and off
again to purge the steam arm
››
Using the black rubber grip position steam arm
as shown Point Tip to Drip Tray &
Purge Steam Arm
Keep Jug in Same
Position
››
Gradually lower the jug as the milk grows
››
When the temperature reaches 140° turn off the black
steam tap
››
Remove the jug from the steam arm
1
2
3
4
5
6
Turn Off Steam Tap
››
Wipe the steam arm with the probe wipes & turn the
black steam tap to purge the arm
››
Ensure the tip of the steam arm is pointed towards the
drip tray
Steam Arm Over Tray
Wipe Steam Arrm
››
Remove the correct handle from the machine -
single handle for one drink or double
handle for two drinks
Single Handle Double Handle
7
Knockout
Bar
››
Remove the old coffee pod by knocking the handle
against the plastic bar in the knockout box

Magrini VIVA GTV Espresso Machine
Finished Cappuccino Drink
››
Remove the thermometer from the jug
››
Place the coffee cup on a saucer
››
Take the milk jug and knock on bar top 3 times
››
Swirl to mix milk and foam
››
Pour thick milk into the centre of the espresso
››
Dust with chocolate
››
Serve
››
Remember the rule of 3:
Single handle, single pod, single button
Double handle, double pod, double button
CAPPUCCINO using Manual Milk Arm
8
9
10
11
12
Pour Milk Into Centre of
Espresso
Knock Jug on Bar Top
then Swirl
››
Check the handle is clean
››
Select the correct coffee pod – single (7g) for single
handle or double (14g) for double handle
››
Ensure the pod selected is in a sealed pack
››
Open the pack carefully making sure the pod is not torn
››
Place the correct pod into the correct handle -
››
REMEMBER: SINGLE HANDLE, SINGLE POD - DOUBLE HANDLE, DOUBLE POD
Single Coffee Pod Double Coffee Pod
Place Handle in Machine
››
Before placing the handle into the machine press the
single coffee button on and off to purge the group.
››
Place the handle into the machine
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Cappuccino Cup
››
Place the cup under the handle
››
Press the single button if single handle or double coffee
button if double handle.
››
When the machine stops pouring place the cup on a saucer
Single Coffee Button
Single Coffee Button

Magrini VIVA GTV Espresso Machine
HOT CHOCOLATE using Manual Milk Arm
››
Take the Milk jug
››
CHECK: Milk jug is clean
››
Fill with milk to no more than 1/2 full -
(This will make 1-2 drinks)
››
Attach the thermometer to the milk jug Mik Jug Jug & Thermometer
››
Put the jug under the steam arm so the tip of the steam
arm is just below the surface of the milk
››
Turn the steam arm on fully
Tip of Steam Arm Just
Below Surface of Milk
Turn Steam Arm on
Fully
Steam Arm Position
››
Make sure the manual steam arm tip is
pointed towards the drip tray
››
Turn the black steam tap 1/4 turn on and off
again to purge the steam arm
Point Tip to Drip Tray &
Purge Steam Arm
Keep Jug in Same
Position
››
Keep the jug in the same position until the milk
temperature reaches 140°
››
Turn off the black steam tap
››
Remove the jug from the steam arm
1
2
4
5
6
Turn Off Steam Tap
››
Wipe the steam arm with the probe wipes & turn the
black steam tap to purge the arm
››
Ensure the tip of the steam arm is pointed towards the
drip tray
Steam Arm Over Tray
Wipe Steam Arrm
››
Using the black rubber grip position steam arm
as shown
3

››
Mix powder and water together
10
››
Put 2 teaspoons of hot chocolate powder into cup
Mix to Make Paste
Mix to Make Paste
Magrini VIVA GTV Espresso Machine
Finished Hot Chocolate Drink
››
Place cup on saucer
››
Pour milk into centre of drink and stir with teaspoon
››
Serve
HOT CHOCOLATE using Manual Milk Arm
7
11
Stir to Mix
››
Select the cup
››
CHECK: No cracks or chips
››
CHECK: Cup is clean and dry
››
CHECK: Cup is warm – if not then rinse with hot water
from the hot water outlet and empty out the water Latte Cup
8
››
Place cup under hot water outlet
››
Press hot water button on and off to dispense enough
water to make a paste
9
Dispense Hot Water

Tel: [phone] Email: [email protected]
www.magrini.co.uk
Magrini VIVA GTV Espresso Machine
BEST PRACTICE
››
Never wash coffee cups in the glass washer
››
Never leave the steam arms soaking in any liquid
››
Do not leave milk to dry on the steam arm
››
Wipe steam wand and clean sleeve after every use
››
Purge steam wand before and after foaming milk
››
Ensure cups are always warm, if not, warm quickly using hot water
››
Do not empty coffee pod into the bin until the next coffee is needed
››
If milk is not foaming correctly, check the following:
• Level of milk in foaming jug is 10cm above the tip of the steam arm
• The three holes as indicated in the cleaning instructions are clean
• The milk being used is cold and has not already been foamed
Coffee Pods
››
Coffee Pods contain ground coffee only
››
Coffee Pods should be in date and in a sealed bag
››
Do not store coffee pods on the cup warmer
Milk
››
Milk should be used chilled from the fridge
››
Only use fresh milk that is in date
5 Point Check List
››
Purge both steam wands - you should see water/steam.
If milk residue is present then site are not purging steam wand 4
››
Appearance of steam wand - should not see milk residue 4
››
Use consumables checklist to ensure all parts are at machine 4
››
Have a drink - use best serve guide 4
››
Take filter basket out of handle - you should see metal not black 4
