Mahindra Centuro User manual

Dear Customer,
Welcome to the Mahindra family of Thinking Machines.
Congratulations! You are now a proud owner of Mahindra Centuro.
Centuro is an Intelligent Machine that will create a new milestone in the evolution of
motorcycles. The intelligence of Centuro is due to many extraordinary features found in
various combinations across the three variants O1,O2 & O3.
The O3 variant has a premium, attractively designed Flip key with Remote that makes
you the envy of all other bike owners. It is equipped with an Intelligent MCi-5 ( Micro
Chip Ignited 5 Curve) engine that responds to your need for power and mileage as per
your command. The “Guide Lamps” stay on even after you switch off the ignition
keeping your path illuminated. Locating the Bike's ignition lock in the dark becomes
easy with the LED light in the key.
In addition to these features the O2 Variant comes with the “Find-Me” lamps that help
you easily locate your bike in crowded parking lots with just a click of a button. It is
loaded with an Anti-Theft System that comes with an inbuilt Engine Immobilizer that
sounds an alarm and locks the engine when someone tries to steal your bike.
The top-end O1 variant has all these features and also includes a stylish Digital
Dashboard which comes with a white back light and a Distance to Empty Indicator that
allows you to know approx. distance you can travel once your bike hits reserve. The
Service Reminder indicator tells you when your bike is due for service.

We are with you to ensure that you enjoy many happy miles on the Mahindra Centuro.
Your motorcycle is a product of Mahindra Two Wheelers's advanced engineering and
exhaustive testing to deliver Comfort, Safety, Reliability and Optimum performance.
This booklet will guide you to the basic operation, routine maintenance and service
policy of Mahindra Centuro. Please spend time to read this booklet carefully which will
let you know the proper care and maintenance of your Centuro. This is essential for
trouble free operation and optimum performance.
All Authorized outlets of Mahindra Two Wheelers are well equipped to handle all your
service requirements and will be glad to provide you further information and assistance
for the same.

© MAHINDRA TWO WHEELERS LIMITED
Information contained in this owner's guide is based on the latest product
information available at Wheeler time of approval for printing. Mahindra Two
Limited reserve the rights to make at any time without notice & changes
Accessories shown may not be part of standard equipment.
This Owner Guide can be referred to for Centuro and all its variants for functional,
No part of this publication may be reproduced without prior written consent of
Mahindra Wheelers Limited. Two
operational and maintenance information.
NOTE :-
without incurring any obligation.
All copyrights reserved with the company.

OWNER IDENTIFICATION
STAMP OF AUTHORIZED DEALER
Owner's Name :
Address :
City : State : C ountry :
Mobile No.: Tel. No. :
E-mail :
Frame No.:
Engine No.:
(Stamped on the lower side of the LH crankcase.)
Key No.: Battery Make :
Battery Sr. No.: Battery Mfg. Code :
Date of Regn.:
D
ealer Code :
(Stamped on the right side of the steering stem of the chassis.)
Colour :

MAINTAINING YOUR CENTURO
Warranty :
Quality of Centuro vehicles is guaranteed through a comprehensive warranty policy
that
sale. Details of warranty terms and conditions and warranty registration card is
included in this owner's guide.
Maintenance :
The ownership experience of any automotive product is strongly affected by usage and
maintenance. A vehicle is a machine and is subject to wear and tear during daily use as
well as damage resulting from accidents, adulterated fuel etc. We strongly advise you to
read this owner's guide carefully and follow the maintenance schedules to ensure
optimum performance of the machine.
Mahindra Two Wheelers recommended servicing schedules :
designed to keep your vehicle in perfect running condition during daily use. This
owner's guide includes instructions and coupons for availing the company
recommended servicing schedule. The coupons will be accepted at all Authorized
Mahindra Two wheelers dealerships and service centres.
It has been a constant endeavor from Mahindra Two Wheelers to provide the best care
and service for your motorcycle. Remember that your Mahindra Two Wheeler dealer is
just a call away. The Technicians at Mahindra Two Wheeler dealer are thoroughly
trained and our workshops have 'State of Art' equipments to take care of your vehicle.
covers a period of 2 years or running of 30,000 km, whichever is earlier from the date
of
We offer you 6 free services. Later on periodic program of paid services is specially

So make sure to take your Centuro to the nearest Mahindra Two Wheeler dealer for
regular service and check- ups.
We understand your vehicle more than anybody else.
We strongly urge you to practice safe driving and please do remember to wear helmet
while riding.
Wishing you a happy and safe ride.
Thank you.
Warm Regards,
Customer Care
Mahindra Two Wheelers Limited ,
D-1 Block, Plot No. 18/2(Part) M.I.D.C.,
Chinchwad, Pune - 411 019.
E-mail Id : [email protected]
Help Line No.: 1800 233 8883 (Toll Free)

MOTORCYCLE IDENTIFICATION 1
TECHNICAL SPECIFICATION 3
SAFETY GUIDELINES 5
SAFE LOADING AND ACCESSORIES 7
DAILY SAFETY CHECKLIST 8
RECOMMENDED USAGE GUIDELINES 9
PART LOCATION 11
PART FUNCTION 14
lIGNITION SWITCH 14
lDIGITAL INSTRUMENT PANEL 15
lANALOG INSTRUMENT PANEL 17
lWOW FEATURES 18
lRIGHT HANDLE BAR CONTROL 20
lLEFT HANDLE BAR CONTROL 21
lFUEL COCK 22
lFUEL TANK 23
TYRE 24
BATTERY 25
INSPECTION BEFORE RIDING THE VEHICLE 26
STARTING THE ENGINE 26
RIDING 28
BRAKING 29
PARKING 29
MAINTENANCE GUIDELINES 30
CONTENTS :
DESCRIPTION PAGE NO.

CONTENTS :
DESCRIPTION PAGE NO.
MAINTENANCE SCHEDULE 33
ENGINE OIL 35
MAINTENANCE 37
lSPARK PLUG 37
lOIL FILTER SCREEN & CENTRIFUGAL FILTER 39
lAIR CLEANER 40
lCARBURETTOR 42
lCLUTCH 43
lFRONT BRAKE ADJUSTMENT 44
lREAR BRAKE ADJUSTMENT 45
lDRIVE CHAIN 46
lFRONT WHEEL REMOVAL 48
lREAR WHEEL REMOVAL 49
lBRAKE WEAR INDICATOR 50
BASIC TROUBLE SHOOTING 51
WARRANTY
WARRANTY REGISTRATION CARD
SERVICE RECORD SHEETS
DELIVERY CERTIFICATE
FREE SERVICE COUPONS
SERVICE ADVICE SHEETS
CERTIFICATE OF FITNESS

Frame No. (Alpha Numeric 17 digit)
Frame No. Location- Stamped on the right side of the steering stem of the chassis .
Plant Code
WMI Code Month Code
Year Code
Transmission
Engine Production Serial No
Model Code Drive
1
M A
1
D
4
1
KB
1
GC D0
0 0 10
16
14
13
12
11
10
9
876
5
3 42 15 17
VIN - Vehicle Identification Number
MCDKM1B14C1H00001
MOTORCYCLE IDENTIFICATION
1
VIN NUMBER - 17 DIGIT

Engine No. (Alpha Numeric 11 digit)
Engine No. Location- Stamped on the lower side of the LH crankcase .
10
987654321 11
00000
A
D
E
NV 1
Model Code Engine Year Code
Month Code
Serial No
2
10
987654321 11
00
0
00
ADE
BU 1
Model Code Engine Year Code
Month Code
Serial No
Electric & Kick start
Kick start
VNE-CL 000713

TECHNICAL SPECIFICATIONS
Dimensions Overall Length : 2030 mm
Overall Width : 740 mm
Overall Height : 1111 mm
Wheelbase : 1265 mm
Weight Kerb Weight (With 90% Fuel, : 120 kg
Capacities Engine Oil - First Fill :
1000 ml
:
Fuel Tank
Engine Oil - Service Fill 900 ml
:
Engine
:3
106.7 cm
Bore And Stroke :52.4 x 49.5 mm
Compression Ratio :9.6 : 1
Spark Plug (Standard) :MICO UR4AC
Spark Plug Gap :0.7 mm
Idle Speed :1400 rpm± 100
Intake : 0.05 mm±0.03
Minimum Ground Clearance : 173 mm
12.7 Liters
Max Power :8.5 N.m@ 5500 rpm
:
Displacement
Valve Clearance (Cold )
Tools etc.)
3
Exhaust : 0.05±0.03 mm
[ [
(SAE 20W40 SL-JASO MA)
Castrol Activ 4T

Chassis And Suspension
Chassis Type : Tubuler
Telescopic and coil spring
Front Suspension :
Power Transmission
Primary Reduction :3.722 : 1
:
Gear Ratio,
Final Reduction :
Lights
:
Tail / Brake light : LED
Turn Signal Indicator : 12V, 10W
12V, 5W
10A, 15A
:
:
Head Lamp : 12V 35/35W (HS1)
Number Plate Bulb
th
4
rd
3
nd
2
0.958 : 1
1.238 : 1
1.706 : 1
3.182 : 1
3.154 : 1
Electrical Alternator Output :
:
:
90W -Kick start, 110W-Electric start
Fuse Capacity
Starting System Electric And Kick Start/Kick start
Speedometer Digital / Analogue
Wheels Alloy Wheel/Spoke wheel
Battery 12V 2.5Ah-Kick start/12V 6Ah-Electric start
Tyre Size - Front 2.75 - 18 4 PR, 42P
Rear 3.00 - 18 6 PR, 52P
Swing arm and shock absorber with coil spring
Rear Suspension :
st
1
4
ITEM SPECIFICATION

SAFETY GUIDELINES :
Importance of Safety :
Your motorcycle can provide many years of service and pleasure - if you take
responsibility for your own safety and understand the challenges that you can meet on
the road.
There is much that you can do when you ride to protect yourself. You will find many
helpful recommendations throughout this booklet. Few most important are -
a) Always wear a Helmet
b) Make yourself easy to see
c) Ride within your limits.
Mahindra Two Wheelers urges you to practise safe riding. Here are few tips :
lFamiliarize yourself thoroughly with your motorcycle by reading this Owner's
Guide and follow operating instructions especially about starting, acceleration and
braking your vehicle.
lInitially, before riding in regular traffic practise riding in an uncongested area.
lStay within speed limits dictated by road, weather and traffic conditions. Riding at
a proper speed and avoiding unnecessary acceleration is important for your safety,
better fuel consumption, smooth operation and longitivity of your vehicle.
Helmets & Eye Protection :
Wearing helmet is most important because it offers, if it occurs, the best protection
against head injuries. A helmet should fit your head comfortably and securely. Always
wear a face shield or goggles to protect your eyes and help your vision.
5

Additional Riding Safety :
Sturdy footwear with non slip soles to help protect your feet and ankles. Leather gloves
to keep your hands warm and help to prevent blisters, cuts & burns.
A motorcycle riding suit or jacket for comfort as well as protection.
lIf it is must to ride during heavy or light rain, to avoid skidding exercise greater
caution.
lTo avoid injury to the brain caused by head injury in accidents, always wear a
helmet (conforming to appropriate specified standards) and other protective
apparel such as gloves, footwear etc.
lWhen faced with speed breakers, wet roads and potholes, slow down your
vehicle to avoid loss of control and mechanical damage to your motorcycle.
l During braking, use both front and rear brakes simultaneously, rear little harder to
retain control.
l Always follow the traffic rules.
l Always carry documents of vehicle registration, insurance, PUC certificate and a
valid driving license with you.
WARNING : Not wearing a helmet increases the possibility of serious injury or
death in a crash. Be sure you and your pillion rider also always wears a helmet, and
preferable eye protection and other protective apparel while riding.
6

SAFE LOADING AND ACCESSORIES :
General guidelines to help you to decide how to equip your motorcycle and how to
load it safely :
l
Ensure all luggage and accessories are secure for stable handling.
l
Do not carry items that protrude through the vehicle and affect vehicle
l
performance and operation.
Do not carry children or pets on the front.
l
Do not modify the motorcycle. It has been designed carefully by our experts and
l
any modification may adversely impact on it’s safety and performance.
Loading Guidelines :
Your motorcycle is primarily intended for transporting you and a passenger.
If you wish to carry cargo, check with your Mahindra Two Wheelers dealer for advice.
Improper loading of your motorcycle can affect its stability and handling. Even if your
motorcycle is properly loaded, you should ride at reduced speed whenever carrying
cargo.
Check that both tyres are properly inflated, with recommended air tyre pressure.
7

DAILY SAFETY CHECKLIST :
For assured safety and to save time & money in future before riding be sure to check the
following.:-
There is enough fuel in the tank to cover your planned journey, and there is no
Rear view mirrors are positioned to give good rear visibility.
Tyres have correct air pressure, adequate tread depth and no cracks/cuts on tyre.
Center stand and side stand are at fully up position.
All electricals (lights and horn) are working.
Brakes are not dragging.
Steering lock is operating well.
Throttle operation and it’s return is smooth.
Engine oil level is adequate.
8
fuel leakage.

It is important to drive your vehicle properly during initial 1000 km to ensure longitivity
and hassle free running. New engine components initially wear in quickly.
Please follow underneath instructions during "Running-In" period :
Do not exceed
ation.
After you start the engine, run it at idle for a minute to enable the oil to lubricate
entire the engine.
Cleaning Procedure :
Avoid spraying water under high pressure at the following areas :
Wheel hubs, Silencer outlet.
Ignition switch, handlebar switches and other electrical parts.
Underseat storage.
Dry the motorcycle, start the engine and let it run for several minutes.
Test the brakes before riding in traffic. Applications of brakes several times may
be necessary to restore normal braking performance.
l
l
l
t
t
t
After cleaning, rinse the motorcycle thoroughly with plenty of clean water to avoid
l
corrosion by residual detergent.
l
l
a speed limit of 50 km/h
lAvoid full throttle operation, and rapid acceler
RECOMMENDED USAGE GUIDELINES :
Running in Procedure :
CAUTION :
Immediately after washing the motorcycle Braking performance may be impaired.
9

General Tips For Maximizing Fuel Efficiency :
While your Centuro has been designed to give maximum fuel efficiency of its
specifications, it is important to understand that fuel efficiency is affected by several
extraneous factors i.e. rider usage habits, road conditions, traffic, wind flow etc.
lEnsure tyre pressure is maintained as per manufacturer’s recommended levels.
Different tyre pressures are recommended for single seat and double seat. Observe
them carefully. (Page No. 24)
lFront and Rear brakes should have the right amount of free play.
lEngine oil should be changed religiously as recommended in the maintenance
schedule.
lAlways use choke for cold start.
lTotal weight on the two wheeler makes a big difference to mileage, avoid
overloading.
lWhile filling the tank to full fill in the morning as petrol expands during the day as
atmospheric temp. increase & may spill.
lKeep your two wheeler clean and dust free.
lDo not fill fuel to the brim of the tank as there can be spillage and petrol can expand
and overflow.
lFill petrol from busy and well known petrol stations where quality and quantity are
assured.
lDo not rev the engine, unnecessarily.
lTry and avoid congested roads as far as possible, even if it means you have to take a
slightly longer route.
lGo gentle on the throttle.
10

0
2
468
10
12
PART LOCATION
1.
2. Turn signal switch 7. Instrument panel 12. Self start switch
3. Head light dimmer switch 8. Ignition switch 13. Lid fuel tank
4. Pass light switch 9. Front brake lever 14. Choke Lever
5. Clutch lever 10. Throttle grip
Horn switch 6. Rear view mirror 11. Head light switch
11
1
2
3
5
6
7
9
12
10
13
14
4
11
8

LEFT SIDE VIEW
1. Crash guard 4. Gear shift pedal 7. Side stand 10. Gabrail
2. Fuel cock 5. LH Side cover 8. Pillion foot rest 11. Seat Lock
3. Carburettor 6. Main stand 9. Saree guard
12
10
9
6
3
11
5
148
7
2
