Malloca MF-246EBI Technical manual

operation instruction
Please read this instruction carefully before use
Our company reserves the right to explain the instructions
The appearance of the product is subject to the actual product
Product technology or software upgrade without prior notice
MF-246EBI
Vui lòng đọc kỹ hướng dẫn trước khi sử dụng
Công ty chúng tôi giải thích các hướng dẫn
Sản phẩm phụ thuộc vào sản phẩm thực tế
Công nghệ sản phẩm hoặc nâng cấp phần mềm mà không cần thông báo trước
hướng dẫn sử dụng

Important Safety Caution
First Use of Product
Instruction Manual
Attentions before installation
Parts list for installation
Product and cabinet dimensions
Preparation before installation
Steps to put the refrigerator inside cabinet
Steps to install the cabinet door
Instruction to adjust cabinet door
Major Function Introduction
Steps for first use of product
Name for refrigerator components
Control panel
Power switch
Temperature adjustment in fresh compartment
Temperature adjustment in frozen compartment
Fast freeze function
Fast cooling function
Holiday mode function
Fridge compartment refrigeration power off function
Open door alarm function
Instruction and attentions for usage of refrigerator compartment
Suggested storage area for various foods
Usage of crisper box
Usage of bottle rack
Attentions for food storage in refrigerator compartment
Instruction and attentions for usage of freezer compartment
Attentions for food storage in refrigerator compartment
Attentions for food storage in freezer compartment
Daily maintenance for refrigerator
Clean refrigerator
Transportation of refrigerator
Abandon refrigerator
Table of contents

Dear customer：
Thanks for choosing our products. In order to guarantee the proper
usage of refrigerator and avoid personal injury, please carefully read
the contents with below symbols in this manual:
Electricity
Power
alternating current of this refrigerator is220V/50H，if voltage fluctuate too large(exceed
the range of 187-242V), the refrigerator may not start to work, The thermostat
compressor will burns out and compressor may sound abnormally,at this time, it must
be equipped with an automatic voltage stabilizer of more than 750W
Grounding
Power cord and plug
The refrigerator has to be powered with a special independent socket and reliably
grounded.
Please do not pull out the plug with jerk. Hold the power plug tightly, then pull
it out from socket directly. Make sure the power cord is not squeezed by the
refrigerator or user. Please be cautious to avoid damaging the power cord when
moving refrigerator away from the wall.
Do not use the damaged power cord or worn power plug. Please ask the
authorized service personals to replace the damaged power cord.
Please disconnect the refrigerator with power supply before cleaning, maintenance
and replacing LED light.
Leakage of flammable gas
In case of leakage of flammable gas, please open the doors and windows, do not
plug or unplug the power plug.
Important safety instructions
Warning
Attention
Mistaken operation may
result in personal injury
Mistaken operation may
result in personal injury
Strictly forbidden behavior
or operation
Behavior or operation that
must be observed

Usage
Food storage
Usage environment
This is household refrigerator which can only be used for food storage, please do
not store blood, medicine or biological in refrigerator. The flammable and explosive
dangerous products, highly corrosive acid or alkali shall not be stored in refrigerator.
When the refrigerator is running, do not touch the freezing surface in freezer
compartment with wet hands to avoid the skin adhered to the freezing surface.
Do not put bottled beer or drink inside the freezer compartment to avoid frost crack.
The refrigerator should be built-in the cabinet, please refer to the “Installation
instruction” for the specifications of cabinet.
  The refrigerator shall be placed away from heat source and avoid direct sunshine
to guarantee the performance.
Do not expose the refrigerator to freezing environment, outdoors or rain.
Do not place the refrigerator in moisture, if the refrigerator is splashed with
water, wipe the water out immediately in order to avoid rusting or damage of
electrical insulation performance.
Do not place the heavy or container filled with water on top of refrigerator in order
to avoid the personal injury or leakage of electricity caused by falling of the heavy
or container.
Do not place or use electrical appliances such as power plug, stabilized voltage
supply, microwave on top of or inside refrigerator to avoid electromagnetic
interference.
Do not store or use gasoline or other flammable substances near to refrigerator to
avoid fire disaster.
Maintenance
Clean
Service
Do not use water to spray the refrigerator, make sure the refrigerator is not
placed in wet environment to avoid damage of electrical insulation performance.
When clean the refrigerator, please pull out the power plug. Make sure the
refrigerator is powered off for at least 5 minutes before connecting to power supply
again, or else the compressor may breakdown due to consecutive operation.
Do not use water to spray the refrigerator, make sure the refrigerator is not
placed in wet environment to avoid damage of electrical insulation performance.
The refrigerator can only be disassembled or repaired by qualified serviceman.
Danger: Risk of child entrapment. Before you throw away your old refrigerator
or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily climb inside.

Tips: After changing the temperature setting, it will take some time before the cabinet temperature reach
balance.The length of time depends on ambient temperature,frequency of opening refrigerator doors and
the food storedin refrigerator.
First use of product
Preparations before using refrigerator
Remove all packaging materials including the foaming base and the adhesive
tapes to fix the accessories.
Please check the parts inside package according to packing list. If there is
difference, please consult the seller.
Check the accessories and materials
Place the refrigerator in proper position.
Please clean the refrigerator before use(refer to the chapter “clean of
refrigerator” on page 22)
After the refrigerator is leveled and cleaned, please wait 2 hours before
connecting to the power supply.
Please remove the protection film before use to guarantee the heat
dissipation of refrigerator.
Remove the protection film
Steps for first use of product
Connect to
power supply
After first connecting to
power supply, it will take
several hours for refrigerator
to complete the refrigeration.
The default preset
temperature is:
refrigerator compartment(5℃)
freezer compartment( -18℃)
Put the food
inside refrigerator
The food can be put into refrigerator
2-3 hours after connecting to power
supply.Please do not store too much
food in freezer compartment. The
total weight of the food stored in
each shelf should not be more
than 24kg.
Using
refrigerator
Keep the refrigerator running
for 24 hours to reach the
steady state after putting the
food inside refrigerator. After
that, the temperature can
be changed.

In order to make the refrigerator work well, please obey below installation steps.
Attentions before installation
Installation position
Please keep the refrigerator away from direct sunshine and heating appliances such as stove top,
over and dishwashers.
Power supply
Make sure the power plug can be easily pulled in and out when installing the refrigerator.
The power plug should be inserted into a special socket to avoid the unexpected power off of
refrigerator. Do not use extension cord or porous adapter.
To understand the requirement for power supply by referring to the nameplate in left side of
refrigerator.
The refrigerator should be correctly grounded.
Installation parts list
Installation instruction
1.front top plate 2.Hinge plate 3.Mounting plate
5.sealing strip
10.screw
(already installed)
Pcs Pcs Pcs Pcs
Pcs
Pcs
Pcs
10
Pcs
10
Pcs
6.Screw cap
Pcs
30
Pcs
2 Pcs
PcsPcs
7.Display small fixing plate 8.screw
9.screw 11.screw 12.bolt driver
B
A
CD

Basics size
cabinet size(mm) product size(mm)
Net empty width
Net empty depth
Net empty Height
Depth
Height
Width
upper
cabinet door
bottom
cabinet door
A:Edge dimension between the bottom door and cabinet body
H:Cabinet height
B:The distance between the lower and upper cabinet doors
The top plate front end of the cabinet is 10mm lower than the cabinet

Preparations before installing the refrigerator
1.Confirm the direction of opening the door
The refrigerator door is opened from left side.
If change to open door from right side,please
install the upper and lower hinge on left side
after reversing the hinges. The reversing
direction is shown as arrow in the diagram. I
nstall the hinge fixing plate, remove the small
fixing plate in left side, then install the small
fixing plate in right side after changing the
direction of opening the door.
Install the front top plate
Fix the front top plate in front top of
refrigerator with screws.
Hinge alignment indication Hinge fixation enlarge picture
Remove the left side fixed plate install the right mounting plate
front top plate
AA

The steps to put the refrigerator inside cabinet
Fix the side of hinges with 2 screws(one screw
to fix the first hinge, the other screw to fix the
fourth hinge), after installing the cabinet door ,
insert other screws into the screw holes on the
hinge,then tighten the screws.
Fix the lower bottom feet to cabinet with screws.
B
B
B
Pass the power cord through the hole on the back of the cabinet. If the power socket is inside cabinet, firstly
plug the power plug into socket then put the refrigerator inside cabinet
Move the refrigerator into cabinet, adjust the refrigerator position in fore-and-aft direction to ensure the front
of hinge fixing plate is leveled with cabinet.
CAUTION
Do not squeeze the power cord. A broken power cord may lead to fire disaster.

Loosen cap screws, then remove the mounting plate.
The cap screw
The cap screw
Mounting plate
DD
The steps to install the upper cabinet door
Measure the distance between upper mounting plate of refrigerator compartment door and top/left of
cabinet and record the position.
cabinetbody
Mounting plate

The procedure of installing the cabinet door to freezer compartment door is the same with the
procedure of installing the cabinet door to refrigerator compartment door .
Tuck the sealing strip into the gap between refrigerator and cabinet.
Fix the refrigerator door to cabinet door with lower mounting plate.
AC
C
A
The refrigerator door
cabinet shutter
bolt driver
plate to cabinet door with screws.
Fix the cabinet door to refrigerator compartment door with mounting plate, then tighten the screws ( please
do not overtighten the screws
because the screws need to be loosened later).
cabinet shutter
Mounting plate
AA

The steps to adjust the refrigerator cabinet door
Steps to adjust the upper end of refrigerator cabinet door
1.Adjustment of cabinet door in upward and downward direction
Adjustment in upward direction: Firstly adjust the cap screw D1
upwards,then adjust the cap screw
D2
upwards.
Adjustment in downward direction: Firstly adjust the cap screw
D2 downwards,then fix the cap screw .
2. Adjustment of cabinet door in leftward and downward/fore-and-aft direction
Adjustment in leftward and downward direction: Loosen cap screw D1, move the mounting plate to
right position, then fix cap screw D2.
Steps to adjust the lower end of refrigerator cabinet door
D1
D2
1.Loosen the screws slightly , then adjust
the
depth( Z) and tighten the screw.
.
adjust the depth
cabinetdoor
srew
2. Affter adjusting the horizontal position of refrigerator cabinet door fix the lower fixing pate refrigerator door
with screws.
A
C
D1

Tips for energy saving
During the installation process
Install the refrigerator in the place with the lowest indoor temperature , keep away from direct sunlight,
heating pipe,ventilation adjustment device and other heating appliances.
Make sure the refrigerator is well ventilated.
During use process
  Do not make the refrigerator full of foods to guarantee the air circulation.
Do not pad the shelves with anything such as aluminum foil,waxed paper or tissue.
    Do not make the refrigerator full of foods to guarantee the air circulation.
    Shorten unnecessary time of opening the door.
Before putting the food into refrigerator
Remove all packages.
Clean the cabinet with warm dish detergent to remove the dust during manufacturing and
transportation.
There is odor when first use the refrigerator, but the odor will disappear after the temperature
inside refrigerator is low enough.
Have the refrigerator running for 2-3 hours with no food inside to make every compartment
reach adequate temperature.
Main function introduction
The steps of first usage of refrigerator
During use process
main panel
The glass shelf
Fruit crisper
drawer
door rack

Control panel
1.Power switch
Power on the refrigerator
When the refrigerator is in power off status,press ”power switch”button for 3 seconds,
the indicator is on and the refrigerator starts running.
Power off the refrigerator
Press ”power switch”button for 3 seconds, the indicator is off and the refrigerator
stops running.
Power switch:
Temperature zone selection:
Temperature adjustment:
Function selection:
Temperature zone
displaying icon:
Temperature displaying icon:
Fast cooling icon:
Fast freeze icon:
Holiday mode icon:
Fridge compartment
refrigeration power off icon:
Power on/off the refrigerator
Select the temperature zone of refrigerator and freezer compartment
Adjust the temperature settings in selected temperature zone
Select functions of fast cooling,fast freeze, holiday
Display current temperature zone
Display the temperature setting or value for current temperature zone
Indicate the refrigerator is in fast cooling status
Indicate the refrigerator is in fast freeze status
Indicate the refrigerator is in holiday mode status
Indicate the fridge compartment refrigeration is power off
power switch
temperature
area displays icon
Temperature
range to choose
temperature
area displays icon The function icon
temperature control The function icon
Press 3 seconds the indicator goes
on( the
�refrigerator
starts running)
press 3 seconds agai nt he indicator goes
off( the
�refrigerator �
stops running)

2. Adjust the temperature inside refrigerator compartment
1.Press the “temperature zone selection”button, the refrigerator and freezer temperature
zone displaying icon will be lighted in turn.
2.Select refrigerator compartment temperature zone, the corresponding displaying icon will
be lighted and the actual temperature inside refrigerator compartment will be displayed.
3.Press “temperature regulation”button, the temperature displaying icon will display current
setting of refrigerator compartment and blink.
4.Press “temperature regulation”button again,the refrigerator compartment temperature
setting will cycle in turns:”08”-”07”-”06”-”05”-”04”-”03”-”02”-”08”.
If there is no pressing button operation in 5 seconds, current setting
will be confirmed.
3.Adjust the temperature inside freezer compartment
1.Press the “temperature zone selection”button, the refrigerator and freezer temperature
zone displaying icon will be lighted in turn.
2.Select freezer compartment temperature zone, the corresponding displaying icon will be
lighted and the actual temperature inside freezer compartment will be displayed.
3.Press “temperature regulation”button, the temperature displaying icon will display current
setting of freezer compartment and blink.
4.Press “temperature regulation”button again, the refrigerator compartment temperature
setting will cycle in turns:
"-12" "-13" "-14” "-15" "-16" "-17" "-18" "-19" "-20" "-21" "-22" "-23" "-24"
If there is no pressing button operation in 5 seconds, current setting will be confirmed.
Press select the refrigerate
temperature area
Press select Set the current gear Press select agains To set the gears
Press select the refrigerate
temperature area
Press select Set the current gear Press select agains To set the gears

4. Fast cooling function
Turn on fast cooling function
Press “mode selection”button, ”fast cooling” icon will blink. After 5 seconds,”fast cooling”
icon will be lighted and fast cooling function is enabled.
Turn off fast cooling function
In fast cooling mode, press “mode selection” button, the “fast cooling” icon will blink.
After 5 seconds, the “fast cooling”icon turns off and the refrigerator quits fast cooling mode.
5. Fast cooling function
Turn on fast freeze function
Press “mode selection”button, ”fast freeze” icon will blink. After 5
seconds,”fast freeze” icon will be lighted and fast freeze function is enabled.
Turn off fast freeze function
In fast freeze mode, press “mode selection” button, the “fast freeze” icon
will blink. After 5 seconds, the “fast freeze”icon turns off and the refrigerator
quits fast freeze mode.
Press select Quick cold icon flickers Quick freeze icon lights
up and enters quick freeze
Wait for 5
seconds
Press select Quick cold icon flickers
Wait for 5
seconds
The quick freeze icon
goes out exit quick-freeze state
Press select Quick cold icon flickers Press the selection again
and the frozen icon flashes
Quick freeze icon lights
up and enters quick freeze
Wait for 5
seconds
Press 2 times The frozen icon flickers
Wait for 5
seconds
The quick freeze icon goes
out exit quick-freeze state

6. Holiday mode function
Turn on holiday mode function
Press “mode selection”button 3 times, ”holiday mode” icon will blink. After 5 seconds,”
holiday mode” icon will be lighted and holiday mode function is enabled.
7. Fridge compartment refrigeration power off function
Turn on fridge compartment refrigeration power off function
Press “mode selection”button 4 times, ”fridge compartment refrigeration power off” icon will
blink. After 5 seconds,”fridge compartment refrigeration power off” icon will be lighted and
fridge compartment refrigeration power off function is enabled.
Turn off holiday mode function
In holiday mode function, press “mode selection” button 3 times, the “holiday mode” icon will
blink. After 5 seconds, the “holiday mode”icon turns off and the refrigerator quits holiday mode.
Turn off fridge compartment refrigeration power off function
In fridge compartment refrigeration power off mode, press “mode selection” button 4 times,
the “fridge compartment refrigeration power off” icon will blink. After 5 seconds, the “fridge
compartment refrigeration power off”icon turns off and the refrigerator quits fridge compartment
refrigeration power off mode.
8. Open door alarm function
If the refrigerator door is open for 180 seconds, the buzzer will sound alarm 3 times by 0.5
second interval.
If the refrigerator door is still open after 30 seconds, the buzzer will repeat sounding alarm 3
times by 0.5 second interval until the refrigerator door is closed.
Wait for 5
seconds
Wait for 5
seconds
Wait for 5
seconds
Wait for 5
seconds
Press 3 times Holiday icon flashing Holiday icon lighting
Press 3 times Holiday icon lighting Holiday icon quench
Press 4 times Close the refrigerated
icon to flicker
Close the refrigerator
icon and light up
Press 4 times Close the refrigerated
icon to flicker Close the refrigerated
icon and extinguish

Instruction and attentions for usage
of refrigerator compartment
The average temperature in refrigerator compartment is 0~10℃, so it can only be used
for short-term storage of food.
Suggested storage area for various food
The temperature in different areas of refrigerator is different, so the food should be
stored in recommended area shown as below figure:
Usage of crisper box
The food and vegetable stored in
refrigerator compartment lose moisture
soon. Maintain the humidity in the
crisper to keep more moisture of food
and vegetable, fresh food and vegetable
is good for health.
Usage of bottle rack
The position of bottle rack can be moved
according to storage requirement. The
bottle rack can be pulled out by lifting up.
When assemble the bottle rack, first place
the bottle rack in restraint of door liner,
then push it down to position.
Salted food
canned food, etc
Canned food
spices, etc
Pasta, canned and
milk, tofu, etc
Drinks and
bottled foods
Cooked meat
sausage, etc
Fruit, vegetables
salad, etc
Eggs, butter, etc

Attentions for food storage in refrigerator compartment
Do not place hot food in refrigerator The food need to be cleaned before
putting into refrigerator
Cool the hot food to room temperaturebefore
putting into the refrigerator. Directly putting
hot food will not only result in the
temperature rise insiderefrigerator but also
reduce the freshnessof other food.
Cool the hot food to room temperaturebefore
putting into the refrigerator. Directly putting
hot food will not only result in the
temperature rise insiderefrigerator but also
reduce the freshnessof other food.
The food need to be sealed and
classified stored
Seal the food before putting into refrigerator.
Classify the food and store separately, this
can not only help to keep freshness of food,
but also avoid the smell pollution.
Do not place too much food in
refrigerator
The food should be stored separately to
leave enough room for air circulation, thus
better refrigeration effect can be guaranteed.
Prevent oil food contacting the liner
Contact of food especially oil food with liner
will result in corrosion of liner. The liner
being polluted with oil should be cleaned
immediately.
Do not place food too close to liner
Please keep the food a little distance from
liner to avoid being frozen.

Attentions for food storage in freezer compartment
The low temperature of freezer compartment is helpful to keep freshness of food, so the
food need to be stored for a long time is recommended to be stored inside freezer
compartment, but please pay attention to the suggested storage period on food package.
Recommended preservation period and quality
guarantee period for various food
Food preservation
period(month) quality guarantee
period(month)
chicken,beef,mutton,shrimp
dumpling,frozen bun,spareribs,popsicle
cake,bread,sliced meet,cheese
crab,sea food,sausage,ice cream
Please refer to the instructions on the package of the food manufacturer or the
professional refrigeration manual for detailed instructions.
The specific storage time depends on the quality of the food, the pretreatment before
freezing and the different requirements of each family for the food quality
