Manta 5 Hydrofoiler SL3 User manual

Europe/United Kingdom: [phone]
United States: [phone]
New Zealand: 0800 114 235
Email: [email protected]
SL3 MAIN PARTS
BLUETOOTH RIDE CONTROLLER
TOOL REQUIRED
6 mm hex key
B
D
H
E
C
A
F
G
I J K
HYDROFOILER™SL3
QUICK START GUIDE
A. Power Button
B. Rocker Buttons (+/-)
C. Throttle lever
D. Activate motor Button
E. Battery State of charge
F. Throttle power gauge
G. Assistance Level (0-10)
H. Motor Activate symbol
I. Bluetooth Connection
J. Temperature Warning
K. Error/ Fault Warning
A. Hydropack Battery
B. Chassis
C. Cowling
D. Foil Shoe
E. Front Foil
F. Tiller
G. Propeller and Shroud
H. Rear Foil
I. Steering Tube
J. Mini Tilller
B
A
I
C
F
J
E
D
G
H
CYCLING’S NEW FRONTIER.

Lithium-ion battery packs can be dangerous if charged incorrectly. Only use the battery
charger supplied by Manta5 for charging the Hydrofoiler SL-3 lithium-ion battery.
Do not use the battery charger with any other batteries. Never connect the charger to an
unregulated generator.
Never let a battery be charged unattended. The battery and charger can get hot while
charging. Do not charge near any sources of heat, humidity or flammable materials and
never cover the charger or battery with clothes or other objects.
The battery will not charge if it is 0°C (32°F) or less and greater than 45°C (113°F).
WARNING! - RISK OF FIRE:
Do not allow children to handle the battery or charger.
CAUTION - RISK OF INJURY:
Connect your battery to the charger and then to the power outlet. A red light should turn on, which
means your battery is charging. The light will turn green when it’s completely charged.
If the battery is malfunctioning or housing is damaged immediately discontinue use. Move the battery
to an open area away from people and property if safe to do so. In all cases contact Manta5
immediately.
When storing batteries in confined quarters e.g. A boat, we recommend use of a Zarges (or equivalent)
case.
Charge your battery.1. PLEASE REVIEW WARNINGS ON BACK PAGE.
HYDROFOILER™SL3 QUICK START GUIDE
IMPORTANT:

2. Attach Drivetrain onto Rear Foil
1.2 SL3 Warnings
The battery will communicate safety information through clear warnings displayed on the ride
controller.
Plug the battery into the charging cable - Ensure the battery is safely connected to the charger by
checking that the red dot on the connector is not visible.
Once confirmed it is connected correctly, plug the charger into the wall.
Whilst charging the LED will illuminate red, once charging is complete the LED will be illuminated
green.
1.1 Battery state of charge indications
HYDROFOILER™SL3
If an error (‘Err’) is displayed
return to shore immediately and
refer to SL3 Owners Manual.
Using the 6mm hex key
* Tip – Ensure to assemble this on a flat surface. If assembling on a rocky or uneven surface the drivetrain may tip
over causing damage to the strut cowling (black protective surface)

HYDROFOILER™SL3
A
3. Attach chassis to drivetrain
4. Attach the front tiller to the chassis
3.1 Align the hole to the square gearbox ensuring it’s
connected correctly. The chassis will rest in place on the
drivetrain.
3.2 Tighten the chassis lock located in the rear of the battery
tub.
3.3 Check that there is no movement and the chassis is
correctly connected to the drivetrain by gently lifting it.
4.1 Align the front tiller’s Quick Connect connection with the
bottom of the steering post and slide the connection into the
slot until the red latch clicks up into place.
4.2 There will be an audible click when Front Tiller is connected
correctly.
3.4 Connect the remote cable to the control box input and
rotate the twist lock (A) to tighten the connection.

5. Connect battery to chassis
6. Once at the water, power the bike on
5.1 Connect the battery cable to the control box by pushing the
plug into the socket.
5.4 Next, push the handle down locking the battery into place.
An audible click can be heard once connected correctly. Your
bike is now ready to be carried to the water.
6.2 Once ready to ride, hold the ACTIVATE MOTOR button
down for 3 seconds to activate the motor. You will see a 10
second timer which means you are ready to go. If you don’t use
the motor within the counter the motor will deactivate and you
will need to repeat this step.
5.2 Once connected the screen pops up displaying the battery
level of charge.
5.3 Insert the battery into the tub with the handle arrows
pointing towards the front of the bike.
6.1 Power the SL3 on by pressing the POWER button for 3
seconds. The screen will show “ON”.
The propeller still won’t turn until you have activated the motor.
QUICK START GUIDE
HYDROFOILER™SL3

7 . Launching
7.1 At a minimum depth of 2 meters, place your hands on the
chassis and push the bike down under the water keeping it
upright. Push the handlebars and seat down to sink it further
while you climb on top of the bike.
The SL3 floats vertically allowing it to be easily mounted.
Make sure you are using the FC2 rear foil to optimize your
learning experience.
7.3 First time riders are encouraged to get comfortable riding
on the bike completely submerged. Do not attempt to launch
right away. Do this for a minute until you can feel the pitch of
the bike increase as you throttle faster and faster until you are
at maximum throttle. Practise leaning your chest over the
handlebars to control the launch angle.
7.2 Stand on the pedals whilst staying in an upright position
and rotate the pedals one full rotation to activate the motor,
allowing the throttle to become active.
7.4 Once you are comfortable riding underwater at maximum
throttle you can begin to slowly lean back. As you lean back
you will feel the take-off. Think aircraft taking off on a runway.
The heavier you are the longer your runway needs to be.
QUICK START GUIDE
HYDROFOILER™SL3

WARNINGS
USE OF THIS PRODUCT AND PARTICIPATION IN THE SPORT INVOLVES INHERENT RISKS OF INJURY
OR DEATH. TO REDUCE RISKS:
• Ride in water conditions that do not exceed the skills of the rider.
• Riders should remain within reasonable swimming distance to shore at all times.
• Attempting to ride in rough water, or in waves can increase the risk of injury or death.
• Do not use in shallow water or near swimmers or other watercraft.
• Always wear a suitable personal floatation device that is approved by your relevant local
regulating body .
• Riders are highly recommended to wear suitable aquatic footwear and swimwear to protect from
potential injury.
• Understand and abide by your local maritime regulations.
• When losing control of the bike, push off pedals to fall away from the bike.
• Children shall be a minimum of 16 years of age to operate the bike.
• Never ride after consuming drugs or alcohol.
• Never ride without a suitable communication device or supervision from the land.
• Read the User Manual before use.

WWW.MANTA5.COM
SL3 QUICK START GUIDE
