Maquet Compressor mini User manual

User´s Manual

VENTILATION/ANESTHESIA

COMPRESSOR MINI

1 Before use............................................................................... 3

2 Device description................................................................. 7

3 Preparation/Connection...................................................... 11

4 Function check..................................................................... 13

5 Preventive maintenance / Storage..................................... 15

6 Cleaning................................................................................ 17

7 Alarms................................................................................... 19

8 Troubleshooting................................................................... 21

9 Technical data...................................................................... 23

COMPRESSOR MINI, User´s Manual

English version

28.0

1

Table of contents

General information

This symbol on the unit means:

Attention, consult accompanying

documents.

The device complies with the

requirements of the Medical

Device Directive 93/42/EEC.

• The Compressor Mini may only be used by

authorized personnel. Users must have a

thorough knowledge of the unit and follow

the instructions in this Operating Manual.

• The owner or user is solely responsible for

safety if the equipment is not used as

intended, or has been serviced or repaired

by personnel not authorized by MAQUET.

• Documentation for the Compressor Mini

consists of:

Operating Manual-

- Service manual

- Spare parts list

- Installation instructions

KMP-034X

0

OUT

IN

• Remove the transport safety lock before

the compressor is used. Place it in the

transport safety lock holder.

• After unpacking the compressor, carry out

a function check.

• Pressure data for the Compressor Mini is

given in psi or kPa.

1 psi = 6,895 kPa

1 kPa = approx. 10 cm H2O

100 kPa = 1 bar ~ 1 atm ~ 1 kgf/cm2

(kp/cm2)

• In addition to the Important information

here, always follow local and national

regulations.

• The central compressed air supply, when

connected to Compressor Mini, must not

exceed a pressure of 94 psi (650 kPa/6.5

bar).

COMPRESSOR MINI, User´s Manual

English version

28.0

3

1. Before use

Connection

• The function check must always be carried

out before the unit is put into use, or once

a week when the unit is in continuous use.

• Make sure the mains power and gas fulfill

requirements for medical equipment.

• The Compressor Mini must only be

connected to a grounded outlet.

Operation

• When in use, the compressor must be

placed so that the air vents at the back and

on the underside are not covered.

• When in use, the drainage bottle must be

checked regularly.

• If the temperature alarm or the pressure

alarm is activated during operation, make

sure that a fully operational compressor is

connected as soon as possible.

Cleaning

The unit should be cleaned at least every 200

hours of operation or once a week when in

continuous use. If the compressor is used in

a dusty environment the dust filters must be

cleaned daily.

Service

• Service and repair must be carried out at

regular intervals by MAQUET-authorized

service personnel as follows:

5 000 hour preventive maintenance-

- 10 000 hour preventive maintenance

• Only original parts from MAQUET must be

used in the compressor.

Intended use

The intended use of the Compressor Mini is

to supply dry, filtered, compressed air for a

medical respiratory ventilator or anesthesia

machine that is compatible with the

specifications of the Compressor Mini. Its

capacity is approx. 30 l/min at 50 – 64 psi (350

– 450 kPa/3.5 – 4.5 bar).

Intended user

The Compressor Mini may be used only by

health care providers who have sufficient

training and experience.

4COMPRESSOR MINI, User´s Manual

English version

28.0

1. Before use

Caution

• The Compressor Mini has been designed

and tested to comply with requirements

specified in electromagnetic compatibility

standard EN 60601-1-2. It is the

responsibility of the user to take necessary

measures to ensure that the EMC

environment in which the system will be

used is compatible with the requirements

of EN 60601-1-2. If limits are exceeded,

this may impair the safety of the system.

Such measures should include, but are not

limited to:

normal precautions with regard to

relative humidity and conductive

characteristics of clothing in order to

minimize the build-up of electrostatic

charges

-

- restricted use of cellular phones.

• This compressor can provide only limited

flow of compressed air (30 l/min), and the

compressed air will not be dried to the

same standard as compressed medical air.

The water content and the limited air flow

may adversely affect the operation of, or

may damage, certain ventilators or other

equipment. Verify that the equipment to be

supplied by this compressor is compatible.

• Do not direct the flow of compressed air

towards the eyes or other unprotected parts

of the body.

• Federal law restricts this device to sale by

or on the order of a physician.

COMPRESSOR MINI, User´s Manual

English version

28.0

5

1. Before use

........................................................ ........................................................

6COMPRESSOR MINI, User´s Manual

English version

28.0

1. Before use

0

KMP-001X

Description

The Compressor Mini can be placed on a

ventilator cart to form a compact unit that is

easy to move. Since the compressor runs very

quietly, it can be used at bedside with a

minimum of disturbance.

The Compressor Mini is fitted with three

alarms:

- a temperature alarm that is activated if the

compressor overheats,

- a pressure alarm that is activated if the air

pressure drops or increases, outside the

specified ranges,

- a power failure alarm.

A high pitched audible alarm is heard, together

with an LED indication and a text displayed.

The Compressor Mini is equipped with a

Standby function. In Standby mode, the

compressor will start to deliver compressed

air to the ventilator if the central compressed

air supply fails. The compressor stops

automatically when the central air supply

returns.

The system

1. Display

2. Fuse holder

3. Mains inlet

4. Mains switch

Turns the Compressor Mini on (I) and

off (O).

-

COMPRESSOR MINI, User´s Manual

English version

28.0

7

2. Device description

Display messages

KMP-042US

61 psi

12345 hours

On Standby Alarm

The display shows status of the compressor,

current outlet air pressure, different alarm

messages and elapsed operating hours.

1. Outlet air pressure

The air pressure delivered by the

compressor is normally between 50 –

64 psi (350 – 450 kPa/3.5 – 4.5 bar).

-

2. Operating time

Elapsed operating hours.-

8COMPRESSOR MINI, User´s Manual

English version

28.0

2. Device description

Display LED's

There are three lamps (LEDs), green, yellow

and red, indicating the status shown on the

display above the lamps.

KMP-045

61 psi

12345 hours

On Standby Alarm

1. Green LED - On

The green LED lights up when the

mains switch is on. Display message:

The pressure in the compressor and

elapsed operating hours (when green

LED only).

-

2. Yellow LED - Standby

The yellow Standby LED will be on

while the central compressed air supply

is sufficient from the central air supply

-

to the ventilator via the compressor.

Display message: The central

compressed air pressure and the word

STANDBY.

3. Red LED - Alarms

The red Alarm LED indicates different

alarm situations. Display message:

Shows if the alarm is related to gas

-

distribution, dryer condition or

overheating of the compressor. The

alarms are described in detail in the

Alarms section.

4. Audible alarm

A buzzer for audible alarm signals (3

beeps/second). The buzzer sounds

when an alarm is activated.

-

COMPRESSOR MINI, User´s Manual

English version

28.0

9

2. Device description

0

OUT

IN

OUT

IN

KMP-013aX

Connections

1. Inlet

2. Outlet

3. Drainage bottle

4. Condensation drain valve

Empty the air reservoir by pressing the

pin on the drain valve while the

compressor is running.

-

Compressed air

When the Standby function is required, air

from the central compressed air supply is

connected to the inlet.

The compressed air hose to the ventilator is

connected to the compressed air outlet

Drainage bottle

There is a water separator in the compressor.

It is automatically emptied twice a minute by

a solenoid valve. The water collected in the

water separator drains into the drainage

bottle. A brief ”pssh” sound is heard each time

the solenoid valve opens. The bottle must be

checked regularly and emptied when

necessary. The higher the degree of humidity

in the ambient air, the quicker the bottle fills

Condensation drain valve

The drain valve is used to ensure that there is

no water build-up in the air reservoir by

releasing any collected condensed moisture.

If the compressor is running continuously, a

small amount of water may collect in the air

reservoir.

10 COMPRESSOR MINI, User´s Manual

English version

28.0

2. Device description

Preparation

KMP-032X

4 inch (10 cm)

• Place the compressor in a suitable location.

The air vent at the back of the compressor

must not be covered or blocked

Do not place the compressor near a

radiator or heating unit, since the

operating temperature might increase

and activate the temperature alarm.

-

- When the compressor is used as a

standby unit, connect the central

compressed air supply to the air inlet on

the compressor.

- Check that an empty drainage bottle is

fitted.

- MAQUET Compressor Mini mounting

kits are mandatory for both stand-alone

arrangements and for mounting on carts.

The mounting kits ensure that there is

sufficient air circulation around the

compressor.

Connection

KMP-052X

0

OUT

IN

OUT

IN

• Connect the compressed air hose from the

compressor air outlet to the ventilator.

Plug in the compressor mains cable to

a grounded outlet.

-

Start-up

A function check should be done before the

unit is put into use, and once a week when in

continuous use.

Caution: If a fault is discovered during the

function check, the compressor must not be

used until it has been repaired by authorized

service personnel.

COMPRESSOR MINI, User´s Manual

English version

28.0

11

3. Preparation/Connection

........................................................ ........................................................

12 COMPRESSOR MINI, User´s Manual

English version

28.0

3. Preparation/Connection

Function check

KMP-035X

1. To check the internal air reservoir for

water, press the pin on the drain valve.

• Disconnect the inlet (if connected) and

outlet air connection to the compressor.

• Start the compressor with the Mains switch.

KMP-029X

On Standb Alarm

• Make sure that the startup sequence runs:

- The display and LEDs light up and the

alarm buzzer sounds

- The display shows Comp Mini, the

software version, the air pressure and

the elapsed operating hours.

• Check that the air pressure is between

approximately 50 – 64 psi (350 – 450

kPa/3.5 – 4.5 bar).

Cooling fans

KMP-007X

• Make sure that air circulates through the

ventilating holes.

COMPRESSOR MINI, User´s Manual

English version

28.0

13

4. Function check

Standby mode (when

applicable)

KMP-017X

IN

=

On Standby Alarm

63 psi

STANDBY

• Connect the central air supply.

The compressor is automatically

switched off when the air pressure

exceeds 44 psi (300 kPa/3.0 bar) for

more than 30 seconds.

-

KMP-046X

IN

• Disconnect the central air supply

KMP-030X

=

On Standby Alarm

61 psi

12345 hours

• Decrease the internal pressure with the

manual drain valve. When the air pressure

drops below approximately 36 psi (250

kPa/2.5 bar) for more than 2 seconds the

compressor starts.

Checks during operation

KMP-018X

1. Check the water level in the drainage

bottle regularly.

2. Empty the bottle if necessary; the

compressor does not need to be turned

off.

KMP-019X

• To check the internal air reservoir for water,

press the pin on the drain valve. Check that

no water, or only a very small amount of

water flushes out through the drain valve.

14 COMPRESSOR MINI, User´s Manual

English version

28.0

4. Function check

Preventive maintenance

10 000 hour maintenance5 000 hour maintenance

Authorized service personnel carry out the maintenance

after 10 000 hours of operation.

The filters must be replaced after every 5000 hours of

operation by authorized service personnel.

Shut-off for storage

KMP-020X

0

1. Switch off the compressor.

2. If the compressor is not to be used for a

long period, empty, wash and drain the

drainage bottle

KMP-051X

• Drain the air reservoir by pressing the

manual drain valve.

COMPRESSOR MINI, User´s Manual

English version

28.0

15

5. Preventive maintenance / Storage

........................................................ ........................................................

16 COMPRESSOR MINI, User´s Manual

English version

28.0

5. Preventive maintenance / Storage

Daily cleaning

If the compressor is used in a dusty

environment, the dust filters must be cleaned

daily.

200 hour cleaning

The compressor should be cleaned after every

200 hours of operation or once a week when

in continuous use.

KMP-047X

• Wash the drainage bottle

KMP-048X

• Wipe all parts with a soft lint-free cloth

moistened in soap and water or

detergent-based disinfectant.

Note: In case of more contaminated surfaces

use ethylene alcohol or isopropyl alcohol.

KMP-049X

OUT

IN

a

b

• Clean the dust filters (a+b) on the back and

the underside of the compressor if

necessary

KMP-050X

• The dust filters may be rinsed in water.

Ensure the filters are free of excess water

before returning them to the compressor.

COMPRESSOR MINI, User´s Manual

English version

28.0

17

6. Cleaning

........................................................ ........................................................

18 COMPRESSOR MINI, User´s Manual

English version

28.0

6. Cleaning

Maquet COMPRESSOR MINI User manual

Popular Air Compressor manuals by other brands
