Marabut RED Series User manual

WYMIARY NAMIOTU:
COLOUR:
USER MANUAL
MAYO
216
210
55 104
110
103
165
55 72
1 persons
GUARANTEE
3 YEAR
ALU PINS
UV
RESISTANT
2,0 kg
w/ wo apron
1,65 kg
w/ wo apron
poliester
RIP - STOP
3000 mm H
2
O
ALU FRAME
min. max.
TECHNICAL SPECIFICATIONS:
Flysheet: Rip-Stop polyamide 40D 240T (3000 mm H20) silicone finish)
Sleeping area: polyamide
Floor: Rip-Stop polyamide 50D 240T, silicone finish
Frame: aluminium 7001 T6 ø9,5 mm
Pins: aluminium 7001 T6
Seams: all taped
Tent capacity: 1- 2
Weight: min. weight 1.65 kg;
max. weight 2.0 kg
Min. weight = the tent with frame poles
Max. weight the tent with accessories, e.g. pins,
repair kit, guy lines, bag, manual, guarantee.
Dimensions: 216 x 165 x 110 cm (external)
55 -104 x 210 cm (sleeping area)

SETTING UP THE TENT
 Spread out the tent on the ground, not necessarily in the place where you want to set it. Do not fix it with
pins to the ground! Fasten the zippers.
 Insert assembled frame pole into the sleeves of the flysheet (Fig. 1).
 Bend the upper pole to mount its other end in openings of the tape in the corners of the floor and flys-
heet (Fig. 2.). Similarly fix the other end of the frame pole.
Note: 3 openings in tapes are provided for adjusting the tension of the tent.
 Tent prepared as described above should be set at the desired location. Stretch the floor and attach it
with the pins in the corners, then stabilize the tent using guy lines.
1.
2.
facebook.com/namioty.marabut
youtube.com/MarabutArco
Marabut Sp z o.o.
ul. Przemysłowa 10, 32-070 Czernichów, Poland
telefon: [phone], [e-mail]
www.namioty.marabut.com
MAYO
USER MANUAL
ACCESSORIES
repair kit: a rope with tensioner, frame repair elements.
AFTER-SALES SERVICES FOR MARABUT TENTS
All our tents are covered by a 3-year guarantee. When buying
a MARABUT tent, you can be sure that even after the guarantee
period we will quickly and professionally repair any damage.
Our after-sales services include attaching snow aprons, repla-
cing worn-out floors and providing spare frame poles.
COMPONENTS:
 flysheet and sleeping area (integrated) frame (1 frame
poles) aluminium pins (12) guy lines (4) bag manual
guarantee
