User Manual
DPA480P

Described below are the functions of the front panel control buttons and encoders for the
DPA480P.
•Getting Started
As soon as the DPA480P is turned ON the device model name will appear in the LCD screen:
and a status bar will show the progress of the DPA480P initialization process:
After the first time activation, the DPA480P will show on the LCD :
DPA480P
Speaker Management
DPA480P
DPA480P
P01: Factory Default

•Encoders and ENTER, ESC buttons
The DPA480P is equipped with 3 Relative Encoders, “PM1”, “PM2” and “PM3”, These encoders
allow you to navigate the user interface and edit sections of the processor. They allow the user
to navigate within the screen for the selection of sub-menus, pages and parameters and to select
the values to be assigned during the editing operations.
The “ENTER” and “ESC” buttons allow the user to confirm or NOT confirm the operations
performed by the encoders.
• UTILITY, A/B/C/D and 1/2/3/4/5/6/7/8 buttons
The UTILITY button allows the User to enter the Sub-menus and set the general characteristics of
the Processor. The A , B , C and D buttons allow the User to enter the Editing Menus of the
Processor's Input Channels and buttons 1, 2, 3 , 4, 5, 6, 7 and 8 allow the User to enter the
Editing Menus of the Processor's Output Channels.
The A , B , C and D buttons as well as the 1, 2, 3 , 4, 5, 6, 7 and 8 buttons have double functions
dependent on the push and hold time.
When the A , B , C and D buttons are pushed and held for more than one second Input Channels
A or B or C or D are either muted or unmuted. The red LED will illuminate when the Channel is
muted. When the “MUTE” LED is OFF, then the related Input Channel is UN-MUTED.
A momentary push of the A , B , C and D buttons enters the Editing Mode for the Input Channels
(see later for the Input Channel Editing details).
The blue “EDIT” LED will now be ON.
When the 1, 2, 3 , 4, 5, 6, 7 and 8 buttons are pushed and held for more than one second the
Output Channels 1, 2, 3 , 4, 5, 6, 7 and 8 are either muted or unmuted. The red LED will
illuminate when the Channel is muted. When the “MUTE” LED is OFF, then the related Output
Channel is UN-MUTED.
A momentary push of the 1, 2, 3 , 4, 5, 6, 7 and 8 buttons enters the Editing Menu for the Output
Channels (see later for the Output Channel Editing details). The blue “EDIT” LED will now be ON.
•DPA480P Menu and Sub-Menu Structures
As stated above, the start-up default screen is the following factory preset:
From this point, sub-menus are accessed and exited using the UTILITY”, “A/B/C/D”,
“1/2/3/4/5/6/7/8”, buttons and all parameters and values are navigated by the “PM1”, “PM2” and
“PM3” encoders. Please refer to the following menu structures:
DPA480P
P01: Factory Default

MENU “UTILITY MENU” [Access by pushing the “UTILITY” button]
PM1 Encoder PM2orPM3Encoder
[to navigate between menus] [to chose option, then ENTER to load it;
(*) indicates the selected option]
1 UTILITY MENU:......
<< System Utilities >>
1.1 SYSTEM UTILITY: Delay Units
<<DelayUnits >> Unit= Time(ms)
Unit=Distance(m)
1.2 SYSTEMUTILITY: SetDefaultValue
<<Set DefaultValue >> [Enter]toconfirm
1.3 SYSTEMUTILITY: Firmware Version
<< Firmware Version >> Version= 2.0.6
2 UTILITY MENU:......
<< Program Utilities >>
2.1 PROGRAM UTILITY: Recalla Program
<< Recalla Program >> 01:Factory Default
: :
24: Factory Default
2.2 PROGRAM UTILITY: Savea Program
<< Save aProgram >> 01: Factory Default
: :
24:Factory Default
2.3 PROGRAM UTILITY: Deletea Program
<< Deletea Program >> 01:Factory Default
: :
24:Factory Default
3 UTILITY MENU:......
<< Interface Utilities >>
3.1 Interface setup Interface Setup
configure RS485 ID=1,…,32
4 UTILITY MENU:......
<< Security Utilities >>
4.1 SECURITY UTILITY: Parameter will
ShowParameter beshown
not be shown
4.2 SECURITY UTILITY: Lock Unit
LockUnit Lock:Off
Lock: On
4.3 SECURITY UTILITY: ChangePassword
ChangePassword [ ]
4.4 SECURITY UTILITY: Enter Password
LockWithPassword [ ]
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER
ESC
ENTER
ESC
ENTER
ESC
ENTER
ES
C
ENTER
ESC
ENTER
ES
C
ENTER
ES
C
ENTER
ESC
ENTER
ESC
ENTER
ESC
ENTER
ESC

MENU “Input A/B/C/D” Input Channels Editing [Access by pushing the “A/B/C/D” button]
PM1 Encoder PM1Enc. PM2 Enc. PM3Enc.
[to navigate between menus] [to chose values for the parameters, no need to confirm the chosen values,
which are automatically loaded during the encoders use]
1. In-A/B/C/D [Name] Name
Name= [Name]
->Name = _ (For Editing the Device's Name, refer to the Details on the“Utility Menus Use” Section)
2. In-A/B/C/D [Name] N.Gate
Bypass=On
-> Bypass=On PM1 N/A. Byp=On/Off Thr=-80.0dBu …-50 dBu
Rel=10ms …1000ms Atk=1ms …1000ms
3. In- A/B/C/D Gain
Gain= +0.0 dB
->Gain = + 0.0 dB PM1 N/A. -18dB 0.1dB
: :
+12dB 0.9dB
Step1dB Step0.1dB
4. In-A/B/C/D Delay
Delay = 0.000 ms
-> Delay = 0.000 ms PM1 N/A. 000.0000mS 000.0000mS
[1ms steps] [10.4ussteps]
420.0000mS 000.9984mS
5 In- A/B/C/D [Name] Polarity
Polarity=Normal
-> Polarity=Normal PM1 N/A. Polarity= Normal/Invert
6. In- A/B/C/D [Name] RMS Cmp
Bypass=On
-> Bypass=On PM1 N/A. Byp=On/Off
PM1 N/A. Threshold=+16dBu …-14dBu
PM1 N/A. Ratio =2:1 …32:1 Knee=0% … 100%
PM1N/A. Rel=0.1sec …3.0sec Atk=5ms … 200ms
PM1N/A. Make-up=-12dB …+12dB
7. In- A/B/C/D [Name] EQ Byp
Bypass=On
-> Bypass=On PM1 N/A. Byp=On/Off
8. In- A/B/C/D [Name] PEQ-XX(00 to 30)
Byp=on Type=Peaking_Eq
-> Byp=on Type=Peaking_Eq PM1 N/A. Byp=On/Off Type=Peaking_Eq/ Hi Shelv
1/ Hi Shelv 2/ Hi Shelv Q/ Lo Shelv 1/ Lo Shelv 2/Lo Shelv Q/ Lo Pass 1/ Low-Pass 2/Low Pass Q/HighPass1/ HighPass2/HighPass Q/Band-Pass/ Notch Filt/All Pass
1/All Pass 2
Type=Peaking_Eq PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=0.4 …128
Type= Hi-Shelv1/Hi-Shelv 2 PM1 N/A. Frequency=20Hz …20000Hz
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC

PM1 N/A. Gain=-15dB …+15dB Q=Fixed
Type= Hi-ShelvQ PM1N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=0.1 …5.1
Type= Lo-Shelv 1/ Lo-Shelv2 PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=Fixed
Type= Lo-Shelv Q PM1 N/A. Frequency=20Hz …20000Hz
PMN/A. Gain=-15dB …+15dB Q=0.1 …5.1
Type= Low Pass 1/ Low Pass2 PM1N/A. Frequency=20Hz …20000Hz
Type= Low Pass Q PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-Fixed Q=0.1 …5.1
Type= HighPass1/ Hi ghPass2 PM1 N/A. Frequency=20Hz …20000Hz
Type= HighPassQ PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-Fixed Q=0.1 …5.1
Type= Band-Pass PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=4 …104
Type= NotchFilt PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=Fixed Q=4 …104
Type= AllPass 1 PM1N/A. Frequency=20Hz …20000Hz
Type= AllPass 2 PM1N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=Fixed Q=4 …104

MENU “Output 1/2/3/4/5/6/7/8” Output Channels Editing [Access by pushing the “1/2/3/4/5/6/7/8”
button]
PM1 Encoder PM1Enc. PM2 Enc. PM3Enc.
[to navigate between menus] [to chose values for the parameters, no need to confirm the chosen values,
which are automatically loaded during the encoders use]
1. Output[x] [Name] Name
Name= [Name]
->Name = _ (For Editing the Device's Name, refer to the Details on the“Utility Menus Use” Section)
2. Output[x] [Name] Routing
A=On B=Off C=Off D=Off
->InA: Level=0dB On PM1 N/A 0dB On/Off
:
-30dB
->InB: Level=0dB Off PM1 N/A 0dB On/Off
:
-30dB
->InC: Level=0dB Off PM1 N/A 0dB On/Off
:
-30Db
->InD: Level=0dB Off PM1 N/A 0dB On/Off
:
-30Db
3. Output[x] [Name] Gain
Gain= +0.0 dB
-> Gain = + 0.0 dB PM1 N/A -18dB 0.1dB
: :
+12dB 0.9dB
Step1dB Step0.1dB
4. Output[x] [Name] Delay
Delay = 0.000 ms
-> Delay = 0.000 ms PM1 N/A 000.0000mS 000.0000mS
[1ms steps] [10.4 us steps]
128.0000mS 000.9984Ms
5. Output[x] [Name] Polarity
Polarity=Normal
-> Polarity=Normal PM1 N/A. Polarity= Normal/Invert
6. Output[x] [Name] Limiter
Bypass=On
-> Bypass=On PM1 N/A. Bypass= On/Off
PM1 N/A. Threshold=-10dBu …20 dBu
PM1 N/A. Rel=0.1sec …5sec Atk=1ms …900ms
7. Output[x] [Name] HPF
20.0Hz Bypass
-> 20.0Hz Bypass PM1 N/A [Freq.] 20Hz [Type/Slope] Bypass
: :
20kHz LR -48 dB /Oct
Slope=Bypass/ BW -6 dB/Oct / BW -12 dB/Oct / LR -12 dB/Oct / BS -12 dB/Oct / BW -18 dB/Oct / BW -24 dB/Oct / LR -24 dB/Oct / BS -24
dB/Oct / BW -36 dB/Oct / LR-36 dB/Oct / BW -48 dB/Oct / LR-48 dB/Oct /
8. Output[x] [Name] LPF
20.0Hz Bypass
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC
ENTER ESC

-> 20.0Hz Bypass PM1 N/A [Freq.] 20Hz [Type/Slope] Bypass
: :
20kHz LR -48dB/Oct
Slope=Bypass/ BW -6 dB/Oct / BW -12 dB/Oct / LR -12 dB/Oct / BS -12 dB/Oct / BW -18 dB/Oct / BW -24 dB/Oct / LR -24 dB/Oct / BS -24
dB/Oct / BW -36 dB/Oct / LR-36 dB/Oct / BW -48 dB/Oct / LR-48 dB/Oct /
9. Output[x] [Name] EQ Byp
Bypass=On
-> Bypass=On PM1 N/A. Byp=On/Off
10. Output[x] [Name] PEQ-XX(00 to 07)
Byp=on Type=Peaking_Eq
-> Byp=on Type=Peaking_Eq PAR1 N/A. Byp=On/Off Type=Peaking_Eq/ Hi -Shelv
1/ Hi -Shelv 2/ Hi -Shelv Q/ Lo-Shelv 1/ Lo-Shelv 2/Lo-Shelv Q/ Low-Pass 1/ Low-Pass 2/Low-Pass Q/High-Pass1/ High-Pass2/High-Pass Q/Band-Pass/ Notch
Filt/All Pass 1/All Pass 2
Type=Peaking_Eq PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=0.4 …128
Type= Hi-Shelv1/Hi-Shelv 2 PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=Fixed
Type= Hi-ShelvQ PM1N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=0.1 …5.1
Type= Lo-Shelv 1/ Lo-Shelv2 PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=Fixed
Type= Lo-Shelv Q PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=0.1 …5.1
Type= Low-Pass 1/ Low-Pass2 PM1N/A. Frequency=20Hz …20000Hz
Type= Low-Pass Q PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-Fixed Q=0.1 …5.1
Type= High-Pass1/ High-Pass2 PM1 N/A. Frequency=20Hz …20000Hz
Type= High-Pass Q PM1N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-Fixed Q=0.1 …5.1
Type= Band-Pass PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=-15dB …+15dB Q=4 …104
Type= NotchFilt PM1 N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=Fixed Q=4 …104
Type= AllPass 1 PM1N/A. Frequency=20Hz …20000Hz
Type= AllPass 2 PM1N/A. Frequency=20Hz …20000Hz
PM1 N/A. Gain=Fixed Q=4 …104
ENTER ESC
ENTER ESC
ENTER ESC

zMenu “UTILITY” [access by pushing the “UTILITY” button]
From the “Default Screen”, it is possible access the “UTILITY” menu pushing the “UTILITY” button
and the Sub-Menus pages can be selected just rotating clockwise and counter-clockwise the
“PM1” encoder.
Once selected the sub-menu page, using the “ENTER” button can be accessed the Sub-Menus
pages, again “scrollable” using the “PM1” encoder and accessible for the parameters' editing
pushing again the “ENTER' button.
Note: In each sub-menu choice, the current selected or running choice is what shown on the LCD
screen.
System Utilities Sub-menu – this sub-menu allows to access several operations related to the
DPA480P Start Up and General Configuration:
UTILITY MENU:
From the “System Utilities Sub-menu”, pushing “ENTER” will give access to the following pages:
-Delay Units: this page allows you to select the measurement unit to be used for the Delays:
Time (in milliseconds “ms”) or Distance (in meters “m”):
By pressing ENTER button and rotating the “PM2” or “PM3” encoder, it is possible to select the
measurement unit to be used for the delay, which will be confirmed by pushing the ENTER
button.
The following screen shows the selected delay measurement is Time (milliseconds)
-Set Default Value: All setting for DPA480P can be set to default value:
By pressing ENTER button, will show up the following screen of an interface to confirm to set
the default value:
SYSTEM UTILITY
-- DelayUnits --
Delay Units
Unit: Time(ms)
UTILITY MENU
-- System Utilities --
SYSTEM UTILITY
-- Set Default Value --
Set Default Value
[Enter] to confirm

By pressing ENTER button one more time, will show up the following screen:
Wait around 3 sec for the processor set to the default value.
−Firmware Version: this page allows you to confirm the Firmware Version running on the
DPA480P:
The correct Firmware Version is “V2.0.6”
Program Utilities Sub-menu – this sub-menu allows you to access several options related to
the DPA480P operating mode and to manage the presets stored and recallable within the Unit:
−Recall a Program: this page allows the Loading of a preset program by pressing the “ENTER”
button. You can store up to 24 presets in the DPA480P memory:
If presets have previously been stored by the user, anyone of them can be recalled:
By using the “PM1” encoder it is possible to scroll through the stored presets. Once the
desired preset appears on the screen, select it by pressing the “ENTER” button and this will
force the DPA480P to begin to load this selected preset and the following transitory screen will
appear:
[ENTER] to Recall.
01: PRESET 1
PROGRAM UTILITY
-- Recall a Program --
UTILITY MENU
-- Program Utilities --
Set Default Value
Wait : loading default….
SYSTEM UTILITY
-- Firmware Version --

Once loaded the DPA480P will exit to the “Recall a Program” screen automatically and the
above screen will disappear:
Note: at any time it is possible to quit the recalling action by pressing the “ESC” button.
Loading New Program ......
01: PRESET 1
PROGRAM UTILITY
- RecallaProgram -

−Save a Program: this page allows you to store a new preset in the DPA480P’s memory:
By pressing the ENTER button and rotating the “PM1” encoder, it is possible to scroll through
the previously saved presets or the available empty locations (identified by “Factory default”).
If no user presets are stored, the “Save a Program” screen will show empty memory locations
for all 1-24 presets as shown in the example below for location 10:
When storing an edited configuration for the DPA480P, select the location for a preset from the
24 available by using the “PM1” encoders.
Once the desired location appears on the screen, press “ENTER” button again to reach the
“Set Program Name” page.
In this page the User can set a Preset Name by using the “PM3” encoder to choose a character
and the “PM2” encoder to move between the available locations for the character’s positioning.
The following is an example of a screen while entering the preset name “Stage 1 2x2” in
location 10:
To store the Preset Name press the “ENTER” button again.
The above action will take you to the “Enter to Save” page showing the selected location for
the preset and the final edited name:
Pressing “ENTER” again, will store the preset in the selected location with the chosen name
and the following transitory screen will appear on the LCD:
Once the preset is stored, the above screen will disappear returning to the following screen:
Save a Program
10: Factory default
Edit Program Name.
10: Stage 1 2x2
PROGRAM UTILITY
-- SaveaProgram --
[Enter] to Save
10: Stage 1 2x2 ?
Saving to Memory.....
10: Stage 1 2x2

If during the Preset Storing process you want to overwrite an existing memory location select
this location in the “Save a Program” page, then press ENTER button and you will be asked if
you want to overwrite this preset with the following “[ENTER] to Overwrite” screen
displaying the currently stored preset and location:
If you wish to proceed press “ENTER” again and the DPA480P will go ahead with the “Set
Program Name” page and the subsequent overwrite on completion of the previously
described storing process..
Note: at any time it is possible to quit the storing action by pressing the “ESC” button.
−Delete a Program: this page allows you to delete a preset already stored in the DPA480P
memory:
By pressing the ENTER button and rotating the “PM1” encoder, it is possible to scroll through
the previously saved presets and the available empty locations (identified by “Factory default”).
If no user presets are stored, the “Delete a Program” screen will show empty memory
locations for all 1-24 presets as shown in the example below for location 10:
If Presets are available they will be shown in the “Delete a Program” page as follows:
By using the “PM1” encoder it is possible to select a preset to be deleted.
Pressing the “ENTER” button on a selected preset will bring up the “[Enter] to Delete.” page
showing the selected preset.
Delete a Program
10: Stage 1 2x2
PROGRAM UTILITY
-- Save a Program --
[Enter] to Overwrite
10: Stage 1 2x2
PROGRAM UTILITY
-- DeleteaProgram --
Delete a Program
10: Factory default

For example, if we want to delete the preset 10, “Stage 1 2x2”, the screen will be the
following:
Confirming the deletion by pressing “ENTER” again, will force the DPA480P to erase the
selected preset and the following transitory screen will appear:
Once the preset is deleted, the above screen will disappear returning to the following screen:
Note: At any time it is possible to quit the deleting action by pressing the “ESC” button.
Interface Utilities Sub-menu – this sub-menu allows you to define the remote control interface
[RS485] to be used for controlling the DPA480P:
If use would like to connect more than one unit under the RS485 mode. By using “PM2”/“PM3”
encoder, user can set the ID number from 1 to 32, to assign to the units connected, and
confirm by pressing “ENTER” button.
Security Sub-menu – this sub-menu allows the User to set the parameters shown, lock the
DPA480P and set a Password therefore limiting the unit's functions and controls to those who have
only access to the appropriate Password.
Press “ENTER” button and then use the “PM1” encoder to scroll between options.
−Show Parameter: Pressing “ENTER” button from the above menu will access the “Show
Parameter” Sub Menu
UTILITY MENU
-- Security Utilities --
SECURITY UTILITY
-- Show Parameter --
PROGRAM UTILITY
-- DeleteaProgram --
Erasing Xover Memory.....
10: Stage 1 2x2
[ENTER] to Delete.
10: Stage 1 2x2
Interface Setup
Configure RS485 ID= 1

Press ENTER button again and use the “PM2” or “PM3” encoders to select between “be shown”
or “not be shown” options.
Choosing the “be shown” option means that once the unit is locked, you cannot access
parameter editing features, but they will be displayed on the LCD screen.
Choosing the “not be shown” option means that once the unit is locked, the parameters will
not be shown at all. With this option, when trying to access a parameter, the following
screen message will appear:
−Lock Unit: this sub-menu allows the user to lock the device so no parameters can be edited
or modified.
When the Unit is in an unlocked condition, all parameters will be available for editing. When
you select On, all parameters will be locked and are not available for editing.
When you select lock from the menu, the unit will be locked and the lock menu automatically
exited. The screen will revert to the “Default” showing the current XOVER configuration and
the preset selected and beside the preset’s name a “keylock” icon indicating that the DPA480P
is locked.
−Change Password: from the “Change Password” sub-menu:
Press “ENTER” to access the “Change Password” page:
Use the PM2 encoder to move between available locations, and the PM3 encoder to choose a
character. The current position of the cursor for the characters to be entered is shown by a
“blinking underscore”.
Change Password
[_ ]
Parameter will
not be shown
SECURITY UTILITY
-- LockUnit --
Lock Unit
Lock=On
SECURITY UTILITY
-- Change Password --
Change Password
[ ]

Input the original password “000000” for the DPA480P, and press “ENTER” button, will access
to the “New Password” Page. Use the “PM2” encoder to move between available locations,
and rotate the PM3 encoder to edit a 6-position new password.
The following screen is the example with the new password after edition is “111111”
Press the ENTER button again, will access the “Confirm password” page, use the “PM2”
encoder to move between available locations and rotate “PM3” encoder to choose a character,
input the new password edited just now.
The following screen is the example with typing in new password “111111” edited just now.
Press the ENTER button one more time, the new password will be set successfully.
−Lock With Password: from the “Lock With Password” sub-menu:
There’s limitation to the editing function if the DPA480P is locked with password. All functions for
this unit are banned.
Press “ENTER” to gain access to the “Enter Password” screen:
Use the “PM2” encoder to move between available locations, and rotate “PM3” encoder to select
characters. If the password of this DPA480P never modified, input the default password “000000”,
the unit will be locked. In this case, default screen will show a “Key” icon, user cannot enter into
the sub-menu, unless he holds the password.
Confirm Password
[111111]
SECURITY UTILITY
-- Lock With Password --
Enter Password
[ ]
New Password
[111111]

zMenu “Input A/B/C/D” Input Channels Editing [access by pushing the “A/B/C/D”
buttons]
From the “Default Screen”, it is possible to access the “Input A/B/C/D” menu by pushing the “A”
or “B” or “C” or “D” button. Once the button is pressed, the related blue “EDIT” LED will turn ON.
The Sub-Menu pages can now be scrolled through by rotating clockwise and counter-clockwise the
“PM1” encoder.
For parameter editing it is necessary to press “ENTER” button and an arrow will appear on the left
of the screen “->”. Then use the “PM2” and “PM3” encoders for editing and setting the
parameter values. On some parameters that have three independent values, you will also need to
use the PM1 encoder, eg filter parameter settings.
Note: All options can be done using the “PM1”, “PM2”, and “PM3” encoders and the current shown
value of the selected option is AUTOMATICALLY loaded during the encoders' use and stored as the
current value once leaving the page.
Remark 1: Select parameters the user desire by using 3 encoders. Once the user leaves this
page, the above mentioned parameters would be saved to the DPA480P systems automatically.
Remark 2: Exit this page by pressing “ESC” button.
Audio Signal Input (A/B/C/D)
Name page – from this screen, it is possible to assign input channel a name with 6 characters
For example, name the Input A as “In L” in the Name Page:
By pressing ENTER in the Name page, user can edit the name, and there will be an arrow, as the
following screen shows:
The first character will flash.
Select character from these 6 positions by rotating “PM2” encoder and choose the desired
characters by rotating “PM3” encoder. Once the new name is defined, for example, “In A”, confirm
this new name by pressing ENTER… A new name will display on the screen, after replaced the old
one.
The following screen is shown with the new name “In A”, by replacing the previous one “In L”
N.Gate page– from this page, it is possible to set the Input Channels Noise Gate. Noise gate can
be set as “ON” or “OFF” status. The following screen is the selected “ON” status:
In-A: In L Name
Name = InL
In-A: In L Name
->Name = InL
In-A: In A Name
Name = InA

By pressing ENTER button in this page, an arrow “->” will show up on the left of the screen, and
enter into the setting interface 1 of the noise gate:
By using the “PM2” encoder, it is possible to set the noise gate as “ON” or “OFF”. By using the
“PM3” encoder, it is possible to select its attack threshold from -80dBu to -50dBu.
By rotating “PM1” encoder, user can enter into the setting interface 2 of the noise gate:
By using “PM2” encoder, user can set noise gate release time: from 10ms to 1000ms, and using
“PM3” encoder to set noise gate attack time: from 1ms to 1000ms.
Gain page – from this screen it is possible to set the Input Channels Level from -18dB to +12dB,
press “ENTER” button, an arrow will appear on the left of the screen “->” then use the “PM2” or
“PM3” to set parameters.
The value set on this screen will only affect the input level of the selected Channel A.
The following is an example screen for the “Gain” page that has set the Gain of Input Channel A to
+0.0dB:
Delay page – from this page it is possible to set the Input Channels Delay Time from
000.0000mS up to 420.9984mS, by steps of 1mS or 10.4uS.
To set the Delay time press ENTER, an arrow will appear on the left of the screen “->”. then use
the “PM2” encoder to set the Delay Time in steps of 1mS and the “PM3” for setting the “fine”
Delay Time in steps of 10.4 microseconds.
The following is an example screen for the “Delay” page where the Delay Time of Input Channel A
is set to 160.1872mS:
Polarity page– from this page, it is possible to set input channels phase as “Normal” or “Invert”.
The following is an example screen of “Normal” Polarity：
In-A In A N.Gate
->Byp=On Thr=-80.0dBu
In-A: Name N.Gate
Bypass = On
In-A In A N.Gate
->Rel=10ms Atk=3ms
In-A InA Polarity
Polarity = Normal
In-A InA Gain
-> Gain = + 0.0dB
In-A InA Delay
-> Delay = 160.1872mS

By pressing ENTER button in this page, an arrow will appear on the left of the screen “->”. then
use the “PM2” or “PM3” encoder for setting “Normal” or “Invert” Polarity.
RMS Cmp page– from this page, it is possible to set RMS Compressor for input channels. RMS
Compressor can be set as “ON” or “OFF” status. The following is an example screen of “ON” status:
By pressing ENTER in this page, an arrow will appear on the left of the screen “->”. Then enter
into the setting interface 1 of RMS Compressor.
RMS compressor status can be set as “ON” or “OFF” by using “PM2” or “PM3” encoder.
By rotating “PM1” encoder, user can enter into setting interface 2 of RMS Compressor:
RMS Compressor attack threshold can be set with “PM2” or “PM3” encoder, with its range from
-14dBu to +16dBu.
By rotating “PM1” encoder one more time, user can enter setting interface 3 of RMS Compressor:
RMS Compressor ratio can be set by “PM2” encoder, with its range rom 2:1 ~ 32:1. RMS
Compressor knee can be set by “PM3” encoder, with its range from 0% ~ 100%.
By rotating “PM1” encoder once again, user can enter setting interface 4 of RMS Compressor:
RMS Compressor release time can be set by “PM2” encoder, with its selectable range from 0.1s ~
3s, and its attack time can be set by “PM3” encoder from 5ms ~ 200ms.
By rotating “PM1” encoder, user can enter setting interface 5 of RMS Compressor:
By using “PM2” and “PM3” encoder, user can set RMS Compressor make up, from -12dBu to
In-A: In A RMS Cmp
Bypass = On
In-A InA RMSCmp
->Bypass = On
In-A InA RMSCmp
->Threshold = +16.0dBu
InputA: Name RMS Cmp
->Ratio =32:1 Knee =0%
In-A InA RMSCmp
->Rel =0.1sec Atk =5ms
In-A InA RMSCmp
->Make-up = 0.0dB

+12dBu.
EQ Byp page – in this page, it is possible to set EQ Bypass of input channels, with its selectable
status of “ON” and “OFF”. Following is the example screen as Bypass ON:
By pressing “ENTER” button in this page, an arrow will appear on the left of the screen “->”, then
enter setting interface of EQ Bypass:
By using “PM2” or “PM3” encoder, user can set the EQ Bypass as “ON” or “OFF”.
PEQ-[xx] (01to30) page – In this page, it is possible to set 30 available parametric equalization
filters for input channels, with each parametric equalization filters can be selected as BELL,
Shevling, High-Pass, Low-Pass, Band-Pass, Notch filter and Allpass.
When EQ Bypass is set as “OFF”, by pressing ENTER in any parametric equalization page, an
arrow will appear on the left of the screen “->”, then enter setting interface 1 of parametric
equalization filter:
By using “PM2” encoder, it is possible to set the flat on or off for the current parametric
equalization filter. By using “PM3” encoder, user can set the current parametric equalization
filter’s type, selectable as Peaking_Eq/ Hi -Shelv 1/ Hi -Shelv 2/ Hi -Shelv Q/ Lo-Shelv 1/
Lo-Shelv 2/Lo-Shelv Q/ Low-Pass 1/ Low-Pass 2/Low-Pass Q/High-Pass1/ High-
Pass2/High-Pass Q/Band-Pass/ Notch Filt/ All Pass 1/ All Pass 2
When the parametric equalization filter is selected as Peaking Eq, by rotaing “PM1” encoder
again, user can enter the setting interface 2 of current input parametric equalization filter:
By using “PM2” or “PM3” encoder, it is possible to set current input PEQ filter’s frequency from the
range of 20Hz to 20kHz.
By rotaing “PM1” encoder again, user can enter the setting interface 3 of current input parametric
equalization filter:
In-A InA EQByp
Bypass = On
In-A InA EQByp
->Bypass=On
In-A InA PEQ-01
Byp=Off Type=Peaking_Eq
In-A InA PEQ-01
->Byp=Off Type=Peaking_Eq
In-A InA PEQ-01
->Frequency = 20Hz
