Marshall Electronics V-R151P-4A User manual

Marshall Electronics
1910 East Maple Ave.
El Segundo, CA 90245
Tel.: [phone] • 310-333-0606
Fax: [phone]
www.LCDRacks.com
Email: [email protected]
Marshall Electronics warranties to the first consumer, that this V-R151P-4A 15 inch LCD rack mounted monitor will, under normal use, be free from defects in workmanship and materials, when
received in its original container, for a period of one year from the purchase date.
This warranty is extended to the purchasing end user only and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, Marshall
Electronics reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to you.
This warranty does not apply to product exterior and cosmetics. Misuse, abnormal service or handling, improper alterations or modifications in design or construction, voids this warranty. No
sales personnel of the seller, nor any other person is authorized to make any warranties other than those described above, or to extend the duration of any warranties on behalf of Marshall
Electronics, beyond the time period described above.
An extra note about LCD displays: It is considered normal for a minimal amount of pixels, not to exceed three, to fail on the periphery of the display active viewing area. Marshall Electronics
has the option to reserve service for display pixel failure if deemed unobtrusive to effective use of the monitor by our technicians.
Due to constant effort to improve products and product features, specifications may change without notice.
Product Overview
Features
Specifications
Setup
Connectors
Front Panel Indicators and Controls
Menu Functions
PC Formats Supported from VGA and DVI Connectors
Video Formats Supported By Component and DVI Inputs
Video Formats Supported By Composite and S-Video Inputs
Standard Accessories
Optional Accessories
Warranty
1
2
3
4
5
6
7
8
V-R151P-4A
V-R151P-4A
Users Guide
Users Guide
13 Warranty
9
10
11
12
13
12 Optional Accessories
11 Standard Accessories
Accessories Supplied with the V-R151P-4A
• Users manual
• “Brick” type 12vdc power supply with 4 Pin Female XLR connector
• “V” Mount battery adapter
• VESA 75 Mount
Desk Stand - VP-LCD171H-ST-01 - Use for Desk Top

• XGA Resolution 1280 × 1024 pixels, 3.93 million total RGB pixels produce 16.7 million colors
• 300 candela per meter2luminance
• Compact design fits in EIA standard rack 8U high
• VESA 75 mount for wall, ceiling or desk top
• Automatic Gamma Correction
• 16:9 or 4:3 aspects
• Self-powered tally system for 4 Video Inputs
• NTSC/PAL Factory Configuration
• 1500 CRT viewing angles
• 12 VDC 4-pin XLR power connector with external power supply
1Product Overview
The V-R151P-4Ais a rack-mounted monitor with a 15”, 4:3 aspect ratio active matrix LCD/TFT module. Mounting can also be achieved via
a VESA 75 reinforced mount point on the rear of the unit or with the included rack ears.The display will produce a high-resolution 1280W x
1024H SXGA image from a computer withAnalog RGBHV outputs plus DVI-Digital or display scaled video images. Component, Composite
Video or Y/C (S-video) images are displayed via a proprietary internal scaling LSI The unit is designed to fit into an EIAstandard 19” rack and
occupies 6RU of space. For ease of operation the V-R171P-4Aincludes front mounted selector buttons for menu operations with On Screen
Menu Display (OSD) and “ON AIR” tally.A U.L. Class 2 power supply is included and the unit is factory ready for rack mount installation.
2Features
25
V-R151P-4A Users Guide
V-R151P-4A Users Guide Marshall Electronics
3Specifications
Display (Viewing Area) 15” Diagonal
Resolution (Pixels) 1024H × 768V
Screen Format 4 x 3
Screen Treatment Anti-Glare and Anti-scratch Hard Coat
Dot Pitch 0.264 square pixel
Pixel Response 13ms Maximum - Black to White to Black (3.5ms rise, 9.5 ms decay)
Viewing Angle 80° (D) From Center
Brightness (in cd/m²) 300 cd/m²
Color Temp D-65
Color Gamut SMPTE/EBU
Backlight CCFL 50,000 hour
Contrast Ratio 500:1
Video Inputs System NTSC or PAL Factory Configured
TV Tuner System NTSC
Inputs YPrPb Component (3 BNC), Composite Video (4BNC)
S-Video (Y/C) (4 Pin Mini Din female), sXGA15Pin HD-15 Female
DVI 27 (Pin DVI-I Female), Tally (HD-15 Female)
Rack Mount Dimensions 19.12”W × 10.5”H × 2.5”D (48.5cm x 26.7cm x 6.35cm)
Desk Top Dimensions 17”W x 13”H x 2.5”D (40.6cm x 35cm x 6.35cm)
Approx. Weight 13 lbs (5.9kg)
Power Consumption 70Watt Max 12 VDC from included power supply (V-PS12-5V1(XLR))
Operating Temperature 0°C to 50° C (Storage -20°C to +60°C)
Compliance FCC-Class A, ANSI-63.4 (Certificates on file)
RoHS WEEE/Environmental Do not dispose. Return to Manufacturer or Authorized Recycle Facility
Resolution H Frequency ( kHz ) V Frequency ( Hz ) Pixel Frequency ( MHz )
640x480 31.469 59.94 25.175
640x480 35.000 66.667 30.24
640x480 34.940 69.884 28.513
640x480 37.861 72.809 29.765
640x480 37.500 75.0 31.5
720x400 31.469 70.087 28.322
800x600 35.156 56.25 36.0
800x600 37.879 60.317 40.0
800x600 43.764 70.02 45.513
800x600 48.077 72.188 50.0
800x600 46.875 75.0 49.5
1024x768 48.780 60.001 64.11
1024x768 48.363 60.004 65.0
1024x768 56.476 70.069 75.0
1024x768 57.703 72.039 78.476
1024x768 60.030 75.029 78.75
1280x720 47.760 60.0 74.481
1280x768 47.700 60.0 80.136
1280x768 60.150 75.0 102.977
720x480 Interlaced 15.735 60/59.94 13.500
720x576 Interlace 15.735 50.0 13.595
480 Progressive 60 27
720 Progressive 60 74.25
1080 Interlace 60 74.25
4Setup
1. Unpack the V-R151P-4Aand accompanying power supply.
Physically inspect for any damage that may have occurred during shipping. Should there be any damage, immediately
contact Marshall Electronics at 800-800-6608. If you are not located within the continental united states call [phone].
2. Install in your desired location.
3. Connect required cables for signal input and output.
4. Attach connection from power supply to the back of the unit.
5. Plug the power supply into the A.C. source
6. Turn on the V-R151P-4A by depressing the power switch located on the front of the unit.
7. Perform input selections and screen adjustments as detailed in following sections of this document
720x480 Interlaced 15.735 59.94 13.500
720x576 Interlaced 15.735 50.0 13.595
8PC Formats supported from VGA and DVI connectors
9Video Formats Supported By Component and DVI Inputs
10 Video Formats Supported By Composite and S-Video Inputs

3
5Connectors
6Front Panel Indicators and Controls
Marshall Electronics
VESA 75mm
Attach Points
7Menu Functions Note: MENU select will toggle through 5 menus, PICTURE, SCREEN, FUNCTION, SOURCE and TV
1. Picture Menu (Use UP/DOWN/LEFT/RIGHT buttons to select function)
YPrPb S-Video Video PC DVI
Brightness 99 999
Contrast 99 999
Sharpness 99 9
Tint 99 9
Phase 99
Color 99 9
Color temp 99
12 VDC from
power supply
4 Pin Male XLR
Pin 4 - Pos
Pin 1- Neg
4 Composite
Video Inputs
S-Video IN
4 Pin Din (Female)
Pin1 - GND
Pin2 - GND
Pin3 – Y in
Pin4 – C in
VGA/XGA Connector
PIN# SIGNAL PIN# SIGNAL
1 RED 9 NC
2 GREEN 10 NC
3 BLUE 11 NC
4 NC 12 NC
5 GND 13 HSYNC
6 RED SHIELD 14 VSYNC
7 GREEN SHIELD 15 NC
8 BLUE SHIELD
Pin1- Green
Pin2- Red
Pin3-Amber
Pin4 Gnd -
Pin5-
Pin6-
Pin7-
Pin8-
Pin 9-
Pin10-
Pin11-
Pin12-
Pin13-
Pin14-
Pin15-
Tally IN HD-15 Female

4
V-R151P-4A Users Guide
V-R151P-4A Users Guide
2. Function Menu (Use UP/DOWN/LEFT/RIGHT buttons to select function)
AUTO Configure – Used for PC signals to auto fit image to screen.
DPMS – When selected to ON, the Digital Power Management System will place the monitor into standby when there is no
input signal for 12 seconds and will automatically turn on the monitor when a signal is applied to the last selected source.
Reset – Restores the monitor to factory settings
OSD TIME-OUT – Set time in seconds (0 to 60) for OSD to drop from screen after last button push
SLEEP TIMER – Used to automatically turn monitor off after programmed delay
Language – Not Used
3. Screen Menu (Use UP/ DOWN/ LEFT/ RIGHT buttons to select function)
YPrPb S-Video Video PC DVI
H-Position 99
V-Position 99
Frequency 99
V-Position – Use LEFT and RIGHT buttons to adjust horizontal position of the PC Image
H-Position – Use LEFT and RIGHT buttons to adjust wertical position of the PC Image
Frequency – Use LEFT and RIGHT buttons to adjust the pixel clock width of the PC Image
YPrPb S-Video Video PC DVI
Auto Configure 99
DPMS 9999
Reset 99 999
OSD Time Out 99 999
Sleep Timer 9
Language
4. Source Menu (Use UP/ DOWN/ LEFT/ RIGHT buttons to select function)
YPrPb S-Video Video PC DVI
Analog RBG (PC) 99 999
Composite Video 99 999
S-VHS Video 99 999
YPrPb 99 999
Analog RGB – Select the on screen source display to be from the HD-15 PC connector on the rear of the unit.
Composite Video – Select the on screen source display to be from the 4 BNC(Video) connectors on the rear of the unit.
S-VHS Video – Select the on screen source display to be from the 4 Pin S-Video Connector
YPrPb – Select the on screen display to be from the component 3 BNC YPrPb connectors
DVI – Select the on screen display to be from the DVI Digital Connector
5. Alternate Menu Functions
Menu is shown by holding down ALT and then pressing the MENU button. (ALT+MENU).
Function selection and cursor movement is performed with the source selection buttons.
