Martin®
Sonic Horns
Operator’s Manual
M3829
Go to Martin®Sonic Horns web page

Important
MARTIN ENGINEERING HEREBY DISCLAIMS ANY LIABILITY FOR: DAMAGE DUE TO
CONTAMINATION OF THE MATERIAL; USER’S FAILURE TO INSPECT, MAINTAIN AND TAKE
REASONABLE CARE OF THE EQUIPMENT; INJURIES OR DAMAGE RESULTING FROM USE OR
APPLICATION OF THIS PRODUCT CONTRARY TO INSTRUCTIONS AND SPECIFICATIONS
CONTAINED HEREIN. MARTIN ENGINEERING’S LIABILITY SHALL BE LIMITED TO REPAIR
OR REPLACEMENT OF EQUIPMENT SHOWN TO BE DEFECTIVE.
Observe all safety rules given herein along with owner and Government standards and regulations. Know
and understand lockout/tagout procedures as defined by American National Standards Institute (ANSI)
z244.1-1982, American National Standard for Personnel Protection - Lockout/Tagout of Energy Sources -
Minimum Safety Requirements and Occupational Safety and Health Administration (OSHA) Federal
Register, Part IV, 29 CFR Part 1910, Control of Hazardous Energy Source (Lockout/Tagout); Final Rule.
The following symbols may be used in this manual:
DANGER
!
Danger: Immediate hazards that will result in severe personal injury or death.
WARNING
!
Warning: Hazards or unsafe practices that could result in personal injury.
CAUTION
!
Caution: Hazards or unsafe practices that could result in product or property damages.
IMPORTANT
Important: Instructions that must be followed to ensure proper installation/operation of equipment.
NOTE
Note: General statements to assist the reader.

Martin Engineering M3829-08/13 iMartin®Sonic Horns
Table of Contents
Section Page
List of Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Required accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Materials required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Before Installing Sonic Horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installing Sonic Horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing sonic horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing restraining cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Connecting air supply to sonic horn. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
After Installing Sonic Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Every month. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Appendix A.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Table of Contents

Martin Engineering M3829-08/13 ii Martin®Sonic Horns
List of Figures
Figure Title Page
1 Flush Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Mid-Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3 Installing Restraining Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Plumbing Detail for Normally-Closed Solenoid Valve . . . . . . . . . . . . . . . . . 8
5 Martin®75Hz Sonic Horn Assembly, P/N SH075-XXXXXXX . . . . . . . . . 14
6 Martin®230Hz Sonic Horn Assembly, P/N SH230-XXXXX . . . . . . . . . . . 16
7 Martin®75Hz Mega Horn Assembly, P/N SH075M-XXXXXX . . . . . . . . . 17
List of Tables
Table Title Page
I Martin®75Hz Sonic Horn Assembly, P/N SH075-XXXXXXX . . . . . . . . . 15
II Martin®230Hz Sonic Horn Assembly, P/N SH230-XXXXX . . . . . . . . . . . 16
III Martin®75Hz Mega Horn Assembly, P/N SH075M-XXXXXX . . . . . . . . . 18
List of Figures & Tables

Martin Engineering M3829-08/13 1Martin® Sonic Horns
Introduction
General The Martin®Sonic Horn is a pneumatic bulk material-moving system that
generates intense sound waves and introduces vibration into vessels, transfer
chutes, gas ducts, and feed pipes to maintain material or gas flow.
This manual provides instructions for installing sonic horns on steel structures
only. For installations on other structures, call Martin Engineering or a
representative.
Specifications See Appendix A for technical data specific to individual models.
Required
accessories
A sonic horn system requires additional accessories in order to be fully
operational. These accessories, which consist of solenoid valves, filters,
regulators, ball valves, air hoses, mounting plates, etc., can be purchased from
Martin Engineering. These accessories are packaged in kits for convenience
and are ordered separately from the sonic horn assembly. Contact Martin
Engineering or a representative to determine which kits are required for your
specific application.
References The following documents are referenced in this manual:
• American National Standards Institute (ANSI) z244.1-1982, American
National Standard for Personnel Protection - Lockout/Tagout of Energy
Sources - Minimum Safety Requirements, American National Standards
Institute, Inc., 1430 Broadway, New York, NY 10018.
• Federal Register, Volume 54, Number 169, Part IV, 29 CFR Part 1910,
Control of Hazardous Energy Source (Lockout/Tagout); Final Rule,
Department of Labor, Occupational Safety and Health Administration
(OSHA), 32nd Floor, Room 3244, 230 South Dearborn Street,
Chicago, IL 60604.
•The National Electrical Code (NEC) Handbook, National Fire Protection
Association, 1 Batterymarch Park, P.O. Box 9101, Quincy MA 02269-9101.
• ICS 1-1988, General Standards for Industrial Control and Systems, and
250-1985, Enclosures for Electrical Equipment (1000 Volts Maximum),
National Electrical Manufacturers Association (NEMA), 2101 L Street
N.W., Washington, D.C. 20037.
Safety All safety rules defined in the above documents, and all owner/employer
safety rules, must be strictly followed when installing and servicing this
equipment.
Materials required Materials other than standard hand tools that are required to complete tasks
are listed where applicable.
Introduction

Martin Engineering M3829-08/13 2Martin® Sonic Horns
Before Installing Sonic Horn
IMPORTANT
The delivery service is responsible for damage occurring in
transit. Martin Engineering CANNOT enter claims for
damages. Contact your transportation agent for more
information.
1. Inspect shipping container for damage. Report damage to delivery service
immediately and fill out delivery service’s claim form. Keep any damaged
goods subject to examination.
2. Remove sonic horn assembly from shipping container.
3. If you purchased accessories from Martin Engineering, they will be
packaged separately. Remove this equipment from its shipping container.
4. Take inventory of the equipment received. If anything is missing, contact
Martin Engineering or representative.
WARNING
!
Before installing sonic horn, lock out/tag out any equipment
that is loading or unloading material from the vessel.
5. Turn off and lock out/tag out energy source to accessory equipment
according to ANSI standards (see “References”).
WARNING
!
If equipment will be installed in an enclosed area, test gas level
or dust content before using a cutting torch or welding. Using
a cutting torch or welding in an area with gas or dust may
cause an explosion.
6. If using a cutting torch or welding, test atmosphere for gas level or dust
content.
Before Installation

Martin Engineering M3829-08/13 3Martin® Sonic Horns
Installing Sonic Horn
NOTE
NOTICE OF LIMITED LIABILITY: Due to possible presence of latent
structural defects in the apparatus of the purchaser, Martin Engineering
shall not be responsible for consequential damage to the purchaser’s
equipment and/or apparatus resulting from the application of a Martin®
Product. Martin Engineering shall not be liable for improper installation
by the purchaser or other circumstances beyond the control of Martin
Engineering. Liability is disclaimed for the structural soundness of
apparatus or equipment not supplied by Martin Engineering. Liability
shall be strictly limited to the replacement of the purchased product or
refund of the purchase price. To secure the integrity of the installation,
specify supervision by qualified personnel from Martin Engineering.
Installing sonic
horn
Sonic horns must be solidly mounted to the vessel and the horn must have
unrestricted flow. A variety of installation methods and mount plate designs
can be used to install sonic horns. This section will describe the installation
using the most common methods. If you are not sure how to install the sonic
horn for optimum performance and convenience, contact Martin Engineering
or a representative.
NOTE
If you are unsure where to locate sonic horn(s) on your vessel,
contact Martin Engineering or your representative.
1. Mark location for each sonic horn on vessel. Make sure sonic horn is not
positioned where material can flow into horn.
Installation

Martin Engineering M3829-08/13 4Martin® Sonic Horns
Figure 1. Flush Mount Installation
2. For flush mount installations:
a. Cut a hole in vessel using flange ring (C) as a template.
b. Tack weld flange ring (C) to vessel.
c. Attach sonic horn to flange ring (C) using cap screws and washers (B).
d. Weld flange ring (C) to vessel. Make a continuous weld around
perimeter of flange ring.
A
C
B
A. Vessel Wall
B. Cap Screw and Washer
C. Flange Ring
Installation

Martin Engineering M3829-08/13 5Martin® Sonic Horns
Figure 2. Mid-Mount Installation
3. For mid-mount installations:
a. Cut a hole in vessel using flange ring (F) as a template.
b. Tack weld flange ring (F) to vessel.
c. Attach flange plate G) to flange ring (F) using cap screws and
washers (E).
d. Weld flange ring (F) to vessel. Make a continuous weld around
perimeter of flange ring.
e. Place sections A and B of sonic horn on the outside of the flange plate
(G) and place section C on the inside of the flange plate. Attach both
sections to flange plate and to each other using cap screws (H) and
washers and nuts (I).
D
F
C
G
E
D
G
I
D
F
G
B
A
A
B
A. Section A
B. Section B
C. Section C
D. Vessel Wall
E. Cap Screw and Washer
F. Flang e R ing
G. Flange Plate
H. Cap Screw
I. Nut and Washer
H
C
Installation

Martin Engineering M3829-08/13 6Martin® Sonic Horns
Installing
restraining cable
WARNING
!
Always install restraining cable to secure sonic horn to vessel.
Without restraining cable, sonic horn could fall and cause
injury.
Do not use restraining cable to mount sonic horn to vessel wall.
Purpose of restraining cable is to keep sonic horn from falling
should it come loose from vessel wall, not as primary means of
securing sonic horn to wall.
Figure 3. Installing Restraining Cable
1. Weld D-ring (A) onto vessel wall (B) with 1/4-in. (6-mm) field weld.
2. Insert one end of wire rope (C) through D-ring (A) on vessel, making a
3-in. (76-mm) loop.
3. Route wire rope (C) through brackets (E) and back to D-ring on vessel.
4. Insert wire rope (C) through D-ring (A) on vessel, making a 3-in.
(76-mm) loop.
5. To fasten each wire loop:
a. Clamp wire rope with one cable clamp (D) as close to loop as possible.
Place another cable clamp 1-3/4 in. (44 mm) from first clamp.
b. Leave at least 1 in. (25 mm) of wire rope on dead end.
c. Gradually tighten nuts alternately and evenly to 15 ft-lbs.
Leave 2 to 3 in. (51 to 76 mm) slack in wire rope.
A.
B.
C.
D.
D-ring
Vessel Wall
Wire rope
Cable clamp
E. Bracket
D
D
A
B
C
D
E
E
D
Installation

Martin Engineering M3829-08/13 7Martin® Sonic Horns
Connecting air
supply to sonic
horn
IMPORTANT
Depending upon the application, a receiver tank may be
needed to supply amount of air required to effectively operate
sonic horns. For more information contact Martin
Engineering or a representative.
IMPORTANT
Do not use a lubricated air supply for sonic horns.
1. Apply pipe sealant to all fittings.
2. See Figure 4. Connect 1” lockout ball valve to compressed air source with
desired length of 1” pipe. Look at arrow on side of ball valve to make sure
flow is correct.
3. Connect air filter/regulator to 1” lockout ball valve with desired length of
1” pipe. Look at arrow on side of air filter/regulator to make sure flow is
correct.
4. Connect 1” to 3/4” reducer to air filter/regulator with desired length of
1” pipe.
5. Connect 3-way electrical solenoid valve to 1” to 3/4” reducer with 6” long
3/4” pipe nipple. See Figure 4 for solenoid connections.
6. Connect 3/4” lockout ball valve to solenoid valve using desired length of
3/4” pipe.
7. Connect sonic horn sound generator to 3/4” lockout ball valve using
braided stainless steel hose.
IMPORTANT
For electrical solenoid valve installations, design and wire
electrical solenoid controls according to NEC Handbook.
Electrical push buttons, timers, and programmable
controllers are available through Martin Engineering.
8. For electrical solenoid valve installations, if using electrical solenoid
controller, install according to instructions provided with controller.
WARNING
!
Do not exceed 80 psi (5.52 bar) maximum working pressure.
Minimum recommended pressure for most applications is
60 psi (4.14 bar), but lower pressures can be used. Make sure
air supply is filtered and regulated.
9. Anchor all pipes and wires to prohibit movement.
Installation

Martin Engineering M3829-08/13 8Martin® Sonic Horns
Figure 4. Plumbing Detail for Normally-Closed Solenoid Valve
* Contact MARTIN ENGINEERING for Recommendation.
** Contact MARTIN ENGINEERING for breakdown of parts contained in assemblies and kits.
Item Description Assembly & Kit
Part Numbers**
AMartin
®Sonic Horn SH075-XXXXXXX &
SH230XXXXX
B Braided Stainless Steel Hose 3/4” 38795-5
C 3-Way Solenoid Valve (normally closed) 38794-XXX
D Lockout Valve 1” 32284-04
E Filter Regulator Unit 38736
F Air Supply Pipe 1” 103005 or by others
G Lockout Valve 3/4” 32284-02
H Controller/PLC *
From PLC or timer
To sound generator
Open to
atmosphere
From
air supply
Electrical Signal Line
(supplied by others)
60 to 80 psi (supplied by others)
Electrical Power Supply
(supplied by others)
Compressed Air Supply
B
A
E
D
H
C
G
F
1” pipe for less than 100’
1” pipe reduced to 3/4”
Installation

Martin Engineering M3829-08/13 9Martin® Sonic Horns
After Installing Sonic Horn
WARNING
!
Sonic horns produce intense sound waves. Use ear protection
to avoid impairment or loss of hearing.
WARNING
!
Do not exceed 80 psi (5.52 bar) maximum working pressure.
Minimum recommended pressure for most applications is
60 psi (4.14 bar), but lower pressures can be used. Make sure
air supply is filtered and regulated.
1. Turn on air supply and open ball valves.
2. Sound sonic horn five times to ensure proper operation.
3. If sonic horn sounds properly, continue to operate as needed. If problems
occur, see “Troubleshooting.”
4. If sonic horn does not sound, see “Troubleshooting.”
5. Check system for air leaks. If leaking, see “Troubleshooting.”
After Installation

Martin Engineering M3829-08/13 10 Martin® Sonic Horns
Maintenance
WARNING
!
Do not open door/port or enter vessel before turning off
compressed air source, locking out controls, and purging line
pressure.
Turn off and lock out/tag out energy source according to ANSI standards
(see “References”).
Every month 1. Inspect all connections from air supply to sonic horn for leaks and
deterioration. If connections are leaking, seal all fittings with pipe sealant
and tighten. Replace any deteriorating connections. Make sure hoses do
not flex more than 1/4 inch (6 mm).
2. Make sure all pipes and wires are anchored to prohibit movement. Secure
as needed.
3. Inspect sonic horn for material buildup. Remove buildup as necessary.
4. Inspect electrical solenoid valve, lockout ball valve, and air filter/
regulator for proper operation. If not operating correctly, replace.
5. Inspect sound generator for correct operation; If not operating correctly
see “Troubleshooting.”
Maintenance

Martin Engineering M3829-08/13 11 Martin® Sonic Horns
Troubleshooting
If sonic horn will not sound, find possible cause(s) in appropriate chart below
and follow steps in “Solution” column. If after doing so you are still
experiencing problems, contact Martin Engineering or a representative.
Problem: Sonic Horn Will Not Sound
Cause Solution
Compressor source. Make sure compressor is on and air line has pressure.
Ball valves open. Check that ball valves are fully open.
Filter/Regulator. Factory-set at zero. Rotate clockwise to increase.
Check plumbing air flow direction (indicated with an
arrow).
Solenoid plumbing. Make sure plumbing is correct.
Check for leaks.
Check plumbing direction.
Solenoid electrical. Make sure wiring is connected.
Check that voltage is correct.
Check for signal.
Blocked discharge—
horn makes high-pitched sound.
Remove blockage.
Titanium diaphragm worn. Replace diaphragm.
Sound generator worn. Return to Martin Engineering for refurbishing.
Troubleshooting

Martin Engineering M3829-08/13 12 Martin® Sonic Horns
Part Numbers
This section provides product names and corresponding part numbers for
Martin®Sonic Horns and related equipment. Please reference part numbers
when ordering parts. Part numbers for accessory equipment not listed here are
available from Martin Engineering or representative.
SECTION A MATERIAL
D: Ductile Iron
S: Stainless Steel
SECTION B MATERIAL
D: Ductile Iron
S: Stainless Steel
SECTION B STYLE
0: Straight
9: 90 Degree Elbow
SECTION C CONSTRUCTION
C: Cast
F: Fabricated
SECTION C MATERIAL
D: Ductile Iron
S: Stainless Steel
M: Mild Steel
SECTION C FLANGE
0: No Flange
(N/A with cast sections)
1: With Flange
SOUND GENERATOR
D: Ductile Iron
S: Stainless Steel
Blank: No Generator
SH075-X X X X X X X
NOMENCLATURE
Section A Material
Section B Material
Section B Style
Section C Construction
Section C Material
Section C Flange
Sound Generator
SECTION A MATERIAL
D: Ductile Iron
S: Stainless Steel
SECTION B CONSTRUCTION
C: Cast
F: Fabricated
SECTION B MATERIAL
D: Ductile Iron
S: Stainless Steel
SECTION B FLANGE
0: No Flange
(N/A with cast sections)
1: With Flange
SOUND GENERATOR
D: Ductile Iron
S: Stainless Steel
Blank: No Generator
SH230-X X X X X
NOMENCLATURE
Section A Material
Section B Construction
Section B Material
Section B Flange
Sound Generator
SECTION B MATERIAL
D: Ductile Iron
S: Stainless Steel
SECTION B STYLE
0: Straight
9: 90 Degree Elbow
SECTION C CONSTRUCTION
C: Cast
F: Fabricated
SECTION C MATERIAL
D: Ductile Iron
S: Stainless Steel
M: Mild Steel
SECTION C FLANGE
0: No Flange
(N/A with cast sections)
1: With Flange
SOUND GENERATOR
D: Ductile Iron
Blank: No Generator
SH075M-X X X X X X
NOMENCLATURE
Section B Material
Section B Style
Section C Construction
Section C Material
Section C Flange
Sound Generator
Part Numbers

Martin Engineering M3829-08/13 13 Martin® Sonic Horns
Recommended Spare Parts
*Recommended quantity for two years of operation.
Accessories Martin®Sonic Horn Mounting Flange Kit: P/N 38800-XXXXXXXXX
Martin®Sonic Horn Air Line Kit: P/N 38793-XXX
Martin®Sonic Horn Manifold Plumbing Kit: P/N 38927
Martin®Sonic Horn Controller: P/N 38901-S
Description Part No. Qty*
Sound Generator Body Assembly 38770 (Standard Horn)
38770-M (Mega Horn)
15% of Total Number of
Sonic Horns
Sonic Horn Diaphragm/Gasket Kit 38798 (Standard Horn)
38798-M (Mega Horn)
40% of Total Number of
Sonic Horns
Part Numbers

Martin Engineering M3829-08/13 14 Martin® Sonic Horns
Figure 5. Martin®75Hz Sonic Horn Assembly, P/N SH075-XXXXXXX
NS = Not Shown
Item Description Part No. Qty
1 75 Hz Section A Table I 1
2 75 Hz Section B Table I 1
3 75 Hz Section C Table I 1
4 Sound Generator Assembly Table I 1
5 Washer Compression 5/16 SS 38698 13
6 Screw, HHC 5/16-18NC X1-1/4 SS 38697 3
7 Screw, HHC 5/16-18NC X1-1/2 SS SP04436-30 10
8 Nut Hex 5/16-18NC SS 37723 10
9 Safety Cable Clip 38797 2
10 (NS) D-ring 32265 1
11 (NS) Cable Clamp 32264 4
12 (NS) Wire Rope 1/4 100258 12 ft
13 (NS) Operator’s Manual M3829 1
14 (NS) Hardware Kit (Items 5–12) 39129 1
1
5,8
4
3
5,6 7
2
9
1
5,8
4
3
5,6 7
2
SH075-XX9XX1X
SH075-XX0XX1X
Part Numbers

Martin Engineering M3829-08/13 15 Martin® Sonic Horns
Table I. Martin®75Hz Sonic Horn Assembly, P/N SH075-XXXXXXX
Assembly
Part No.
Item 1
Part No.
Assembly
Part No.
Item 2
Part No.
SH075-DXXXXXX 38771-P SH075-D0XXXXX 38772-P
SH075-SXXXXXX 38771-SS SH075-S0XXXXX 38772-SS
SH075-D9XXXXX 38777-P
SH075-S9XXXXX 38777-SS
Assembly
Part No.
Item 3
Part No.
Assembly
Part No.
Item 4
Part No.
SH075-XXXCD1X 38773-P SH075-XXXXXXD 38770
SH075-XXXCS1X 38773-SS SH075-XXXXXXS 38770-SS
SH075-XXXFM0X 38773-F0
SH075-XXXFM1X 38773-F1
SH075-XXXFS0X 38773-FC0
SH075-XXXFS1X 38773-FC1
Part Numbers

Martin Engineering M3829-08/13 16 Martin® Sonic Horns
Figure 6. Martin®230Hz Sonic Horn Assembly, P/N SH230-XXXXX
NS = Not Shown
Table II. Martin®230Hz Sonic Horn Assembly, P/N SH230-XXXXX
Item Description Part No. Qty
1 230 Hz Section A Table II 1
2 230 Hz Section B Table II 1
3 Sound Generator Assembly Table II 1
4 Washer Compression 5/16 SS 38698 9
5 Screw, HHC 5/16-18NC X1-1/4 SS 38697 3
6 Screw, HHC 5/16-18NC X1-1/2 SS SP04436-30 6
7 Nut Hex 5/16-18NC SS 37723 6
8 Safety Cable Clip 38797 1
9 (NS) D-ring 32265 1
10 (NS) Cable Clamp 32264 4
11 (NS) Wire Rope 1/4 100258 12 ft
12 (NS) Operator’s Manual M3829 1
13 (NS) Hardware Kit (Items 4–11) 39129 1
Assembly
Part No.
Item 1
Part No.
Assembly
Part No.
Item 2
Part No.
Assembly
Part No.
Item 3
Part No.
SH230-DXXXX 38778-P SH230-XCD0X 38779-P SH230-XXXXD 38770
SH230-SXXXX 38778-SS SH230-XCS0X 38779-SS SH230-XXXXS 38770-SS
SH230-XFS0X 38779-FSS0
SH230-XFS1X 38779-FSS
1
4,6
3
4,5
62
8
Part Numbers
