UH-CC-5-24
UltraHorn™CC
ULTIMATE NOISE-REJECTING DIRECTIONAL
HORN ANTENNA WITH CARRIER CLASS PERFORMANCE
Overview
www.rfelements.com
UltraHorn™ CC
*Estimation based on pre-production units. Subject to change.
Product ID Dimensions Weight* Gain Polarization
UltraHorn™ CC
5-24
UH-CC-5-24 635 x 572 x 615
mm
8.7 kg
19.1 lbs 24 dBi Dual Linear
H + V
Package Contents
www.rfelements.com
UltraHorn™ CC
1
Number Description Quantity
1 UltraHornTM CC Body 1x
2 UltraHornTM CC Bracket Arm 1x
3 UltraHornTM CC Bracket 2x
4 M8 x 90mm Screw 4x
2
34
RF elements s.r.o.
Phone: +421 2 3260 3711
[email protected]
www.rfelements.com
User Guide Part Number: UG-UH-CC-24-v1
RF elements®, TwistPort™, SIMPER™ and UltraHorn™
are trademarks of RF elements s.r.o., Humenne, Slovakia.
All rights of trademark owners reserved.
Installation Guide
www.rfelements.com
UltraHorn™ CC
Tighten all screw equally.
2
1
This part should always
be installed facing up.
1
2
Step 1
USE ANTISEIZE
THREAD LUBRICANT
Installation Guide
www.rfelements.com
UltraHorn™ CC Step 2
Installation Guide
www.rfelements.com
UltraHorn™ CC Step 3
Installation Guide
www.rfelements.com
UltraHorn™ CC
Left side Right side
Step 4
