MARUTI SUZUKI TOUR S 2023 User manual

82PH0-74E
TABLE OF CONTENTS
FUEL RECOMMENDATION 1
BEFORE DRIVING 2
OPERATING YOUR VEHICLE 3
DRIVING TIPS 4
OTHER CONTROLS AND EQUIPMENT 5
VEHICLE LOADING AND TOWING 6
INSPECTION AND MAINTENANCE 7
EMERGENCY SERVICE 8
APPEARANCE CARE 9
GENERAL INFORMATION 10
SPECIFICATIONS 11
SERVICE NETWORK 12

FUEL RECOMMENDATION
1
56RH0-74E
56RM01001
FUEL RECOMMENDATION
Fuel Recommendation ........................................................ 1-1

1-1
FUEL RECOMMENDATION
56RH0-74E
Fuel Recommendation
Petrol Engine
To avoid damaging catalytic converter, you
must use unleaded petrol with an octane
number (RON) of 91 or higher.
Gasoline/Ethanol blends
Blends of unleaded gasoline and ethanol
(grain alcohol), also known as gasohol, are
commercially available in certain areas.
Blends of this type are recommended for
this vehicle if they are no more than 10%
ethanol. The vehicle may also be plied with
blend of no more than 20% ethanol.
NOTE:
If you are not satisfied with the driveability
or fuel economy of your vehicle when you
are using 20% ethanol blend, you should
switch back to blend of no more than 10%
ethanol.
Gasoline containing MTBE
Unleaded gasoline containing MTBE
(methyl tertiary butyl ether) may be used in
your vehicle if the MTBE content is not
greater than 15%. This oxygenated fuel
does not contain alcohol.
CAUTION
Use of spurious, low quality, adulter-
ated fuel can cause damage to the
engine and engine auxilliaries, affect
functioning of engine and degrade
engine performance including but
not limited to engine seizure.
NOTICE
• The fuel tank has an air space to
allow for fuel expansion in hot
weather. If you continue to add fuel
after the filler nozzle has automati-
cally shut off or an initial blowback
occurs, the air chamber will
become full. Exposure to heat
when fully fuelled in this manner
will result in leakage due to fuel
expansion. To prevent such fuel
leakage, stop filling after the filler
nozzle has automatically shut off,
or when initial vent blowback
occurs, if using an alternative non-
automatic system.
• Be careful not to spill fuel contain-
ing alcohol while refueling. If fuel is
spilled on the vehicle body, wipe it
up immediately. Fuels containing
alcohol can cause paint damage,
which is not covered under the
New Vehicle Limited Warranty.

BEFORE DRIVING
2
56RH0-74E
60G404
Keys ...................................................................................... 2-1
Door locks ............................................................................ 2-2
Keyless push start system remote controller /
Keyless entry system transmitter (if equipped) ............... 2-3
Security system (if equipped) ............................................ 2-6
Theft deterrent light (if equipped) ...................................... 2-9
Windows .............................................................................. 2-9
Mirrors .................................................................................. 2-9
Front seats ........................................................................... 2-10
Seat belts and child restraint systems .............................. 2-12
Supplemental restraint system (air bags) ......................... 2-28
Instrument cluster (Type A) (if equipped) ......................... 2-35
Speedometer ....................................................................... 2-36
Fuel gauge ........................................................................... 2-36
Brightness control .............................................................. 2-36
Information display ............................................................. 2-37
Warning and indicator lights .............................................. 2-44
Lighting control lever ........................................................ 2- 51
Headlight leveling switch .................................................. 2-53
Turn signal control lever ................................................... 2-53
Hazard warning switch ...................................................... 2-54
Windshield wiper and washer lever ................................. 2-55
Tilt steering lock lever ....................................................... 2-56
Horn ..................................................................................... 2-56
Heated rear window switch (if equipped) ........................ 2-57

2-1
BEFORE DRIVING
56RH0-74E
Keys
54G489
Your vehicle comes with a pair of keys.
The key(s) may or may not be equipped
with a transmitter depending on model
variant. Keep the spare key in a safe
place. One key can open all of the locks on
the vehicle
The key identification number is stamped
on a metal tag provided with the keys or on
the keys. Keep the tag in a safe place. If
you lose your keys, you will need this num-
ber to have new keys made. Write the
number below for your future reference.
Immobilizer system
This system is designed to help prevent
vehicle theft by electronically disabling the
engine starting system.
The engine can be started only with your
vehicle’s original immobilizer ignition key
or keyless push start system remote con-
troller, which has an electronic identifica-
tion code programmed in it. The key or
remote controller communicates the identi-
fication code to the vehicle when the igni-
tion switch is turned to “ON” position or the
engine switch is pressed to change the
ignition mode to “ON”. If you need to make
spare keys or remote controllers, see your
an authorised Maruti Suzuki workshop.
The vehicle must be programmed with the
correct identification code for the spare. A
key made by an ordinary locksmith will not
work.
80JM122
If the immobilizer/keyless push start sys-
tem warning light blinks or comes on when
the ignition switch is in “ON” position or the
ignition mode is “ON”, the engine will not
start.
If this light blinks or comes on, turn the
ignition switch to “LOCK” position, and
then turn it back to “ON” position.
If the light still blinks after or comes on the
ignition switch is turned back to “ON” posi-
tion, there may be something wrong with
your key or with the immobilizer system.
Ask an authorised Maruti Suzuki workshop
to have the system inspected.
NOTE:
• If you lose your immobilizer ignition key
or remote controller, ask an authorised
Maruti Suzuki workshop as soon as pos-
sible to deactivate the lost one, and to
make a new key or remote controller.
• If you own other vehicles with immobi-
lizer keys, keep those keys away from
the ignition switch or the engine switch
when using your MARUTI SUZUKI vehi-
cle. Otherwise, or the engine may not be
started because they may interfere with
your MARUTI SUZUKI vehicle’s immobi-
lizer system.
• If you attach any metal objects to the
immobilizer key or remote controller, it
may not start the engine.
KEY NUMBER:
EXAMPLE

2-2
BEFORE DRIVING
56RH0-74E
Ignition key reminder (if equipped)
A buzzer sounds intermittently to remind
you to remove the ignition key if it is in the
ignition keyhole when the driver’s door is
opened.
Door locks
Side door locks (if equipped)
79MH0201
(1) LOCK
(2) UNLOCK
(3) Front
(4) Rear
To lock a front door from the outside of the
vehicle:
• Insert a key and turn the top of the key
toward the front of the vehicle, or
• Turn the lock knob forward, then pull and
hold the door handle as you close the
door.
To unlock a front door from the outside of
the vehicle, insert the key and turn the top
of the key toward the rear of the vehicle.
74LHT0201
(1) LOCK
(2) UNLOCK
To lock a door from the inside of the vehi-
cle, turn the lock knob forward. Turn the
lock knob backward to unlock the door.
To lock a rear door from the outside of the
vehicle, turn the lock knob forward and
close the door. You do not need to pull and
hold the door handle as you close the door.
NOTE:
Hold the door handle when you close a
locked front door, or the door will not
remain locked.
NOTICE
The immobilizer key and remote con-
troller are sensitive electronic instru-
ments. To avoid damaging them:
• Do not expose them to impacts,
moisture or high temperature such
as on the dashboard under direct
sunlight.
• Keep them away from magnetic
objects.
(1)
(3)
(2)
(4)
EXAMPLE
Door Lock Knob
(1)
(2)
EXAMPLE

2-3
BEFORE DRIVING
56RH0-74E
Child-proof locks (rear door)
(if equipped)
56RH00202
(1) LOCK
(2) UNLOCK
Each of the rear doors is equipped with a
child-proof lock which can be used to help
prevent unwanted opening of the door
from inside the vehicle. When the lock
lever is in LOCK position (1), the rear door
can only be opened from outside. When
the lock lever is in UNLOCK position (2),
the rear door can be opened from inside or
outside.
Trunk lid
56RH00204
You can unlock the lid by pulling the trunk
lid opener lever (2) located on the out-
board side of the driver’s side.
Keyless entry system
transmitter (if equipped)
56RM02003
Your vehicle is equipped with keyless entry
system transmitter. The remote controller
has a keyless entry system and a keyless
push start system. The transmitter has
only a keyless entry system. For details,
refer to the following explanations.
WARNING
Place the child-proof lock in LOCK
position whenever children are
seated in the rear.
(1)
(2)
EXAMPLE
WARNING
• Always make sure that the trunk lid
is closed and latched securely. Oth-
erwise, it may open unexpectedly
while driving. Completely closing it
also helps keep exhaust gases
from entering the vehicle.
• Always make sure that the trunk lid
is fully opened before using the
luggage compartment.
(2)
EXAMPLE
EXAMPLE

2-4
BEFORE DRIVING
56RH0-74E
Keyless entry system transmitter
(if equipped)
56RM02005
(1) LOCK button
(2) UNLOCK button
You can lock or unlock all doors simultane-
ously by operating the transmitter near the
vehicle.
Central door locking system
• To lock all doors, push LOCK button (1)
once.
• To unlock only the driver’s door, push
UNLOCK button (2) once.
• To unlock other doors, push UNLOCK
button (2) once again.
NOTE:
You can switch the function that unlocks all
doors from requiring two pushes to requir-
ing one push, and vice versa, via the infor-
mation display setting mode. For details on
how to use the information display, refer to
“Information display” in this section.
The turn signal lights will flash once and
the siren will sound once when the doors
are locked.
When the doors are unlocked:
• The turn signal lights will flash twice and
the siren will sound twice.
• If the interior light switch is in DOOR
position, the interior light will turn on for
about 15 seconds and then fade out. If
you insert the key into the ignition switch
during this time, the light will start to fade
out immediately.
Check that the doors are locked after you
operate LOCK button (1).
NOTE:
If no door is opened within about 30 sec-
onds after UNLOCK button (2) is operated,
the doors will automatically lock again.
NOTE:
• If you lock the doors using the transmit-
ter when the engine hood is open, the
siren will sound 3 times to remind you.
• If the security system was triggered due
to an unauthorised entry into the vehicle
and then you unlock the doors using the
transmitter, the siren will sound 4 times
to remind you. If this happens, check
whether your vehicle has been broken
into while you were away from it.
WARNING
Radio waves from the keyless push
start system antenna(s) may interfere
with operation of electrical medical
equipment such as pacemakers. Fail-
ure to take the precautions listed
below can increase the risk of severe
injury or death due to radio wave
interference.
• Anyone who uses electrical medi-
cal equipment such as a pace-
maker should consult the medical
equipment supplier or their medical
advisor about whether radio waves
from the antenna(s) can interfere
with the medical equipment.
• If radio wave interference is a con-
cern, have the function of the
antenna(s) disabled by an autho-
rised Maruti Suzuki workshop.
(1)
(2)
EXAMPLE

2-5
BEFORE DRIVING
56RH0-74E
• Once you push both of the LOCK button
(1) and UNLOCK button (2), then you
push one of the buttons within 5 sec-
onds, the siren will not sound. However,
push one of the buttons 5 seconds later,
the siren will sound.
• You can set whether the siren sounds
when locking or unlocking the door(s) via
the setting mode of the information dis-
play. For details on how to use the infor-
mation display, refer to “Information
Display” in this section.
NOTE:
• The maximum operating distance of the
keyless entry system transmitter is about
5 m (16 ft.), but this can vary depending
on the surroundings, especially near
other transmitting devices such as radio
towers or CB (Citizen’s Band) radios.
• The door locks cannot be operated with
the transmitter, if the ignition key is
inserted in the ignition switch.
• When any door is open, the door locks
can only be unlocked with the transmit-
ter, and the turn signal light will not flash.
• If you lose one of the transmitters, ask
your authorised Maruti Suzuki workshop
as soon as possible for a replacement.
Have your dealer program the new
transmitter code in your vehicle’s mem-
ory so that the old code is erased.
Car locator function
This function helps in locating the vehicle.
Push both of the LOCK button (1) and
UNLOCK button (2) for more than 3 sec-
onds.
The turn signal lights will blink for about
27.5 seconds. Also, the siren will sound for
about 27.5 seconds at the same time.
To cancel the car locator function, press
any button (LOCK or UNLOCK).
You can also turn the ignition switch to the
“ON” position to cancel the car locator
function.
NOTE:
The car locator function will not activate
when the key is in the ignition switch or pre
warning / full blast warning by shock sen-
sor or alarm is inactivated condition.
Battery replacement
If the transmitter becomes unusable,
replace the battery.
To replace the battery of the transmitter:
68LM248
1) Remove the screw (1), and open the
transmitter cover.
2) Remove the transmitter (2).
NOTICE
The transmitter is a sensitive elec-
tronic instrument. To avoid damaging
the transmitter:
• Do not expose it to impacts, mois-
ture or high temperature such as
by leaving it on the dashboard
under direct sunlight.
• Keep the transmitter away from
magnetic objects such as a televi-
sion.
(1)
(2)
EXAMPLE

2-6
BEFORE DRIVING
56RH0-74E
68LM249
(3) Lithium disc type battery:
CR1616 or equivalent
3) Put the edge of a flat-bladed screw-
driver in the slot of the transmitter (2)
and pry it open.
4) Replace the battery (3) so its + terminal
faces “+” mark of the transmitter.
5) Close the transmitter and install it into
the transmitter holder.
6) Close the transmitter cover, install and
tighten the screw (1).
7) Check that the door locks can be oper-
ated with the transmitter.
8) Dispose of the used battery properly
according to applicable rules or regula-
tions. Do not dispose of lithium batter-
ies with ordinary household trash.
NOTE:
Used batteries must be disposed of prop-
erly according to applicable rules or regu-
lations and must not be disposed of with
ordinary household trash.
Security system (if equipped)
The security system is armed after you
close and lock all doors (including engine
hood and trunk lid) by using the keyless
entry system transmitter, keyless push
start system remote controller or request
switch.
Once the system is armed, any attempt to
open a door by using any other means (*)
than the keyless entry system transmitter,
keyless push start system remote control-
ler, request switch or open the engine
hood, will cause the alarm to be triggered.
* These means include the following:
– The key
– The lock knob on a door
– The central door locking switch
– The trunk lid unlatch switch
Also, in case that you have set the shock
sensor to enabled state and set sensitivity
of the pre-warning function and full blast
warning function to a level other than 0, the
warning will be triggered in case of any
attempt to tamper with the vehicle. The
shock sensor can be selected enabled or
disabled state, and sensitivity of each
warning can be adjusted as desired. To set
the shock sensor, ask your authorised
(2)
(3)
EXAMPLE WARNING
Swallowing a lithium battery may
cause serious internal injury. Do not
allow anyone to swallow a lithium
battery. Keep lithium batteries away
from children and pets. If swallowed,
contact a physician immediately.
NOTICE
• The transmitter is a sensitive elec-
tronic instrument. To avoid damag-
ing it, do not expose it to dust or
moisture or tamper with internal
parts.
• When replacing the battery by
yourself, the transmitter could be
damaged affected by static electric-
ity. Discharge the static electricity
built up in your body by touching
metal before replacing the battery.
NOTICE
Do not modify or remove the theft
deterrent alarm system. If modified or
removed, the system may not work
properly.

2-7
BEFORE DRIVING
56RH0-74E
Maruti Suzuki workshop or use the setting
mode of the information display.
NOTE:
• The default setting of the shock sensor
is in the disabled state. Set to the
enabled state and adjust sensitivity of
each warning according to your prefer-
ence. For details on how to use the infor-
mation display, refer to “Information
Display” in this section.
• Your dealer may have already set the
shock sensor of the vehicle to the
enabled state before you purchase it.
Consult your dealer for further informa-
tion.
NOTE:
• The security system generates alarms
when any of the predetermined condi-
tions is met. However, the system does
not have any function of blocking unau-
thorised entry into the vehicle.
• Always use the keyless entry system
transmitter, keyless push start system
remote controller or request switch to
unlock the doors when the security sys-
tem has been armed.Using a key
instead will trigger the alarm.
• If a person who does not know the secu-
rity system is going to drive the vehicle,
we recommend you explain the system
and its operation to the person. Mistak-
enly triggering the alarm may cause a
nuisance to others.
• Even if the security system is armed,
you should still be careful to guard
against theft. Do not leave money or
things of value in the vehicle.
• The theft deterrent alarm system is
maintenance-free.
How to arm the security system
Lock all doors (including engine hood and
trunk lid) using the keyless entry system
transmitter, keyless push start system
remote controller or request switch.
When the system is armed, the indicator
continues to blink at intervals of approxi-
mately 2 seconds.
56RH00215
NOTE:
• To prevent the alarm from being acci-
dentally triggered, avoid arming it while
anyone remains inside the vehicle. The
alarm will be triggered if any person
inside opens the door, trunk, engine
hood, or the warning may be triggered if
anyone swings the vehicle (if the shock
sensor is in the enabled state).
• The security system is not armed when
all doors are locked using the key from
outside, using the door lock knobs or the
central door locking switch from inside.
• If any door is not operated within approx-
imately 30 seconds after the doors have
been unlocked using the keyless entry
system transmitter, keyless push start
system remote controller or request
switch, the doors are automatically
locked again. When the doors are
locked, the security system will be
armed.
• If the security system indicator (1) blinks
when the ignition switch is in the “ON”
position or the ignition mode is “ON”,
there may be something wrong with the
security system. Ask your authorised
Maruti Suzuki workshop to inspect the
system.
How to disarm the security system
Simply unlock the doors using the keyless
entry system transmitter, keyless push
start system remote controller or request
switch. The security system indicator will
go out, indicating that the security system
is disarmed.
(1)
EXAMPLE

2-8
BEFORE DRIVING
56RH0-74E
How to stop the alarm
Should the alarm be triggered accidentally,
the alarm will stop by the following opera-
tions.
• Press the engine switch to change the
ignition mode to “ON” or turn the ignition
switch to “ON” position in case of emer-
gency.
• Unlock the doors using the keyless entry
system transmitter, keyless push start
system remote controller or request
switch.
NOTE:
• Even after the alarm has stopped, if you
lock the doors using the keyless entry
system transmitter, keyless push start
system remote controller or request
switch, the security system will be
rearmed.
• If you disconnect the battery while the
security system is in the armed condition
or the alarm is actually in operation, the
alarm will be re-triggered when the bat-
tery is then reconnected.
• Even after the alarm has stopped at the
end of the predetermined operation time,
it will be triggered again if any of the
doors, trunk or engine hood is opened,
without disarming the security system.
Checking whether the alarm has been
triggered during parking
If the alarm was triggered and you then
turn the ignition switch to “ON” position or
the ignition mode is “ON” the security sys-
tem indicator will blink rapidly for about 8
seconds and a buzzer will beep 4 times
during this period. If this happens, check
whether the vehicle has been broken into
while you were away from it.
Security system indication
• If any of the doors or trunk are opened
without unlocking by the keyless entry
system transmitter, keyless push start
system remote controller or request
switch, all turn signal lights start to blink
and the interior buzzer beeps intermit-
tently. After 5 seconds, the siren will
sound for about 27.5 seconds. The
security system indicator continues to
blink during this time.
• If the engine hood is opened, all turn sig-
nal lights blink, and the siren sounds for
about 27.5 seconds. The security sys-
tem indicator continues to blink during
this time.
(If the shock sensor is in the enabled state)
• If the vehicle feels a shock higher than
the pre-warning sensitivity, the siren
sounds for about 2 seconds (pre-warn-
ing). If the vehicle feel a shock higher
than the full blast warning sensitivity, the
siren sounds for about 5 seconds (full
blast warning). The security system indi-
cator continues to blink during this time.
NOTE:
If you set the full blast warning sensitivity
higher than the pre-warning sensitivity in
the setting mode of the information display,
or the vehicle feels such shock as to be
able to trigger the full blast warning, the full
blast warning will be triggered preferen-
tially. In this case, the pre-warning will not
be triggered.

2-9
BEFORE DRIVING
56RH0-74E
Theft deterrent light
(if equipped)
56RH00220
This light will blink with the ignition switch
in “LOCK” or “ACC” position. The blinking
light is intended to deter theft by leading
others to believe that the vehicle is
equipped with a security system.
Windows
Manual window control
(if equipped)
60G010A
Raise or lower the door windows by turning
the handle located on the door panel.
Mirrors
Inside rearview mirror
74LHT0235
You can adjust the inside rearview mirror
by hand so as to see the rear of your vehi-
cle in the mirror. To adjust the mirror, move
the mirror up, down or side ways by hand
to obtain the best view.
EXAMPLE
EXAMPLE
WARNING
Failure to observe following point
may result in loss of vehicle control
and cause an accident, leading to
death or serious injury. Always follow
below points while driving.
• Do not adjust the mirrors while driv-
ing.
• Always unfold all the outside rear-
view mirrors and adjust properly
before driving.
• Do not place objects in the rear of the
vehicle which may hinder visibility or
interfere with your vision from the
rear window glass.
EXAMPLE

2-10
BEFORE DRIVING
56RH0-74E
Outside rearview mirrors
52RM20120
Adjust the outside rearview mirrors so you
can just see the side of your vehicle in the
mirrors.
Front seats
Precaution for front passenger seat
Refer to the NOTICE in the “Front passen-
ger’s seat belt reminder” section.
Seat adjustment
CAUTION
Do not modify the inside rearview
mirror or install a non-genuine wide
mirror. it could result in injury during
accident.
EXAMPLE
WARNING
Be careful when judging the size or
distance of a vehicle or other object
seen in the side convex mirror. Be
aware that objects look smaller and
appear farther away than when seen
in a flat mirror.
WARNING
Never attempt to adjust the driver’s
seat or seatback while driving. The
seat or seatback could move unex-
pectedly, causing loss of control.
Check that the driver’s seat and seat-
back are properly adjusted before
you start driving.
WARNING
• To avoid excessive seat belt slack,
which reduces the effectiveness of
the seat belts as a safety device,
check that the seats are adjusted
before the seat belts are fastened.
• Do not leave cigarette lighters or
spray cans on the floor. If a ciga-
rette lighter or spray can is on the
floor, it may light accidentally when
luggage is loaded or the seat is
adjusted, causing a fire.
• All seatbacks should always be in
an upright position when driving,
or seat belt effectiveness may be
reduced. Seat belts are designed to
offer maximum protection when
seatbacks are in the upright posi-
tion.
• Do not place any object under the
front seat. If an object gets stuck
under the front seat, the seat shall
not be latched properly and may
cause injury.
NOTICE
Do not rest your feet on the seat
adjustment lever or push it down.
This may affect the performance of
the seat adjusters.

2-11
BEFORE DRIVING
56RH0-74E
Adjusting Seat Position
74LM02015
The adjustment lever for each front seat is
located under the front of the seat. To
adjust the seat position, pull up on the
adjustment lever and slide the seat forward
or rearward.
After adjustment, try to move the seat for-
ward and rearward to ensure that it is
securely latched.
If the driver’s seat is equipped with a seat
height adjuster lever on the outboard side
of the seat, raise or lower the seat by pull-
ing up or down the adjuster lever.
Adjusting Seatbacks
74LM02016
To adjust the seatback angle of front seats,
pull up the lever on the outboard side of
the seat, move the seatback to the desired
position, and release the lever to lock the
seatback in place.
NOTE:
To operate the seat back smoothly, pull the
seat back adjustment lever (2) in upward
direction. Ensure to move seat back only
after lever is moved to fully up position.
After adjustment of seat back, release the
lever gently. Check that seat back is locked
by moving it forward and backward.
Head restraints (Adjustable type)
(if equipped)
80J001
Head restraints are designed to help
reduce the risk of neck injuries in the case
of an accident. Adjust the head restraint to
the position which places the center of the
head restraint closest to the top of your
ears. If this is not possible for very tall pas-
sengers, adjust the head restraint as high
as possible.
WARNING
All seatbacks should always be in an
upright position when driving, or seat
belt effectiveness may be reduced.
Seat belts are designed to offer maxi-
mum protection when seatbacks are
in the upright position.
EXAMPLE
EXAMPLE
WARNING
• Never drive the vehicle with the
head restraints removed.
• Do not attempt to adjust the head
restraint while driving.
EXAMPLE

2-12
BEFORE DRIVING
56RH0-74E
NOTE:
It may be necessary to recline the seat-
back to provide enough overhead clear-
ance to remove the head restraint.
Front
75RM004
To raise the front head restraint, pull
upward the head restraint until it clicks. To
lower the head restraint, push down the
head restraint while holding in the lock
lever. If a head restraint must be removed
(for cleaning, replacement, etc.), push in
the lock lever and pull the head restraint all
the way out.
Seat belts and child restraint
systems
65D231S
65D606
EXAMPLE WARNING
• Wear your seat belts at all times.
• An air bag supplements or adds to
the frontal crash protection offered
by seat belts. The driver and all
passengers must be properly
restrained by wearing seat belts at
all times even if driving for a very
short distance, whether or not an
air bag is mounted at their seating
position, to minimize the risk of
severe injury or death in the event
of a crash.
(Continued)
EXAMPLE
WARNING
(Continued)
• Do not modify, remove, disassem-
ble seat belts. Doing so may pre-
vent them from functioning
properly and cause the risk of
severe injury or death in the event
of a collision.
WARNING
• Never allow persons to ride in the
cargo area of a vehicle. In the event
of an accident, there is a much
greater risk of injury for persons
who are not riding in a seat with
their seat belt securely fastened.
(Continued)
Above the pelvis
EXAMPLE

2-13
BEFORE DRIVING
56RH0-74E
65D201
65D199
WARNING
(Continued)
• Ensure that all seat belts are worn
correctly. An improperly worn seat
belt increases the risk of injury or
death if a collision occurs.
• Seat belts should always be
adjusted as follows:
– the lap portion of the belt should
be worn low across the pelvis,
not across the waist.
– the shoulder straps should be
worn on the outside shoulder
only, and never under the arm.
– the shoulder straps should be
away from your face and neck,
but not falling off your shoulder.
(Continued)
Across the pelvis
EXAMPLE
WARNING
(Continued)
• Seat belts should never be worn
with the straps twisted and should
be adjusted as tightly as is com-
fortable to provide the protection
for which they have been designed.
A slack belt will provide less pro-
tection than a snug belt.
• Check that seat belt latch plate
(tongue) is inserted into the proper
buckle especially in the rear seats.
It is not possible to insert into the
wrong buckles in the rear seats.
(Continued)
as low as possible
across the hips
EXAMPLE
WARNING
(Continued)
• Pregnant women should use seat
belts, although specific recommen-
dations about driving should be
made by the woman’s medical advi-
sor. Remember that the lap portion
of the belt should be worn as low
as possible across the hips, as
shown in the illustration.
• Do not wear seat belts over hard,
fragile, or sharp items such as
pens, keys, eyeglasses, etc. in
pockets or on clothing. The pres-
sure from seat belt on such items
can cause injury in case of an acci-
dent.
• Never use the same seat belt for
more than one occupant and never
attach a seat belt over an infant or
child being held on an occupant’s
lap. Such seat belt use could cause
serious injury in the event of an
accident.
(Continued)
