MasterCraft 5268 User manual

IMPORTANT:
Read and understand this instruction manual
thoroughly before using the product.
20V max* LITHIUM-ION
CORDLESS DRILL/DRIVER
INSTRUCTION
MANUAL
054-1332-6

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
3
TABLE OF CONTENTS
Technical Specifications 4
Safety Guidelines 5
Key Parts Diagram 12
Operating Instructions 13
Maintenance 21
Troubleshooting 23
Parts List 24
Warranty 25
NOTE:
If any parts are missing or damaged, or if you have any questions,
please call our toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
• This manual contains important safety and operating instructions. Read all
instructions and follow them with use of this product.
TABLE OF CONTENTS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-1332-6 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Cordless Drill/Driver Model 5268
Rated Voltage 20 V d.c.
Chuck 3/8” (10 mm) keyless chuck
No-Load Speed 0–600 RPM
Max. Torque 115 in-lb
Clutch 23 + 1 positions
Cordless Drill/Driver Weight (Without Battery) 1 lb 12 oz (0.8 kg)
Battery Type Lithium-Ion
Battery Voltage 20 Volt max* DC
Charger Input 120 Volts, 60 Hz AC only
Optimum Charging Temperature Range 5–40°C (41–104°F)
*Maximum battery voltage without workload; with workload nominal voltage is 18V.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
5
SAFETY GUIDELINES:
WARNING!
Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do not,
by themselves, eliminate any danger, nor are they substitutes for proper accident prevention
measures.
WARNING!
This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.
KNOW YOUR TOOL
To operate this tool, carefully read this Instruction Manual and all labels affixed to the Cordless Drill/Driver
before using it. Keep this Instruction Manual available for future reference.
IMPORTANT
This tool should only be serviced by a qualified service technician. For more information, call the
toll-free helpline at 1-800-689-9928.
READ ALL INSTRUCTIONS THOROUGHLY
SAVE THESE INSTRUCTIONS
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and specifications provided with
this power tool. Failure to follow all instructions listed below may result in electric shock,
fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks, which may ignite the dust or
fumes.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
6
model no. 054-1332-6 | contact us 1-800-689-9928
• Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground-fault circuit
interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol
or medication. A moment of inattention while operating power tools may result in serious personal
injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energising power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing
away from moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
7
• Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe injury
within a fraction of a second.
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or remove the battery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are
caused by poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories, and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result in a
hazardous situation.
• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
• Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
8
model no. 054-1332-6 | contact us 1-800-689-9928
• Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130 °C (265 °F) may cause explosion.
• Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
SERVICE
• Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service providers.
DRILL SAFETY WARNINGS
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
• Hold the power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory or fasteners may contact hidden wiring or its own cord.
Cutting accessory or fasteners contacting a “live” wire may make exposed metal parts of the
power tool “live” and could give the operator an electric shock.
SAFETY INSTRUCTIONS WHEN USING LONG DRILL BITS
• Never operate at higher speed than the maximum speed rating of the drill bit. At higher
speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece,
resulting in personal injury.
• Always start drilling at low speed and with the bit tip in contact with the workpiece. At
higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece,
resulting in personal injury.
• Apply pressure only in direct line with the bit and do not apply excessive pressure. Bits
can bend causing breakage or loss of control, resulting in personal injury.
ADDITIONAL SAFETY GUIDELINES FOR CORDLESS DRILL/DRIVER
• When working with the power tool, always hold it firmly with both hands and provide
for a secure stance. The power tool is guided more securely with both hands.
• Keep the cord and charger from heat to prevent damage to the housing or internal parts.
• Secure the workpiece. Clamping devices or a vise are more effective than your hand for holding the
workpiece in place.
• Do not allow gasoline, oils, petroleum-based products, etc. to come in contact with
plastic parts. These materials contain chemicals that can damage, weaken, or destroy plastic.
• Always wait until the machine has come to a complete stop before placing it down.
The tool insert can jam and lead to loss of control of the power tool.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
9
• Before performing any kind of work on the machine (e.g., maintenance, tool change,
etc.) as well as when transporting and storing it, always set the direction-of-rotation
switch to the centre (locked) position. Unintentional activation of the On/Off switch may result
in personal injury.
• Do not open the battery. There is risk of a short circuit.
• Protect the battery from heat and fire. There is risk of explosion.
• Wear ear protectors when using the drill/driver. Exposure to noise can cause hearing loss.
• Use protective gloves when removing the bit from the tool, or first allow the bit to cool
down. The bit may be hot after prolonged use.
• Use protective gloves when operating the tool. Protective gloves can help to keep youfrom
being burnt and hurt.
• Keep your hands away from the motor-housing vents. Hot gas comes from the vents
during operation.
• Release the trigger immediately when a screw is tightened to avoid breaking the screw.
• For best results, your battery and tool should be charged, used and stored in a location
where the temperature is more than 5°C (41°F) but less than 40°C (104°F). Do not store
outside or in vehicles.
• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V ..................... Volts
A ..................... Amperes
Hz ................... Hertz
W .................... Watts
min ................. Minutes
................. Alternating current
or d.c .............. Direct current
n0 ................... No-load speed
............... Class II Construction
…/min ........... Revolutions or reciprocation per minute
............... Grounding terminal
RPM ............... Revolutions per minute
.............. WARNING – To reduce the risk of injury, user must read instruction manual.
.............. WARNING – To reduce the risk of injury always wear eye protection.
.............. WARNING – To reduce the risk of injury always wear ear protection.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
10
model no. 054-1332-6 | contact us 1-800-689-9928
SAFETY GUIDELINES FOR CHARGER
WARNING!
Read and understand all instructions. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious personal injury.
WARNING!
To reduce the risk of electric shock or damage to the charger and battery, use only the
batteries and charger listed.
BATTERY PACK CHARGER
054-3124-0
054-7553-4
054-7557-6
054-2434-8
5331,054-3126-6,054-7559-2
• Before using the battery charger, read all instructions and cautionary markings in this
Instruction Manual, on the battery charger, the battery and the product using the battery to
prevent misuse of the products and possible injury or damage.
• Do not use the charger outdoors or expose it to wet or damp conditions. Water entering
the charger will increase the risk of electric shock.
• Use of an attachment not recommended and sold by the battery charger manufacturer
may result in a risk of fire, electric shock or personal injury. Following this rule will reduce
the risk of electric shock, fire or serious personal injury.
• Do not abuse the cord or charger. Never use the cord to carry the charger. Do not pull the charger
cord rather than the plug when disconnecting the plug from the receptacle. Damage to the cord or
charger could occur and create an electric shock hazard. Replace damaged cords immediately.
• Make sure that the cord is located so that it will not be stepped on, tripped over, come
in contact with sharp edges or moving parts or otherwise be subjected to damage or
stress. This will reduce the risk of accidental falls, which could cause injury and damage to the
cord, which could result in electric shock.
• Keep the cord and charger from heat to prevent damage to the housing or internal
parts.
• Do not let gasoline, oils, petroleum-based products, etc. come in contact with plastic
parts. They contain chemicals that can damage, weaken or destroy plastic.
• An extension cord should not be used unless absolutely necessary. Use of an improper
extension cord could result in a risk of fire and electric shock. If an extension cord must be used,
make sure that:
• The pins on the plug of the extension cord are the same number, size and shape as the those
of the plug on the charger.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
11
• The extension cord is properly wired and in good electrical condition.
• The wire size is large enough for the AC ampere rating of the charger as specified below:
Cord Length (Feet) 25’ 50’ 100’
Cord Size (AWG) 16 16 16
NOTE: AWG = American Wire Gauge
• Do not operate the charger with a damaged cord or plug, which could cause shorting
and electric shock. If damaged, have the charger repaired or replaced by a qualified service
technician.
• Do not operate the charger if it has received a sharp blow, been dropped or otherwise
damaged in any way. Take it to a qualified service technician for an electrical check to
determine if the charger is in good working order.
• Do not disassemble the charger. Take it to a qualified service technician when service or
repair is required. Incorrect reassembly may result in a risk of electric shock or fire.
• Unplug the charger from outlet before attempting any maintenance or cleaning to
reduce the risk of electric shock.
• Disconnect the charger from the power supply when it is not in use. This will reduce the
risk of electric shock or damage to the charger if metal items should fall into the opening. It will
also help prevent damage to the charger during a power surge.
• Risk of electric shock. Do not touch the uninsulated portion of the output connector or the
uninsulated battery terminal.
• Save these instructions. Refer to them frequently and use them to instruct others who may use this tool.
If you lend this tool to someone, also lend these instructions to prevent misuse of the product and possible
injury.
SAFETY GUIDELINES

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-1332-6 | contact us 1-800-689-9928
12
PACKAGE CONTENTS:
Cordless Drill/Driver, Battery Pack, Charger, 2 double-ended bits, Instruction Manual.
KEY PARTS DIAGRAM
1
2
3
4
5
7 6 8
No. Description No. Description
1 Keyless Chuck 5 Direction-of-Rotation Selector
2 Torque-Adjustment Ring 6 LED Charger Indicator
3 Trigger Switch 7 Bit Clip
4 Battery-Release Button 8 Charger Base
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the following operating instructions carefully
before using.
•
WARNING!
• Remove the Cordless Drill/Driver from the package, and examine it carefully. Do not discard the carton or any packaging
material until all parts have been examined.
• If any part of the Cordless Drill/Driver is missing or damaged, do not attach the battery pack to the tool or use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious injury.
• Do not allow familiarity with the Cordless Drill/Driver to cause a lack of alertness. A fraction of a second of carelessness is
enough to cause severe injury.
FPO
KEY PARTS DIAGRAM

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
13
OPERATING INSTRUCTIONS
KNOW YOUR LITHIUM-ION RECHARGEABLE BATTERY
80-100% Charge
60-79% Charge
40-59% Charge
20-39% Charge
Under 20% Charge
Completely Discharged
Fuel gauge
This Lithium-Ion battery pack is equipped with a Fuel Gauge, which displays the remaining charge of
the battery pack. Press the Fuel Gauge button to display the LED lights. The LED lights will stay lit for
approximately 4 seconds.
LOW CAPACITY WARNING
If one LED on the Fuel Gauge begins to flash, the battery pack’s charge is under 20% capacity and
should be recharged.
Unlike other battery pack types, Lithium-Ion battery packs deliver fade-free power for their entire run time.
The tool will not experience a slow, gradual loss of power as you work. To signal that the battery pack is
at the end of its run time and needs to be charged, power to the tool will drop quickly. The Fuel Gauge will
begin to display four flashing LED lights when it is completely discharged. When this happens, remove the
tool from the workpiece, remove the battery pack and charge the battery pack as needed.
BATTERY PROTECTION
To protect the battery from damage and prolong its life, the battery pack circuitry will turn off the
battery pack if it becomes overloaded or if the temperature becomes too high during use. This may
happen in extremely high torque, binding and stalling situations. The battery pack will begin normal
operation when it cools down. The Fuel Gauge will display four flashing LED lights if the circuitry
detects a momentary overload. You can conveniently reset the battery pack by releasing the power tool
trigger switch. Press the Fuel Gauge button again to display the remaining charge.
OPERATING INSTRUCTIONS
NOTE:
• The Fuel Gauge can be used when the battery pack is attached to or removed from the tool.
• A significantly reduced run time after fully charging the battery pack indicates that the battery pack is near the end of its
usable life and must be replaced.
• If the Fuel Gauge continues to flash four LED lights after reset, place the battery pack on the charger to evaluate the battery
pack condition.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
14
model no. 054-1332-6 | contact us 1-800-689-9928
COLD WEATHER OPERATION
When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself. Put the
battery pack on the tool and use the tool in a light application. After about a minute, the battery pack
will have warmed itself and will operate normally.
WHEN TO CHARGE THE BATTERY PACK
The Lithium-Ion battery can be charged at any time and will not develop a “memory” when charged
after only a partial discharge. It is not necessary to run down the battery pack charge before
recharging. Remove the battery pack from the tool when it is convenient for you and your job.
1. Use the Fuel Gauge to determine when you need to recharge the battery pack.
2. You can “top-off” your battery pack’s charge before starting a big job or long period of use.
3. Due to Lithium-Ion’s fade-free properties, the only time it is necessary to charge the Lithium- Ion battery pack
is when the pack has reached the end of its charge. To signal the end of charge, power to the tool will drop
quickly. Charge the battery pack as needed.
HOW TO CHARGE THE BATTERY
PACK
(fig 1)
1. Charge the Lithium-Ion battery pack with the correct
charger.
2. Align the raised electric contacts on the charging
base with the corresponding slots in the battery
pack, and slide the charging base onto the battery
pack (fig 1).
3. Connect the charger to a power supply.
4. The charger will communicate with the battery pack’s circuitry to evaluate the condition of the battery
pack.
5. The Fuel Gauge LED lights will cycle from right to left during charging. This is part of the normal charging
operation.
6. After charging is complete, the green LED on the charger will be on and the Fuel Gauge LED lights will
turn off. The Fuel Gauge LED lights will not be displayed when the Fuel Gauge button is pressed while the
battery pack is on the charger.
7. The battery pack will fully charge, but will not overcharge, if left on the charger.
OPERATING INSTRUCTIONS
fig 1
NOTE: This Lithium-Ion battery pack is shipped partially charged. Before using it the first time, fully charge the battery pack.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
15
LED INDICATOR ON CHARGER
LED Indicator Battery Pack
Status
Red
LED
Green
LED Explanation
HI/LO TEMP.
(SEE MANUAL) Hot/Cold battery ON ------- Charging will begin when battery
returns to 5°C (41°F)–40°C (104°F)
DEFECTIVE
BATTERY Defective Flashing -------- Battery pack is defective
BATTERY
CHARGING Charging -------- Flashing Charging
BATTERY
FULL Fully charged -------- ON Charging is complete
TO ATTACH BATTERY PACK
(fig 2)
1. Lock the trigger switch on the drill/driver by placing
the direction-of-rotation
(forward/centre-lock/reverse) selector in the centre
position.
2. Align the raised portion on the battery pack with the
groove on the bottom of the drill/driver, and then
attach the battery pack to the drill/driver as shown.
3. Make sure that the latch on the battery pack snaps
into place and that the battery pack is secured to
the drill/driver before beginning operation.
TO DETACH BATTERY PACK
(fig 2)
1. Lock the trigger switch on the drill/driver by placing the direction-of-rotation selector
(forward/centre-lock/reverse) in the centre position.
2. Depress the battery-release button located on the front of the battery pack to release the battery pack.
3. Pull forward on the battery pack to remove it from the drill/driver.
fig 2
CAUTION!
• Avoid the possibility of accidental starting. Always take care not to activate the trigger switch when you are
attaching the battery pack or performing other adjustments to the tool.
• Avoid the possibility of accidental starting. Always take care not to activate the trigger switch when you are
detaching the battery pack or performing other adjustments to the tool.
FPO
NOTICE: When placing a battery pack on the tool, be sure that the raised rib on the battery pack aligns with the groove on the
cordless drill/driver and the latches snap into place properly. Improper assembly of the battery pack can cause damage to internal
components.
OPERATING INSTRUCTIONS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
16
model no. 054-1332-6 | contact us 1-800-689-9928
TRIGGER SWITCH
(fig 3)
To turn the drill/driver ON, depress the trigger switch.
To turn it OFF, release the trigger switch.
VARIABLE SPEED
(fig 3)
The variable-speed trigger switch delivers higher
speed with increased trigger pressure and lower speed
with decreased trigger pressure.
DIRECTION-OF-ROTATION SELECTOR
(FORWARD/CENTRE-LOCK REVERSE)
(fig 4)
The direction of rotation of the bit is reversible and is
controlled with the direction-of-rotation selector located
above the trigger switch. With the drill/driver held in
normal operating position:
Position the direction-of-rotation selector to the left of
the tool for forward rotation.
Position the direction-of-rotation selector to the right of the tool for reverse rotation.
Position the direction-of-rotation selector in the centre to lock the tool off.
ELECTRIC BRAKE
To stop the tool, release the trigger switch and allow the keyless chuck to come to a complete stop.
The electric brake quickly stops rotation. This feature engages automatically when you release the
trigger switch.
OPERATING INSTRUCTIONS
fig 3
Direction-
of-Rotation
Selector
Variable
Speed
Trigger
Switch
NOTE:
• To prevent gear damage, always allow the drill/driver to come to a complete stop before changing the direction of rotation.
• The drill/driver will not run unless the direction-of-rotation selector is engaged fully to the left or right.
fig 4
Forward Reverse

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
17
KEYLESS CHUCK
(fig 5)
The arrows on the keyless chuck indicate the
direction of rotation of the body of the chuck to GRIP
(tighten) or OPEN (release) the jaws of the chuck on
the drill/driver bit.
ADJUSTABLE TORQUE CLUTCH
(fig 6)
The torque clutch can be adjusted to any of 24
different settings. The higher the torque setting, the
more force the cordless drill/driver produces to turn
an object.
When using the cordless drill/driver for driving
applications, it is necessary to increase or decrease
the torque to help prevent damage to screw heads,
threads, workpiece, etc.
Adjust the torque by rotating the torque-adjustment
ring. The proper setting depends on the job and the type of bit, fastener, and material you will be using.
In general, use greater torque for larger screws, but if the torque is too high, the screws may be
damaged or broken. For delicate operations, such as removing a partially stripped screw, use a low
torque setting. For operations such as drilling into hardwood, use a higher torque setting.
fig 6 Torque-Adjustment Ring
Arrow
fig 5 Open
Grip
Keyless
Chuck
CAUTION!
• Do not hold the body of the keyless chuck with one hand while using the power of the drill/driver to tighten
the jaws of the chuck on the drill bit. The body of the keyless chuck could slip in your hand, or your hand
could slip and come into contact with the rotating bit. This could cause an accident and result in serious
personal injury.
FPO
NOTICE: Do not change the torque setting when the tool is running.
OPERATING INSTRUCTIONS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
18
model no. 054-1332-6 | contact us 1-800-689-9928
BIT STORAGE
(fig 7)
When not in use, the bits that are provided with the
cordless drill/driver may be stored on either side of
the cordless drill/driver by snapping the bit into place
in the bit clip.
INSTALLING A BIT
(fig 8a)
1. Lock the trigger switch by placing the direction-of-
rotation selector in the OFF (centre) position.
2. Rotate the chuck in the “OPEN” direction to release
the jaws of the chuck on the bit.
3. Insert the drill bit.
4. Rotate the chuck in the “GRIP” direction to tighten the
jaws of the chuck securely on the bit.
REMOVING A BIT
(fig 8a)
1. Lock the trigger switch by placing the direction-of
rotation selector in the OFF (centre) position.
2. Rotate the chuck in the “OPEN” direction to release
the jaws of the chuck on the bit.
3. Remove the drill bit.
OPERATING INSTRUCTIONS
fig 7 Bit Clip
fig 8a Open
Grip
Keyless
Chuck
fig 8b
WARNING!
• Be sure to insert the drill bit straight into the jaws of the chuck. Do not tighten the jaws of the chuck with the drill bit
inserted at an angle (fig 8b). Doing so could cause the drill bit to be thrown from the drill/driver, which could result in
possible serious personal injury or damage to the chuck.
• Use protective gloves when removing the bit from the tool, or first allow the bit to cool down. The bit may be hot after
prolonged use.
FPO

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
19
GENERAL DRILLING
(fig 9)
1. Use a vise or clamps to secure the material to be
drilled to keep it from turning as the drill
bit rotates.
2. Check the direction-of-rotation selector for the
correct setting (forward or reverse).
3. Hold the cordless drill/driver firmly, and place the bit
at the point to be drilled.
4. Depress the trigger switch to start the cordless drill/
driver.
5. Move the drill bit into the workpiece, applying only
enough pressure to keep the bit cutting.
6. Do not force the cordless drill/driver or apply
sideways pressure to elongate a hole. Allow the tool
to do the work.
7. When drilling hard, smooth surfaces, use a centre
punch to mark the desired location of the hole. This
will prevent the drill bit from slipping off-centre when the hole is started.
8. When drilling metal, use light oil on the drill bit to prevent it from overheating. The oil will prolong the life
of the bit and will increase the drilling efficiency.
9. If the bit jams in the workpiece or if the drill/driver stalls, stop the tool immediately. Reverse the direction of
rotation and gently squeeze the trigger switch to remove the bit from the workpiece. Investigate and correct the
cause of jamming before resuming work.
fig 9
WARNING!
• Always wear safety goggles or safety glasses with side shields during power tool operation or when
blowing dust. If the operation is dusty, also wear a dust mask.
• Be prepared for binding when the bit breaks through the workpiece, because the drill/driver has a tendency
to grab and kick opposite to the direction of rotation, which could cause a loss of control. If the operator is
not prepared, this loss of control could result in serious injury.
FPO
OPERATING INSTRUCTIONS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
20
model no. 054-1332-6 | contact us 1-800-689-9928
DRILLING MODE OPERATION
For drilling in wood, use twist bits, spade bits, power auger bits or hole saws.
1. When drilling “through” holes, place a block of wood behind the workpiece to prevent ragged or splintered
edges on the back side of the hole.
2. Select the desired speed to match the planned operation.
3. Begin drilling at a very low speed to prevent the bit from slipping off the starting point, and then increase
the speed as the drill bit bites into the material.
4. If the drill/driver stalls, it is usually because it is being overloaded. Release the trigger switch immediately,
reverse the direction of rotation and gently squeeze the trigger switch to remove the bit from the workpiece.
Investigate and correct the cause of stalling before resuming work.
5. Keep the motor running when pulling the bit back out of the drilled hole. This will prevent jamming.
For drilling in metal, use high-speed steel twist drill bits.
1. Use light oil on the drill bit to keep it from overheating; the oil will prolong the life of the bit and increase
the drilling action.
2. When drilling a large hole, first use a smaller bit to drill a small pilot hole to prevent the larger bit from
slipping.
3. Select the desired speed to match the planned operation. Begin drilling at a very low speed to prevent
the bit from slipping off the starting point. Maintain a speed and pressure that allows cutting without
overheating the bit.
4. If the drill/driver stalls, it is usually because it is being overloaded. Release the trigger switch immediately,
reverse the direction of rotation and gently squeeze the trigger switch to remove the bit from the workpiece.
Investigate and correct the cause of stalling before resuming work.
5. Keep the motor running when pulling the bit back out of drilled hole.This will prevent jamming.
SCREWDRIVER OPERATION
1. Select the desired speed/torque range to match the planned operation.
2. Attach the desired fastener accessory into the chuck.
3. Make a few practice runs in a scrap piece before working.
OPERATING INSTRUCTIONS
This manual suits for next models
1
Table of contents
Other MasterCraft Drill manuals

MasterCraft
MasterCraft 054-3118-6 User manual

MasterCraft
MasterCraft 5296 User manual

MasterCraft
MasterCraft 054-1343-0 User manual

MasterCraft
MasterCraft M 54-1213 User manual

MasterCraft
MasterCraft 054-1319-0 User manual

MasterCraft
MasterCraft 54-2896-8 User manual

MasterCraft
MasterCraft 054-1209-2 User manual

MasterCraft
MasterCraft TBD User manual

MasterCraft
MasterCraft 054-7520-2 User manual

MasterCraft
MasterCraft 54-2903-2 User manual
