MasterCraft 5296 User manual

1
IMPORTANT:
Read and understand this instruction manual
thoroughly before using the product.
3-IN-1 DRILL/DRIVER
INSTRUCTION
MANUAL
054-7527-8

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
3
TABLE OF CONTENTS
Technical Specifications 4
Safety Guidelines 5
Key Parts Diagram 11
Operating Instructions 12
Maintenance 22
Troubleshooting 23
Parts List 24
Warranty 25
NOTE:
If any parts are missing or damaged, or if you have any questions, please
call our toll-free helpline at 1-800-689-9928.
SAVE THESE INSTRUCTIONS
• This manual contains important safety and operating instructions. Read all
instructions and follow them with use of this product.
TABLE OF CONTENTS

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-7527-8 | contact us 1-800-689-9928
4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rated Voltage 20 V d.c.
No-load Speed 0-400 RPM / 0-1700 RPM
Max. Torque 350 in-lb
Clutch 24, including drill mode
Removable Chucks
1/2” (13 mm) drill chuck
1/4” (6.4 mm) hex-drive removable right-
angle adaptor
Cordless Drill/Driver Weight(without chuck and battery) 2 lb 6 oz (1.08 kg)
*Maximum battery voltage without workload; with workload nominal voltage is 18V.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
5
SAFETY GUIDELINES
SAFETY GUIDELINES:
WARNING!
Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do
not, by themselves, eliminate any danger, nor are they substitutes for proper accident
prevention measures.
WARNING!
This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.
KNOW YOUR TOOL
To operate this tool, carefully read this Instruction Manual and all labels affixed to the cordless drill/
driver before using. Keep this instruction manual available for future reference.
IMPORTANT
This tool should only be serviced by a qualified service technician. For more information, call the toll-
free helpline at 1-800-689-9928.
READ ALL INSTRUCTIONS THOROUGHLY.
SAVE THESE INSTRUCTIONS.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING!
Read all safety warnings, instructions, illustrations and specifications provided
with this power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
6
model no. 054-7527-8 | contact us 1-800-689-9928
SAFETY GUIDELINES
ELECTRICAL SAFETY
• Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adaptor plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
• Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
• Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a ground-fault circuit
interrupter (GFCI) protected supply. Use of an GFCI reduces the risk of electric shock.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs,
alcohol, or medication. A moment of inattention while operating power tools may result in
serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective equipment
such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energising power tools that have the switch on invites accidents.
• Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
• Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe injury
within a fraction of a second.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
7
SAFETY GUIDELINES
POWER TOOL USE AND CARE
• Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or remove the battery pack,
if detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
• Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc., in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could result in a
hazardous situation.
• Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
BATTERY TOOL USE AND CARE
• Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
• Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
8
model no. 054-7527-8 | contact us 1-800-689-9928
SAFETY GUIDELINES
• Do not use a battery pack or tool that is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or tool to fire or excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause explosion.
• Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures
outside the specified range may damage the battery and increase the risk of fire.
SERVICE
• Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed by
the manufacturer or authorized service providers.
DRILL SAFETY WARNINGS
SAFETY INSTRUCTIONS FOR ALL OPERATIONS
• Hold the power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory or fasteners may contact hidden wiring or its own cord.
Cutting accessory or fasteners contacting a “live” wire may make exposed metal parts of the
power tool “live” and could give the operator an electric shock.
SAFETY INSTRUCTIONS WHEN USING LONG DRILL BITS
• Never operate at higher speed than the maximum speed rating of the drill bit. At higher
speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece,
resulting in personal injury.
• Always start drilling at low speed and with the bit tip in contact with the workpiece.
At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the
workpiece, resulting in personal injury.
• Apply pressure only in direct line with the bit and do not apply excessive pressure. Bits
can bend causing breakage or loss of control, resulting in personal injury.
ADDITIONAL SAFETY GUIDELINES FOR CORDLESS DRILL/DRIVER
• When working with the power tool, always hold it firmly with both hands and provide
for a secure stance. The power tool is guided more securely with both hands.
• Secure the workpiece. Clamping devices or a vise will hold the workpiece in place more
effectively than your hand can.
• Do not allow gasoline, oils, petroleum-based products, etc., to come in contact with
plastic parts. These materials contain chemicals that can damage, weaken, or destroy plastic.
• Always wait until the machine has come to a complete stop before placing it down.
The tool insert can jam and lead to loss of control over the power tool.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
9
SAFETY GUIDELINES
• Before performing any kind of work on the machine (e.g., maintenance, tool change,
etc.), or when transporting and storing the tool, always set the direction-of-rotation
switch to the centre (locked) position. Unintentional activation of the On/Off switch may
result in personal injury.
• Do not open the battery. There is a risk of a short circuit.
• Protect the battery from heat and fire. There is a risk of explosion.
• Wear ear protectors when using the drill/driver. Exposure to noise can cause hearing loss.
• Use protective gloves when removing the bit from the tool, or first allow the bit to cool
down. The bit may be hot after prolonged use.
• Use protective gloves when operating the tool. Protective gloves can help to keep you from
being burnt or injured.
• Keep your hands away from the motor-housing vents. Hot gas comes from the vents
during operation.
• Release the trigger immediately when a screw is tightened to avoid breaking the
screw.
WARNING!
To reduce the risk of electric shock or damage to the charger and battery, use only the
Mastercraft®batteries and chargers listed.
BATTERY PACK CHARGER
054-3124-0, 054-7553-4,
054-7557-6, 054-2434-8 054-3126-6, 054-7559-2
• Keep the cord and charger from heat to prevent damage to the housing or internal
parts.
• For best results, your battery tool should be stored and used in a location where the
temperature is more than 5°C (41°F) but less than 40°C (104°F). Do not store outside or
in vehicles.
• The label on your tool may include the following symbols. The symbols and their
definitions are as follows:
V ..................... Volts
A ..................... Amperes
Hz ................... Hertz
W .................... Watts
min ................. Minutes
................. Alternating current

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
10
model no. 054-7527-8 | contact us 1-800-689-9928
SAFETY GUIDELINES
or d.c. .............. Direct current
n0 ................... No-load speed
............... Class II Construction
…/min ........... Revolutions or reciprocation per minute
............... Grounding terminal
RPM ............... Revolutions per minute
.............. WARNING – To reduce the risk of injury, user must read instruction manual.
.............. WARNING – To reduce the risk of injury always wear eye protection.
.............. WARNING – To reduce the risk of injury always wear ear protection.

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
11
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
KEY PARTS DIAGRAM
PACKAGE CONTENTS:
Cordless drill/driver, 1/2” (13 mm) drill chuck, 1/4” (6.4 mm) hex-drive right-angle adaptor, 1 belt clip, 1
bit holder, 2 single-ended screwdriver bits and instruction manual.
KEY PARTS DIAGRAM
1
No. Description No. Description
1 Two-speed gearbox switch 5 Magnet
2 Torque-adjustment ring 6 Direction-of-rotation selector
3 Keyless chuck 7 LED worklight
4 Variable-speed trigger switch 8 Right-angle adaptor
Before attempting to use this tool, become familiar with all of its operating features and safety
requirements. For optimum performance and safety, read the following operating instructions carefully
before using.
1
2
3
8
4
7
5
6

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 054-7527-8 | contact us 1-800-689-9928
12
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
TO ATTACH BATTERY PACK (fig 1)
1. Lock the variable-speed trigger switch on the
cordless drill/driver by placing the direction-of-
rotation selector in the OFF (centre) position.
2. Align the raised portion on the battery pack with
the groove on the bottom of the cordless drill/
driver, and then attach the battery pack to the
cordless drill/driver as shown.
3. Make sure that the latch on the battery pack
snaps into place and that the battery pack is
secured to the cordless drill/driver before beginning operation.
TO DETACH BATTERY PACK (fig 1)
1. Lock the variable-speed trigger switch on the cordless drill/driver by placing the direction-of-
rotation selector in the OFF (centre) position.
2. Depress the battery-release button located on the front of the battery pack to release the battery
pack.
3. Pull forward on the battery pack to remove it from the cordless drill/driver.
NOTICE: When placing a battery pack on the tool, be sure that the raised rib on the battery pack aligns with the groove on the
cordless drill/driver and the latches snap into place properly. Improper assembly of the battery pack can cause damage to internal
components.
WARNING!
• Carefully read the Instruction Manuals for your Mastercraft®Rechargeable Battery (054-3124-0, 054-7553-4,
054-2434-8, 054-7557-6) and Mastercraft®Battery Charger (054-3126-6, 054-7559-2) for safety and operation
instructions.
CAUTION!
• Avoid the possibility of accidental starting. Always take care not to activate the variable-speed trigger switch when you are
attaching or detaching the battery pack or performing other adjustments to the tool.
FPO
fig 1
Battery-release
button
ATTACH
DETACH

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
13
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
OPERATING INSTRUCTIONS
INSTALL THE DRILL CHUCK (fig 2)
1. Set the direction-of-rotation selector in the OFF
(centre) positon.
2. Pull the unlocking ring forward (1) and press the
drill chuck all the way onto the hex chuck of the
drill/driver (2).
3. Release the unlocking ring. Check that the drill
chuck is locked in position.
REMOVE THE DRILL CHUCK (fig 2)
1. Set the direction-of-rotation selector in the OFF (centre) positon.
2. Pull the unlocking ring forward and remove the drill chuck.
INSTALL THE RIGHT-ANGLE ADAPTOR
( fig 3a )
1. Pull the unlocking ring forward (1) and hold the
hex chuck of the right-angle adaptor with your
finger to prevent the hex chuck from rotating.
2. Rotate and press the right-angle adaptor onto the
drill/driver (2).
3. Release your finger while still holding the
unlocking ring, then the right-angle adaptor can
be locked in the required angular position by
rotating the right-angle adaptor.
4. Release the unlocking ring and check that the
right-angle adaptor is locked into the correct
position.
REMOVE THE RIGHT-ANGLE ADAPTOR
( fig 3b )
Pull the unlocking ring forward (1) and remove the
right-angle adaptor from the drill/driver.
1
fig 2
Unlocking
ring
CAUTION!
• Before carrying out any work on the drill/driver, lock the variable-speed trigger switch by placing the
direction-of-rotation selector in the OFF (centre) position.
NOTICE: The right-angle adaptor facilitates working in places which are difficult to access. The right-angle adaptor can be
locked in different 30° angular positions.
FPO
1
2
1
fig 3b
1
2
fig 3a Hex chuck
Unlocking ring

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
14
model no. 054-7527-8 | contact us 1-800-689-9928
INSTALL THE BIT HOLDER (fig 4)
1. Remove the battery from the tool.
2. Align the rib of the bit holder with the hole on the
base of the cordless drill/driver.
3. Insert the screw (included) and tighten the screw
securely with a screwdriver (not included). The bit
holder can be positioned on either side of the tool.
REMOVE THE BIT HOLDER (fig 4)
1. Remove the battery from the tool.
2. Use a screwdriver (not included) to loosen the screw that attaches the bit holder to the cordless
drill/driver.
3. Remove the screw and the bit holder.
INSTALL THE BELT CLIP (fig 5)
1. Remove the battery from the tool.
2. Align the rib of the clip with the hole on the base
of the cordless drill/driver.
3. Insert the screw (included) and tighten the screw
securely with a screwdriver (not included). The
belt clip can be positioned on either side of the
tool.
REMOVE THE BELT CLIP (fig 5)
1. Remove the battery from the tool.
2. Use a screwdriver (not included) to loosen the screw that attaches the belt clip to the cordless drill/
driver.
3. Remove the screw and the belt clip.
TRIGGER SWITCH (fig 6)
To turn the cordless drill/driver on, depress the
variable-speed trigger switch. To turn it off, release
the variable-speed trigger switch.
VARIABLE SPEED (fig 6)
The variable-speed trigger switch delivers higher
speed with increased trigger pressure and lower
speed with decreased trigger pressure.
OPERATING INSTRUCTIONS
fig 4
Screw
fig 6
Direction-of-
rotation selector
Variable-speed
trigger switch
Bit holder
fig 5
Belt clip
Screw

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
15
OPERATING INSTRUCTIONS
DIRECTION-OF-ROTATION SELECTOR
(FORWARD/CENTRE-LOCK/REVERSE)
(fig 7)
The direction of rotation of the bit is reversible and is
controlled with a selector located above the variable-
speed trigger switch. With the cordless drill/driver
held in normal operating position:
Position the direction-of-rotation selector to the left
of the tool for forward rotation.
Position the direction-of-rotation selector to the right
of the tool for reverse rotation.
Position the direction-of-rotation selector in the centre to lock the tool off.
TWO-SPEED GEAR BOX (fig 8)
This cordless drill/driver features a two-speed
gearbox that is designed for drilling or driving at
speed “1” (low speed range) or at speed “2” (high
speed range). A slide switch is located on the top of
the cordless drill/driver to select either low or high
speed.
When using the cordless drill/driver in the low speed
range, the speed will decrease and the cordless drill/
driver will have more power and torque.
When using the cordless drill/driver in the high speed range, the speed will increase and the cordless
drill/driver will have less power and torque.
Use low speed for high power and torque applications, and use high speed for fast drilling applications.
fig 7
Forward Reverse
NOTICE:
• To prevent gear damage, always allow the cordless drill/driver to come to a complete stop before changing the direction of
rotation.
• The cordless drill/driver will not run unless the direction-of-rotation selector is engaged fully to the left or right.
CAUTION!
• Do not change between low speed and high speed while the tool is running. Failure to obey this caution
could result in serious damage to the cordless drill/driver.
FPO
fig 8
Slide switch
Low speed
High speed

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
16
model no. 054-7527-8 | contact us 1-800-689-9928
NOTICE:
• Do not change the torque setting when the tool is running.
• When adjusting the torque ring, make sure that the speed switch is either completely in the low or the high position.
OPERATING INSTRUCTIONS
ADJUSTABLE TORQUE CLUTCH (fig 9)
The torque clutch can be adjusted to any of 24
different settings (23 driving and 1 drilling). The
higher the torque setting, the more force the
cordless drill/driver produces to turn an object in
either low or high rotation speed.
When using the cordless drill/driver for driving
applications, it is necessary to increase or decrease
the torque to help prevent damage to screw heads,
threads, and the workpiece. Adjust the torque by
rotating the torque-adjustment ring. The proper
setting depends on the job and the type of bit, fastener, and material you will be using.
In general, use greater torque for larger screws; but if the torque is too high, the screws may be
damaged or broken. For delicate operations, such as removing a partially stripped screw, use a low
torque setting.
When using the cordless drill/driver for drilling applications, rotate the torque-adjustment ring in the
torque-increased direction until the drilling symbol ( ) aligns with the arrow on the housing.
fig 9 Torque-adjustment ring
Arrow

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
17
OPERATING INSTRUCTIONS
LED WORKLIGHT (fig 10)
The LED worklight, located on the base of the
cordless drill/driver, will illuminate when the
variable-speed trigger switch is depressed, and
will automatically turn off for a brief while after
the variable-speed trigger switch is released. This
provides additional light on the surface of the
workpiece for operation in lower light situations.
ELECTRIC BRAKE
To stop the tool, release the variable-speed trigger
switch and allow the chuck to come to a complete stop. The electric brake quickly stops rotation. This
feature engages automatically when you release the variable-speed trigger switch.
MAGNET ON TOP (fig 11)
The magnet on the top of the cordless drill/driver
allows for convenient temporary storage of screws
and bits.
fig 10
LED
worklight
NOTICE: The worklight is for lighting the immediate work surface and is not intended to be used as a flashlight.
fig 11
Magnet
Bit

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
18
model no. 054-7527-8 | contact us 1-800-689-9928
INSTALL A BIT INTO DRILL CHUCK (fig 12)
1. Lock the variable-speed trigger switch by placing
the direction-of-rotation selector in the OFF
(centre) position.
2. Rotate the chuck in the “UNLOCK” direction to
open the jaws of the chuck.
3. Insert the drill bit.
4. Rotate the chuck in the “LOCK” direction to
tighten the jaws of the chuck securely on the bit.
REMOVE A BIT FROM DRILL CHUCK ( fig 12)
1. Lock the variable-speed trigger switch by placing the direction-of rotation selector in the OFF
(centre) position.
2. Open the jaws of the chuck (rotate in the “UNLOCK” direction.)
3. Remove the drill bit.
WARNING!
• Do not hold the body of the chuck with one hand while using the power of the drill/driver to tighten the jaws of the chuck on
the drill bit. The body of the chuck could slip in your hand, or your hand could slip and come into contact with the rotating
bit. This could cause an accident and result in serious personal injury.
• Be sure to insert the drill bit straight into the jaws of the chuck. Do not tighten the jaws of the chuck with the drill bit inserted
at an angle. Doing so could cause the drill bit to be thrown from the drill/driver, which could result in possibly serious
personal injury or damage to the chuck.
• Use protective gloves when removing the bit from the tool, or first allow the bit to cool down. The bit may be hot after
prolonged use.
FPO
OPERATING INSTRUCTIONS
fig 12 UNLOCKLOCK

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
19
OPERATING INSTRUCTIONS
INSTALL A BIT INTO THE RIGHT-ANGLE
ADAPTOR (fig 13)
1. Lock the variable-speed trigger switch by placing
the direction-of-rotation selector in the OFF
(centre) position.
2. Insert a suitable bit into the hex chuck on the
right-angle adaptor as far as it will go. Then the
bit can be tightened by the magnetic force in the
hex chuck.
REMOVE A BIT FROM THE RIGHT-ANGLE
ADAPTOR (fig 13)
1. Lock the variable-speed trigger switch by placing the direction-of-rotation selector in the OFF
(centre) position.
2. The bit can be easily pulled out from the hex chuck on the right-angle adaptor.
INSTALL A BIT INTO THE DRILL/DRIVER
(fig 14)
1. Lock the variable-speed trigger switch by placing
the direction-of-rotation selector in the OFF
(centre) position.
2. Insert a suitable bit into the hex chuck on the
drill/driver as far as it will go, then the bit can be
tightened.
REMOVE A BIT FROM THE DRILL/DRIVER
(fig 14)
1. Lock the variable-speed trigger switch by placing the direction-of-rotation selector in the OFF
(centre) position.
2. The bit can be easily pulled out from the hex chuck on the drill/driver.
fig 13
Remove
Install
fig 14
Install
Remove

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
20
model no. 054-7527-8 | contact us 1-800-689-9928
OPERATING INSTRUCTIONS
GENERAL DRILLING (fig 15)
1. Check the direction-of-rotation selector for the
correct setting (forward or reverse).
2. Use a vise or clamps to secure the material to
be drilled to keep it from turning as the drill bit
rotates.
3. Hold the cordless drill/driver firmly, and place the
bit at the point to be drilled.
4. Depress the variable-speed trigger switch to
start the cordless drill/driver.
5. Move the drill bit into the workpiece, applying
only enough pressure to keep the bit cutting.
• Do not force the cordless drill/driver or apply
sideways pressure to elongate a hole. Allow the
tool to do the work.
• When drilling hard, smooth surfaces, use a
centre punch to mark the desired location of the hole. This will prevent the drill bit from slipping
off-centre when the hole is started.
• When drilling metal, use light oil on the drill bit to prevent it from overheating. The oil will prolong
the life of the bit and will increase the drilling efficiency.
• If the bit jams in the workpiece or if the drill/driver stalls, stop the tool immediately. Reverse
the direction of rotation and gently squeeze the trigger to remove the bit from the workpiece.
Investigate and correct the cause of jamming before resuming work.
fig 15
WARNING!
• Always wear safety goggles or safety glasses with side shields during power tool operation or when blowing dust. If the
operation is dusty, also wear a dust mask.
• Be prepared for binding when the bit breaks through the workpiece, because the drill/driver will tend to grab and kick
opposite to the direction of rotation, which could cause a loss of control. If the operator is not prepared, this loss of control
could result in serious injury.
FPO
