MasterCraft MSR-15E Guide

SAFETY,
OPERATION
AND
MAINTENANCE
MANUAL
MSR-15E
SCRUBBER
This Unit is intended for commercial user.
READ & FOLLOW
ALL INSTRUCTIONS, WARNINGS &
CAUTIONS BEFORE USING
THIS SCRUBBER
SAVE THESE INSTRUCTION
MSR-15E Manual - Part No 411019 - Printed in USA 08/17/04
PAGE 1
This scrubber will afford you many years of
trouble-free operating satisfaction, provid-
ed it is given proper care. All parts have
passed rigid quality control standards prior
to being assembled to produce the finished
product. Prior to packaging, the scrubber
was again inspected for assurance of flaw-
less assembly.
Your scrubber is protectively packed to
prevent damage in shipment. We recom-
mend that upon delivery, unpack your
scrubber and inspect it for any possible
damage. Only a visual examination will
reveal damage that may have occurred in
transit.
If damage is discovered, immediately notify
the transportation company that delivered
your scrubber. As a shipper, we are unable
to report any claim for damage. You must
originate any claim within 5 days of delivery.
The manufacturer takes no responsibility
for damages caused to property or per-
sons due to improper use of the scrubber.
Operating instructions must always be
available for the operator. The scrubber
may only be operated by persons who have
been fully trained and authorized to use it.
READ ALL
INSTRUCTIONS
BEFORE
OPERATING

IMPORTANT
SAFETY
INSTRUCTION
1) DO NOT leave the electric scrubber
when plugged in. Unplug from outlet when
not in use and before servicing.
2) Turn OFF all controls before unplug-
ging.
3) This is NOT a toy. Close attention is
necessary when used around or near chil-
dren.
4) Use only as described in this safety
manual. Use only manufacturer's recom-
mended attachments and accessories.
5) DO NOT use electric scrubber with
damaged cord or plug. If the scrubber is
not working as it should, because it has
been dropped, damaged, left outdoors or
dropped into water, contact an authorized
service center or the factory.
6) DO NOT pull electric scrubber by the
cord, use cord as a handle, close a door
on cord or pull cord around sharp edges
and corners. DO NOT run scrubber over
cord. Keep the cord away from heated
surfaces.
7) DO NOT unplug the scrubber by pulling
on the cord. To unplug, grasp the plug,
not the cord.
8) DO NOT handle the plug of the electric
scrubber with wet hands.
9) Store scrubber indoors in a dry area.
DO NOT expose to freezing temperatures.
10) DO NOT use this scrubber for dry
vacuuming. This scrubber is not fitted with
a fine dust filter.
11) DO NOT use the scrubber to pick up
flammable or combustible liquids such as
gasoline or use in areas where they may
be present.
12) DO NOT use this scrubber to clean
surfaces that have dust or substances
which are flammable, poisonous, caustic,
or irritants and represents a health hazard.
13) DO NOT use where anesthetics or
oxygen are used.
14) DO NOT use an extension cord unless
absolutely necessary. If an extension cord
is used, then wire size must be #14 or
larger and should not exceed 50 feet in
length. The extension cord must be a
three-wire grounded type.
15) Replace damaged or worn parts
immediately with genuine original equip-
ment parts to maintain safety and to pro-
tect your limited warranty.
16) DO NOT run pump dry. When the
solution tank is empty, turn off the pump.
17) NEVER drive scrubber over steps.
Electrical equipment must be connected
to a properly grounded outlet only. (See
grounded instructions)
PAGE 2
To Avoid Electric Shock, Do Not Expose To Rain
Store Indoors.
When using this equipment basic precautions should
always be followed, including the following:
WARNING:
This scrubber is designed to be safe when
used to per-form cleaning functions as
specified. Should damage occur to electri-
cal parts, the unit should NOT be used
until the damage is repaired by the manu-
facturer or an authorized service center.
This will avoid further damage to the
scrubber or injury to the user.
These instructions are for your protection
and information. PLEASE READ CARE-
FULLY! Failure to follow instructions or
precautions could result in injury or dam-
age to the user and/or the scrubber.
CARE OFTHE
SCRUBBER

Improper use of the grounding plug can result in a risk of electric shock.
GROUNDING
SAFETY
INSTRUCTIONS
Electrical equipment must be grounded. If
it should mal-function or breakdown,
grounding provides a path of least resist-
ance for electrical current to reduce the
risk of electric shock. The scrubber is
equipped with a cord having an equipment-
grounding conductor and grounding plug.
The plug must be inserted into an appropri-
ate outlet that is properly installed and
grounded in accordance with all local
codes and ordinances.
If repair or replacement of the cord or plug
is necessary, DO NOT connect the ground-
ed wire to either flat blade terminal. The
wire with insulation having an outer sur-
face that is green with or without yellow
stripes is the grounding wire.
GROUNDING
METHODS
This electric equipment is for use on a nom-
inal 120 volt circuit, and has a grounded
plug that looks like the plug illustrated in (Fig
A). A temporary adaptor that looks like the
adaptor illustrated in (Fig B & C) may be
used to connect this plug to a 2-pole recep-
tacle as shown in (Fig B) if a properly
grounded outlet is not available.
The temporary adaptor should be used only
until a properly grounded outlet (Fig A) can
be installed by a qualified electrician. The
green color rigid ear, lug or the like extend-
ing from the adaptor must be connected to
a permanent ground such as a properly
grounded outlet box cover. Whenever the
adaptor is used, it must be held in place by
a metal screw (Fig 3).
Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are
in doubt as to whether the outlet is properly grounded.
DO NOT modify the plug provided with the equipment. If it will not fit the outlet,
have a proper outlet installed by a qualified electrician.
Note: In Canada, the use of a temporary adaptor is not permitted
by the Canadian Electrical Code.
DANGER:
WARNING:
PAGE 3

1) This scrubber is designed for wet
cleaning on waterproof surfaces inside
buildings. All other usage is improper.
2) The manufacturer takes no responsibil-
ity for damage due to improper use of the
scrubber. The user takes the entire risk
for damage due to improper use.
3) Following the operating, maintenance
and repair instructions are required.
4) The appropriate accident prevention
rules, as well as other known regulations
for health and safety in operation must be
followed.
5) Any changes to the scrubber will void
the warranty. Any damage that may occur
as a result of those changes will be the
sole responsibility of the owner.
6) Check the suitability of the floor surface
before using the scrubber.
7) Check that the wheels and brushes will
not damage any surface to be cleaned,
especially gymnasium floors.
8) If the scrubber is misused, the manu-
facturer will not be responsible for any
form of warranty.
Operation Safety
1) DO NOT run the brushes when the
scrubber is stationary as it may cause
damage to the surface being cleaned.
2) Tilt scrubber back when moving, espe-
cially over thresholds or sills to prevent
damage to the brushes.
3) When transporting in elevators, there
safety regulations and precautions are to
be respected as well as maximum load
capacity of the elevator.
Chemicals
1) Always consult correct use and safety
precautions as detailed on manufacturers
label. If required, wear appropriate recom-
mended clothing and safety glasses.
2) Only use low foaming and non-flamma-
ble chemicals which do not include haz-
ardous components.
3) DO NOT use flammable, poisonous,
hazardous or explosive chemicals.
OPERATION OF
SCRUBBER
SAFETY &
CHEMICAL
INFORMATION
Type Of Cleaning Chemicals Scrub Brushes/Pads
Daily or weekly cleaning on water- Floor cleaner, degreaser, maintenance Nylon brushes, red, green or white
proof surfaces. cleaner, scented cleaner depending pads depending on condition of floor.
upon the degree of dirt on surface.
Note: Maximum water and chemical temperature is 72° F
WHAT TOUSE WITH SCRUBBER
If you maintain this scrubber properly it will
stay in working order for a long period of
time. Check the unit regularly for any wear
and tear.
1) Check rubber squeegee blades.
2) DO NOT clean scrubber with pressure
washer.
3) When servicing or making repairs use
only genuine original equipment parts.
4) Repairs and service should only be
made by an authorized service center or
the factory.
5) Monthly Maintenance: Check all gas-
kets, tighten loose nuts and bolts.
6) Every (6) months check vacuum motor
carbon brushes, if worn to
3
/ 8 ” length or
less replace.
ROUTINE
MAINTENANCE
PAGE 4

Tank Construction: Rotationally Molded Polyethylene
Scrub Path: 13.5”
Cleaning Direction: Forward/Back
Brush Spread: Two (6.5”)
Squeegee Width: 15”
Solution Capacity: 3.5 Gallons
Recovery Capacity: 4 Gallons
Vacuum Motor: 120 Volt, By-Pass - 850 Watts
Brush Motor: 200 Watts
Brush Speed: 200 RPM
Brush Pressure: 22 Lbs
Water Output: .2 (GPM)
Power Cord: 25 Ft, 3 Wire Grounded
Storage Dimensions: 15” W X 22” L X 16” H
Includes: 6.5” Counter Rotating Scrub Brush
Net Weight: 48 Lbs Net/54 Lbs Shpg
SCRUBBER
FEATURES
Quick Release Brush
Compact Fold-Up Design
Removable Easy Fill Tank
Disc Brushes
Intermittent Solution Lever
Brush/Solution Switch
Cord and Cord Wrap
Adjustable/Folding Handle
Sight Dome
Solution/Recovery
Tank
Handle Grip
Squeegee
Vacuum
Switch
PAGE 5
SCRUBBER
SPECIFICATIONS

1) Prepare the floor surface by sweeping
or vacuuming before using the scrubber.
2) Make sure all the switches are OFF.
3) Select the proper floor brushes or pad
drivers and floor pads for the cleaning
operations.
Handle Height
Adjustment
Handle Angle
Adjustment
4) Adjust the handle to the best position
for comfortable operation.
5) Add the chemical required. Check the
label for dilution rates.
6) Fill a clean bucket with clean water, and
pour it into the solution tank opening,
maximum capacity 3.5 gallons.
Gasket
Short Solution
Hose
Rear Rim
7) Place the solu-
tion hose to the far side of the tank mak-
ing sure the hose is not bent. Place the
dome to the rear rim of the tank and
press the dome gasket gently into the
front rim.
8) Check to make sure the short solution
hose located at the bottom right on the
scrubber is plugged into the female QDC
connector.
9) When using an external cleaning tool
unplug the hoe and plug in the solution
hose to the attachment you are using.
10) Plug-in the power cord, turn on the
vacuum switch,and then the brush switch.
Solution Lever
11) Start cleaning by squeezing the solu-
tion lever and push the scrubber forwards
or backwards.
Squeegee
Lever
12) If the floor is very dirty, turn OFF the
vacuum switch. Using the squeegee lever,
lift the squeegee off the floor. Squeeze the
solution lever to add more cleaning solution
to the floor. Scrub the floor thoroughly.
13) Turn ON the vacuum switch, lower
the squeegee to the floor, and vacuum up
the dirty solution.
14) While cleaning, monitor foam level in
the recovery tank. If heavy foam is build-
ing, pour a quality defoamer into the
recovery tank.
15) Periodically check the solution level in
the tank. NEVER allow brushes or pads to
run dry, otherwise both the pump and the
floor may be damaged.
16) Periodically inspect the squeegee
blades for obstructions (sand, cigarette
butts, paper etc) clear, then continue the
cleaning.
17) Before refilling the solution tank, flush
the recovery tank with clean water.
OPERATING
PROCEDURES
PAGE 6

PAGE 7
DAILY
MAINTENANCE
1) Remove dome cover from the tank and
set it down behind the scrubber.
2) Lift tank by the grip and carry it to a
floor drain or sink.
Drain Plug
3) Remove the drain plug from recovery
tank and empty the tank.
4) Remove solution bladder from tank by
pulling tab on the bladder upwards gently.
5) Once the edge of the bladder comes
over tank rim opening, push the entire
bladder into the tank and remove bladder
through the large opening of the recovery
tank.
6) Empty the solution bladder and rinse
with clean water.
7) Hang up the solution bladder to dry.
8) Flush out the recovery tank with clean
water to remove dirty solution. Drain tank.
9) When replacing the bladder make sure
it fits properly into the recovery tank.
10) The bladder tab must be fitted on the
left side of solution tank opening seen
from the rear operators position.
11) Clean the dome, cover, vacuum hose
and solution hose thoroughly. Make sure
that the solution hose filter is also
cleaned.
12) Clean the scrubber and squeegee
with a damp cloth.
13) Store squeegee in the raised position
to prevent damaging the blades.
14) Rinse brushes or pads with clean
water. To remove brushes or pads, tilt
scrubber back and slightly pull them down-
ward. When replacing make sure they
lock into the grooves.
DO NOT leave solution in the bladder.
After each use thoroughly wash out the bladder.
This will help extend the bladder’s life.
IMPORTANT:

MSR-15E Manual- Part No 411019 - Printed in USA 08/17/04
PAGE 8
TROUBLE
SHOOTING
GUIDE PROBLEM: Scrubber does not run, no power.
Possible Cause Possible Solution
1) Fuses or circuit breakers have tripped. 1) Check and replace fuses or reset
circuit breakers.
PROBLEM: Insufficient vacuuming power.
Possible Cause Possible Cause
1) Debris caught under squeegee blades. 1) Remove debris and wipe blades with
clean cloth.
2) Vacuum hose not connected. 2) Connect hose.
3) Tank cover not properly seated or gasket 3) Reseat tank cover correctly or replace
on the dome cover is damaged. gasket.
4) Filter in tank cover blocked. 4) Clean filter with water.
5) Recovery tank drain plug not properly placed. 5) Check drain plug and replace properly.
PROBLEM: Squeegee not picking up water.
Possible Cause Possible Cause
1) Rubber blades on squeegee dirty or worn-out. 1) Clean or replace blades.
2) Squeegee not in contact with floor. 2) Check blades and replace if necessary.
3) Recovery tank full. 3) Empty recovery tank.
4) Vacuum hose loose or hose is damaged. 4) Reinstall or replace hose.
PROBLEM: Little or no water flow going to brushes.
Possible Cause Possible Cause
1) Solution line blocked. 1) Flush out solution tank and lines
with clean water.
2) Solution tank filter clogged. 2) Unclog filter.
3) Solution tank empty. 3) Refill solution tank.
Before working on the scrubber disconnect power cord.
Service and repairs, should only be performed by an
authorized service center.
CAUTION:
WARNING:
777 South Street P.O. Box 3210, Newburgh, NY 12550-0606
TEL: [phone] [phone]
FAX: [phone] [phone]
Internet Access
www.mastercraftusa.com
techsuppor[email protected]
