Cleanfix RA 330 IBC Instruction Manual

weekly daily
Swiss Made Quality.
before start-upInstruction of use Maintenance
Cleanfix Reinigungssysteme AG - Stettenstrasse
CH-9247 Henau-Uzwil / SG
Tel. [phone]
Fax [phone]
www.cleanfix.com
[email protected]
Service No.
CH 0041 79 357 40 33
D0049 180 500 91 76
A0043 662 85 69 53
Remove the transparent cover
Remove the airfilter and clean it
Reassemble the airfilter
(pay regard to the suction hose adapter)
Remove the fresh water and dirty water
tank, empty and flush the tanks and the
fresh water filter
Remove the brushes and the pad drives
Clean and check them
Clean and check the suction nozzles
regarding abrasion, clean also the machine
Motor protection
switch
What to do if…..
… The machine does not function at all?
Check the charge level of the battery.
Check the battery connection
– is on the socket under tension
– motor protection switch press
… if there is weak or no suction at all?
Are the suction nozzles clean
Does the dirty-water-filter coverfit airtight
/ properly? Is the suction motor running?
Switch on? Suction at nozzle?
… the brushes or drive discs with pads
do not turn?
Check the battery charging level
Check that the disc brushes / pad driver
are well attached
… there is no water supply to the
brushes / floor?
Check that the fresh water filter is clean
Water supply only functions, when the
brush motor runs!
Technical Data
Rated voltage 12 V
...
Capacity fresh water 9 liters
Capacity waste water 11 liters
Brush rotation 240 rpm.
Brush diameter 2 x 170 mm
Number of brushes 2 circular brushes
Working width 330 mm
Suction Width 390 mm
Theoretical capacity 1320 m2/h
Dimension L / W / H 520/400/550 mm
Shipping weight 35,5 kg
Total weight 44,5 kg
Sound pressure level 67 dBA
Acceleration value <2,5 m/s2
Safety class I
Item No. 322-GB - 04/2012
Recharge after each use
Turn off all switches
Before using the ma-
chine the floor must be
clean swept
The machine must be
cleaned with forward
and backward
Battery indicator is blinking
red = Battery almost empty
Battery indicator glows red=
Machine switches off after 20 sec.
Battery indicator
green = Battery is loaded
Operation lever for water and
brush drive constantly pressed. With this machine,
it has to be cleaned by moving forward and backward
Switcher suction motor
Switcher fresh water
and brush motor
RA 330 IBC
simply clean…
red =Battery charge
green = Battery charged
Please use the machine on flat
surfaces and not inclined to
( For safety ).
Tilt the machine back-
wards and ensure that
the brushes and the
suction nozzles are fixed
Fill the fresh water Tank
and the dose cleaning
product with dosing.
After charging
replug device
Adjust the handle bar
at the correct height
(hip level) and tighten
the clamp

RA 330 IBC
Brush
As at: 07/07/15 Time:15:32

RA 330 IBC
Brush
As at: 07/07/15 Time:15:32
Pos. Description Reference
01 Hexagon screw M 6x10 P...471 Z
02 Cable for motor, red 2,5mm2, L=240mm 320.319
03 Motor compl. 320.120
04 DC-motor 12V 146W 320.121
05 320.123
06 Holder for motor 320.114
07 Covering plate 320.233
08 Cylindrical screw M 6x16 P...481 P
09 Chassis 330.111
10 Distance stops P...484 UC
11 Stopp-nut M 8 P...492 H
12 Main belt pulley even 320.155
13 Washer M 6 P...500 Q
14 Countersunk screw M 6x12 P...487 U
15 Washer M 4 P...500 J
16 Ball bearing P...316 D
17 Washer M 4 P...496 D
18 Clafette 4x4x12 P...512 OA
19 Axle 320.142
20 Cable for motor, black 2,5mm2, L=400mm 320.318
21 Washer M 8 P...496 Q
22 Sensor compl. Pos. 19+28 300.368
23 Brush Ø 16,5 320.059
24 Screw M 4x10 P...481 P
25 320.151
26 Poly-V belt 320.125
27 Bearing flange compl. 320.140
28 Safety lock pin 4x30 P...512 Y
29 Threaded pin M 3x4 P...482 Y
30 Spring Ø 1,5 Ø 14x35 P...511 G
31 Washer DIN 125-A M 10 10,5/20/2 P...496 T
32 320.127
33 Ring DIN 472 32/1,2 P...514 K

RA 330 IBC
Front suction nozzle
As at: 07/07/15 Time:15:33

RA 330 IBC
Front suction nozzle
As at: 07/07/15 Time:15:33
Pos. Description Reference
01 Support of squeegee 320.204
02 Suction nozzle compl. 320.421
03 Air canal compl. 320.215
04 Spraying protection 320.312
05 P...204 H
06 Screw DIN 912 M 4x20 P...488 C
07 Washer M 5 5,3/16/2,8 P...500 U
08 P...509 L
09 Bolting 320.255
10 Countersunk allen screw M 5x12 P...480 U
11 Rivet P...485 Y
12 Seal for screw-in-socket 718.914 A
13 Hexagon nut M 6 P...491 MA
14 Washer DIN 125-A M 4 4,4/9/0,8 P...496 D
15 Screw-in-socket 320.170
16 Spray hose 6/4x370 320.254
17 Spray hose 6/4x280 320.253
18 Front air canal 320.217
19 Rear air canal 320.216
20 Tube air canal 320.218
21 Canal 320.214
22 Hose clamp P...206 D

RA 330 IBC
Handle housing
As at: 07/07/15 Time:15:33

RA 330 IBC
Handle housing
As at: 07/07/15 Time:15:33
Pos. Description Reference
01 Cover for handle 300.620
02 Set LED red, green, 2.1V Ø 5 mm P...415
03 Controlling lever 380.267
04 Key switch 950.453
05 Fixing lever 380.262
06 Adjustment 380.259
07 Pin 380.265
08 Lower lever left 320.615
09 Threaded bolt 320.361
10 Support 320.235
11 Bolt 320.282
12 Switch 320.262
13 Spring 320.263
14 Axle 320.362
15 Minifit 12 pol. P...411
16 Tumbler switch white P...231
17 Handle housing assembled and edited 330.612
18 Cable 320.315
19 Cable tightener 380.252
20 PT-screw KA 40x16 P...516 C
21 P...419
22 Screw DIN 912 M5x12 P...488 B
23 Locknut DIN 985 M 5 A2 P...493 G
24 Upper pushbar cpl. 330.600
25 Connection cable VDE 3x1,00 mm2, black 436.790
26 Connection cable SEV 3x1,00 mm2, black 436.791
27 330.618
28 330.092
29 330.610
30 438.805

RA 330 IBC
Magnetic valve-Suction motor
As at: 07/07/15 Time:15:33

RA 330 IBC
Magnetic valve-Suction motor
As at: 07/07/15 Time:15:33
Pos. Description Reference
01 Washer M 6 P...496 K
02 Thermal relay 20A 500.958
03 Protection cap E-T-A 500.957 A
04 Housing 330.055
05 Cable for motor, black 2,5mm2, L=240 mm 320.317
06 Magnetic valve 12V P...265
07 Cable for magnetic valve with connector 320.709
08 Adapter piece 320.145
09 Angle nipple 432.091
10 Angled hose nipple P...541 J
11 Cylindrical screw M 5x6 P...489 C
12 Motor cover 320.164
13 PT-screw KA 40x16 P...516 C
14 Water distribution block 320.166
15 Screw-in socket 320.170
16 Hexagon screw M 6x8 P...472 P
17 Suction motor 12V DC, 175W, up to masch. no. 9209/008,+pos.22+24 order P...882
18 Silicone hose 10/14x300 320.251
19 Silicone hose 10/14x125 320.252
20 Cable for motor, black 2,5mm2, L=400 mm 320.318
21 PT-srew KA 40x18 P...516 G
22 330.056
23 Sealing ring 380.019
24 Motor sealing ring black 330.057
25 Tapping screw 3,5x9,5 P...484 N
26 Fuse carrier Set 330.371
27 Fuse carrier 320.314
28 Fuse ATO 30A P...362 A
29 Hose clamp P...206 D

RA 330 IBC
Tank cover
As at: 07/07/15 Time:15:33

RA 330 IBC
Tank cover
As at: 07/07/15 Time:15:33
Pos. Description Reference
01 Suction hose 475 mm 320.741
02 Hose 570 mm 320.743
03 Cover 320.513
04 Seal for cover 380.554
05 Covering compl. 320.387
06 Clean water tank compl. 330.340
07 Wastewater tank compl. 330.270
08 PT-schrew KA 30x6 P...515 Y
09 Angled fitting 380.552
10 Filter compl. 400.766 A
11 Sleeve for filter 380.556
12 Cover compl. 320.700
13 Filter screen compl. as from maschine no. 9012.001 320.345
14 Valve compl. 320.309
15 320.305
16 320.308
17 320.307
18 320.306
19 330.273
20 330.274

RA 330 IBC
Wheel
As at: 07/07/15 Time:15:33

RA 330 IBC
Wheel
As at: 07/07/15 Time:15:33
Pos. Description Reference
01 Chassis 330.111
02 Wheel axle 330.245
03 Wheel compl. 320.244
04 Round buffer 320.118
06 Countersunk screw M 6x12 P...487 U
07 Hexagon screw M 8x10 P...471 B
08 Lock washer M 8 P...498 G
09 Countersunk screw M 6x20 P...470 X
10 Washer M 6 P...496 L
11 Retaining ring DIN 472 29/1.2 P...499 GA
12 Ball bearing 6000 2RS P...315 K
13 Pulley 320.378
14 Axle 320.162
15 Stop plate 320.161
16 Hexagon screw M 6x10 P...471 Z
17 Washer DIN 9021 M 6 6,4/18/1,6 P...497 H
18 Tension pulley pos.9-17+24 320.375
19 Hexagon socket screw M 4x14 P...486 F
20 Hexagon nut M 8 P...490 E
21 Axle journal 320.134
22 Guide pulley 320.132
23 Washer DIN 9021 M 8 8,4/24/2 P...496 Q
24 Washer DIN 522 M 6 6,4/25/1,8 P...497 Y
25 Security washer DIN 471 10/1,0 P...513 C
26 Guide pulley compl. 320.385
27 PT-srew KA 40x16 P...516 C
28 Washer M 6 18/4,8 P...500 Q
29 Attaching washer DIN 522 M 12 13/30/1,6 P...496 A

RA 330 IBC
Wiring diagram
As at: 07/07/15 Time:15:33

RA 330 IBC
Wiring diagram
As at: 07/07/15 Time:15:33
Pos. Description Reference
BM DC-motor 12V 146W 320.121
F 1 Fuse 1A
F 2 Fuse 30A
S 1 Brush motor switch P...231
S 2 Suction motor switch P...231
S 3 Valve - switch 950.453
SM Suction motor 12V P...878
T 1 Temperature switch 20 A
V 1 Valve P...265

RA 330 IBC
Battery
As at: 07/07/15 Time:15:32

RA 330 IBC
Battery
As at: 07/07/15 Time:15:32
Pos. Description Reference
01 Covering of battery 330.265
02 Battery 12V / 33 Ah 330.091
03 P...484 WA
04 P...485 PA
05 Battery container 330.261
06 PT-srew KA 40x8 P...515 W
07 Electronic with housing 320.371
08 Hexagon screw M 6x12 P...470 R
09 Spring ring M 6 P...498 U
10 Washer M 6 P...496 K
11 320.112
12 320.113
13 Screw DIN 963 M 4x20 P...481 A
14 320.268
15 Angled hose nipple WES 10/R 1/4" P...541 J
16 Valve 320.243
17 Washer M 5 P...496 G
18 O-Ring 16,0x2mm, NBR, 70ShA P...960 P
19 Fuse T1A 5x20 mm P...218 A
20 Valve compl. 320.247
21 320.089
22 Red handle P...358 D
23 Including housing cover machined black 320.371 A
