MasterForce Flexpower 241-0436 User manual

Page 1
241-0436
Right Angle Drill
CAUTION: To Reduce The Risk Of Injury, User Must
Read And Understand Operator’s Manual. Save These
Instructions For Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)
OPERATOR’S MANUAL

Page 2
TABLE OF CONTENTS
Safety Symbols..........................................................Page 2
Safety Instructions .......................................................Page 4
Overview/Specifications ...............................................Pages 7-8
Assembly ..............................................................Page 9
Operation ..............................................................Page 9
Maintenance ...........................................................Page 13
Troubleshooting ........................................................Page 14
Warranty ..............................................................Page 18

Page 2
SAFETY SYMBOLS
Some of these following symbols may be used on this tool. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the tool better and
more safely.
Symbol Name Designation / Explanation
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watts Power
∿Alternating current Type of current
�Direct current Type or characteristic of current
noNo-load speed Rotational speed at no load
lbs Pounds Weight
Class II construction Double insulated construction
.../min Per minute Revolutions, strokes, surface speed
orbits, etc., per minute
Wear safety goggles WARNING: The operation of any
power tool can result in foreign objects
being thrown into your eyes, which can
result in severe eye damage. Before
beginning power tool operation, always
wear safety goggles or safety glasses
with side shields and a full-face shield
when needed. We recommend a Wide
Vision Safety Mask for use over eye-
glasses or standard safety glasses with
side shields. Always use eye protection
which is marked to comply with
ANSI Z87.1.
WARNING: To ensure safety and reliability, all repairs should be performed by a
qualified service technician.

Page 3
Page 3
SAFETY INSTRUCTIONS
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols and the explanations with them deserve your careful attention and understanding.
The symbol warnings do not, by themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures.
WARNING: Be sure to read and understand all safety instructions in this manual,
including all safety alert symbols such as “DANGER,” ”WARNING,” and “CAUTION”
before using this tool. Failure to following all instructions listed below may result in
electric shock, fire, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
DANGER: Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, could
result in minor or moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates a situation that may result in property
damage.
SAVE THESE INSTRUCTIONS!

Page 4
SAFETY INSTRUCTIONS
WARNING: Read all safety
warnings and instructions.Failure to follow
the warnings and instructions may result in
electric shock, fire and / or serious injury.
Save all warnings and instructions for future
reference.
The term power tool in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
WARNING: Risk of fire and
electric shock. Dry location use only. Do
not expose to rain. Risk of injury.
WORK AREA SAFETY
1. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
3. Keep children and bystanders away
while operating a power tool. Distractions
can cause you to lose control.
ELECTRICAL SAFETY
1. Power tool plugs must match the
outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of
electric shock.
2. Avoid body contact with earthed
or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if your
body is earthed or grounded.
3. Do not expose power tools to rain or
wet conditions. Water entering a power tool
will increase the risk of electric shock.
4. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging the
power tool. Keep the cord away from heat,
oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
6. If operating a power tool in a damp
location is unavoidable, use a ground fault
circuit interrupter (GFCI) protected supply.
Use of a GFCI reduces the risk of electric
shock.
PERSONAL SAFETY
1. Stay alert, watch what you are doing
and use common sense when operating a
power tool. Do not use the tool while tired
or under the influence of drugs, alcohol, or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
2. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as a dust mask, non-skid
safety shoes, hard hat, or hearing protection,
used for appropriate conditions, will reduce
personal injuries.
3. Prevent unintentional starting. Ensure
that the switch is in the off-position before
connecting to power source and / or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energizing power tools that have
the switch on invites accidents.

Page 5
SAFETY INSTRUCTIONS
4. Remove any adjusting key or wrench
before turning the power tool on. A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
5. Do not overreach. Keep proper footing
and balance at all times. This enables better
control of the power tool in unexpected
situations.
6. Dress properly. Do not wear loose
clothing or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose
clothes, jewelry or long hair can be caught in
moving parts.
7. If devices are provided for the
connection of dust extraction and
collection facilities, ensure that these are
connected and properly used. Use of these
devices can reduce dust-related hazards.
USE AND CARE OF THE
POWER TOOLS
1. Do not force the power tool. Use the
correct power tool for your application. The
correct power tool will do the job better
and more safely at the rate for which it was
designed.
2. Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
3. Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
tools. Such preventive safety measures
reduce the risk of starting the power tool
accidentally.
4. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
5. Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
7. Use the power tool, accessories,
tool bits etc., in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
BATTERY TOOL USE
AND CARE
1. Recharge only with the charger
specified by the manufacturer. A charger
that is suitable for one type of battery pack
may create a risk of fire when used with
another battery pack.
2. Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
3. When the battery pack is not in use,
keep it away from other metal objects,
such as paper clips, coins, keys, nails,
screws or other small metal objects that
can make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
4. Under abusive conditions, liquid may
be ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, also seek
medical help. Liquid ejected from the battery
may cause irritation or burns.

Page 6
SAFETY INSTRUCTIONS
SERVICE
1. Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
SPECIFIC SAFETY RULES FOR
CORDLESS DRILL/DRIVER
1. Use the tool only with the batteries and
charger listed below:
Battery pack Charger
252-8024
252-8028
252-8029
252-8030
252-8031
252-8032
252-8033
252-8034
252-8025
252-8036
252-8037
252-8044
2. Hold power tools by their insulated
gripping surfaces when performing an
operation where the cutting tool may
contact hidden wiring or its own cord.
Contact with a live wire will make exposed
metal parts of the tool live and shock the
operator.
3. Use protective gloves when removing
the bit from the tool, or first allow the bit
to cool down. The bit may be hot after
prolonged use.
4. Use protective gloves when operating
the tool. Protective gloves can help to keep
you from being burnt and hurt.
5. Always wear safety glasses with side
shields. Everyday glasses have only impact
resistant lenses. They are NOT safety
glasses. Following this rule will reduce the
risk of eye injury.
6. Protect your lungs. Wear a face or dust
mask if the operation is dusty. Following
this rule will reduce the risk of serious
personal injury.
7. Protect your hearing. Wear hearing
protection during extended periods of
operation. Following this rule will reduce the
risk of serious personal injury.
8. Keep your hands away from the motor-
housing vents. Hot gas comes from the
vents during operation.
9. Release the trigger immediately when
the screws are tightened to avoid breaking
the screw.
10. Secure work. Use clamps or a vise to
hold work when practical. It is safer than
using your hand and frees both hands to
operate tool.
11. Know your power tool. Read operator’s
manual carefully. Learn the tool’s applications
and limitations, as well as the specific potential
hazards related to this tool. Following this rule
will reduce the risk of electric shock, fire, or
serious injury.
DANGER: People with electronic
devices, such as pacemakers, should
consult their physician(s) before using
this product. Operation of electrical
equipment in close proximity to a heart
pacemaker could cause interference or
failure of the pacemaker.
WARNING: Some dust created by
power sanding, sawing, grinding, drilling
and other construction activities contains
chemicals known to the state of California
to cause cancer, birth defects or other
reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks and cement
and other masonry products, and
• Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.

Page 7
OVERVIEW
Keyless chuck
LED Worklight
Variable speed
trigger Switch
Bit storage
Direction of
Rotation Selector
(Forward/Center
Lock/ Reverse)
Vents
SPECIFICATIONS
Switch VSR (Variable Speed Reversible)
No Load Speed 0-1050 RPM
Chuck 3/8"single sleeve
Max.torque 150 in. lbs.
Drill Weight (without battery) 2 lbs. 7 oz.

Page 8
OVERVIEW
VARIABLE SPEED
The variable-speed trigger switch
delivers higher speed with increased
pressure and lower speed with decreased
trigger pressure.
KEYLESS CHUCK
The keyless chuck allows you to
hand-tighten or release the drill bit in the
chuck jaws.
FORWARD/CENTER
LOCK/REVERSE
The direction-of-rotation selector located
above the trigger switch changes the
direction of bit rotation. Setting the trigger
switch in the OFF (center lock) position helps
to reduce the possibility of accidental starting
when not in use.
LED WORK LIGHT
Pressing the trigger switch illuminates the
LED worklight, located on the front of the
Right Angle Drill. This feature provides extra
light for increased visibility.
BIT STORAGE
When not in use, bits provided with your drill
can be placed in the storage area located on
the base of the motor housing.
RIGHT ANGLE DESIGN
The drill’s right angle head design allows
you to get into tight work areas for drilling
and driving.

Page 9
ASSEMBLY
OPERATION
WARNING: If any part is broken or
missing, do not attempt to plug in the power
cord or operate the tool until thebroken
or missing part is replaced. Failure to do
so could result inpossible serious injury.
WARNING: Do not attempt
to modify this circular saw or create
accessories not recommended for use
with this saw. Any such alteration or
modification is misuse and could result in
a hazardous condition leading to possible
serious injury.
WARNING: To prevent accidental
starting that could cause serious personal
injury, always remove the battery pack
from the circular when assembling parts.
UNPACKING
This product has been shipped completely
assembled.
1. Carefully remove the tool and any
accessories from the box. Make sure
that all items listed in the packing list
are included.
2. Inspect the tool carefully to make sure
no breakage or damage occurred
during shipping.
3. Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the tool.
CONTENTS
Right angle drill, double ended bit and
Operator’s manual.
TO ATTACH BATTERY
PACK (FIG. 1)
FIG. 1
1. Lock the trigger switch on the drill
by placing the direction of rotation
(forward/center lock/reverse) selector in
center (OFF) position.
2. Align the raised portion on the battery
pack with the grooves on the bottom
of the drill, and then attach the battery
pack to the drill as shown.
3. Make sure that the latch on the battery
pack snaps into place and the battery
pack is secured to the drill before
beginning operation.
TO DETACH BATTERY
PACK (FIG. 1)
1. Lock the trigger switch on the drill
by placing the direction of rotation
(forward/center lock/reverse) selector in
center (OFF) position.
2. Depress the battery release button
located on the front of the battery pack
to release the battery pack.
3. Pull forward on the battery pack to
remove from the tool.
WARNING: Battery tools are always
in operating condition. Therefore, the switch
should always be in the center-lock position
when it is not in use or when carrying it at
your side.

Page 10
DIRECTION-OF-ROTATION
SELECTOR (FORWARD/CENTER
LOCK/REVERSE) (FIG. 2B)
FIG. 2B
FORWARD
REVERSE
The direction of rotation is reversible and is
controlled by a selector located above the
trigger switch. With the drill held in normal
operating position, the direction of rotation
selector should be positioned to the left of
the trigger switch for drilling. The drilling
direction is reversed when the selector is
to the right of the trigger switch. When the
selector is in center position, the trigger
switch is locked.
To stop, release trigger switch and allow the
chuck to come to a complete stop.
NOTICE: To prevent gear damage, always
allow the right angle drill to come to
a complete stop before changing the
direction of rotation.
NOTICE: The right angle drill will not run
unless the direction of rotation selector is
engaged fully to the left or right.
ELECTRIC BRAKE
To stop the right angle drill, release the
trigger switch and allow the tool to come to a
complete stop. The electric brake quickly
stops the chuck rotation. This feature engages
automatically when you release the trigger
switch.
WARNING: when placing battery
pack on the tool, be sure that the raised
rib on battery pack aligns with the groove
on the saw and the latches snap into
place properly. Improper assembly of
the battery pack can cause damage to
internal components.
TRIGGER SWITCH (FIG. 2A)
FIG. 2A
Variable-
speed
Trigger
Switch
Direction
of Rotation
Selector
(Forward/
Center Lock/
Reverse)
To turn the drill ON, depress the trigger
switch. To turn it OFF, release the trigger
switch.
VARIABLE SPEED (FIG. 2A)
The variable-speed trigger switch delivers
higher speed with increased trigger pressure
and lower speed with decreased trigger
pressure.
OPERATION

Page 11
NOTICE: This drill has an electric brake.
When the trigger switch is released, the
chuck stops turning. When the brake is
functioning properly, sparks will be visible
through the vent slots on the housing. This is
normal and is the action of the brake.
KEYLESS CHUCK (FIG. 3)
FIG. 3 UNLOCK (Release)
LOCK (Tighten)
WARNING: Do not hold the chuck
with one hand and use the power of the drill
to tighten the chuck jaws on the drill bit. The
chuck could slip in your hand, or your hand
could slip and come in contact with the
rotating bit. This could cause an accident
resulting in serious personal injury.
The drill has a keyless chuck to tighten or
release drill bits in the chuck jaws. Grasp
and hold the tool with one hand. Rotate the
chuck with your other hand. The arrows on
the chuck indicate which direction to rotate
the chuck body in order to LOCK (tighten) or
UNLOCK (release) the drill bit
OPERATION
LED WORKLIGHT (FIG. 4)
FIG. 4
The LED worklight, located on the front
of the drill; it will illuminate when the
trigger switch is depressed. This provides
additional light on the surface of the work-
piece for operation in lower-light areas. The
LED worklight will turn off when the trigger
switch is released.
INSTALLING BITS (FIG.5)
FIG. 5
UNLOCK (Release)
Drill bits
LOCK (Tighten)
Chuck jaws
1. Lock the trigger switch by placing the
direction of rotation selector in center
(OFF) position.
2. Open or close the chuck jaws to a point
where the opening is slightly larger than
the bit size you intend to use. Also, raise
the front of the drill slightly to keep the
bit from falling out of the chuck jaws.
LED Worklight

Page 12
3. Insert the drill bit straight into the chuck
the full length of the jaws.
4. To tighten: grasp and hold the tool with
one hand, while rotating the chuck with
your other hand.
NOTICE:Rotate the chuck in the direction
of the arrow marked LOCK to tighten the
chuck jaws. Do not use a wrench to tighten
or loosen the chuck jaws.
REMOVING BITS (FIG.5)
1. Lock the trigger switch by placing the
direction of rotation selector in center
position.
2. To loosen the chuck jaw: grasp and hold
the tool with one hand, while rotating
the chuck with your other hand.
NOTICE:Rotating the chuck in the direction
of the arrow marked UNLOCK to loosen
the chuck jaws. Do not use a wrench to
tighten or loosen the chuck jaws.
3. Remove the drill bit from the chuck
jaws.
WARNING: The bit may be hot after
use. Wear protective gloves or wait until the
bit has cooled down before removing the
bit.
WARNING: Make sure to insert the
drill bit straight into the chuck jaws. Do not
insert the drill bit into the chuck jaws at an
angle, and then tighten. This could cause
the drill bit to be ejected from the drill,
resulting in possibly serious personal injury
or damage to the chuck.
BIT STORAGE (FIG. 6)
FIG. 6
When not in use, bits provided with the drill
can be placed in the storage area located on
the base of the drill.
DRILLING (FIG. 7)
FIG. 7
When drilling hard, smooth surfaces, use
a center punch to mark the desired hole
location. This will prevent the drill bit from
slipping off center as the hole is started.
The material to be drilled should be
secured in a vise or with clamps to keep it
from turning as the drill bit rotates. Hold the
tool firmly and place the bit at the point to
be drilled. Depress the trigger switch to start
the tool.
OPERATION

Page 13
OPERATION
MAINTENANCE
Move the drill bit into the workpiece,
applying only enough pressure to keep
the bit cutting. Do not force or apply side
pressure to elongate a hole.
WARNING: Be prepared for binding
at bit breakthrough. When these situations
occur, the drill has a tendency to grab and
kick opposite to the direction of rotation and
could cause loss of control when breaking
through the material. If not prepared, this
loss of control can result in possibly serious
injury.
When drilling metals, use light oil on the drill
bit to keep it from overheating. The oil will
prolong the life of the bit and increase the
drilling action.
If the bit jams in workpiece or if the drill stalls,
release trigger switch immediately. Remove
the bit from the workpiece and determine the
reason for jamming.
WARNING: To avoid serious
personal injury, always remove the battery
pack from the tool when cleaning or
performing any maintenance.
WARNING: When servicing, use
only identical replacement parts. Use of any
other parts may create a hazard or cause
product damage. To ensure safety and
reliability, all repairs should be performed
by a qualified service technician at an
Authorized Service Center.
GENERAL MAINTENANCE
The tool may be cleaned most effectively
with compressed dry air. Always wear
safety goggles when cleaning tools with
compressed air.
Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to
damage from various types of commercial
solvents. Use clean cloths to remove dirt,
dust, oil, grease, etc.
CHUCK REMOVAL (FIG. 8 & 9)
FIG. 8
Mallet
Hex key
Chuck jaws
FIG. 9
Mallet
Chuck jaws Hex key

Page 14
To remove the chuck:
1. Remove the battery.
2. Lock the trigger switch by placing the
direction of rotation selector in the
center (OFF) position.
3. Open the chuck jaws.
4. Use a Philips screwdriver (available
separately) to remove the chuck screw
by turning it clockwise.
NOTICE: The screw has left hand threads.
5. Insert the hex key in chuck and tighten
the chuck jaws securely. Tap sharply
with a mallet in a counterclockwise
direction. This will loosen the chuck on
the spindle. It can now be unscrewed by
hand.
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The Driver does not work Battery is depleted Charge the battery
Bit cannot be installed
Chuck is not sufficiently
open Open the chuck
Bit does not fit the chuck Use the the appropriate bits
Motor overheating Cooling vents are obstructed
Clean, clear vents. Do not
cover with hand during
operation
MAINTENANCE
To retighten a loose chuck
The chuck may become loose on the spindle
and develop a wobble. Periodically check
the chuck screw for tightness.
1. Remove the battery.
2. Lock the trigger switch by placing the
direction of rotation selector in center
position.
3. Open the chuck jaws.
4. Insert the hex key into the chuck and
tighten the chuck jaws securely. Tap
the hex key sharply with a mallet in a
clockwise direction. This will tighten the
chuck on the spindle.
5. Open the chuck jaws and remove the
hex key.
6. Tighten the chuck screw.
NOTICE: The chuck screw has left hand
threads.

Page 15
NOTES

Page 16
NOTES

Page 17
NOTES

Page 18
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
RIGHT ANGLE DRILL
WARRANTY
90-DAY MONEY BACK GUARANTEE:
This MASTERFORCE® brand power tool carries our 90-DAY Money Back
Guarantee. If you are not completely satisfied with your MASTERFORCE® brand
power tool for any reason within ninety (90) days from the date of purchase, return
the tool with your original receipt to any MENARDS® retail store, and we will provide
you a refund – no questions asked.
3-YEAR LIMITED WARRANTY:
This MASTERFORCE® brand power tool carries our famous No Hassle 3-Year
Limited Warranty to the original purchaser. If, during normal use, this
MASTERFORCE® power tool breaks or fails due to a defect in material or
workmanship within three (3) years from the date of original purchase, simply bring
this tool with the original sales receipt back to your nearest MENARDS® retail store.
At its discretion, MASTERFORCE® agrees to have the tool or any defective part(s)
repaired or replaced with the same or similar MASTERFORCE® product or part
free of charge, within the stated warranty period, when returned by the original
purchaser with original sales receipt. Not withstanding the foregoing, this limited
warranty does not cover any damage that has resulted from abuse or misuse of the
Merchandise. This warranty: (1) excludes expendable parts including but not limited
to blades, brushes, belts, bits, light bulbs, and/or batteries; (2) shall be void if this
tool is used for commercial and/or rental purposes; and (3) does not cover any
losses, injuries to persons/property or costs. This warranty does give you specific
legal rights and you may have other rights, which vary from state to state. Be
careful, tools are dangerous if improperly used or maintained. Seller’s employees
are not qualified to advise you on the use of this Merchandise. Any oral
representation(s) made will not be binding on seller or its employees. The rights
under this limited warranty are to the original purchaser of the Merchandise and may
not be transferred to any subsequent owner. This limited warranty is in lieu of all
warranties, expressed or implied including warranties or merchantability and fitness
for a particular purpose. Seller shall not be liable for any special, incidental, or
consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or
able to replace this product or is willing to refund the purchase price as provided
above. For insurance purposes, seller is not allowed to demonstrate any of these
power tools for you.
For questions / comments, technical assistance or repair parts – Please Call Toll
Free at: 1-866-917-4374. (M-F 8am – 6pm EST)

Page 19
09/2014
© 2014 Menard, Inc., Eau Claire, WI 54703
