Matatakitoyo Torque Tools NTP User manual
Main Scale Graduation Scale
Hand Force
Ratchet Lever
GripTube
Lock Ring
Insert square drive securely to the socket.
For example : ITEM NO. NTP-210N
To set torque to 135 Nm. Firstly push down and hold the lock
ring and turn the handle clockwise until the upper edge to 130
Nm (see A) and the reading “5” on the long tube must align
with the center link of scale perpendicularly so as to acquire
130+5=135 Nm. (see B)
0
28
N-M
210
170
130
190
150
200
160
120
180
140
64
N-M
210
170
130
190
150
200
160
120
180
140
0
28
210
170
130
90
50
190
150
110
70
200
160
120
80
40
180
140
100
60
0
28
210
170
130
90
50
190
150
110
70
200
160
120
80
40
180
140
100
60
A
1 2 3
B
0
28
210
170
130
190
150
110
200
160
120
180
140
100
1. Push down the lock ring to unlocked.
2. Turn the adjustable handle Clockwise or
Anti-clockwise (Right or left) to set the desired torque.
3. Pull upper the lock ring to set finished.
Unlock
Lock
Set
1. Study this instruction before use.
2. This torque wrench as calibrated and tested before leaving the factory is certified to meet the current standard specification and has
an accuracy of ±4%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTERNERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Over torque will cause tool damage and personal injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result of losing accuracy and void the warranty.
7. Do not continuously apply force after hear click or feel shock.
8. Do not use any format of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Do not immerse grease inside ratchet head. It may cause unexpected damage.
10. Use special care at minimum torque setting.
11. Please wear gloves and goggles when working.
Position of ratchet lever for clockwise tightening.
right NTP-30N~NTP-350N left For above NTP-500N
BEFORE STARTING
CONTENTS
HOW TO SET TORQUE VALUE
HOW TO USE
1/4” 3/8” 3/4”1/2” 1”
TORQUE
Choose quality socket
ManualSupplied in a plastic box.
Torque wrench
Manual
WARNING
NTP
OPERATION MANUAL
Adjustable Torque Ｗｒｅｎｃｈ
Models covered
MAY 2020
01
Edition
Metric SAE
WH
A
L
ØD2
N-m
L
NTP-30N
NTP-110N
NTP-210N
NTP-350N
NTP-500N
NTP-700N
NTP-980N
NTP-1500N
NTP-2000N
1/4”
3/8”
3/8”
1/2”
1/2”
3/4”
3/4”
3/4”
1”
1”
1”
0.2 Nm
0.5 Nm
1 Nm
1 Nm
2.5 Nm
2.5 Nm
7 Nm
10 Nm
10 Nm
6-30 Nm
20-110 Nm
40-210 Nm
70-350 Nm
100-500 Nm
140-700 Nm
140-980 Nm
300-1500 Nm
400-2000 Nm
0.74
0.96
1.70
2.54
3.66
5.94
6.46
11.58
14
295
380
535
650
860
1090
1230
1745
2176
W
28.2
36.3
46.7
47.5
72.0
72.0
72.0
79.7
79.7
H
20.3
23.6
27.7
33.3
37.3
51.6
51.5
51.5
57.0
66.7
66.7
B
9.0
12.4
12.6
15.2
16.8
23.6
24.0
24.1
28.5
30.6
30.6
20.3
23.6
27.7
33.3
37.3
51.6
51.5
51.5
57.0
66.7
66.7
9.0
12.4
12.6
15.2
16.8
23.6
24.0
24.1
28.5
30.6
30.6
ØD
35.0
35.0
40.0
47.0
47.0
47.0
47.0
40.0
40.0
KG
A
L
NTP-250i
NTP-80F
NTP-150F
NTP-250F
NTP-300F
NTP-600F
NTP-700F
NTP-1000F
NTP-1500F
1/4”
3/8”
3/8”
1/2”
1/2”
3/4”
3/4”
3/4”
1”
1”
1”
1 in.lb
0.5 ft.lb
1 ft.lb
1 ft.lb
2.5 ft.lb
2.5 ft.lb
5 ft.lb
5 ft.lb
5 ft.lb
40-250 in.lb
15-80 ft.lb
30-150 ft.lb
50-250 ft.lb
50-300 ft.lb
100-600 ft.lb
100-700 ft.lb
200-1000 ft.lb
300-1500 ft.lb
0.74
0.96
1.70
2.54
3.66
5.94
6.46
11.58
14
295
380
535
650
860
1090
1230
1745
2176
W
28.2
36.3
46.7
47.5
72.0
72.0
72.0
79.7
79.7
HBØD
35.0
35.0
40.0
47.0
47.0
47.0
47.0
40.0
40.0
KG
A
ITEM NO. Range ITEM NO. Range
Unit : mm
Accuracy : ± 4%
STOP
CLICK
0
28
210
170
130
90
50
190
150
110
70
200
160
120
80
40
180
140
100
60
N-M
C
MAINTENCE AND STORAGE
TORQUE CONVERSION FACTORS
1. Please return torque value to just below lowest reading when not in use. Do not turn below lowest reading. (see c)
2. If this tool has not been used for a period of time, it shall be preloaded several times at its maximum torque setting.
This will allow internal lubricant to recoat.
3.
Clean this tool by wiping with a clean cloth after operation and storage in a dry environment.
Do not dip any type of liquid in this tool. This may damage the internal of this tool.
4. This tool should be recalibrated a period of 12 months, or 5,000 cycles, whichever occurs first.
To contact with local vendor, an authorized repair center for supporting. 1 Years
5000 Times
Units to be
converted
1 mN.m
1 cN.m
1 N.m
1 ozf.in
1 lbf.in
1 lbf.ft
1 gf.cm
1 kgf.cm(kp.cm)
1 kgf.m(kp.m)
1
10
1000
7.062
113
1356
0.098
98.07
9807
0.1
1
100
0.706
11.3
135.6
0.01
9.807
980.7
0.001
0.01
1
0.007
0.113
1.356
0.0001
0.098
9.807
0.142
1.416
141.6
1
16
192
0.014
13.89
1389
0.009
0.088
8.851
0.0625
1
12
0.0009
0.868
86.8
0.0007
0.007
0.738
0.005
0.083
1
0.00007
0.072
7.233
10.2
102
10197
72
1152.1
13826
1
1000
100000
0.01
0.102
10.2
0.072
1.152
13.83
0.001
1
100
0.0001
0.001
0.102
0.0007
0.0115
0.138
0.00001
0.01
1
=mN.m =cN.m =N.m =ozf.in =lbf.in =lbf.ft =gf.cm =kgf.cm
(kp.cm)
=kgf.m
(kp.m)
Corresponding unit
Conversion-formula :
Units to be converted × Factor = Corresponding unit
Example : Convert 5 lbf.ft into cN.m
Solution : 5 × 135.6 = 678 cN.m
SPECIFICATION
Do not continuously apply force after hear click or feel shock.
E-mail:[email protected]om
www.matatakitoyo.com Made in Taiwan
MATATAKITOYO TOOL CO., LTD.
No. 63, Ln. 493, Sec. 3, Zhongshan Rd., Tanzi Dist.,
Taichung City 42754, Taiwan
TEL : 886-4-2533 5893
Manufacturer
This manual suits for next models
