Matrix MFU801 Reference manual

Undercounter freezer
Manual for installation,
use and maintenance
MFU801
parts +1 year labour
year
guarantee
www.matrixappliances.co.uk

2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault
with your appliance and to register your appliance for guarantee
purposes.
Appliance Model
Serial Number
EU Declarations of Conformity
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2014/35/EU and Electromagnetic interference (EMC) 2014/30/EU.
Appliance Model
Serial Number

3
Parts intended to come into contact with food conform to 1935/2004/
EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed of as
urban waste. The refrigeration system contains insulating gases and
refrigerants, which require specialised waste disposal. The valuable
materials contained in this appliance can be recycle. It must be
taken to a special local authority differentiated waste collection
centre or to a dealer providing this service.
Before disposing of an old appliance, remove the door seals, latch or
bolt lock to avoid the risk of child entrapment.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both
energy and resources. As a reminder of the need to dispose of
household appliances separately, the product is marked with a
crossed-out wheeled dustbin.

4
Important
Never store inflammable or explosive items and strong corrosive
acids or alkalis in the appliance.
This is a household appliance, which is produced in accordance
with the national standard. It is intended for food storage only, not for
storage of blood, medicine and biological products.
To prevent risk of fire, keep the appliance away from petrol or any
other inflammables.
To prevent risk of electromagnetic interference or other accidents,
do not place a microwave oven on top of the refrigerator or use any
electric appliance inside the refrigerator.
Do not allow children to play with or near the appliance.
The internal surfaces of the fridge compartment may be very cold
when the appliance is running. Avoid touching, if possible, the
surfaces especially when hands are wet.
Do not splash water onto the appliance. Keep it away from places of
high humidity that may have adverse effect on the electric insulation
performance.
This appliance is designed to be used in ambient temperatures
between 10 and 32˚C. Use outside of this range may cause the
appliance to fail.

5
Before first use
You must allow the freezer to settle for at least twenty four hours
prior to switching the power on.
It is recommended that you clean the interior of the appliance prior
to first use, using a solution of bicarbonate of soda and warm water
and then thoroughly drying the interior.
The freezer may have an odour to it at first use. This will disappear as
the appliance cools.
When first switching the appliance on it is advisable to set the freezer
to setting 3 on the thermostat dial and leaving the freezer to settle for
24 hours before adusting the temperature to the preferred setting.
Please note:
The appliance will work continuously until it comes down to the
correct temperature.
If the appliance is switched off, you should allow five minutes
before switching it on again to prevent unnecessary damage to the
compressor.
Never store inflammable or explosive items and strong corrosive
acids or alkalis in the appliance.
The presence of some frosting within the appliance is not a
malfunction of the freezer.

6
Use
Freezer
• The freezer compartments are designed to store only frozen food.
• Never put hot or warm foods in the freezer, allow them to cool fully
before putting them into the freezer.
• Follow the instructions on the food packaging for storage of frozen
food. If no information is provided, foods should not be stored for
more than three months after the purchase date.
• Store food in small packages (ideally less than 2.5kg). This reduces
the freezing time and improves the quality of the food after thawing.
• Wrap food before putting into the freezer. To stop the wrapping
sticking together, ensure it is dry.
• Label the food before freezing with information including type of
food and dates of storage and expiry.
• Once food is thawed, it must not be refrozen unless it has been
completely cooked. Only defrost as much food as is required, to
prevent wastage.
• Bottled or canned drinks should not be stored in the freezer
compartments as they could explode.
• Check the rating plate to confirm the maximum amount of fresh food
that can be frozen within a 24 hour period.
• Do not attempt to freeze more than the maximum amount.
• To freeze fresh food more quickly, switch the dial to setting 5 a few
hours prior to placing the food in the freezer.

7
Storage and use
This freezer is suitable for storing deep frozen food (food which
has already been frozen before being added to the freezer), for
storing fresh food for a short period (2-3 weeks) by freezing it and for
making ice and ice cream.
Always remember to observe and adhere to the recommended
expiration date of food.
Fresh food, and food which needs to
be stored for a long period, should be
kept at a temperature of -18°c or below.
For this, we recommend using setting 4
or 5.
If food only needs to be stored for a
short period then a setting of 2 or 3 will
suffice.
Please remember: Ice cream or ice
for drinks should be allowed to sit at room temperature for several
minutes before being used as they can still be cold enough to cause
damage to skin and lips.
Please note: The freezer should be defrosted regularly. If you are
unsure of when then it is advisable to do so when, and if, the ice
layer reaches 5mm thickness.
Fig.
Fig. 1

8
Controls
Thermostat dial
The temperature controls for this fridge are simple and consist of a
single thermostat dial (1). To change the temperature, simply turn the
dial left and right to cycle through the available settings. A centrally
located embossed arrowhead indicates the setting. The settings
available range from OFF to 5 with OFF being the ‘Off’ setting and ‘5’
being the coldest.
After changing the temperature setting, the time taken to achieve
the new temperature will depend on how big the change is from the
previous setting.
Switching On and Off
When the fridge is connected to a power supply the power
indicator (2) will illuminate and the freezer will begin cooling unless
the thermostat dial is set to ‘OFF’. To begin cooling, turn the dial to a
setting between 1 and 5. The temperature warning indicator (3) will
illuminate if the interior is not yet cold enough. To switch the appliance
off, turn the dial to setting ‘OFF’. If you are turning the appliance off for
a long time, then switch off the mains power supply also.
OFF
Fig. 2

9
Super freeze function
The freezer is equipped with a super freeze function which causes
the compressor to run continuously. This is intended to be used for
freezing large amounts of produce as quickly as possible. For best
results, switch the function on a few hours before introducing the
items to be frozen. To avoid damage to the system, do not use this
function for more than 24 hours.
To switch the super freeze function on simply press the superfreeze
button (5). The super freeze light (4) should illuminate.
To switch the function off, simply press and hold the super freeze
button (5) for 3 seconds. The super freeze light should extinguish.
Care and cleaning
Always disconnect the appliance from the power supply before
any cleaning or maintenance.
The freezer should be cleaned using a solution of bicarbonate
of soda and lukewarm water. Do not use abrasive products or
detergents. After washing, rinse and dry thoroughly.
Clean the drawers separately by hand with a mild solution of washing
up liquid and water. Do not put them in the dishwasher.
If the appliance is not to be used for prolonged periods of time,
unplug and clean the appliance. The doors should be left slightly
ajar to prevent the formation of mildew and unpleasant odours. It
is important however that you ensure that no child or person could
become trapped in the appliance.

10
Defrosting the freezer
Do not use heaters or defrosting sprays in this appliance.
Never use any metallic or sharp objects such as knives or forks to
remove the ice as this could damage the lining.
The freezer compartment should be defrosted regularly to ensure the
most efficient running of the freezer.
Once the ice is more than 5mm thick, the freezer should be defrosted.
• 24 hours before defrosting the freezer, turn the thermostat dial to
setting 5 or switch on the super freeze function to ensure the frozen
food is fully frozen.
• Before switching off the freezer, wrap the the frozen food in sheets
of paper and store it in a cool place.
• Switch the appliance off at the thermostat dial and the mains and
then remove the freezer drawers.
• To speed up the defrosting process, place a bowl of warm water in
the base of the freezer compartment.
• The freezer should be cleaned using a solution of bicarbonate
of soda and lukewarm water. Do not use abrasive products or
detergents. After washing, rinse and dry thoroughly.
• Clean the drawers separately by hand with a mild solution of
washing up liquid and water. Do not put them in the dishwasher.
• Once cleaning is complete, reconnect the power.

11
Troubleshooting
If you have any problems with your appliance, you should check
the troubleshooting prior to calling CDA Customer Care to prevent
unnecessary service calls and potential cost.
If the appliance is not working, check the following:
• There is power to the appliance.
• The house fuses are intact and the fuse in the plug has not blown.
• The on/off switch is not set to off.
• The plug socket is functioning fine. To check this, plug another
electrical appliance in to see if the socket is faulty.
If the appliance is working, but not very well, check the following:
• The appliance is not overloaded.
• The thermostat is set to an appropriate temperature.
• The doors are closing properly.
• The cooling system at the rear of the appliance is clean and free of
dust, and not touching the rear wall.
• There is enough ventilation at the side and rear walls.
If the appliance is noisy, check the following:
• The appliance is level and stable.
• The side and rear walls are clear, and there is nothing resting on
the appliance.
• Note: The cooling gas in the refrigerator may make a slight bubbling
or gurgling noise, even when the compressor is not running.

12
If there is water in the freezer, check the following:
• The appliance has power and the green power light is on.
• There are no items touching the rear wall of the appliance. If there
are, adjust their position so that they no longer touch it.
• That there is some resistance when opening the door of the
appliance. If it opens at the slightest touch it may mean that the
door seal needs to be replaced.
• Inspect the door seal for any kinks, debris or damage. If you notice
any, and are unable to resolve the issue yourself, contact CDA
Customer Care so that the seal can be replaced.
If excessive ice or frost has formed in the freezer:
• It is normal for some ice and frost to form in the freezer. This does
not constitute a fault with the appliance. If the ice layer is thicker
than 5mm, try defrosting the appliance.
• Ensure that the thermostat is at the position you intend for it to be
and hasn’t been accidentally set to the highest setting. If the
freezer is set to the maximum, try lowering the setting.
• Check that there is some resistance when opening the door of the
appliance. If it opens at the slightest touch it may mean that the
door seal needs to be replaced.
• Check the door seal for any kinks, debris or damage. If you notice
any, and are unable to resolve the issue yourself, contact CDA
Customer Care so that the seal can be replaced.
If the temperature warning light (
!
) is on:
• It may mean that your door seal is defective. Carry out the above
two door seal checks. If the door has been reversed recently,
check page 19. If the problem persists, contact CDA Customer Care.

13
Installation and Ventilation
This appliance must never be installed close to heat sources,
e.g. heating elements, cookers or in damp places.
• To ensure the appliance is level, you should use the height
adjustable feet at the front of the appliance.
• The ventilation system at the bottom of the appliance must not be
blocked.
• Fig. 3 shows the installation requirements for your appliance. All
measurements are in millimetres. Failure to install the appliance
correctly can lead to increased running costs, premature failure
and may invalidate the warranty provided with the appliance.
Fig. 3

14
Mounting the fascia doors
2
1
Fig. 5 - Fitting the decor door bracket
Remove the white decorative cover (Fig. 4) by lifting it upwards.
Obtain the below measurements:
Dimension B= Measure from
the underside surface of
kitchen unit to the bottom of
fixing bracket.
Dimension C= Measure from
the underside surface of
kitchen unit to the top of next
unit door.
Unscrew and remove the
nuts and washers from the top of the
appliance door to remove the bracket.
Fig. 6 - Fitting the decor door bracket
Subtract C from B and put the
fixing bracket (2) in place using this
measurement for vertical position and
place to the centre for horizontal
position. Secure the fixing bracket (2)
using screws(1).
Fig. 7 - Fitting the decor door
Place the decor door onto the
appliance door by inserting adjustment
bolts into the slots on the fixing bracket.
Fig. 4
Fig. 5
Fig. 6
Fig. 7

15
Locate the washers and screw the nuts
onto the adjustment bolts.
Fig. 8 - Aligning the decor door
Close the door and check the
alignment with the other unit doors.
Adjust the decor door by screwing or
unscrewing the adjustment bolts for
vertical adjustment and by the help of
the slots on the fixing bracket for other
directions. Lock the screws into place as shown in Fig. 8.
Fitting the decor door base fixings
With the appliance door open, locate the metal decor door base
fixing brackets and screw the fixings to the decor door. You may
need to remove and re-fit these brackets depending upon the decor
door used.
Fitting the decorative cover
Re-fit the decorative cover, that you removed in the first step, on to
the decor door fixing bracket.
Check that the whole door assembly operates smoothly and that the
door seal of the freezer is still creating a seal.
10
10
8
Fig. 8

16
Reversing the freezer door
We recommend you seek the help of another individual to support the
doors whilst performing this operation.
1. Open the door.
2. Carefully prise off the white cover
caps for the side that you wish to
switch the hinges to.
3. Loosen the screws that hold the
hinges to the freezer cabinet and
remove the door.
4. Remove the screws that secure the
hinge to the door.
5. Place the door somewhere
safe where it will not cause or
receive damage.
6. Relocate the hinges to their
opposing corners as shown in Fig.
9.
7. Refit the door to the hinges.
Do not turn the door upside down.
8. Insert the cover caps (3) on the
opposite side in the exposed holes.
9. Ensure that the door seal is correct,
as per page 17.
Fig. 9

17
Ensuring the door seals correctly:
It is normal for the seal to be compressed after the door has been
reversed.
With the door closed, use a hair dryer to expand the seal and fill the
gap between the door and the body of the appliance.
Take care not to use the hair dryer too close to the appliance, which
could damage the seal. A distance of approximately 10cm should be
adequate.
When completed, allow the seal and door to cool before touching
them.
Once done, the seal will remain in position.

18
Electrical Information
Warning! This appliance must be earthed.
The mains lead of this appliance has been fitted with a BS 1363A
13Amp fused plug. To change a fuse in this type of plug, follow the
steps below:
1. Remove the fuse cover and fuse.
2. Fit replacement 13A fuse, ASTA approved to BS 1362 type, into the
fuse cover.
3. Replace fuse cover.
Important: Do not use the appliance without the fuse cover in
position.
How to connect an alternative plug
If the fitted plug is not suitable for your socket outlet, then it should be
cut off and disposed of safely to avoid possible shock hazard. A
suitable alternative plug of at least 13 Amp rating to BS 1363 should be
used.
As the colours of the wires in the mains lead of this appliance may not
B
A
Green and Yellow to Earth
Brown to Liv e
13 Amp fuse
Cord Clamp
Blue to Neutral
13 Amp
Fig. 10

19
correspond with the coloured markings identifying the terminals in
your plug, proceed as follows:-
• The wire which is coloured GREEN and YELLOW must be
connected to the terminal which is marked with letter (E) or by the
Earth symbol or coloured GREEN and YELLOW.
• The wire which is coloured BLUE must be connected to the terminal
which is marked with the letter (N) or coloured BLACK.
• The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter (L) or coloured RED.
If in doubt regarding the electrical connection of this appliance,
consult a qualified electrician. Do not shorten the supply cable, the
appliance may require removing for servicing.
N.B. Ensure that the plug socket is situated in an easily
accessible place after installation.
E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve
the right to change specifications without prior notice.

20
NOTES:
