Matrix OmniFlow 330 Specification sheet

OmniFlow 330
- 1 -
1 Introduction .......................................................................................................... 1
1.1 Preface ....................................................................................................... 1
1.2 Specifications .................................................................................................. 1
2 Safety .......................................................................................................................... 2
2.1 Environment .............................................................................................. 2
2.2 Do’s and Don’ts ............................................................................................... 2
3 Main parts ............................................................................................................. 4
3.1 Overview ................................................................................................... 4
4 Installation ............................................................................................................ 5
4.1 Deflectors and side guides ......................................................................... 6
4.2 Power socket and switch ....................................................................... 6
4.3 Mount the conveyor to the machine ........................................................... 7
5 Operation .............................................................................................................. 9
5.1 Setting ........................................................................................................ 9
5.1.1 Separator finger adjusting knob ....................................................... 9
5.1.2 Blowing adjusting knob ................................................................... 9
5.1.3 Upper limiting height adjustment for feeding table ......................... 9
5.1.4 Place sheets ................................................................................... 10
5.1.5 Speed adjusting knob .................................................................... 11
5.2 Key panel ................................................................................................ 11
5.3 Standby .................................................................................................... 12
5.4 Set Batch .................................................................................................. 13
5.5 Set Batch Pause ........................................................................................ 13
5.6 Set Feed Pause ......................................................................................... 13
5.7 Check Speed ............................................................................................ 13
5.8 DBL feed detect ! Optional " ................................................................. 14
5.9 Machine Information ............................................................................... 14
6 Trouble shooting ................................................................................................ 15
6.1 C-5 no paper ....................................................................................... 15
6.2 C-2 infeed jam ......................................................................................... 15
6.3 C-1 top cover open ................................................................................... 16
6.4 E-1elevator error ................................................................................. 16
6.5 C-6 Double or multiple feed .................................................................... 16
7 Maintenance ....................................................................................................... 17
7.1 Clean the rubber rollers ....................................................................... 17
7.2 Clean the sensor .................................................................................. 17

OmniFlow 330
1
1 Introduction
1.1 Preface
This manual only applies to OmniFlow 330 machine. Before using the machine,
please read the instruction manual carefully first. Please keep the manual properly
so that consulting it at any time in the future. Any question while operating please
contact our technicians.
1.2 Specifications
Items
Parameter
Machine size!Length*Width*Height" #
850×545×450mm
Feeding extension table!Optional" #
1250mm
Machine weight
85.5kg
Power
220V/165W
Max sheet length!Width*Length" #
330×650mm
Min sheet length!Width*Length" #
140×160mm
Sheet thickness
120g-350g/0.12-0.35mm
Sheet flatness
$ 5 mm
Load capacity
100mm
Max speed!A4" #
6900 sheet per hour
Feeding type
Suction on the right
Outfeed transmission belt
Optional
Notes ： The machine is under upgrading#information in this manual can be changed
without notification.

OmniFlow 330
2
2 Safety
2.1 Environment
Temperature：10$%to 35$%Humidity
： 30% to 70% Altitude：Below
elevation 1000m
There is no corrosiveness gas, flammable gas, oil mist and so on in room.
2.2 Do’s and Don’ts
Do -Read this manual and fully understand before the operation.
Do -Check the plug and machine voltage and frequency to your main
supply, and that the socket has a correct working earth lead for this
single insulated machine
Do make sure all safety covers are in place. The top covers have
an interlock switch which will disable the unit if removed.
Do contact the local maintenance center before you are about to move
the machine.
Do disconnect the power before clean the inner side.
Do unplug the cord if you won’t use the machine for a long while.
Don’t install the machine on an unstable ground.
Don’t operating with wet hand, especially plug or unplug the cord.
Don’t wear long hair, loose fitting clothes or put your fingers into the
creasing unit nip, while the operation.
Don’t place any receptacles with any liquid on any surface of machine.

OmniFlow 330
3
Don’t -put other pieces, especially tiny pieces on loading table.
Don’t- alter or uninstall the machine, unless by Vivid authorized
engineer.
Don’t touch any running parts while running.
Don’t shut down the machine while running.
Don’t put heavy matter on machine or shock it.
Be careful of any metal or flammable thing in internal machine,
or it may cause fire or electronic shock. If it happens, first shut
down the power, disconnect the cord, and then contact the
technician.
If machine becomes heat, smoke, or smelly, shut down at once,
disconnecting the cord, and contact the maintenance staff.

OmniFlow 330
4
3 Main parts
3.1 Overview
No.
Name
Description
1
Key Panel
Operation
2
Screen
Display
3
Emergency Stop Button
Stops the system in an emergency
4
Blowing adjusting knob
Turn the knob clockwise to increase the
speed while turn the knob anticlockwise to
slow down.
5
Separator finger adjusting knob
Turn the knob clockwise when feeding table
gets stuck or feeding thicker paper. Turn the
knob anticlockwise when double feeding.
6
Feeding back stop guide
Hold the sheets and make them fed stably.
7
Feeding table
Feeding sheets.
8
Feeding extension board
For longer sheets.
9
Storage unit
Storage for extra sheets.
3
2
5
1
4
6
8
7
9

OmniFlow 330
5
Deflector 3
Deflector 2
Deflector 1
4 Installation
4.1 Deflectors and side guides
Deflector 3 is used for wider sheets.
4.2 Power socket and switch
As shown in the following figures, the power switch and socket are on the operating
side. The power supply is 220V/50HZ& %
!
!
!
Switch(“O” is on and“I”is off.)
Power socket
Fuse 3.15A
Notes ： Do not use wet hands to operate the machine.

OmniFlow 330
6
Finger
Sheet
5 Operation
5.1 Setting
5.1.1 Separator finger adjusting knob
As shown in the following figures. Turn the knob anticlockwise can increase the gap
while clockwise decrease the gap. When the sheets double fed, we need to decrease
the gap. When the sheets get stuck at the entrance, we should increase the gap.
Adjusting knob
5.1.2 Blowing adjusting knob
Turn the knob clockwise can weaken the blowing. When we run smaller and thinner
sheets, we can try weakening the blowing to make it fed smoothly and stably.
Adjusting knob
5.1.3 Upper limiting height adjustment for feeding table
Turn the knob clockwise the table will rise higher. If the sheets get stuck when
feeding, we can turn the knob anticlockwise a little.

OmniFlow 330
7
5.1.4 Place sheets
The deflectors and the side guides are placed based the sheet width. As for wider
sheets ,you may need to lift the edge of sheet on operation side a little to make it fed
square.
Side guides
Deflector 1
%&'(&)*+,##- #
!
Deflector 3

OmniFlow 330
8
5.1.5 Speed adjusting knob
Turn the knob anticlockwise the speed will slow down . Before we turn the knob#we
need to unlock the key by following the arrow direction first.
5.2 Key panel
Please read the instructions for each key in the following form before you run the
machine.
15 14 13 12 8 6 4 2
11 10 9 7 5 3 1

OmniFlow 330
9
No.
Name
Description
! "
# $% &$ "" ' ($ $)* "
./0 ## *1& ## 23 ) 140& 5 #
+ "
, -. $ "" '( $$ )* "
The paper will stop near the exit. It can be used to adjust the
connecting machines to the correct position.
/ "
#$ )0 12 %( .- "" '( $$ )* "
# $) 0 "" $3 - "" 4%5 36 *- 7 "
8 "
9:-%&"'($$)* "
9 :- %& "" $ 3- "" 6* 0( $ "" ;% $% "" )& "" $ 3- "" < %&*6* = "" 4- .. %= -7 "
> "
9 )* ?6 &4 "" ' ($$ )* "
9 )* ?6 &4 "" $ 3- "" 6* 0( $ "" ;% $%7 "
@ "
A(4 '- & "" '( $$) * "
B* 0( $ "" ;% $% 7 "
C "
2 %=- "" ;) <* "" '( $$ )* "
D-.-&E-;"'($$)*7"
F "
2%=-"(0"'($$)*"
D-.-&E-;"'($$)*7"
G "
H );- "" '( $$ )* "
# -: -5 $ "" ;6 ??- &- *$ "" 6 *$ -&? %5-. 7 "
!I"
J%5K<%&;"'($$)*"
When paper gets stuck inside, they can be used to drive the
paper out.
!!"
L)&<%&;"'($$)*"
When paper gets stuck inside, they can be used to drive the
paper out.
!+"
A)".3--$."6*;65%$)&"
The indicator will be illumined without placing paper in long
run.
!/"
M&&)&"6*;65%$)& "
N3 -* "" 4% 53 6* - ""5 )4 -. "" (0 "" - && )& .O "" $3 - "" 6 *; 65 %$ )& ""<6 :: "" '- "
6: :( 46 *- ;7 "
!8"
2% 0- & "" P% 4 "" 6 *; 65 %$ )& "
N 3-* "" .3 -- $. "" P% 4 "" 6* .6 ;-O "" $ 3- "" 6 *; 65%$) & ""<6 :: "" '- "
6: :( 46 *- ;7 "
!>"
,)0 "" 5)E- & "" 6 *; 65 %$ )& "
N 3-* "" $) 0 "" 5)E -& "" )0-*- ;O "" $3 - "" 6*;6 5%$)& "" < 6:: "" '- "
6: :( 46 *- ;7 "
5.3 Standby
When power on the machine, it will come up the Vivid welcome interface. Then it
will enter standby interface. Ver'1.01 means the current software version of
machine is 1.03.As for the “Ready 0/0,the left 0 means quantity of the paper being
run and the right 0 means the preset quantity of paper. When the being run quantity
reach the preset quantity, the machine will stop automatically. In standby interface,
we can use number keys for quantity preset and “C” button to clear the quantity.
The largest input is 999.
Note：Only in standby interface can we press the green start button to run the
machine.

OmniFlow 330
10
5.4 Set Batch
Press “M” to enter Set Batch interface. We can set the batch quantity. Shown in the
following pictures. After confirming, it will enter the standby interface. Then we can
set the sheet quantity for each batch. For example, we set 3 batches and 2 sheets for
each batch on the machine. And then the machine will stop when it finishes running
3 batches and 2 sheets for each batch.
Notes 'When the sheet quantity is less than the setting, the machine will stop. Then
after we place more sheets on the table, it will continue the last job.
5.5 Set Batch Pause
Press “M” to enter the set batch pause interface. In this interface, we can set the
batch delay time. It can be set from 1s to 99s.
5.6 Set Feed Pause
Press “M” to enter the interface. We can set the delay time between each sheet fed
into the machine. It can be set from 0 to 9s.
5.7 Check Speed
Press “M” to enter the interface. Then press the green start button. It will show the
current running speed. We can use the speed adjusting knob to change the speed.
Press red stop button can stop the test. Then press the stop button again to enter the

OmniFlow 330
11
standby interface.
5.8 DBL feed detect （ Optional ）
Press “M” to enter the interface. We can select to open or close the double feed
detecting function.
Notes ： The double feed detecting sensors are optional. If there are no double feed
detecting sensors on the machine but the double feed detect is on, it will come up
the error message.
5.9 Machine Information
Press “M” to enter the interface. The SHEET means the total sheet count and the SN
means the serial number of the machine. This information is used for warranty
service.

OmniFlow 330
12
6 Trouble shooting
6.1 C-5 no paper
As shown in the following figure, there is a sensor for the detection of sheets. When
the sensor detect no sheets on the table, it will come up C-5.
6.2 C-2 infeed jam
（ 1 ） C-2 comes up without any sheet getting stuck
As shown in the following figure, the sensor may be covered by paper dust. So you
may need to do some cleaning for the sensor. Make sure the upper and bottom
sensors are in one line. If it still didn’t work, then the sensors itself may have issue.
Note 'There may exist a lot of dust on it after a long time use.
（ 2 ） C-2 comes up during running.
Machine is running without feeding for a long while.

OmniFlow 330
13
Top cover switch
Flag
①
Reset button
6.3 C-1 top cover open
When the top cover is opened, it will come up C-1. If the flag didn’t press the
switch or the switch broken, it will come up the C-1 as well.
6.4 E-1elevator error
!6" When feeding table gets stuck at the bottom, we can restart the machine. Then
press the start button and reset button at the same time.
!-" When feeding table gets stuck on the top, we can restart the machine. Then
press the stop button and reset button at the same time.
6.5 C-6 Double or multiple feed
!(" The machine didn’t have double feed detecting sensors on it.
!)" Adjust the knob or blower by flowing the instructions in section 5.1.1 and
5.1.2.

OmniFlow 330
14
②
①
7 Maintenance
Maintenance of machinery is crucial, necessary maintenance can extend the service
life of machinery, and can improve the efficiency of machinery. After long run, the
mechanical parts may be covered by lots of dust#which will have bad effects on the
operation. The operation environment should be dry and clean.
Note ： Please unplug the power cord before any cleaning.
7.1 Clean the rubber rollers
As shown in the following figure, open the top cover and use the cleaning cloth to
clear the dust on the surface.
7.2 Clean the sensor
Use the air gun or cotton swab to clean the surface of sensors.
