Matsui M510WM16G Service manual

INSTALLATION/
INSTRUCTION MANUAL
5KG WASHING MACHINE
M510WM16G
ΠΛΥΝΤΗΡΙΟ 5KG
ΕΓΧΕΙΡΙΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ / ΟΗΓΙΝ
GR
5KG WASHING MACHINE
INSTALLATION / INSTRUCTION MANUAL
GB
M510WM16G_IB_2L_RC_160810_grace.indb 1 10/8/16 12:04 pm

GB Contents
Safety Warnings............................................................................................................................................................... 4
Unpacking........................................................................................................................................................................ 8
Installing Your Washing Machine ................................................................................................................................... 9
Choosing The Right Location For Your Washing Machine.........................................................................................................................9
Moving and Installing ................................................................................................................................................... 10
Removing The Transit Bolts ...............................................................................................................................................................................10
Moving The Washing Machine From One Location To Another...........................................................................................................10
Hose And Cable Lengths....................................................................................................................................................................................11
Levelling The Washing Machine ......................................................................................................................................................................11
Water Supply Hose ...............................................................................................................................................................................................11
Connecting The Water Supply Hose...............................................................................................................................................................12
Water Drain Hose .................................................................................................................................................................................................. 12
Connecting To The Mains Supply....................................................................................................................................................................13
Product Overview.......................................................................................................................................................... 14
The Unit ....................................................................................................................................................................................................................14
The Control Panel..................................................................................................................................................................................................15
Preparation .................................................................................................................................................................... 16
Organising Laundry..............................................................................................................................................................................................16
Preparing Laundry................................................................................................................................................................................................16
Adding Detergent And Softener ..................................................................................................................................................................... 16
Before First Use.............................................................................................................................................................. 18
Wash Setting .................................................................................................................................................................. 18
Standard Washing.................................................................................................................................................................................................18
Removing Washing (Once Programme is Finished).................................................................................................................................. 18
Selecting The Programme..................................................................................................................................................................................19
Important Information.................................................................................................................................................. 20
Washing Delicates (Wool And Silk Programmes) ...................................................................................................................................... 20
Adding Delicate Laundry Items To The Drum.............................................................................................................................................20
Which Detergent To Use..................................................................................................................................................................................... 20
Maintenance - Cleaning The Washing Machine........................................................................................................... 21
Cleaning The Drum............................................................................................................................................................................................... 21
Cleaning The Exterior Of Your Washing Machine ......................................................................................................................................21
Cleaning The Detergent Drawer...................................................................................................................................................................... 21
Cleaning The Door Seal And Window............................................................................................................................................................21
Cleaning The Drain Filter.................................................................................................................................................................................... 22
Preventing A Frozen Water Supply Hose......................................................................................................................................................22
Cleaning The Filter Net Of The Water Supply Hose................................................................................................................................... 22
Hints and Tips ................................................................................................................................................................ 23
Questions and Answers................................................................................................................................................. 25
Indicator Issues ......................................................................................................................................................................................................26
Specications................................................................................................................................................................. 26
Product Fiche ................................................................................................................................................................. 27
M510WM16G_IB_2L_RC_160810_grace.indb 2 10/8/16 12:04 pm

GR Περιεχόμενα
προειδοποιήσεις ασφαλείας........................................................................................................................................... 6
αφαίρεση συσκευασίας ................................................................................................................................................ 28
εγκατάσταση του πλυντηρίου σας............................................................................................................................... 29
επιλογή της κατάλληλης θέσης για το πλυντήριό σας............................................................................................................................. 29
μεταφορά και εγκατάσταση ......................................................................................................................................... 30
αφαίρεση των μπουλονιών μεταφοράς........................................................................................................................................................ 30
μεταφορά του πλυντηρίου από τη μία θέση στην άλλη ......................................................................................................................... 30
μήκος σωλήνων και καλωδίων.........................................................................................................................................................................31
στάθμιση του πλυντηρίου..................................................................................................................................................................................31
σωλήνας παροχής νερού....................................................................................................................................................................................31
σύνδεση του σωλήνα παροχής νερού........................................................................................................................................................... 32
σωλήνας αποστράγγισης νερού...................................................................................................................................................................... 32
σύνδεση στην τροφοδοσία από το κύριο δίκτυο...................................................................................................................................... 33
επισκόπηση προϊόντος ................................................................................................................................................. 34
η μονάδα..................................................................................................................................................................................................................34
ο πίνακας ελέγχου................................................................................................................................................................................................. 35
προετοιμασία................................................................................................................................................................. 36
οργάνωση των ρούχων....................................................................................................................................................................................... 36
προετοιμασία των ρούχων ................................................................................................................................................................................36
προσθήκη απορρυπαντικού και μαλακτικού..............................................................................................................................................36
πριν από την πρώτη χρήση........................................................................................................................................... 38
ρύθμιση πλύσης............................................................................................................................................................. 38
τυπική πλύση ..........................................................................................................................................................................................................38
αφαίρεση ρούχων (αφού τελειώσει το πρόγραμμα)................................................................................................................................38
επιλογή του προγράμματος ..............................................................................................................................................................................39
σημαντικές πληροφορίες ............................................................................................................................................. 41
πλύσιμο ευαίσθητων (προγράμματα για μάλλινα και μεταξωτά)........................................................................................................41
προσθήκη ευαίσθητων ρούχων στον κάδο ................................................................................................................................................41
ποιο απορρυπαντικό να χρησιμοποιήσετε..................................................................................................................................................41
συντήρηση - καθαρισμός του πλυντηρίου .................................................................................................................. 42
καθαρισμός του κάδου .......................................................................................................................................................................................42
καθαρισμός του εξωτερικού του πλυντηρίου σας ....................................................................................................................................42
καθαρισμός του συρταριού απορρυπαντικού ........................................................................................................................................... 42
καθαρισμός του παρεμβύσματος και του παραθύρου της πόρτας ....................................................................................................42
καθαρισμός του φίλτρου αποστράγγισης.................................................................................................................................................... 43
αποτροπή παγώματος του σωλήνα παροχής νερού ................................................................................................................................43
καθαρισμός του πλέγματος του φίλτρου του σωλήνα παροχής νερού.............................................................................................44
υποδείξεις και συμβουλές............................................................................................................................................. 45
ερωτήσεις και απαντήσεις ............................................................................................................................................ 48
Προβλήματα δείκτη .............................................................................................................................................................................................49
προδιαγραφές................................................................................................................................................................ 50
δελτίο τεχνικών δεδομένων προϊόντος....................................................................................................................... 51
M510WM16G_IB_2L_RC_160810_grace.indb 3 10/8/16 12:04 pm

4
GB Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions
listed below.
WARNING!
• If you will not be using the washing machine for a while such as when you go on holiday, disconnect the plug from
the mains supply and turn o the water supply to the washing machine. This is particularly important if there is no
drainage around the washing machine.
• If the water supply is left on, water pressure may build up and cause a leak.
General Use
• Transit bolts are used to transport the washing machine. You should remove these using a spanner or similar tool
before you install the washing machine. If you do not, it will cause strong vibrations when the washing machine is
spinning.
• Do not install your washing machine anywhere that is damp or exposed to the weather. If you do, it may cause an
electric shock, re, failure or deterioration.
• Do not pour water directly onto any part of the washing machine. It may cause a short circuit or electric shock.
• Keep burning objects such as candles or cigarettes, away from the washing machine.They may cause a re or
damage.
• Keep ammable substances well away from the washing machine – for example kerosene, gasoline, benzene,
paint thinner and alcohol, or clothing soaked with these. They may cause an explosion or a re.
• This washing machine is only suitable for washing textiles labelled‘washing machine washable’.
• Do not connect the washing machine to hot water. The washing machine works with cold water only.
• Before you start using the washing machine, turn the tap on to check that the hose is properly connected. If it’s not,
there may be a water leak.
• Do not put too much laundry or detergent into the washing machine. It may cause issues with the washing
machine or laundry.
• Be careful not to get your laundry caught in the door when you close it. This could cause a water leak or damage
your laundry.
• This washing machine is for household (domestic) use only.
Power Source and Cable
• Use an independent household dedicated mains socket, rated at 10 Amp 220V to 240V AC. If the washing machine
is plugged in with other appliances, it may overheat and cause a re.
• Make sure the mains plug is pushed rmly into the socket. A loose connection may overheat and cause electrical
shock or a re.
• Check the mains lead and mains plug for any damage. If the mains cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.
• Unplug the mains lead when cleaning the washing machine.
• Do not touch the mains lead or mains plug with wet hands. It may cause an electric shock.
• Check the mains plug regularly for dirt. If dirt accumulates on the mains plug, it could cause a re. To prevent this,
unplug the cable and clean the mains plug with a dry rag.
• If you disconnect the mains plug, hold onto the mains plug not the cable. Pulling the cable may cause an electric
shock or a re.
• Do not use a mains plug adapter or extension cable. It may overheat and cause a re.
• Make sure your home voltage matches the voltage displayed on the washing machine. If you are not sure, contact
an electrician.
M510WM16G_IB_2L_RC_160810_grace.indb 4 10/8/16 12:04 pm

5
• The mains plug must remain accessible to allow disconnection or an all pole switch must be incorporated in
the xed wiring in accordance with the wiring regulations.
To Prevent Injury / Damage
• Do not climb on the washing machine.You may hurt yourself or damage the washing machine.
• When opening and closing the door ensure you keep ngers away from the door hinge, or this could lead to
injury.
• Check your washing for objects such as nails, pins, coins, clips etc. They could damage your laundry or the
washing machine.
• To prevent any large, heavy objects (e.g., buckles, large buttons, etc.) from hitting the glass door, turn your
clothing inside out or remove the heavy objects. They could damage your laundry or the washing machine.
• Do not wash, rinse or spin water-proof sheets or clothing. These may cause vibration or washing machine
failure during spin-drying, which could lead to injury, damage to the washing machine or damage due to
water leaking.
• Be careful when draining hot water or any detergent from the drum.
• Do not dismantle, repair or modify the washing machine.The washing machine could malfunction and cause
a re or injury.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure that they do not play with the appliance.
• Children of less than 3 years should be kept away unless continuously supervised.
• Do not touch the laundry inside the washing machine, until the drum has completely stopped. Even if the
drum is spinning at low speed it can cause an injury. Take particular care of children in this respect.
• The appliance is to be connected to the water mains using the new hose-set supplied. Old hose-sets should
not be reused.
• The ventilation openings in the base of the washing machine must not be obstructed by a carpet.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED SERVICE PERSONNEL TO CARRY OUT
SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF COVERS.
TO AVOIDTHE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS YOURSELF.
M510WM16G_IB_2L_RC_160810_grace.indb 5 10/8/16 12:04 pm

6
GR προειδοποιήσεις ασφαλείας
Για τη συνεχή ασφάλειά σα και τη είωση του κινδύνου πρόκληση τραυατισού ή ηλεκτροπληξία, ακολουθήστε
όλε τι προφυλάξει ασφαλεία που αναφέρονται παρακάτω.
ΠΡΟΕΙΟΠΟΙΗΣΗ!
• Αν δεν πρόκειται να χρησιοποιήσετε το πλυντήριο για κάποιο χρονικό διάστηα, όπω όταν λείπετε για διακοπέ,
αποσυνδέστε το βύσα από την τροφοδοσία κύριου δικτύου και κλείστε την παροχή νερού στο πλυντήριο. Αυτό
είναι ιδιαίτερα σηαντικό αν δεν υπάρχει σύστηα αποστράγγιση γύρω από το πλυντήριο.
• Αν η παροχή νερού είνει ανοιχτή, η πίεση του νερού πορεί αυξηθεί και να προκαλέσει διαρροή.
Γενική χρήση
• Τα πουλόνια εταφορά χρησιοποιούνται για τη εταφορά του πλυντηρίου. Θα πρέπει να τα αφαιρέσετε
χρησιοποιώντα ένα κλειδί ή παρόοιο εργαλείο, πριν εγκαταστήσετε το πλυντήριο. Σε αντίθετη περίπτωση, θα
προκληθούν έντονε δονήσει κατά τη φάση στυψίατο του πλυντηρίου.
• Μην εγκαθιστάτε το πλυντήριό σα σε έρο που είναι υγρό ή εκτεθειένο στα καιρικά φαινόενα. Αν το κάνετε
αυτό, πορεί να προκληθεί ηλεκτροπληξία, πυρκαγιά, βλάβη ή υποβάθιση.
• Μην χύνετε νερό απευθεία σε οποιοδήποτε έρο του πλυντηρίου. Μπορεί να προκληθεί βραχυκύκλωα ή
ηλεκτροπληξία.
• Κρατάτε τα φλεγόενα αντικείενα, όπω κεριά ή τσιγάρα, ακριά από το πλυντήριο. ιαφορετικά, πορεί να
προκαλέσουν πυρκαγιά ή ζηιά.
• Κρατάτε τι εύφλεκτε ουσίε σε απόσταση από το πλυντήριο, για παράδειγα, την κηροζίνη, την βενζίνη,
τη βενζόλη, τα αραιωτικά χρωάτων και το οινόπνευα, ή πανιά εποτισένα ε αυτέ τι ουσίε. Μπορεί να
προκαλέσουν έκρηξη ή πυρκαγιά.
• Αυτό το πλυντήριο είναι κατάλληλο για πλύσιο όνο των υφασάτων ε ετικέτα «πλένεται στο πλυντήριο».
• Μη συνδέετε το πλυντήριο σε ζεστό νερό.Το πλυντήριο λειτουργεί όνο ε κρύο νερό.
• Πριν αρχίσετε να χρησιοποιείτε το πλυντήριο, ανοίξτε τη βρύση για να ελέγξετε ότι ο σωλήνα έχει συνδεθεί
σωστά. Αν δεν έχει συνδεθεί σωστά, πορεί να υπάρχει διαρροή νερού.
• Μην τοποθετείτε πάρα πολλά ρούχα ή απορρυπαντικό στο πλυντήριο. Μπορεί να προκληθούν προβλήατα ε το
πλυντήριο ή τα ρούχα.
• Προσέχετε να ην πιαστούν τα ρούχα στη πόρτα, όταν την κλείνετε. Αυτό θα πορούσε να προκαλέσει διαρροή
νερού ή να καταστρέψει τα ρούχα σα.
• Αυτό το πλυντήριο προορίζεται όνο για οικιακή χρήση.
Πηγή ισχύο και καλώδιο
• Χρησιοποιήστε ια ανεξάρτητη, αποκλειστική πρίζα κύριου δικτύου του νοικοκυριού σα, ε ονοαστική τιή
10 Amp 220V έω 240V εναλλασσόενου ρεύατο. Αν το πλυντήριο είναι συνδεδεένο στην ίδια πρίζα ε άλλε
συσκευέ, ενδέχεται να υπερθερανθεί και να προκαλέσει πυρκαγιά.
• Βεβαιωθείτε ότι το βύσα τροφοδοσία από το κύριο δίκτυο είναι τοποθετηένο σταθερά έσα στην πρίζα. Μια
χαλαρή σύνδεση πορεί να οδηγήσει σε υπερθέρανση και να προκαλέσει ηλεκτροπληξία ή πυρκαγιά.
• Ελέγξτε το καλώδιο τροφοδοσία από το κύριο δίκτυο και το βύσα τροφοδοσία από το κύριο δίκτυο για ζηιέ.
Εάν το καλώδιο ρεύατο υποστεί φθορά, πορεί να αντικατασταθεί από τον κατασκευαστή, ένα αντιπρόσωπο
σέρβι ή έναν αντίστοιχο εξειδικευένο τεχνικό για να αποφευχθεί ο κίνδυνο.
• Αποσυνδέετε το καλώδιο τροφοδοσία από το κύριο δίκτυο κατά τον καθαρισό του πλυντηρίου.
• Μην αγγίζετε το καλώδιο τροφοδοσία από το κύριο δίκτυο ή το βύσα τροφοδοσία από το κύριο δίκτυο ε
βρεγένα χέρια. Μπορεί να προκληθεί ηλεκτροπληξία.
• Ελέγχετε το βύσα τροφοδοσία από το κύριο δίκτυο τακτικά για ρύπου. Αν συσσωρευτούν ρύποι στο βύσα
τροφοδοσία από το κύριο δίκτυο, πορεί να προκληθεί πυρκαγιά. Για να το αποτρέψετε αυτό, αποσυνδέστε το
M510WM16G_IB_2L_RC_160810_grace.indb 6 10/8/16 12:04 pm

7
καλώδιο και καθαρίστε το βύσα τροφοδοσία από το κύριο δίκτυο ε ένα στεγνό πανί.
• Αν αποσυνδέσετε το βύσα τροφοδοσία από το κύριο δίκτυο, τραβήξτε το βύσα και όχι το καλώδιο. Αν
τραβήξετε το καλώδιο, πορεί να προκληθεί ηλεκτροπληξία ή πυρκαγιά.
• Μη χρησιοποιείτε ετασχηατιστή βύσατο τροφοδοσία από το κύριο δίκτυο ή καλώδιο επέκταση. Μπορεί
να υπερθερανθεί και να προκληθεί πυρκαγιά.
• Βεβαιωθείτε ότι η τάση του σπιτιού σα ταιριάζει ε την τάση που αναγράφεται στο πλυντήριο. Αν δεν είστε
βέβαιοι, επικοινωνήστε ε έναν ηλεκτρολόγο.
• Το βύσα τροφοδοσία από το κύριο δίκτυο πρέπει να παραένει προσβάσιο για να είναι δυνατή η
αποσύνδεση ή πρέπει να ενσωατωθεί ένα πολυπολικό διακόπτη στη σταθερή καλωδίωση σύφωνα ε του
κανονισού καλωδίωση.
Για να αποτραπεί τραυματισμός / ζημιά
• Μην σκαρφαλώνετε πάνω στο πλυντήριο. Μπορεί να τραυατιστείτε ή να καταστρέψετε το πλυντήριο.
• Όταν ανοίγετε και κλείνετε την πόρτα βεβαιωθείτε ότι έχετε τα δάχτυλά σα ακριά από το εντεσέ τη πόρτα,
καθώ αυτό θα πορούσε να προκαλέσει τραυατισό.
• Ελέγξτε τα ρούχα για αντικείενα όπω καρφιά, καρφίτσε, κέρατα, συνδετήρε κ.λπ.Τα αντικείενα αυτά θα
πορούσαν να καταστρέψουν τα ρούχα σα ή το πλυντήριο.
• Για να ην προσκρούουν εγάλα και βαριά αντικείενα (π.χ. αγκράφε, εγάλα κουπιά κ.λπ.) στη γυάλινη
πόρτα, γυρίστε τα ρούχα ανάποδα ή αφαιρέστε τα βαριά αντικείενα.Τα αντικείενα αυτά θα πορούσαν να
καταστρέψουν τα ρούχα σα ή το πλυντήριο.
• Μην πλένετε, ξεβγάζετε ή στύβετε αδιάβροχα σεντόνια ή ρούχα. Θα πορούσαν να προκαλέσουν δονήσει ή
βλάβη στο πλυντήριο κατά το στύψιο-στέγνωα, κάτι που θα πορούσε να οδηγήσει σε τραυατισό, βλάβη
στο πλυντήριο ή ζηιά λόγω διαρροή νερού.
• Να προσέχετε όταν αποστραγγίζετε ζεστό νερό ή απορρυπαντικό από τον κάδο.
• Μην αποσυναρολογείτε, επισκευάζετε ή τροποποιείτε το πλυντήριο. Το πλυντήριο θα πορούσε να
παρουσιάσει βλάβη και να προκαλέσει πυρκαγιά ή τραυατισό.
• Αυτή η συσκευή πορεί να χρησιοποιηθεί από παιδιά ηλικία από 8 ετών και άνω και από άτοα ε ειωένε
σωατικέ, αισθητήριε ή διανοητικέ ικανότητε ή έλλειψη επειρία και γνώση, εφόσον επιβλέπονται ή
του έχουν δοθεί οδηγίε σχετικά ε τη χρήση τη συσκευή ε ασφαλή τρόπο και κατανοούν τι κινδύνου που
επλέκονται.Τα παιδιά δεν πρέπει να παίζουν ε τη συσκευή. Ο καθαρισό και η συντήρηση από το χρήστη
δεν θα πρέπει να γίνεται από παιδιά χωρί επιτήρηση.
• Τα ικρά παιδιά πρέπει να επιτηρούνται για να διασφαλιστεί ότι δεν παίζουν ε τη συσκευή.
• Τα παιδιά κάτω των 3 ετών δεν θα πρέπει να πλησιάζουν στη συσκευή, εκτό αν επιβλέπονται συνεχώ.
• Μην αγγίζετε τα ρούχα έσα στο πλυντήριο, ώσπου ο κάδο να σταατήσει τελείω. Ακόα κι αν ο κάδο
περιστρέφεται ε ικρή ταχύτητα, πορεί να προκαλέσει τραυατισό. Προσέχετε ιδιαίτερα τα παιδιά από αυτή
την άποψη.
• Η συσκευή πρέπει να συνδέεται στο κεντρικό δίκτυο νερού ε χρήση του νέου σετ σωλήνων που παρέχεται. Τα
παλιά σετ σωλήνων δεν πρέπει να χρησιοποιούνται ξανά.
• Τα ανοίγατα αερισού στη βάση του πλυντηρίου δεν πρέπει να φράζονται από τη οκέτα.
ΠΡΟΕΙΟΠΟΙΗΣΗ
ΕΙΝΑΙ ΕΠΙΚΙΝΥΝΟ ΓΙΑ ΟΠΟΙΟΝΗΠΟΤΕ ΕΚΤΟΣ ΑΠΟ ΤΟ ΕΞΕΙΙΚΕΥΜΕΝΟ ΠΡΟΣΠΙΚΟ ΣΕΡΒΙΣ ΝΑ
ΠΡΑΓΜΑΤΟΠΟΙΕΙ ΕΡΓΑΣΙΕΣ ΣΕΡΒΙΣ Ή ΕΠΙΣΚΕΥΕΣ ΠΟΥ ΠΕΡΙΛΑΜΒΑΝΟΥΝ ΤΗΝ ΑΦΑΙΡΕΣΗ
ΚΑΛΥΜΜΑΤΝ.
ΠΡΟΣ ΑΠΟΦΥΓΗ ΤΟΥ ΚΙΝΥΝΟΥ ΠΡΟΚΛΗΣΗΣ ΗΛΕΚΤΡΟΠΛΗΞΙΑΣ ΜΗΝ ΕΠΙΧΕΙΡΕΙΤΕ ΝΑ ΚΑΝΕΤΕ
ΕΠΙΣΚΕΥΕΣ ΜΟΝΟΙ ΣΑΣ.
M510WM16G_IB_2L_RC_160810_grace.indb 7 10/8/16 12:04 pm

GB
8
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit Instruction ManualWater Supply Hose x 1
U-Shape Drain Hose HolderTransit Bolt Covers x 4
Instruction
Manual
Thank you for purchasing your new Washing Machine.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this installation/
instruction manual in order that you fully understand all the operational
features it oers.
Read all the safety instructions carefully before use and keep this
installation/instruction manual for future reference.
M510WM16G_IB_2L_RC_160810_grace.indb 8 10/8/16 12:04 pm

INSTALLATION
GB
9
Installing Your Washing Machine
Please Read And Follow The Instructions Carefully.
• In addition to the instructions mentioned here, special regulations of the relevant
water and power supply companies may apply. If in doubt, have the washing machine
connected by a qualied technician.
• The washing machine is heavy - caution when lifting it. Do not lift by projecting
components (e.g. washing machine door).
• Warning: Frozen hoses may tear/burst. Do not install washing machine in outdoor areas or
where there is a risk of frost.
• Lay hoses and cables in such a way that there is no risk of tripping over them.
Choosing The Right Location For Your Washing Machine
• Make sure there’s enough space for your washing machine.
• Install your washing machine on a at, stable surface to avoid excessive vibrations and
noise.
• Don’t install your washing machine in direct sunlight or in a place where temperatures can
reach freezing.
• The ventilation openings in the base of the washing machine must not be obstructed by
carpet.
• Start by tilting the washing machine backwards.
• One person should stand behind it, holding the rear of the top panel. The other person
should grip the bottom feet at the front.
• Check that you have all the required accessories for installation.
• We recommend that you entrust the installation of the washing machine to a qualied
technician.
Two or more people are required to move
the washing machine.
ÒÒÒ
Sloping
surface
Unstable Bumpy
surface
xSloping
surface
xUnstable xBumpy
surface
An additional space (approximately 120mm) is required at the rear of the washing
machine. This is to allow enough space for the water hose and drain hose
connections.
M510WM16G_IB_2L_RC_160810_grace.indb 9 10/8/16 12:04 pm

INSTALLATION
GB
10
Moving and Installing
Removing The Transit Bolts
Four transit bolts keep the interior of the washing machine in place while it’s being moved.
They need to be removed before installation. Use a spanner (not supplied) and follow the
instructions detailed below.
To remove the transit bolts:
1. Use a spanner to loosen the four bolts. They are located at the rear of the washing
machine.
2. Pull the bolts out horizontally. Make sure the entire bolt is removed.
3. Push the four cover caps (included with your accessories) into the respective bolt holes.
Moving The Washing Machine From One Location To Another
Before you move the washing machine:
• Shut o the tap and run the washing machine to drain the water. Drain any remaining
water from the pump hose.
• Disconnect the mains cable.
• Attach the transit bolts.
Don’t run the washing machine without removing the transit bolts, as this can cause
excessive vibrations and may damage your machine.
You’ll need the transit bolts again if you move the washing machine, so make sure
you keep them in a safe place.
Make sure to x the transit bolts prior to moving the washing machine.
M510WM16G_IB_2L_RC_160810_grace.indb 10 10/8/16 12:04 pm

INSTALLATION
GB
11
Levelling The Washing Machine
There are 4 levelling feet on the underside. They must be adjusted to make sure the washing
machine is level.
1. On each foot, loosen the lock ring by turning it
clockwise.
2. Adjust all four feet by rotating each upwards or
downwards.
3. Use a spirit level to ensure the washing machine
is level.
4. Tighten each lock ring by turning them anti-
clockwise (towards the washing machine body).
Ensure all four lock rings are tightened securely.
Check that the feet are still bolted to the washing
machine - if they’re unbolted, the washing machine
will move around.
Water Supply Hose
Points to remember
• Follow the instructions in this section to avoid water leaks.
• Don’t connect the hose to a combination tap.
• Don’t twist, squash, modify or cut the hose.
• This machine is designed to connect to the cold water supply. Do not connect to the hot
water supply.
• Use only the new water supply hose supplied. Old hose sets should not be reused.
Hose And Cable Lengths
How to connect from the left side How to connect from the right side
~80cm
~90cm
110 -135cm
min. 60cm
max. 100cm
~40cm
~130cm
M510WM16G_IB_2L_RC_160810_grace.indb 11 10/8/16 12:04 pm

INSTALLATION
GB
12
Connecting The Water Supply Hose
• To prevent leakage from the connection
joints, ensure the rubber washer seals
are tted to each end of the water supply
hose. Do not use without the seals in
place.
• Fit the straight end of the water supply
hose to the cold water tap.
• Connect the angled end of the white
headed hose to the water inlet valve on
the machine. Hand tighten the plastic
parts of the connections. If you are
unsure, please call a qualied plumber for
safer connections.
• Open the tap slowly and check that there
are no leaks around the connection joints.
Leak-proof System - Overow Detection
This system is designed to prevent water leaks from the washing machine. If water collects
in the washing machine above a certain level, this function prevents the washing machine
overowing by stopping the water supply and activating the drain pump.
Water Drain Hose
Points to remember:
• Don’t twist, pull out or bend the drain hose.
• Your washing machine should be no more than 85cm from the drain outlet.
• The water drain hose should be mounted at a height of minimum 60 cm, maximum 100
cm from the ground.
Draining to a sink or wash-basin
• Secure the drain hose in position, so it can’t drop out of the basin.
• Don’t block the basin’s drain outlet, and make sure that the drainage through it is
sucient to prevent overowing.
• Don’t let the tip of the drain hose dip into the drained water, as this can cause the water to
ow back into the washing machine.
3/4”
3/4”
min. 10 mm min. 10 mm
Plastic joint
U-Shape Holder
Draining to a wash-basin Draining to a drain hose
Before connecting to the waste pipe, make sure to check the waste pipe and remove
any stopper or blockage inside, otherwise the unit may not be able to expel the
waste water properly.
M510WM16G_IB_2L_RC_160810_grace.indb 12 10/8/16 12:05 pm

INSTALLATION
GB
13
Connecting To The Mains Supply
For your safety:
• Do not use a mains plug adapter or extension cable.
• If the mains cable or mains plug are damaged, stop using them and call a qualied
technician for assistance.
• An earthed plug has been attached to the power cable of your washing machine. This
plug must be inserted into an earthed socket capable of supplying 13 Amps. If you have
no such sockets and fuses in your house, call a qualied electrician.
• The mains plug must remain accessible to allow disconnection or an all pole switch must
be incorporated in the xed wiring in accordance with the wiring rules.
Installation check list
By now, you should have installed the washing machine.
Let’s go through the checklist to ensure that the installation has been done correctly!
Questions Checkbox
Transit bolts - Have you removed them and attached the cover caps properly?
4 levelling feet Four Adjustable Feet - Are they bolted securely to the
washing machine?
Four Feet Cushions - Are they standing flat?
Power supply - Is the household dedicated mains socket rated for 220V - 240V
AC and can supply 13 Amps?
Location - Is your washing machine on a flat, stable surface?
Water Supply Hose - Is it free from leaks and is the water supply normal?
Water Drain Hose - Is it free from leaks and is it draining normally?
M510WM16G_IB_2L_RC_160810_grace.indb 13 10/8/16 12:05 pm

GB
14
Product Overview
The Unit
Detergent
Compartment Control Panel
Door Handle
Service Panel
Window
M510WM16G_IB_2L_RC_160810_grace.indb 14 10/8/16 12:05 pm

GB
15
The Control Panel
Temp.
Cotton Intensive
1000
500
700
20
Spin Speed
Button
Select the desired
spin speed of the
selected wash
programme -
you can also select
Rinse Hold.
Temperature
Button
Press to select the
desired temperature.
(If no temperature
indicator is lit, the
water temperature
is cold.)
Start/Pause
Button
Press to start your
wash. Press while
in operation to
pause your wash.
Programme Dial
Different wash programmes can
be selected according to your
wash requirements.
• If you need to change a setting, press Start / Pause button, then re-select the desired
programme.
• Water is poured into the washing machine to perform an inspection at the time of
shipment from the factory, so there may be drops of water or condensation in the
washing machine. This is not an indication of a malfunction.
During initial start-up and use of the unit, there may be a slight smell while the motor is
settling in. This is not a fault; this is normal operation.
Power Button
Press to turn on the machine.
Press and hold to turn off the
machine.
M510WM16G_IB_2L_RC_160810_grace.indb 15 10/8/16 12:05 pm

GB
16
Preparation
Read the following to understand how best to prepare your laundry for washing.
Organising Laundry
• Read the washing label on each garment to help you sort your washing into dierent loads.
• Sort the laundry by colour, type of fabric and by how soiled it is. This will help you choose the
correct programme and temperature for each wash.
• Do not exceed the maximum load! See the programme selection table for the maximum load
for the programme you require.
Preparing Laundry
• Treat stains before washing.
• Some items should be put into a cleaning net before going
into the washing machine, i.e. bras with metal wires, tights
and lace clothing to prevent damage.
• Check that pockets do not contain any objects which may
damage your clothes and the washing machine.
• Tie up any loose strings on laundry, close zippers and
reverse clothing with zips inside out.
• To prevent any large, heavy objects (e.g., buckles, large
buttons, etc.) from hitting the glass door, turn your clothing
inside out, or remove the heavy objects. These could
damage your laundry or the washing machine.
• Remove any surplus hair, animal fur, sand, and other
materials with a brush before washing.
• If clothes have raised fabric turn them inside out.
• Clothes that are not colour fast should be washed
separately.
• Insert your clothes into the washing machine. Close the
washing machine door. Ensure that you do not trap any
items of clothing between the loading door and the rubber
seal.
Adding Detergent And Softener
• Add detergent into the appropriate dispenser.
• Apply softener before you start washing.
• Apply detergent and softener according to the washing
amount, the soiling level, the water hardness in your area
and the manufacturer’s instructions of these products.
• For slightly dirty clothes, put a small amount of detergent
in compartment (II) of the detergent drawer.
• For excessively dirty clothes, put ¼ of the detergent to be used in compartment (I) of the
detergent drawer and the remaining amount in compartment (II).
• Do not use the washing machine when the detergent drawer is removed. It may cause water
leak or it may not work normally.
II
I
Main wash
detergent
Softener
Pre-wash
detergent
Detergent
Detergent
Softener
M510WM16G_IB_2L_RC_160810_grace.indb 16 10/8/16 12:05 pm

GB
17
• To prevent powder detergent staying in the drawer, dry the inside of the drawer with a cloth.
Make sure the powder isn’t lumpy when you add it into the drawer.
• If the rinse cycle isn’t removing all the detergent from your wash, use less detergent.
• Softener should not exceed the MAX level in the compartment.
• Wash out unused softener with a splash of water or a damp cloth after the programme has
nished.
• You can use liquid detergents in all programmes.
• If you forget to add detergent, you can drain the washing machine by running a spin only
programme. Then you can add detergent and start the programme again. Detergent only
reaches the drum when water ushes through the detergent drawer.
Dilute viscous fabric softener and fabric conditioner with water. Prevent blockage of the
overow. Maximum level is 40ml.
M510WM16G_IB_2L_RC_160810_grace.indb 17 10/8/16 12:05 pm

GB
18
Wash Setting
Standard Washing
1. Pull the door handle and put the laundry in the
drum. (Refer to Preparation to sort your laundry
before it goes into the drum.) Make sure no washing
gets caught in the door.
2. Close the door and press the Power button.
3. Turn the Programme Selection Dial to select your
wash programme.
4. Select the temperature if desired.
5. Add detergent into the detergent drawer. The
quantity of detergent will depend on the amount
of laundry, the degree of soiling and the water
hardness. Use the amount of detergent suggested
on the packaging.
6. Press the Start / Pause button to start the washing.
7. The washing machine will sound when the
programme is complete.
Before First Use
Before washing your clothes for the rst time, run a full wash programme rst:
1. Connect the machine to the mains power supply and the water supply.
2. Put a small amount of detergent in the detergent drawer. Close the drawer.
3. Press the Power button.
4. Select a wash programme.
5. Press the Start / Pause button.
Removing Washing (Once Programme is Finished)
• Open the washing machine door and remove your washing.
• Remove any foreign objects to avoid risk of rusting.
• Leave the door and detergent drawer open so that residual water can evaporate.
Temp.
Cotton Intensive
1000
500
700
20
If the door is locked and you switched the washing machine o and then on - or if
there’s a power cut - it will stay locked for 1 minute.
Door remains locked for 1 minute after wash stopped.
M510WM16G_IB_2L_RC_160810_grace.indb 18 10/8/16 12:05 pm

GB
19
Selecting The Programme
Here are the available programmes, additional functions and option settings.
Temperature can be selected separately for certain programmes.
Procedure
Description
Load(kg)
Detergent Box Default
Temp.(˚C)
Default
Time (Min)
Default
Speed
(rpm)
Case
I
Case
II
Softener
Case
Quick 1.5 X O NA 15 1000
Cotton Intensive 5.0 X O 40 200 1000
Spin 5.0 X X X NA 15 1000
Drum clean 0 X X X 90 90 500
Underwear 5.0 X O 40 108 1000
Wool 1.5 X O 40 85 500
Synthetic 2.5 X O 40 105 700
Cotton 5.0 X O 60 130 1000
Means must
O Means optional
X Means not necessary
Energy test programme: Cotton 60˚C/40˚C (under the highest speed; others as the default)
Half load for 5.0Kg machine: 2.5Kg.
“Cotton 60˚/40˚” are the standard washing programmes to which the information in the label and
the che relates, and they are suitable to clean normally soiled cotton laundry and they are the
most ecient programmes in terms of combined energy and water consumption for washing
that type of cotton laundry, the actual water temperature may dier from the declared cycle
temperature.
Note: The parameters in this table are only for user’s reference. It is dierent from the normal
time when using depending on the temperature and the load.
• Washing times depend on programme and temperature settings selected.
• Washing times may be longer if the laundry in the drum needs to be balanced.
• For all washing programmes, please follow the detergent recommendations on the
garment label or on the detergent’s packaging.
• Depending on the programme, you may not be able to add optional functions, or
change the wash temperature when the programme is running.
• Energy and water consumption will vary according to wash load and type, extra
functions, tap water and ambient temperatures.
• The duration of 2 minutes is required before the door of your machine can be opened
is not included in the washing period.
• The actual water temperature may dier from the declared cycle temperature.
M510WM16G_IB_2L_RC_160810_grace.indb 19 10/8/16 12:05 pm

GB
20
Important Information
Washing Delicates (Wool And Silk Programmes)
These programmes rock the drum gently for best results on delicate laundry.
• Silk laundry loads: 2kg or less
• Tips for Wool programme:
Approximate Weights:
- Wool sweater (400g)
- Silk blouse / under garment (200g)
- Trousers (400g)
Adding Delicate Laundry Items To The Drum
• Close zips and buttons.
• Add items one by one on top of each other.
• Don’t overload the drum as it may cause excessive
vibrations or damage the washing machine.
Which Detergent To Use
• For woolen items, use a mild liquid detergent. Other detergents may damage your woolen
clothes.
• With wool or silk, you may need to use an extra rinse cycle to remove excess detergent from
your clothes. This depends on the amount of detergent you use, and the amount of foam that
develops in the main wash cycle.
M510WM16G_IB_2L_RC_160810_grace.indb 20 10/8/16 12:05 pm
