Maven TIBURON Guide

TIBURON
INSTRUCTIONS & INSTALLATION INFORMATION
WARNING
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL
Section 1: Safety & Warnings
Section 2: Warranty
Section 3: Dimensions & Diagrams
Section 4: Parts List
Section 5: Gas Requirements
Section 6: Set Up & Installation
Section 7: Operation
Section 8: Troubleshooting
CONTENTS
MAVEN
FIRE FEATURES

SECTION 3: DIMENSIONS & DIAGRAMS
PARTS LIST
01
04
05
06
07
24” Burner
65,000 BTUs Orifice
3/8” Flex Line Hose
Key
Gas Key Valve
03 3/8” Male Flared Fitting
02
PART NO. PART NAME QTY.
56”L x 38”W x 16”H Fire Table
Lava Rock
08
LP MODEL ONLY
3/8” Propane Hose 12ft
65,000 BTUs LP Regulator
10
11
1
1
1
1
1
1
1
1
1
SECTION 4: PARTS LIST
TOOLS REQUIRED
• Gloves
• Screw Gun with #2 phillips head tip to remove packaging.
• Box cutter to cut bands & miscellaneous plastic.
• Cresesnt wrench to attach gas line.
SPECIFICATIONS
Width
Length
Weight
Fuel Source
Ignition
Material
56”
16”
24”/65,000 BTUs
LP or NG
Key valve
Glass fiber reinforced concrete
Media Lava rock
Burner Size
360 lbs.
11”
Height
Surface
38”
3411 11
16
56
2711
56 24
38
27 LBS

We create visionary designs coupled with handcrafted processes.
Maven Fire Features is dependable, personalized products & services that capture your outdoor living area ideas down to the last detail.
Before you break ground on a new project, you first need to consider your design preferences. That means learning how to select the
perfect colors, shapes and patterns to create an outdoor living space that not only fit your yard, but your lifestyle and vision. Let
Maven Fire Features help get you there.
Phone: [phone] • Fax: [phone]
MAVEN
FIRE FEATURES
