Maxfire Torch User manual

OWNER’S MANUAL / MANUAL DEL PROPIETARIO
WARNING/ADVERTENCIA
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS
ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE CASO OMISO A
ESTAS ADVERTENCIAS E INSTRUCCIONES. LEA Y SIGA TODAS LAS ADVERTENCIAS
E INSTRUCCIONES EN ESTE MANUAL PARA EVITAR LESIONES PERSONALES,
INCLUSO LA MUERTE, O LOS DAÑOS MATERIALES.
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
NOTICE TO INSTALLER:
LEAVE THESE INSTRUCTIONS
WITH THE GRILL OWNER FOR
FUTURE REFERENCE.
AVISO PARA EL
INSTALADOR:
ENTREGUE ESTAS
INSTRUCCIONES AL
PROPIETARIO DE LA PARRILLA
PARA REFERENCIA FUTURA.
2 Burner Gas Grill
Parrilla a Gas de 2 Quemadores
Torch™

1
WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE.
THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR
ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL.
WHEN YOU SEE THE SAFETY ALERT SYMBOL
PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS!
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
DANGER
IMPORTANT SAFETY
WARNINGS
IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. Open lid.
4. If odor continues, keep away from the appliance and immediately call your gas supplier or your
re department.
1. Do not store or use gasoline or other ammable liquids or vapors in the vicinity of this or any
other appliance.
2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other
appliance.
a) Do not store a spare LP cylinder under or near this appliance.
b) Never ll the cylinder beyond 80% full.
c) If the information in (a) and (b) is not followed exactly, a re causing death or
serious injury may occur.
WARNING
DANGER

2
General Warnings ............................................3-4
LP Gas Cylinder (Tank) Specications and Installation................4-6
Hose & Regulator Specications and Installation ....................6-7
Leak Testing.................................................7-8
Pre-start Check List .............................................9
Lighting Instructions ..........................................9-10
Operating the Grill ..........................................10-11
Proper Care and Maintenance.................................12-14
Transporting and Storage........................................14
Trouble Shooting ...........................................15-16
Grill Cooking Tips..............................................16
Assembly Instructions .......................................17-26
Warranty Information ................................... Back Cover
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: Be alert to the possibility of serious bodily injury if the instructions are not followed. Be sure to read and
carefully follow all of the messages.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
www.MaxFireGrills.com
CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals, including lead in the brass of certain component parts, that are
known to the State of California to cause cancer, and birth defects or other reproductive harm.
Wash hands after handling. When used, this product emits fuel combustion chemicals that are known
to the State of California to cause cancer, and birth defects or other reproductive harm.
Follow all instructions in this manual and use only in well ventilated, outdoor area.
TABLE OF CONTENTS:

3
WARNING
 even if grill was purchased fully assembled and after
each tank rell. Check the propane tank rubber seal for damage.
 

 
 
contained in a metal smoking box to contain ash and prevent res.
 Spiders and insects like to build nests
in burner tubes. Blocked burner tubes can prevent gas ow to the burners and could result in
a burner tube re or re beneath the grill.
 
 
or combustible materials in or near your grill.
 
 
ventilation and damage to grill or personal injury may occur.
 
lift grill using side tables.
 
 
 
necessary.
 
turn gas supply OFF at once. Empty grease tray/cup and clean the hose and regulator assembly
and inspect for damage before use.
 
 
 
Use type BC dry chemical re extinguisher or smother with dirt, sand or baking soda.
 
 FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed
or breezeway.
 
safe distance 10 ft. (3.1 m) from combustible materials, buildings and overhangs.
 
an LP gas grill in your apartment complex. Only use outside on the ground (not on a balcony,

combustible material.
 
other combustible material. Not adhering to these clearances may prevent proper ventilation and
can increase the risk of a re and/or property damage, which could also result in personal injury. DO
NOT use grill under overhead unprotected combustible construction.
 
 
 
cooking surfaces prior to grilling as loose bristles may attach to food.
 
supplies/chemicals, table cloth, wood chips).
GENERAL WARNINGS:

LP GAS CYLINDER (TANK) SPECIFICATIONS AND INSTALLATION:
 
   
  
  
  
  
 
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR GAS GRILL.
FAILURE TO ADHERE TO THE SAFETY WARNINGS AND GUIDELINES IN THIS
MANUAL COULD RESULT IN SEVERE BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
WARNING
 ONLY connect this grill to a Type 1 cylinder valve. The Type 1 valve can be identied with the
large external threads on the valve outlet.
 DO NOT
 DO NOT connect to a cylinder that uses any other type of valve connection device.
 
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.
 
 
 
 
 
 
 
 
 
product.
 
excess pressure to be expelled through the vapor relief valve resulting in re, explosion, or
severe personal injury, including death.
 

obstructions and debris.
 
rubber seal. Do not use propane tank with a damaged rubber seal. A damaged rubber seal can
cause a gas leak, possibly resulting in explosion, re, severe bodily harm, or death. Inspect
rubber seal for cracks, wear or deterioration prior to use.
 
DANGER
4

5
 
 
 DO NOT 

propane gas vapors. The vapor is combustible and if it comes in contact with a spark source or
ame an explosion causing severe burns, bodily harm, or death could occur.
 
 

 
damaged rubber seal can cause a gas leak, possibly resulting in an explosion, re or severe
bodily harm.

WARNING

LP gas cylinder (not supplied with this grill)
The LP (Liquid Propane) gas cylinder specically designed to be used with this grill must be 12” (30.5 cm)
diameter x 18” (45.7 cm) tall and have a 20 lb. (9.1 kg) capacity incorporating a Type 1 cylinder valve and
an over-lling protection device (OPD).
This grill is designed to t Worthington, Manchester or SMPC brand 20 lb. (9.1 kg) cylinders. Other brand
DOT cylinders may t this grill if the cylinder has similar dimensions of the top and bottom rings.
The installation of this appliance must be in accordance with:
All applicable local codes, or in the absence of local codes, either:
• NationalFuelGasCodeANSIZ223.1NFPA54
• NaturalGasandPropaneInstallationCode:CAN/CGAB149.1
• NaturalGasInstallationCode:CAN/CGAB149.1(Canada)
• PropaneInstallationCode:CAN/CGAB149.2(Canada)
To check your local codes, see your local LP gas dealer or natural gas company. This grill was not
intended to be connected to a natural gas supply line. If an external electrical source is utilized, it must be
electrically grounded in accordance with local codes, or in the absence of local codes, with the National
ElectricalCode,ANSI/NFPA70,ortheCanadianElectricalCode,CSA22.1.
When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in
accordance with the specications for LP gas cylinders of the U.S. Department of Transportation (DOT)
ortheNationalStandardofCanada,CAN/CSA-B339Cylinders,SpheresandTubesforTransportation
of Dangerous Goods; and Commission, as applicable; and provided with a listed over-lling prevention
device (OPD), and provided with a cylinder connection device compatible with the connection for outdoor
cooking appliances.
The cylinder must also be equipped with:
 • Ashut-offvalveterminatinginaType1gascylindervalveoutlet.
 • AType1valvethatpreventsgasowuntilapositivesealisobtained.
 • Anarrangementforvaporwithdrawal.
 • Acollartoprotectthecylindershut-offvalve.
 • Asafetyreliefdevicehavingdirectcommunicationwiththevaporspaceofthecylinder.
 • Alistedover-llingpreventiondevice(OPD).


1. Check that the cylinder valve is closed by turning the knob clockwise. Inspect cylinder valve rubber
seal for cracks or deterioration. Do not use propane tank with damaged seal as a gas leak may occur.
2. Place the cylinder into the notches of the tank holder on the bottom of right legs.
3. Orient the cylinder such that the valve opening faces the right side of the grill, and the hose is not
kinked or damaged. Then slide tank brace over cylinder handle and secure tightly.
• Inspectthepropanetankvalverubbersealforcracks,
wear or deterioration prior to use. A damaged rubber
seal can cause a gas leak, possibly resulting in an
explosion, re or severe bodily harm.
• Inspectionshouldbedoneeachtimethepropanetank
is connected to the grill, has been relled, exchanged or
has not been used for more than 60 days.
• Donotuseapropanetankwithadamagedrubberseal.
Exchange the tank or have the rubber seal replaced at a
qualied propane lling station.

6
Good
Rubber Seal Damaged
Rubber Seal
Tank Support
Bracket
Tank Support Bracket
Tank Heat
Shield
Tank Brace
HOSE & REGULATOR SPECIFICATIONS AND INSTALLATION:
 
source such as a natural gas line.
 DO NOT use any other pressure regulator/hose assembly other than the one supplied with your


 DO NOT attempt to adjust or repair a regulator. The regulator is designed to operate at a

 CLOSED prior to connecting the LP gas cylinder to your grill. Turn the
valve knob clockwise to properly close the valve. Read and follow all instructions and warnings
on the supply hose safety tags. Read and follow all warnings in this manual concerning the safe
use of LP gas cylinders and the hose and regulator before connecting cylinder to grill. Read
and follow all warnings on the LP cylinder.
WARNING

7
HOSE AND REGULATOR:
Your grill is equipped with a Type 1 connection device with the following features:
1. Thesystemwillnotallowgasowfromthecylinderuntilapositiveconnectiontothevalvehasbeenmade.
Note: The cylinder valve and all grill burner knobs must be turned OFF before any connection is made or
removed.
2. Aregulatorowlimitingdevice,whenactivated,restrictstheowofgasto10cubicfeetperhour.Ifthe
owlimitingdeviceisactivated,performRegulatorResettingProcedure.
Note: Ifyourgrillwillnotgethotenoughtocook,theowlimitingdevicemayhavebeenactivated.
CONNECTING HOSE AND REGULATOR:
1. Inspect the propane tank valve rubber seal for cracks, wear or
deterioration prior to use. A damaged rubber seal can cause a gas
leak, possibly resulting in an explosion, re or severe bodily harm. Do
not use a propane tank with a damaged rubber seal.
2. Attach or detach regulator to the LP gas cylinder only when cylinder is
at rest in tank holder.
3. Check that the cylinder valve is closed by turning the knob clockwise.
4. Check that the grill’s burner control knobs are in the “OFF” positions.
5. Visually inspect the hose assembly prior to each use for evidence of damage, excess wear, or
deterioration. If found, replace the assembly before using your grill. Only the manufacturer’s supplied
replacement should be used.
6. Remove the protective plastic cap from the cylinder valve.
7. Check that the hose does not contain kinks, does not contact sharp edges, and does not contact
surfaces that may become hot during use.
8. Hold regulator and insert the brass nipple into the LP cylinder valve outlet. Ensure that the device is
centered properly.
9. Turn the large coupling nut clockwise by hand and tighten to a full stop. Take care not to cross thread
the coupling nut onto the cylinder valve. Do not use tools to tighten connection.
Note: If you are unable to make the connection, repeat Steps 7 and 8.
10. Leak check all ttings before lighting your grill. See section on “Leak Testing” in this manual.
REGULATOR RESETTING PROCEDURE:
Ifyourgrillwillnotgethotenoughtocook,theowlimitingdevicemayhavebeenactivated.
Mini Reset:
Turn ALL burner control knobs to “OFF”, turn off the cylinder valve. Wait one minute. Slowly turn
cylindervalveONandrelightgrill.Ifburnerameishigherandgrillheatsupproperly–proceedwith
cooking.
Full Reset:
Turn ALL burner control knobs to “OFF”, turn off the cylinder valve. Disconnect hose and regulator from
cylinder. Wait two minutes, reattach hose and regulator and perform leak test.
WARNING
 

LEAK TESTING:
Inspect Rubber Seal (see page 6)

8

• Afterassemblingyourgrillandbeforelightingforthersttime,evenifpurchasedfullyassembled.
• EverytimetheLPgascylinderisrelled,exchangedorifanyofthegascomponentsaredisconnectedor
replaced.
• Anytimeyourgrillhasbeenmoved.
• Atleastonceperyearorifyourgrillhasnotbeenusedformorethan60days.

CAUTION: Strong odors, colds, sinus congestion, etc. may prevent the detection of propane by smell.
Use caution and common sense when testing for leaks.
Note: The leak test must be performed in an area that has adequate lighting in order to see if bubbles are
developing and not in a windy or noisy area so larger leaks can be detected by smell or sound.
1. Create a mixture of 50% water and 50% liquid dishwashing soap.
2. Open the lid.
3. Ensure all control knobs are set to the “OFF” position.
4. Turn on the gas at the cylinder valve. Turn the cylinder valve knob counter-
clockwise to full open. If you hear a rushing sound or smell gas, turn the gas
off. Tighten any leaking connections. If leak is detected at connection nut and
tightening does not stop leak, reinspect propane tank rubber seal.
5. Apply the soapy water mixture to the following:
Supply tank (cylinder) welds.
Connection nut to tank valve.
Back side of connection nut to brass nipple.
Brass nipple connection into regulator.
Regulator connections to gas supply hoses.
Hose connection to gas manifold.
The full length of gas supply hose.
Tank valve to cylinder.
6. Checkeachplacelisted(A–H)forgrowingbubbles,which
indicates a leak. Large leaks may not be detected by bubbles but
should produce a rushing sound or gas smell.
7. Turn off gas supply at cylinder valve.
8. Turn on control knobs to release gas pressure in hose.
9. Turn control knobs to “OFF” position.
10. Tighten any leaking connections. If leak is detected at connection nut and tightening does not stop leak, reinspect
propane tank rubber seal. (see page 6)
11. Repeat soapy water test until no leaks are detected.
12. Turn off gas supply at cylinder valve until you are ready to use your grill.
13. Wash off soapy residue with cold water and towel dry.
14. Wait 5 minutes to allow all gas to evacuate the area before lighting grill.
WARNING: DO NOT use the grill if leaks cannot be stopped. Contact a qualied gas appliance repair service.
To prevent re or explosion hazard:
  DO NOT smoke or permit ignition sources in the area while conducting a leak test.
  
  
  
A
B
C
D
E
F
G
H
Watch For Bubbles
DANGER
A
B
C
D
E
F
G
H

LIGHTING THE MAIN BURNERS:
1. Open lid before lighting burner.
2. Make sure both control knobs are in the “OFF” position.
3. Push and hold down the IGNITION BURNER control knob and turn SLOWLY
(2 to 3 seconds) to “HIGH”. You should hear the igniter click.
Note: Step 3 may need to be repeated 2-3 times to light grill.
4. If ignition does NOT occur in 5 seconds, turn control knob to “OFF”, wait
5 minutes to allow gas to dissipate and repeat lighting procedure.
5. To light the other burner, push and turn control knob to “HIGH”.
9
WARNING
DANGER
Property damage, bodily harm, severe burns, and death could result from failure to follow these
safety steps. These steps should be performed after the grill has been assembled and prior to
each use. DO NOT operate this grill until you have read and understand ALL of the warnings and
instructions in this manual.
 Ensure that the grill is properly assembled.
 Inspect the gas supply hose for burns, chaffing, kinks, and proper routing before each use. If it is
evident there is excessive abrasion or wear, or the hose is cut, it must be replaced prior to the grill
being used. Replace with hose and regulator Model No. 155-9213-0, which can be obtained by
contacting customer service at 800-272-4443.
 Leak check all gas connections, hose and propane tank. See section on “Leak Testing”.
 Ensure that all electrical supply cords are properly grounded. Keep any electrical supply cord and the
fuel supply hose away from any heated surfaces. Hose should be at least 3 inches from hot surfaces.
 Position your grill on a non-combustible level surface in a well ventilated location, a safe distance
10 ft. (3.1 m) from combustible materials, buildings and overhangs.
 Properly place the empty grease cup under the grease drain hole in the bottom of the grill to catch
grease during use.
• DO NOT block ventilation areas in sides, back or cart compartment of grill.
PRE-START CHECK LIST:
LIGHTING INSTRUCTIONS:
Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip
any of the warnings and instructions contained in the preceding sections of this manual.
Follow the instructions exactly.
1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside
the grill. An explosion could occur if grill lid is down.
 
 
4. DO NOT stand with head, body, or arms over the grill when lighting.
