the network. Data transfer arrows will appear.
- Please send a text message saying: pw,123456,ts#
In response, the watch will send us the parameters of the watch. Example:
ver: G36WS_YDE_V1.1_2019.12.19_09.45.40;
ID: 1234567890;
imei: 123456789012345;
ip_url: 52.28.132.157;
port: 8001;
upload: 600S;
bat level: 96;
language: 1;
zone: 8.00;
ec: 0;
NET: OK(73);
Check the data received in the SMS with the watch number.
- If the ID / IMEI / REG CODE number is different from the badge on the watch or the bottom of
the package, set a new IMEI number.
Send an SMS from the phone to the number of the card installed in the watch:
pw,123456,imei,xxxxxxxxxxxxxxx#
Where X are the numbers from the badge - the watch, after receiving the SMS with
the code, sends back in the SMS response with the correct IMEI number, for example:
pw,123456,imei,359614514986574#
- If IP_URL and PORT are different than in the example above, send an SMS from the phone
to the number of the SIM card installed in the watch with the following content: pw,12345
6,ip,52.28.132.157,8001# - the watch will send back a text message with the following text
[surl,52.28132.157,port,8001#]ok.!
- The line from GPRS / NET should say „OK”. If it is „NO” the watch is not connected to the
network. Please follow point 8.1. The value in parentheses shows the signal strength.
ATTENTION: when writing text messages, pay attention to punctuation marks and spaces.
This is very important because if the characters are not used correctly, the commands will be
misinterpreted by the watch and will remain unanswered.
2) Could not call the watch. The signal is busy or the subscriber does not answer.
Reason: The watch does not recognize the incoming number or the app is set to do not disturb.
Solution:
- Check if the number you are calling from is unlisted.
- Check if contact numbers are set in the application.
The watch only receives calls from numbers previously set in the application’s contacts.
3) The watch does not show the current time and date.
Reason: The watch did not connect to the application server to update the time.
Solution:
- If the watch shows a few hours back, check and select the correct time zone via the app.
- If the above steps do not help, send from your phone (to the number of the SIM card installed
in the watch)
SMS with the following text: pw,123456,ntpservers,121.40.88.40,8089#
In response, the watch should send an SMS with a similar text „OK”. After that, restart your
watch.
- Additionally, you can send a configuration SMS to the watch’s SIM number with the
following content: pw,123456,time,hour.minute.second,date,year.month.day# - for example by
specifying the current time and date: pw,123456,time,09.50.00,date,2016.06.01#
