Maxsine EP3 AC Series User manual

Wuhan Maxsine Electric Co., Ltd

Wuhan Maxsine Electric Co., Ltd all rights reserved.
Without this company's written permission, forbid strictly the reprint either
the part or the complete content of this handbook.
DECLARATION
Because improves and so on the reasons, the product specification or
dimension has the change, not separate informs even slightly.

I
Safety Precautions
In order to use this product safely, the user should be familiar with and observes the
following important items before proceeding with storage, installation, wiring, operation,
inspection or maintenance for the product.
Indicates a disoperation possibly can cause danger and physical injure or
death.
Indicates a disoperation possibly can cause danger and physical injure, and
may result in damage to the product.
Indicates a prohibited actions, otherwise can cause damage, malfunction to the
product.
1. Service conditions
Do not expose the product in moisture, caustic gas, and ignitable gas situation. Otherwise
can cause an electric shock or fire.
Do not use the product in direct-sunlight, dust, salinity and metal powder places.
Do not use the product in the places that has water, oil and drugs drops.
2. Wiring
Connect the earth terminal (PE) to earth reliably, otherwise can cause an electric shock or
fire.
Never connect the input power terminals (L1, L2, L3) to 380V power supply, otherwise
can result in the equipment damage and an electric shock or fire.
Do not connect the servo motor output terminals (U, V, W) to 3 phase AC power supply,
otherwise can cause personnel casualty or fire.
The output terminals (U, V, W) must be connected with the servo motor connections (U,
V, W) correspondently, otherwise can result in the servomotor flying speed that may cause
equipment damage and the personnel casualty
Please fasten the input power terminals (L1, L2, and L3) and the output terminals (U, V,
W). Otherwise may cause fire.
Referring to wire selection guide, please install all wires with an adequate cross-section.
Otherwise may cause fire.

II
3. Operations
Before operating the mechanical device, it is necessary to set the parameters with
appropriate values. Otherwise, can cause the mechanical device to out of control or break
down.
Before running the mechanical device, make sure the emergency stop switch can work at
any time.
Performing trial run without load, make sure that the servomotor is in normal operation.
Afterwards joins again the load.
Please do not turn on and off the main power supply more frequently, otherwise can cause
the servo driver overheat.
4. Running
Do not touch any moving parts of the mechanical device while the servomotor is running,
otherwise can cause personnel casualty.
Do not touch servo driver and servomotor while the equipment is operating, otherwise can
result in an electric shock or in burn.
Do not move any connection cables while the equipment is operating, otherwise can result
in physical injure or equipment damage.
5. Maintenance and inspection
Do not touch any portion inside of the servo driver and servomotor, otherwise can cause
an electric shock.
Do not remove the front cover of the servo driver while power is on, otherwise can cause
an electric shock.
Please wait at least 5 minutes after power has been removed before touching any terminal,
otherwise the remaining high voltage possibly can cause an electric shock
Do not change the wiring while the power is on, otherwise can cause an electric shock.
Do not disassemble the servomotor, otherwise can cause an electric shock.

III
6. Service ranges
This handbook involves the product for the general industry use, please do not use in some
equipment which may directly harm the personal safety, such as nuclear energy, spaceflight,
aeronautic equipment, and life safeguard, life-support equipment and each kind of safety
equipment. Please make contact with the company if have the need of use mentioned above.

IV
