MAXTEK 66050 User manual

USER GUIDE
9” Dual DVD In-Car Entertainment System
MODEL NUMBER: 66050
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

Contents
1. Welcome Section
2. General Information & Safety Instructions
4. Contents & Features
5. Controls
7. Setup
9. Key Functions
10. Getting Started
11. Using USB, SD/MMC
12. Connecting an External Device
12. Headrest Mounting
13. System Setup
15. Specications
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

Welcome Section
Congratulations!
You have made an excellent choice with the purchase of this quality
MAXTEK®product.
By doing so you now have the assurance and peace of mind which
comes from purchasing a product that has been manufactured to
the highest standards of performance and saftey, supported by the
high quality standards of Quesh Ltd.
We want you to be compeletly satised with your purchase so this
MAXTEK®product is backed by a comprehensive manufacturer’s
3 year warranty and outstanding after sales service through our
dedicated helpline.
We hope you enjoy using this product for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty, please telephone our helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you
have a satisfactory proof of purchase (keep your receipt safe).
This does not affect your statutory rights. However be aware that the
warranty will become null and void if the product is found to have
been deliberately damaged, misused and/or disassembled.
1
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

• Never throw batteries into a re or expose to excessive heat sources.
• If batteries are swallowed, please seek mmediate medical attention.
• Always ensure correct +/- battery polarity when installing batteries.
• Do not recharge non-rechargeable batteries.
Equipment, which is marked with the WEEE logo
(as shown on the left), should not be thrown away with your household waste.
Contact your local authority waste disposal department, as they will be able to
provide details of the recycling options available in your area.
Electrical and electronic equipment (WEEE) contains materials, parts and
substances, which can be dangerous to the environment and harmful to
human health if the waste of electrical and electronic equipment (WEEE) is not
disposed of correctly.
Equipment, which is marked with the WEEE logo
(as shown on the left), should not be thrown away with your household waste.
Contact your local authority waste disposal department, as they will be able to
provide details of the recycling options available in your area.
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
2
General information &
Safety Instructions
CAUTION:
Safely secure any excess wiring to avoid trip hazards, tangling or possible
damage to this product.
This remote control is powered by 1 x ‘CR2025’ battery.
Do not dispose of batteries in your household waste.
Please contact your local authority for details on safe disposal.

3
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
General information &
Safety Instructions
Please read the following safety information before use.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
C A U T I O N
•To avoid risk of electric shock do not attempt to open this appliance.
•Keep away from re.
•Do not expose the appliance to water, rain or dampness.
•Keep this appliance away from direct sunlight and other heat sources.
•Keep this appliance away from strong magnets.
•Never cover the ventilation slots on the underside or back of the appliance.
•Avoid placing heavy objects on top of the appliance.
•Always disconnect the appliance from mains power before cleaning.
•Clean the exterior of the appliance with a soft cloth only.
•The instructions for use shall state that the appliance shall not be exposed to
dripping or splashing and that no objects lled with liquids such as vases,
cups, etc, shall be placed on the appliance.
•CAUTION: Danger of explosion if the battery is incorrectly replaced. Replace
only with the same equivalent type.
•Where the MAINS plug or appliance coupler is used as the disconect device,
the disconected device shall remain readily operable.
•Where an all-pole MAINS SWITCH is used as the disconnect device, the
location on the apparatus and the function of the switch shall be described,
and the switch shall remain readily operable.
NEVER LEAVE CHILDREN UNATTENDED WITH
ELECTRICAL EQUIPMENT

4
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Contents & Features
Contents
2 x 9” DVD players
1 x Remote Control
1 x 9.5V Mains adaptor
1 x 12V In-car adaptor
1 x AUX cable
1 x Power Splitter
1 x 3.5mm to RCA cable
2 x Headrest mounting straps
Features
• 9” digital screens with independent DVD players
• PAL/NTSC/Auto
• USB port
• SD/MMC port
• JPEG picture format supported
• DVD, AVI, MPEG4 & DIVX video formats supported
• CD audio format supported
• 9.5v mains adaptor (included)
• 12v in-car adaptor (included)
• Remote control (included)
• Headphone output
• AV output
• AV input
Region Encoding
In compliance with DVD patent requirements, the region code
for this DVD player it is region 2.

Controls
5
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
DVD PLAYER CONTROLS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
ON/OFF SWITCH
LCD TFT MONITOR
VOLUME -
VOLUME +
PLAY/PAUSE
POWER INDICATOR
INFRARED RECIEVER
CHARGE
REWIND
FAST FORWARD
OPEN
DC IN (9.5-12v)
DC OUT
USB PORT
MEMORY CARD SLOT
AV OUT
HEADPHONE JACK

Remote Control
TFT ON/OFF
MODE
MUTE
TFT
ON/OFF
MUTE
MODE
Battery Installation/removal
Please Note:
Battery type required is ‘CR2025’
6
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

Setup
Setting up one screen
Connect the chosen adaptor to the power outlet and the other end
in to the ‘DC in’ socket on the DVD player.
Charging the Battery
The DVD players uses a built in lithium-polymer rechargeable
battery. To charge the DVD player connect the adaptor as shown in
the diagram above. It takes 6 hours to fully charge the battery. The
LED indicator will change from red to green when it is fully charged.
After a full charge the battery can be used for up to 3 hours.
Use the power splitter to charge both DVD players simultaneously.
Please Note:
Keep away from heat sources when the unit is charging as the unit will become
hot during charging.
Or
Mains Adaptor
In-Car
Adaptor
DC in
Either Screen
7
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

Setup
DC in
DC in
AV out
AV in
AUX Lead
Or
Mains Adaptor
In-Car
Adaptor
Chosen Primary
Screen
Chosen Secondary
Screen
Setting up both screens
Both screens are capable of sharing video content with each other.
Please follow the diagram below to setup the secondany screen to
receive the output video feed from the chosen primary screen.
Select AV1 on the secondary screen to view the output by pressing
‘MODE’ on the remote.
8
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Power Splitter

9
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
The functions of each key are detailed below. The main function keys
appear both on the the remote control (RC) and the DVD player.
Zoom To enlarge the picture
Mode DVD and external audio and video input conversion
Number Key For inputting number digits
Prev/Up To skip Backward / To Move up in the Menus
Angle Switch between multiple camera angles
Rev/Left Reverse/moving left In menus
Enter Enter is used for selecting
Setup To Enter the Setup menu
Next/Down To skip forward / to move down in the menus
Repeat To repeat the selection
Prog To play contents of disc in the order you want by,
programming the track to be played
Slow To slow the DVD down
Mute To mute the DVD player
Audio To change the audio setting.
Subtitle To switch subtitles and turn on or off
Play/Pause To play or pause
Stop To Stop the DVD
FWD/Right Forward/moving right In menus
Volume To adjust the volume level
Title To Show the DVD title
DVD/USB/Card To select between DVD, USB and card input
Menu To access the DVD player menu
Play / Pause Stop
Skip Back Chapter Skip Next Chapter
Rewind Fast Forward
(x2, x4, x8, x16, x32) (x2, x4, x8, x16, x32)
Key Functions

10
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Basic DVD Operation
• Before rst time use, open the disc cover and carefully remove and
discard the white cardboard dust cover from inside both decks
marked “Warning: Please take out this card before playing”.
• Remove all transparent lm protection from the DVD players.
• Connect the mains power adaptor to the mains outlet and the
DC in socket.
• Turn the power switch on the right-hand side panel to ‘ON’ .
• Insert a DVD and press the play button.
Connecting to a TV (RCA cable Included)
You can connect the DVD player to a TV so that your movies,
pictures and music can be played on your larger screen.
• Insert the 3.5mm jack end of the 3.5mm to RCA cable into the
AV out port on the master screen.
• Connect the three RCA plugs to the corresponding coloured ports
on your TV, normally located on the back.
• Choose the correct AV channel on your TV to view the content of
the DVD player.
Please note:
If your TV does not have a ‘RCA in’ port, you may need a RCA to SCART adaptor
to use this function, if a SCART port is available.
Getting Started
(Either Screen)

11
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Memory Cards
• Connect the SD/MMC card into the named port on the side.
• Press and hold the ‘DVD/USB/CARD’ button to enter the
DVD/USB/CARD mode.
• Use the up/down arrow keys to highlight ‘Card Mode’ and press the
‘Enter’ button to select it.
• Press the ‘Play’ button to play selected media from the memory
card.
USB Memory Stick
• Connect the USB memory stick into the named port on the side.
• Press and hold the ‘DVD/USB/CARD’ button to enter the
DVD/USB/CARD mode.
• Use the up/down arrow keys to select ‘USB Mode’ and press
‘Enter’.
• Press the ‘Play’ button to play selected media from the USB
memory stick.
Please note:
Make sure the memory card or USB stick storage is no bigger than 8Gb and
formatted to FAT32. You can do this through a computer/laptop. Video le formats
must be in DVD, AVI, MPEG4 or DIVX.
Using the USB,
SD/MMC Slot

12
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Connecting a Device (RCA cable Included)
You can connect the output of a device that uses RCA out to this
DVD player and show the image or video feed.
• Insert the 3.5mm jack end of the 3.5mm to RCA cable into the
‘AV in’ port on the screen.
• Connect the three RCA plugs to the corresponding coloured ‘RCA
out’ ports on your chosen device.
• Press ‘mode’ on the DVD player and switch it to ‘AV in’. This will now
show the connected live feed on the DVD player.
Connecting external devices
(Either Screen)
Headrest Mounting
To attach the DVD screen to the headrest, thread the velcro strap
through the loops on the back of the screens.
Then wrap the strap tight around the headrest and fasten securely
with the velco straps.

13
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
System Setup
System Setup
Press SETUP on the remote control or DVD player to enter the Setup
Menu. Here you will nd the following options:
General Setup, Audio Setup, Dolby Digital Setup, Video Setup and
Preference Page.
You can navigate through the menus with the arrow buttons
indicated around the outside of the enter button. and select an
option with enter button on the remote control.
General Setup Page
FUNCTION
TV Display
Angle Mark
OSD Language
Captions
Screen Saver
Last Memory
OPTION
Normal/PS, Normal/LB, Wide.
On / Off.
English, French, German, Italian,
Spanish, Portuguese.
On / Off.
On / Off.
On / Off.
Audio Setup Page
FUNCTION
Speaker Setup
OPTION
Downmix, LT/RT, Stereo.

14
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Dolby Digital Setup Page
FUNCTION
Dual Mono
Dynamic
OPTION
Stereo, L-Mono, R-Mono,
Mix-Mono.
DRC slider, Off to Full.
Video Setup Page
FUNCTION
Panel Quality
Sharpness
Brightness
Contrast
Hue
Saturation
OPTION
Quality Panel Setup.
High, Medium, Low.
Range select -18 to +18.
Range select -12 to +12.
Range select -9 to +9.
Range select -9 to +9.
Preference Page
FUNCTION
TV Type
Audio
Subtitle
Disc Menu
Parental
Password
Default
OPTION
PAL, NTSC, Auto.
Language selection list.
Language selection list.
Language selection list.
KID SAF, G, PG, PG13, PGR, R,
NC17, ADULT.
On / Off, Change / Set Password.
Reset

15
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Specifications
Compatible Disc Formats DVD, DVD-R, DVD+R/RW, CD, CD-RW
Compatible Video Formats DVD, AVI, DIVX, MP4
Compatible Image Formats JPEG, JPG
Panel Size 9 Inches
Frequency Response 20Hz to 20KHz
Video Output 1Vp-p75 0Hm unbalanced
Audio Output 1.8Vrms/10K 0Hm
Dynamic Range Greater than 85Db
Laser Semiconductor laser,
Wave length: 650Nm/795Nm
Power Source DC-9.5V - 1.5A
Power Consumption 14.3W
Operation Temperature 5-40oC
Battery Type Lithium-Polymer
Car Adaptor Fuse 3A

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Warranty Certificate
Warranty
This product is warranted to be free from defects in workmanship and parts for a period of 36 months
from the date of purchase. Defects that occur within this warranty period, under normal use and care,
will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and
labour. The benets covered by this warranty are in addition to all rights and remedies in respect of the
product the consumer has under existing U.K. laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable.
Please keep your purchase receipt as proof of purchase and as proof of the date of when the purchase
was made. The receipt must be presented with the warranty card when making a claim under this
warranty.
Service during the Warranty Period
Please ensure the product is properly packaged so as to ensure that no damage occurs in transit. Also
make sure that you have included a detailed explanation of the problem.
Extent of the Warranty
This warranty is limited to defects in workmanship or parts. All defective products or parts will be
repaired or replaced. This warranty does not extend to accessories.
Normal Wear and Tear
This warranty does not cover normal wear and tear of the product or parts.
Exclusions
This warranty does not cover the following:
• Any defect caused by accident, misuse, abuse, improper installation or operation, lack or reasonable
care, unauthorised modication, loss of parts, tampering or attempted repair by a person not
authorised by the distributor.
• Any product that has been damaged by lightning strike either directly or indirectly, or on a main’s
or vehicle outlet power surge or liquid ingress.
• Any product that has not been installed, operated or maintained in accordance with the
manufacturer’s operating instructions provided with the product.
• Any product that has been used for purposes other than domestic use.
• The product if it is located outside of the U.K. and Ireland
• Any damage caused by improper power input or improper cable connection.
This warranty does not affect your statutory rights.

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Warranty Card
9” In-Car DVD Player
Please keep your purchase receipt together with your warranty card
Fault Description:
Name:
Address:
Date of purchase:
Location of purchase:
Service Helpline
QUESH LTD,
B7, FIRST BUSINESS PARK
FIRST AVENUE, CREWE, CHESHIRE.
CW1 6BG
We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this
warranty card and keep it for your reference. In the event of a product fault, please call the After Sales
Support team. Please ensure that you have the product details (as shown on this card) to hand so that
the support team are able to respond as quickly and efciently as possible.
Model Number: 66050
