SkyBox™ by Maytag™
Personal Beverage Vendor
Model # MBV1976AA
The bragging rights are all yours. Congratulations on your purchase
of the SkyBox™ by Maytag™ personal beverage vendor. It’s time to
assemble your SkyBox™ personal beverage vendor, stock it with your
favorite cans or bottles, and give your buddies a call. Don’t be
surprised if they spend more time checking out the SkyBox™
personal beverage vendor than they do the instant replays!
Table of Contents
Important Safety Instructions........................................ 1-2
Product Overview.................................................................... 3
Assembly ............................................................................... 4-9
Operation.......................................................................... 10-11
Features ................................................................................... 12
Maintenance.......................................................................... 13
Before You Call For Service.............................................. 14
Warranty/Customer Service ............................................. 15
Français .....................................................................................16
Espagnol
.....................................................................................32

1
Important Safety Instructions
WARNING – Hazards or unsafe practices which
COULD result in severe personal injury or death.
WARNING
DANGER – Immediate hazards which WILL result
in severe personal injury or death.
DANGER
CAUTION – Hazards or unsafe practices which COULD
result in minor personal injury or property damage.
CAUTION
What You Need to Know About
Safety Instructions
Warning and Important Safety Instructions appearing in
this manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining or operating this appliance.
Always contact your dealer, distributor, service agent or
manufacturer about problems or conditions you do not
understand.
Recognize Safety Symbols, Words,
Labels
Child entrapment and suffocation are not problems
of the past. Junked or abandoned refrigeration
products are still dangerous…even if they will sit for
“just a few days”. If you are discarding an old
SkyBox™ product, please follow the instructions
below to help prevent accidents.
•Remove the SkyBox™
personal beverage vendor
door (see page 13).
•Leave the storage bins in
place so that children may not
easily climb inside the unit.
DANGER
Electrical Grounding Instructions – This appliance
is equipped with a (3-prong) grounding plug for
your protection against shock hazard. It should be
plugged directly into a properly grounded
receptacle. Do not cut or remove the grounding
prong from this plug. If the plug fails to fit into an
existing outlet, contact a qualified electrician to
update the outlet.
Your SkyBox™ personal beverage vendor should not,
under any circumstances, be operated when not
properly grounded.
WARNING

2
Important Safety Instructions
To reduce risk of fire, electric shock, serious
injury or death when using your refrigerated unit
and stand, follow these basic precautions,
including the following:
1. Read all instructions.
2. To prevent injury, children should not climb, hang
or stand on any part of this refrigerated unit or
stand.
3. Use the refrigerated unit and stand only for their
intended purpose.
4. Observe all local codes and ordinances.
5. To prevent the possibility of hazard due to
electrical shock, never plug the refrigerated unit
in to a receptacle that has not been grounded
adequately and in accordance with the local and
national electrical codes. See warning and the
grounding instructions that follow.
6. Do not use a 2-prong adapter, extension cord or
power strip.
7. Disconnect the power cord to the refrigerated unit
before loading cans or bottles into it, cleaning,
servicing or replacing a light bulb. Disconnect
power cord by grasping the plug, not the cord.
8. The refrigerated unit power cord should be
immediately repaired or replaced if it becomes
frayed or damaged or if the plug will not fit
securely into the electrical outlet.
9. To prevent fire hazard, your refrigerated unit
should not be operated in the presence of
gasoline or other flammable vapors and liquids.
10. Keep your SkyBox™ personal beverage vendor in
good condition. Bumping or dropping the
personal beverage vendor and/or SkyBase™ stand
can damage them or cause them to malfunction
or leak. If damage occurs, contact a qualified
service technician for repair.
11. Always read and follow manufacturer’s installation
and operation instructions for items being stored
in refrigerated unit. Load cans or bottles into the
personal beverage vendor as described in this
guide.
12. Do not lift or move the personal beverage vendor
and/or SkyBase™ stand when it is loaded with
beverages or when the door is open.
13. The SkyBox™ personal beverage vendor is not
designed to dispense food items other than the
designated beverage containers outlined within
this guide.
14. Do not kick, pound, or push on the personal
beverage vendor and/or stand, as this may cause
the unit to tip or may damage the refrigeration
system.
15. The SkyBox™ personal beverage vendor is
designed to hold beverage containers within the
designated beverage shelf on top of the main
unit. Do not place additional items on top of the
unit.
16. Do not attempt to place fingers, hands or arms
through the beverage dispenser opening. If a
beverage jams in the SkyBox™ personal beverage
vendor, clear the jam using the instructions
provided on page 13 of this guide.
WARNING
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Important Safeguards

3
Product Overview
SkyBase™ Stand (optional) –A sturdy, level stand that
is able to support approximately 200 pounds of weight
and will safely accommodate your fully stocked personal
beverage vendor. SkyBox™ personal beverage vendor
securely mounts to the SkyBase™ stand. To purchase, visit
your local retailer or www.skyboxbymaytag.com.
SkyBox™ by Maytag Personal
Beverage Vendor – Refrigerated unit
with front door. Opens for easy access to
four beverage storage bins. Fully stocked,
the unit will hold 64 12-ounce cans or
32 12-ounce bottles.
Beverage Cards - Your
SkyBox™ personal beverage
vendor comes with a set
of commonly requested
beverage cards that can be
used to label the beverage
selection buttons. To
purchase additional
beverage cards, visit
www.skyboxbymaytag.com.
Display Panels – Panels
slide into the front and
sides of the main unit.
Your SkyBox™ personal
beverage vendor comes with
a standard front panel. To
purchase customized, inter-
changeable front and side
panels that feature your
favorite sports team, visit
www.skyboxbymaytag.com.
Front Display Graphic –
Packaged with the SkyBox™
personal beverage vendor.

4
Assembly
Dimensions
Once assembled, the Skybox™ (main unit mounted on
stand) has the following dimensions:
Installation Location
•SkyBox™ personal beverage vendor is designed for
indoor use only with room temperatures between

5
STEP 3 – Install Shelves
STEP 2 – Level the Stand
Stand Assembly
Carefully unpack the stand parts (see below) from the
packaging.
Tools Needed:
•#2 phillips head screw driver • Level
•Adjustable Wrench
Parts Quantity
AEnd Frame.......................................................................................................2
BLong Support Rail.......................................................................................4
CRear Leveling Legs (attached to end frames)..............................2
DShelves..............................................................................................................2
EPan-Head Screws.....................................................................................24
FLeft Side Panel (with hinge holes) .....................................................1
GRight Side Panel (with no hinge holes)...........................................1
HBack Panel......................................................................................................1
IDoor....................................................................................................................1
JHinges (attached to the door)..............................................................2
KFront Foot.........................................................................................................2
LM5 x 16 Hex-Phillips Head Cap Screw -
5
⁄ 8 ” (16mm) long....6
MFront Foot Leveling Head........................................................................2
NFlat Head Screws.........................................................................................6
FF M5 x 20 Hex-Phillips Head Cap Screw -
3
⁄ 4
” (20mm) long....2
C
STEP 1 – Assemble Frame of Stand
A
B
K
M
Lx 3 K/M

6
Assembly
•Place back panel (H) over frame and side panels by
aligning screw holes on the back of the unit. Attach
back panel using six pan-head screws (E). During
this process, the screws will also secure the back of
the left and right side panels.
STEP 4 – Assemble Exterior Panels
F
E
G
H
F
E
G
E
STEP 5 –Attach Door to
SkyBase™ Stand
N/J I
E
F
•Lower the top lip of the left side panel (F) over the
top of end frame, aligning screw holes in side panel
with holes in the corner post. Make sure panel is
positioned to accommodate hinges for door on front
left side. Attach panel by installing three pan-head
screws (E) down the front of the unit and two pan-
head screws (E) along the top rail.
•Position the right side panel (G) over frame of
cabinet, aligning screw holes in side panel with holes
in corner post. Attach panel by installing
three pan-head screws (E) down the front of each
side panel and two pan-head screws (E) along the
top rail.
•Position door (I) on the front of the stand by aligning
screw holes in the hinges (J) with hinge holes in the
left side panel on the front of the stand.
•Attach door hinges (J) to the left side panel (F)
using three flat-head screws (N) in each hinge.

7
SkyBox™ Personal Beverage
Vendor Top and Door
Assembly (Select Packaging Only)
Carefully unpack the SkyBox™ personal beverage
vendor from the packaging.
If needed, follow these instructions for attaching the
door to the main unit of your SkyBox™ personal
beverage vendor.
Parts Quantity
Top Cover .........................................1
Main Unit .........................................1
Door ...................................................1
Door Wire Harness.......................1
STEP 1 –Attach Top Cover
•Slide hooks at front of top panel into slots at front of
main unit.
•Press top cover down in back so 3 tabs snap
securely into place onto back of main unit.
Assembly
STEP 2 – Attach Door
•Align hinges of door to hinge
posts on the main unit. Hold
door at an angle (greater
than 90°) from the main unit
opening. (Note: For your safety,
the door will not attach or
detach at a 90° angle.)
•Slide hinges down onto hinge
posts. Door will slide on easily.
DO NOT FORCE.
STEP 3 – Attach Door Wire Harness
•Attach one end of door wire harness to plug-in on
lower left corner of main unit opening, aligning plug
with small tab facing up to fit plug-in. Note: plug will
only fit one direction. DO NOT FORCE.
•Attach other end of door wire harness to plug-in on
lower right corner of door, aligning plug with small
tab facing up to fit plug-in. Note: plug will only fit
one direction. DO NOT FORCE.

8
SkyBox™ Personal Beverage
Vendor Main Assembly
Tools Needed:
•Phillips head screw driver
Parts Quantity
AA Graphic Access Cover ...........................1
BB Front Display Graphic ............................1
CC Clear Panel.................................................1
DD Light bulbs..................................................2
EE Beverage Cards........................................4
FF Connecting Bolts: M5 x 20 ...................
Hex-Phillips Head Cap ............................
Screws - 3⁄4 ” (20 mm) long...................2
STEP 1 – Install Light Bulbs
•Make sure SkyBox™ personal
beverage vendor is OFF and
the power cord is unplugged.
•Flip up the graphic access
cover (AA), exposing a screw
and the top edge of the front
graphics panel.
•Remove the screw.
•Slide the front display graphic
(BB-see page 3)up and out
of the personal beverage
vendor.
•Lift the clear panel (CC) up
and out of the unit, exposing
the sockets for the light bulbs.
STEP 2 – Install Beverage Cards
STEP 3 –Attach SkyBox™ Personal
Beverage Vendor to
SkyBase™ Stand
Assembly
•Place the SkyBox™ personal beverage vendor on the
SkyBase™ stand.
•IMPORTANT: Line up holes on bottom of SkyBox™
personal beverage vendor with holes in top of
SkyBase™ stand. Carefully thread a connecting bolt
(FF–see illustration)into each hole up through the
inside of the stand and into the hole in the SkyBox™
personal beverage vendor. Secure firmly.
FF
•Bend beverage cards (EE) back at score line, so
small fold is away from printed side.
•Gently pull out the bottom edge of the beverage
buttons toward you and slide the beverage cards
(EE) into the buttons, sandwiching them in the small
slit between the clear plastic.
EE
•Remove the two 18" fluorescent light bulbs, type
F15T8 15 watt (DD) from their packaging and install
by sliding them into the light sockets and rotating
away from you until they click into place.
•Replace the clear panel (CC) and slide the front
display graphic (BB) back into place in front of the
clear panel, behind the lower edge of the frame
opening.
DD
•Reinsert the screw.
•Flip the graphic access cover (AA) back down into
place.
AA
CC

9
Assembly
Changing SkyBox™
Display Graphics
Your SkyBox™ personal beverage vendor comes with a
standard front panel. To purchase customized,
interchangeable front and side display graphics visit
your local retailer or www.skyboxbymaytag.com.
•Make sure SkyBox™ personal beverage vendor is
OFF and the power cord is unplugged.
STEP 1 – Install Side Display Graphics
•Remove top of SkyBox™ personal beverage vendor
by lifting up the tabs at rear of top panel. Pull top
cover back slightly to remove from frame. Set aside.
•Slide one customized display graphic into each side
of the SkyBox™ personal beverage vendor, tucking
the panels in at the bottom within the grooves in the
frame.
•Replace the top cover by sliding hooks into front and
then pressing down tabs at the rear.
•Flip up the graphic access cover, exposing a screw
and the top edge of the front display graphic.
•Remove the screw.
•Gently press hands onto front display graphic within
frame and slide it up and out of the personal
beverage vendor.
•Slide the new customized display graphic into the
frame, making sure the panel slides behind the lower
edge of the frame opening.
•Flip the display graphic access cover back down into
place.
STEP 2 – Change Front Display Graphic

10
Operation
1. ASSEMBLE the stand and personal beverage
vendor (see pages 4-9).
2. LOAD personal beverage vendor with beverages
(see below).
3. PLUG UNIT IN to grounded 3-prong outlet.
4. TURN LIGHTS on by pressing switch on the right
side of the personal beverage vendor above the
keyhole.
5. SET THERMOSTAT dial found inside the main unit
in the upper left hand corner by turning dial
clockwise to desired temperature. The further you
turn the dial, the colder the temperature.
6. ALLOW TO COOL. After the personal beverage
vendor is initially plugged in, it will take
approximately 3-4 hours to chill your beverages.
7. SERVE yourself and your guests by pressing the
corresponding button for the beverage of your
choice.
Child Lock-Out
The SkyBox™ personal
beverage vendor comes
equipped with a Child Lock-
Out feature. Simply open the
door to the personal
beverage vendor and lock
each storage bin (or only
those bins you wish to lock).
To lock, slide down the small
switch at the right end of the
corresponding storage bin. To unlock the storage bin,
slide the switch at the right end of that bin up.
IMPORTANT: The Child Lock-Out controls which
beverages are dispensed from the SkyBox™ personal
beverage vendor. However, to completely secure
access to beverages, be sure to use the key provided
to LOCK THE DOOR to the main unit.
Loading SkyBox™ Personal
Beverage Vendor With
Beverages
Your SkyBox™ personal beverage vendor is designed to
hold a total of approximately 64 cans, 32 bottles or a
combination of both. When stocking your unit, keep
the following points in mind:
•Beverage containers should be a
minimum of 2.35" (60 mm) and a
maximum of 3" (76 mm) in
diameter.
•Beverage containers should be
round, since the dispensing system
works in combination with gravity,
and the containers need to be able to roll.
•Beverage containers should be no taller than the
equivalent of 2 standard soda cans stacked on top of
each other or 9.75” (247 mm).
Loading Tips:
•For smooth operation, avoid mixing cans and
bottles within a single storage bin.
•For beverages that are known
to be highly carbonated
(such as high foaming
beer), load
beverage
containers into
the lower 2 bins to
limit fizzing and spillage.
9.75"
(247 mm)
Maximum
Place your
beverage container
here to check size.
2.35" (60 mm)
Minimum
3"
(76 mm)
Maximum

11
Beverage Options
The following beverage containers will fit in the main
unit of your SkyBox™ personal beverage vendor.
12-ounce aluminum beverage cans
12-ounce glass beverage bottles
12-ounce plastic beer bottles
20-ounce plastic water and soda bottles
Each storage bin within the main unit is equipped to
dispense bottles or cans.
Highly Carbonated Beverages: Stock lower storage
bins with highly carbonated beverages and make sure
they are chilled before dispensing. To avoid overflow
spills when experimenting with new, highly carbonated
beverages, wait 10-15 seconds before opening
dispensed beverage containers, and open carefully
over the sink.
Capacity: The top storage bin will hold 10 cans or
5 bottles. The bottom 3 storage bins will each hold 18
cans or 9 bottles.
Important Steps For Loading
Please follow loading instructions. Improper loading
may cause the “low-indicator light” above the beverage
buttons to illuminate prematurely.
1. Make sure the main unit is OFF and the power
cord is unplugged.
2. Open the front door to the main unit, exposing the
four storage bins.
3. When loading the beverage containers, be sure to
load with the TOPS TOWARD THE FRONT
(i.e. long-neck bottles with necks towards the
front).
4. IMPORTANT - Begin loading the left end of the
storage bin, placing one beverage container on its
side all the way to the back with the top facing
forward. If loading cans, push the first one all the
way to the back and then place one directly in
front.
5. Next, move one space to the right and place
another beverage container all the way to the back.
If stocking cans, add another directly in front. (See
illustration at bottom of page.) Continue until the
storage bin is filled. Repeat with remaining storage
bins.
6. Once the bins are filled, close the door, plug the
power cord into a grounded outlet.
7. Insert corresponding
beverage cards into the
beverage selection
buttons by carefully
pulling the bottom edge
of the buttons forward
and up and slipping in
the cards. The far left button corresponds to the
top storage bin. The next button to the right
matches the storage bin that is second from the
top, etc.
Operation

12
Features
5. Customized Display Graphics – Show off your
true colors with interchangeable front and side
graphics. Unlike your old fridge, the front graphic
illuminates just like commercial vending machines.
As each new sports season begins, change out
your graphics with a new logo. To order new
graphics, visit your local retailer or
www.skyboxbymaytag.com.
6. Beverage Selection Buttons – Insert beverage
cards for your favorite beverages, and press the
buttons to serve yourself and your guests. Unlike
industrial vending machines, the SkyBox™ personal
beverage vendor operates without coins or dollar bills.
7. Interchangeable Beverage Cards – Your
SkyBox™ personal beverage vendor is packaged
with 20 beverage cards featuring the top
beverages. The beverage buttons carefully pull
forward and up, allowing you to insert any card you
choose. Order additional brands or replacement
cards online at www.skyboxbymaytag.com.
8. Auto-off Sensor – For safety purposes, any time
the door to the refrigerated main unit is opened,
the unit will not vend.
9. Low-Indicator Light – Avoid being caught with
warm drinks. When your beverage bins get low
(3 bottles or 6 cans remaining), the low-indicator
light will illuminate above the beverage button to
signify that it’s time to restock.
10. Anti-Fizzing – The specially designed SkyBox™
personal beverage vendor beverage dispenser
smoothly delivers your beverages with little shaking
or jostling. That means less foaming when you
open your cans or bottles. Be aware that warm
beverages are more likely to fizz. Cool beverages
prior to dispensing. Refer to pages 10-11 for tips
on loading highly carbonated beverages.
11. Jam Detector – In the unlikely event that your
unit experiences a jam, the low-indicator lights will
flash to identify the problem. Turn the unit off and
unplug the power cord before opening the unit to
inspect for jams. Refer to page 13 for proper steps
to prevent jams.
12. Child Lock-Out – For the safety of children or to
control curious pets, your SkyBox™ personal
beverage vendor is equipped with a child lock-out
feature. Lock individual beverage options or lock
them all with an easy flip of a switch. See page 10
for details.
13. Main Unit Door Keylock – Store your beverages
securely by locking the door to your main unit using
the keyhole on the right side of the main unit.
1. Personal Beverage Vendor/Main Unit – The
main refrigerated unit is equipped with four
storage bins that combine to store up to 64 cans or
32 bottles. Available in either Pitch Black or Grid
Iron Platinum, the main unit is designed to
complement your customized display panels.
2. Beverage Shelf – The top front area on the
personal beverage vendor is designed to hold
beverage containers.
3. SkyBase™ Stand – Your SkyBase™ stand,
available in Pitch Black or Grid Iron Platinum, safely
supports your fully stocked personal beverage
vendor. It also offers additional room temperature
storage space and includes a shelf.
4. Power Cord – The power cord is designed to
operate on a normal 120VAC, 15 amp, 60 cycle line.
For your safety, it is equipped with a grounded,
3-prong plug.
1
2
3
4
55
6,7
9
12
13

13
Maintenance
Cleaning
To avoid electrical shock, which can cause severe
personal injury or death, unplug the refrigerated
personal beverage vendor unit before cleaning.
The modular design of your SkyBox™ personal
beverage vendor allows for easy cleaning. Most spills
can be cleaned up with a damp cloth or sponge. If
using a household cleaner, choose a mild, non-
abrasive cleaner that will not scratch or dull the
surface of your unit. Do not allow beverage spills to
stand; clean up right away.
To avoid spills, do not store previously opened or
partially consumed bottles/cans in the SkyBox™
personal beverage vendor.
Removing The Door
1. Make sure the main unit is OFF and the power
cord is unplugged.
2. Unplug the door wire harness from the lower right
corner of the door and the lower left corner of the
personal beverage vendor.
3. Open the door wider than a 90° angle.
4. Lift the door up, releasing the door hinges from the
hinge posts.
Clearing Jams
If a jam occurs, the low-indicator lights will flash to
indicate the problem. If a single light is flashing, this
indicates that the jam is located within the corres-
ponding storage bin. If all lights are flashing, this
indicates the jam is most likely located in the dispens-
ing pathway. Most jams result from improper loading,
so please refer to pages 10-11 for proper loading
instructions.
To clear a jam open the SkyBox™ personal beverage
vendor door and inspect the dispensing pathway and
the storage bins. Remove or readjust the location of
the beverage containers.
Opening the door to clear the jam will eliminate the
blinking lights.
Consider the following checklist.
•Have you loaded the beverage containers on their
sides all the way to the back with the tops facing
forward?
•Are your beverage containers no more than 3" in
diameter?
•Are you using cans or bottles of odd shapes or
sizes? If so, loading your SkyBox™ personal beverage
vendor with a single row of that product may help to
reduce jams.
•Is your personal beverage vendor crowded beyond its
capacity?
•Has the personal beverage vendor fully cooled
down? Some jams are more likely to occur when the
vendor is first plugged in and has not fully cooled.
Replacing Display Panel Light
Bulbs
1. Make sure SkyBox™ personal beverage vendor is
OFF and the power cord is unplugged.
2. Flip up the graphic access cover, exposing a screw
and the top edge of the front display panel.
3. Remove the screw.
4. Slide the front display graphic up and out of the
personal beverage vendor.
5. Lift the clear panel up and out of the unit, exposing
the sockets for the light bulbs.
6. Remove bulbs by rotating the bulbs toward you.
7. Install new 18" fluorescent bulbs type F15T8, 15
watt by sliding them into the light sockets and
rotating the bulbs away from you until they click
into place.
8. Replace the clear panel and slide the front display
graphic back into place in front of the clear panel,
behind the lower edge of the frame opening.
9. Reinsert the screw.
10. Flip the graphic access cover back down into place.
WARNING

14
Before You Call For Service
PROBLEM
The low-indicator lights are on, but the
main unit is not low on beverages.
The low-indicator lights are flashing rapidly.
No beverages dispense when beverage
button is pushed.
Beverage center is not cooling.
Beverage container jams.
POSSIBLE SOLUTION
The main unit may be improperly loaded, which will cause
the low-indicator light to illuminate prematurely. For
example, if cans or bottles are not pushed all the way to
the back of the unit, this will cause the low-indicator light
to illuminate. Refer to proper loading instructions on
pages 10-11.
The main unit may be jammed, and the light is indicating
the problem. Refer to page 13 to clear the jam. To eliminate
the blinking lights, simply open and close the personal
beverage vendor door.
Make sure unit is loaded with beverages. Beverages
should be loaded on their sides, all the way to the back,
with the tops facing towards the front.
The Child Lock-out feature may be activated. Open the
door to the main unit and make sure the lock at the right
end of the each storage bin is open (upright position).
Check for possible jams. See page 13.
NEVER kick, pound or push on the beverage center to
attempt to dispense beverages.
Make sure you are using the main unit rather than the
stand for refrigerated storage. The stand is not refrigerated.
Check to see if the unit is plugged in to a grounded,
3-prong outlet.
Check thermostat dial in upper lefthand corner of SkyBox™
personal beverage vendor, and turn clockwise all the way
to the right.
See page 13 for suggestions.

15
Warranty/Customer Service
What Is Not Covered By This
Warranty:
1. Warranty is void if the original serial numbers have
been removed, altered or cannot be readily
determined.
2. Products purchased for commercial or industrial
use.
3. Consequential or incidental damages sustained by
any person as a result of any breach of these
warranties. Some states do not allow the exclusion
or limitation of consequential or incidental
damages, so the above exclusion may not apply.
Contacting Customer Service:
1. Call MAYTAG Customer Service at 1-877-366-5426
U.S.A. or 1-800-688-2002 Canada. They may be
able to assist you with troubleshooting product
difficulties. U.S. Customers using TTY for deaf,
hearing impaired or speech impaired, call
1-800-688-2080 (Mon.-Fri., 8 a.m.-8 p.m. Eastern
Time).
2. Write to MAYTAG, Attn. CAIR®Center,
P.O. Box 2370, Cleveland, TN 37320-2370.
When writing or calling about a service problem,
please include the following information:
a. Your name, address and telephone number;
b. Model and serial number of the product (the
model and serial numbers are on a data label on
the back of the vendor);
c. A clear description of the problem you are
having;
d. Proof of purchase (sales receipt).
3. User guides, additional beverage cards, as well as
customized side and front panels, are available
on-line at www.skyboxbymaytag.com.
All SkyBox™ by Maytag™ personal beverage vendors
are warranted for 1 year from date of purchase
against defects in material and workmanship. During
this period, any Maytag product that, upon
inspection by Maytag, is proved defective will be
repaired or replaced, at Maytag’s option, without
charge to the customer.
This warranty does not apply to any defect arising
from a buyer’s or user’s misuse of the product,
negligence, failure to follow Maytag’s instructions,
use on current or voltage other than that stamped
on the product, or alteration or repair not authorized
by Maytag. If a replacement product is sent, it will
carry the remaining warranty of the original
product. Repair or disassembly by anyone other than
a Maytag authorized service center will void the
warranty.
THE WARRANTIES SET FORTH HEREIN ARE
EXCLUSIVE AND NO OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE OR USE, ARE MADE BY
MAYTAG OR ARE AUTHORIZED TO BE MADE
WITH RESPECT TO THE PRODUCT.

Distributeur personnel de
boissons SkyBoxMC de MaytagMC
Modèle n° MBV1976AA
Vous avez le droit de vous vanter. Félicitations pour l’achat du distributeur
personnel de boissons SkyBoxMC de MaytagMC. Maintenant, passez à
l’assemblage de votre distributeur personnel de boissons SkyBoxMC,
remplissez-le de vos bouteilles et canettes favorites, et appelez vos amis.
Ne soyez pas surpris de les voir passer plus de temps avec votre
distributeur personnel de boissons SkyBoxMC qu’à regarder les reproductions
instantanées!
Table des matières
Instructions de sécurité importantes . . . . . . . . . . . . .17-18
Aperçu sur le produit . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-25
Fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-27
Caractéristiques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Avant de contacter un réparateur . . . . . . . . . . . . . . . . . .30
Garantie/Service à la clientèle . . . . . . . . . . . . . . . . . . . . .31
Espagnol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
®

17
Instructions de sécurité importantes
AVERTISSEMENT – risques ou pratiques non
sûres, qui POURRAIENT résulter en de graves
blessures ou même la mort.
AVERTISSEMENT
DANGER – risques immédiats qui RÉSULTERONT
en de graves blessures ou même la mort.
DANGER
ATTENTION – risques ou pratiques non sûres qui
POURRAIENT résulter en des blessures mineures
ou en des dommages matériels.
ATTENTION
Ce que vous devez savoir sur
les instructions de sécurité
Les instructions de sécurité importantes et les
avertissements paraissant dans ce guide ne sont pas
destinés à couvrir toutes les situations et conditions
éventuelles qui peuvent se présenter. Il faut faire
preuve de bon sens et de prudence lors de
l’installation, de l’entretien ou de l’utilisation de ce
distributeur personnel de boissons.
Prenez toujours contact avec votre détaillant,
distributeur, agent de service ou fabricant, au sujet de
problèmes ou conditions que vous ne comprenez pas.
Reconnaissez les étiquettes, phrases
ou symboles sur la sécurité
Les risques d’enfermement et d’étouffement d’un enfant
dans un appareil de réfrigération n’ont pas disparus. Un
appareil de réfrigération abandonné demeure dangereux …
même s’il ne reste ainsi accessible que pendant quelques
jours. Lorsqu’on se débarrasse d’un vieil appareil SkyBoxMC,
il faut appliquer les instructions ci-
dessous pour éviter un accident.
•Démontez la porte du distributeur
personnel de boissons SkyBoxMC
(page 29).
•Laissez les bacs en place, pour
qu’un enfant ne puisse pas
facilement s’introduire dans
l’appareil.
DANGER

18
Instructions de sécurité importantes
Pour réduire le risque d’incendie, de décharge
électrique, de blessures graves ou mortelles lors de
l’utilisation de cet appareil de réfrigération et de son
support, observez ces précautions fondamentales, y
compris ce qui suit :
1. Lisez toutes les instructions.
2. Pour éviter les blessures, les enfants ne doivent pas
escalader cet appareil et son support, ni s’y suspendre
ou s’y tenir debout.
3. Utilisez l’appareil et son support uniquement pour leur
application prévue.
4. Observez tous les codes et règlements locaux.
5. Pour éviter un risque de décharge électrique, ne
branchez jamais l’appareil dans une prise qui n’a pas été
correctement mise à la terre, conformément aux
prescriptions des codes national et local des
installations électriques. Voyez ci-après l’avertissement
et les instructions de liaison à la terre.
6. N’utilisez pas un adaptateur à 2 broches, ni de cordon
prolongateur ou de barre d’alimentation à prises
multiples.
7. Débranchez le cordon d’alimentation de l’appareil avant
d’y mettre des canettes et des bouteilles, de le nettoyer,
d’y faire de l’entretien ou de remplacer une ampoule.
Débranchez le cordon en saisissant la fiche et non pas
le cordon lui-même.
8. Réparez ou remplacez le cordon d’alimentation
immédiatement s’il a été endommagé ou détérioré, ou si
la fiche ne s’adapte pas parfaitement à la prise de
courant.
9. Pour éviter un incendie, votre appareil ne doit pas être
utilisé dans un endroit où se trouve de l’essence ou
d’autres liquides et vapeurs inflammables.
10. Maintenez votre distributeur personnel de boissons
SkyBoxMC en bon état. S’il est tombé ou s’il a subi des
chocs, le distributeur personnel de boissons et/ou son
support SkyBaseMC peuvent être endommagés et par
conséquent, mal fonctionner ou fuir. En cas de
dommage, contactez un technicien qualifié pour les faire
réparer.
11. Lisez et suivez toujours les instructions d’installation et
de fonctionnement du fabricant, pour les articles rangés
dans cet appareil. Placez les canettes et les bouteilles
dans le distributeur, comme il est décrit dans ce guide.
12. Ne soulevez pas et ne déplacez pas le distributeur
personnel de boissons et/ou le support SkyBaseMC quand
le distributeur est chargé ou si la porte est ouverte.
13. Le distributeur personnel de boissons SkyBoxMC n’est pas
conçu pour la distribution d’articles alimentaires autres
que des contenants de boisson spécifiés dans ce guide.
14. Ne donnez pas des coups de pied au distributeur et/ou
à son support SkyBoxMC, ne le frappez pas ou ne le
secouez pas, car cela pourrait renverser l’appareil et
endommager le système de réfrigération.
15. Le distributeur personnel de boissons SkyBoxMC est
conçu pour recevoir des contenants de boisson sur la
tablette désignée, à la partie supérieure de l’appareil. Ne
mettez pas d’autres articles sur l’appareil.
16. N’essayez pas de mettre les doigts, les mains ou les
bras, dans l’ouverture du distributeur de boissons. Si un
contenant se coince dans le distributeur personnel de
boissons SkyBoxMC, dégagez-le en suivant les
instructions fournies à la page 29 de ce guide.
Mesures de sécurité importantes
CONSERVEZ CES INSTRUCTIONS POUR VOUS
Y REPORTER ULTÉRIEUREMENT
AVERTISSEMENT

19
Support SkyBaseMC (en option) –Un support robuste et
stable est prévu pour un poids d’environ 91 kg (200 lb), soit
celui du distributeur personnel de boissons complètement
rempli. Le distributeur personnel de boissons SkyBoxMC se fixe
d’une façon sécuritaire au support SkyBaseMC. Pour l’acquérir,
consultez votre détaillant local ou : www.skyboxbymaytag.com.
Distributeur personnel de boissons
SkyBoxMC de Maytag – Appareil de
réfrigération avec porte avant. S’ouvre pour
fournir un accès facile aux quatre bacs.
Complètement rempli, cet appareil contient
64 canettes de 325 mL (12 oz) ou 32
bouteilles de 325 mL (12 oz).
Cartes de boissons – Votre
distributeur personnel de
boissons SkyBoxMC est livré avec
un jeu de cartes de boissons
les plus demandées, qui
peuvent être utilisées comme
étiquettes pour les boutons de
sélection de boissons. Pour
acheter des cartes de boissons
supplémentaires, consultez :
www.skyboxbymaytag.com.
Panneaux d’affichage – Les
panneaux coulissent dans les
parties avant et latérales de
l’appareil. Votre distributeur
personnel de boissons
SkyBoxMC est fourni avec un
panneau frontal standard. Pour
acquérir des panneaux
personnalisés interchangeables
pour le devant et les côtés,
affichant vos équipes favorites,
consultez :
www.skyboxbymaytag.com.
Graphique d’affichage avant –
Fourni avec le distributeur
personnel de boissons SkyBoxMC.
Aperçu sur le produit
